Summary of Contents for Beko DFN04310W
- Page 1 Dishwasher User’s Manual Document Number : 15 9905 0100_AA_BEKO_A5_EN/ 22-01-18.(12:59)
- Page 2 Please read this user manual first! Dear Customer, We hope that you get the best results from your product which has been manufactured with high quality and state-of-the-art technology. Therefore, please read this entire user manual and all other accompanying documents carefully before using the product and keep it as a reference for future use.
- Page 3 Dishwasher User’s Manual Document Number : 15 9905 0100_AA_BEKO_A5_EN/ 22-01-18.(12:59)
- Page 4 Please read this user manual first! Dear Customer, We hope that you get the best results from your product which has been manufactured with high quality and state-of-the-art technology. Therefore, please read this entire user manual and all other accompanying documents carefully before using the product and keep it as a reference for future use.
-
Page 5: Table Of Contents
CONTENTS 1 INSTRUCTIONS FOR SAFETY rack ............25 Upper basket multipurpose service AND ENVIRONMENT rack ............25 General safety ........4 Adjusting the height of the upper Intended use ..........4 basket ..........26 Children’s safety ........5 Collapsible upper basket wires ..27 Disposing of packaging material ..5 Height setting with empty basket ...27 Transportation of the product ....6... -
Page 6: Instructions For Safety And Environment
instructions for safety and environment This section contains safety Never touch the plug with • instructions that will help to get wet hands! Never unplug by protected from risk of personal pulling on the cable, always injury or property damage. Failure pull out by grabbing the plug. -
Page 7: Children's Safety
instructions for safety and environment Children’s safety This appliance is intended • to be used in household and Electrical products are • similar applications such as: dangerous for the children. - Staff kitchen areas in shops, Keep children away from the offices and other working product when it is in use. -
Page 8: Transportation Of The Product
instructions for safety and environment Transportation of the learn about these collection centers. product Compliance with RoHS If you need to move the Directive product, do it in upright position and hold from The product you have purchased the rear side. Slanting complies with EU RoHS Directive the product onto its (2011/65/EU). -
Page 9: Dishwasher Overview
Dishwasher Overview 1. Upper basket 2. Upper impeller 3. Lower impeller 4. Silverware basket 5. Door 6. Rating Label 7. Control panel 8. Detergent dispenser 9. Lower basket 10. Filters 11. Salt reservoir lid 12. Upper basket rail 13. Upper cutlery basket (depends on model) 14. -
Page 10: Fan Drying System
Dishwasher Technical specifications Compliance to standards and test data / EC declaration of conformity This product complies with the following EU directives; Development, production and sales stages of this product comply with the safety rules included in all pertaining European Community regulations. 2014/35/EU, 2014/30/EU, 93/68/EC, IEC 60436/DIN 44990, EN 50242 Power input 220-240 V, 50 Hz (see rating label) -
Page 11: Installation
Installation Appropriate installation Refer to the nearest Authorised Service Agent for installation of your product. To location make the product ready for use, make sure Place the product on a solid and flat • that the electricity, tap water supply and floor that has sufficient load carrying water drainage systems are appropriate capacity! The product must be... -
Page 12: Connection To The Drain
Installation Permitted water temperature: up the floor. A discharge hose longer than 4 to 25°C meters causes dirty washing. The dishwasher may not be connected to Attach the water discharge hose to the open warm water devices or flow-through drainpipe without bending it. Tightly fix water heaters. -
Page 13: Aquasafe
Installation Aquasafe+ The voltage and allowed fuse or breaker • protection are specified in the “Technical (depends on model) specifications” section. If the current The Aquasafe+ system protects against value of the fuse or breaker in the house water leaks that may occur at the hose is less than 16 Amps, have a qualified inlet.Water contact with the valve box of electrician install a 16 Amp fuse. -
Page 14: Preparation Tips For Energy Saving
Preparation Tips for energy saving Adjusting the water softening system Following information will help you use the product in an ecological and energy- Cleaning, rinsing and drying performance of efficient manner. your dishwasher will increase when water Wipe away any coarse food remnants on softening system is adjusted properly. - Page 15 Preparation Use the test strip supplied with the product according to the steps given below to determine hardness level of your supply water. Remove the test Turn on the tap and Hold the test strip in Remove the test Wait for 1 minute. The test strip shows strip from the let the water run for...
-
Page 16: Adding Salt
Preparation If the water hardness level adjustment is Firstly, take the lower basket out to add set to level 1, the “No salt warning indicator” softening salt. will illuminate continuously although it 2. Turn the salt reservoir lid counter- is not necessary to use salt. If you use clockwise to open it (A). -
Page 17: Detergent
Preparation Put the detergent into the detergent You need to add salt right before dispenser just before operating the starting the machine. Thus, the machine as illustrated below. overflowing salty water will be Push the latch to right to open the flushed immediately, preventing detergent dispenser lid (A). -
Page 18: Tablet Detergents
Preparation The best washing performance in dishwashers is obtained by using detergent, rinse aid and water softening salt individually. Observe the instructions of the detergent manufacturer on the package when using tablet detergents. Contact the detergent manufacturer if your dishes are wet and/or if you notice Use powder or liquid/gel limescale spots particularly on... -
Page 19: Rinse Aid
Preparation Rinse aid 4. If there are stains on tableware items after washing, level must be increased The rinse aid used in and if there is a blue trace after wiping dishwashers is a special them by hand, it must be decreased. combination that aims to This is set to position 3 as factory increase drying efficiency and... -
Page 20: Placing The Dishes Into The Dishwasher
Preparation Placing the dishes into the dishwasher You can use your dishwasher in the optimum way with respect to energy consumption and washing and drying performance only if you place the dishes in an orderly way. Wipe away any coarse food remnants •... - Page 21 Preparation Suggestions for loading the dishwasher Improper Loading Of Dishware Lower basket Upper basket Improper Loading Of Dishware Dishwasher / User’s Manual 19 / 42 EN...
