- Page 1 Distribution Limited Petrol Stump Grinder Operator’s Manual BSF15 FOR YOUR SAFETY READ AND UNDERSTAND THE ENTIRE MANUAL BEFORE OPERATING THIS MACHINE...
-
Page 3: Warranty Registration Form
For the warranty to be valid the Warranty Registration Form must be completed and returned to Lumag Distribution Limited within 14 days of the purchase, together with a copy of the purchase invoice. We will use your email to confirm that we have received the completed Warranty Registration Form and contact you about any errors or omissions on the form. - Page 5 All Other Moving Parts & Lubricate X (2) Cables 1 – First service only, 2 = Should be carried out by your Lumag Dealer, 3 = May need to be done more often in dusty areas & 4 = Replace paper element only...
- Page 7 ................ pg 3 ................pg 4 ........... pg 5 ..............pg 7 ............pg 11 ............pg 12...
- Page 8 Thanks for buying the Stump Grinder, another high-quality machine from our company. To get the most out of your purchase, please read the manual before using the stump grinder. We ask you to please read this manual carefully beforehand in order to familiarise yourself with this product and after reading, please store this instructional manual for future reference.
- Page 9 Handle Bar Emergency Stop Switch (On/Off) Throttle Wheel Brake Lever Engine Pull Start (behind) Cutting Wheel Kill Switch Stump Grinder...
- Page 10 • Keep the working area clean and well lit. • Do not operate the stump grinder in the presence of flammable liquids, gases or dust. • Keep children and bystanders away while operating the stump grinder. Keep the area free of all distractions. •...
- Page 11 Ensure that everyone is in the vicinty is aware of the danger zone associated • with this machine(see diagram). You must avoid the danger zone at all times when the machine is in operation. • Make sure that no-one is working on underneath or close to the machine before starting the engine or beginning to move the machine.
- Page 12 Only fill the fuel tank to a level 15mm lower than the top of the fuel tank. Do not overfill. Use the dipstick to check the oil level. Use 10w-30/ 10w-40/ 15w-30/ 15w-40 non-synthetic engine oil. Fill to the correct level before use. Dipstick Cover The engine is shipped without oil.
- Page 13 • Remove all loose pieces of wood, stones, wire and other debris from the area before beginning stump removal. • Wind direction should be considered, as it influences the direction in which dust and wood chips are directed. • Never operate the grinder after dark.There will be no adequate light for the operator to use the grinder safely.
- Page 14 Prepare the grinder at the stump. Place it into position with the cutting wheel near the top edge of the stump. Removing roots Make sure the throttle is set to fast, the cutter wheel will accelerate to cutting speed. Swing the cutting wheel to one side, then lower it into the nearest roots that are buried at the foot of the stump.
- Page 15 Continue with final roots removal Cut the remaining roots as described in STEP 2 until satisfactorily removed When stopping the machine after normal operation, lower engine speed to slow, and push the emergency switch. Set park brake before leaving the controls. Shut off the engine by pushing the on/off switch.
- Page 16 • Make sure all nuts, bolts and screws are tightened. • Never store the equipment with petrol in the tank inside a building where fumes can reach an open flame or spark. Allow the engine to cool before moving the grinder. •...
- Page 17 Engine 15HP Four Strokes Brake Drum Brake Belt 2PCS v Belt Clutch Centrifugal Clutch Blades 12 Blades w Tungsten (4x left, 4x right, 4x middle) Cutting Depth 12inch Packing Size 1040*780*580mm Gross Weight 130kgs Net Weight 110kgs Stump Grinder...
-
Page 18: Part Drawings
Distribution Limited PART DRAWINGS FOR YOUR SAFETY READ AND UNDERSTAND THE ENTIRE MANUAL BEFORE OPERATING THIS MACHINE... - Page 20 Unit 10, Hatchmoor Industrial Estate, Hatherleigh, Okehampton, Devon EX20 3LP www.lumag-gb.co.uk 01837 811741 Lumag Distribution Limited Company Number: 09267547 VAT Number: GB154566788 Hatherleigh Plant and Tool Hire is a trading name of Lumag Distribution LTD...