-
Page 22: Cutlery Basket
Preparation Cutlery basket Cutlery basket (depends on model) (depends on model) Cutlery basket is designed to wash your Cutlery basket is designed to wash your dishes such as knife, fork, spoon, etc. in an dishes such as knife, fork, spoon, etc. in an efficient manner. -
Page 23: Collapsible Lower Basket Tines
Preparation Collapsible lower basket tines (depends on model) There are foldable tines (A) located at the lower basket of the machine are designed for an easier placement of large pieces such as pans, bowls, etc. You can create larger spaces by folding each tines individually or all of them at once. -
Page 24: Collapsible Lower Basket Tines
Preparation Collapsible lower basket Bringing the tines to the tines horizontal position by holding them from the tips may cause (depends on model) them to bend. Therefore, it There are foldable tines (A) located at the will be appropriate to bring the tines in the middle to horizontal lower basket of the machine are designed or vertical position by holding... -
Page 25: Softtouch Accessory
Preparation SoftTouch Accessory Tray Wash Supports (depends on model) (depends on model) The SoftTouch Accessory found in the Use the supports to wash trays in the lower basket of your machine enables a bottom basket. safe washing for your fragile glasses. See the Auxiliary functions section for appropriate programme and function selection. -
Page 26: Lower Basket Multipurpose / Height Adjustable Service Rack
Preparation Lower basket multipurpose Make sure that the impeller / height adjustable service does not touch the dishes you rack placed on the racks. (depends on model) To close the racks: This accessory located at the lower basket Fold the rack (A). of your machine allows you to easily wash 2. -
Page 27: Lower Basket Bottle Wire
Preparation Lower basket bottle wire (depends on model) The bottle wire is designed for easier washing of long pieces with wide mouths. You may take out the bottle wire from the basket when not in use by pulling it out from both sides (H). -
Page 28: Adjusting The Height Of The Upper Basket
Preparation Adjusting the height of the To lower the basket, while it is in the uppermost position; upper basket Hold the upper basket wires with both (depends on model) hands, slightly lift up the basket and The upper basket height adjustment simultaneously push and release the mechanism has been designed for you to latches shown in the figure (B). -
Page 29: Collapsible Upper Basket Wires
Preparation Collapsible upper basket Height setting with empty wires basket (depends on model) (depends on model) You can use collapsible wires when you In this model, the height setting of the need a larger space for your dishes in the upper basket may be changed using the upper basket of your machine. -
Page 30: Ceiling Cutlery Basket
Preparation Ceiling cutlery basket (depends on model) Ceiling cutlery basket is designed to wash your cutlery items such as forks, spoons and etc. by placing them between the bars on the basket. When the central tray is in the lower position, you can load long/high items such as coffee cups, ladles, etc. -
Page 31: Operating The Product
Operating the product 5 5 5 On/Off/Programme Selection key Rinse Aid indicator Salt indicator On/Off Control light Handle Programme Follow-up lights Start/Pause/Cancel key Half Load function Keys 4. Put adequate amount of detergent into the detergent compartment. On/Off/Programme Selection key 5. - Page 32 Operating the product /42 EN Dishwasher / User’s Manual...
-
Page 33: Auxiliary Functions
Operating the product Auxiliary functions Starting the programme Washing programmes of your dishwasher To start your machine after selecting the are designed to obtain the best cleaning programme and auxiliary functions, press effect, considering the type of the soiling, Start/Pause/Cancel key. soiling degree and properties of the dishes Your machine performs water to be washed. -
Page 34: Adjusting The Amount Of Rinse Aid
Operating the product Programme follow-up Salt indicator You can track the current step of the Please check the salt indicator to see selected programme on the programme whether there is adequate amount of step lights located on the control panel. softening salt in the dishwasher or not. -
Page 35: End Of Programme
Operating the product 5. When you set the Programme Selection Knob to the “Off” position again, the machine will enter the normal mode. Position of Rinse Aid program Rinse Aid Adjustment Amount selection Indicator knob 1 dose of Washing lamp rinse aid is on the panel will dispensed. -
Page 36: Maintenance And Cleaning
Maintenance and cleaning Cleaning the filters Service life of the product extends and frequently faced problems decrease if it is Clean the filters at least once a week in cleaned at regular intervals. order for the machine operates efficiently. Unplug the product and turn off Check if food residues are left on the filters. -
Page 37: Cleaning The Hose Filter
Maintenance and cleaning Cleaning the hose filter Damages on the machine that may be caused by impurities coming from the urban supply water or your own water installation (such as sand, dirt, rust, etc.) can be prevented by means of the filter attached to the water inlet hose. -
Page 38: Cleaning The Impellers
Maintenance and cleaning Cleaning the impellers Upper impeller Clean the impellers at least once a week in Check if the holes on the upper impeller (1) order for the machine operates efficiently. are clogged. If they are clogged, remove and clean the impeller. Turn its nut to left to Lower impeller remove the upper impeller. -
Page 39: Troubleshooting
Troubleshooting Machine does not start. • Power cable is unplugged. >>> Check if the power cable is plugged in. • Fuse is blown. >>> Check the fuses in your house. • Water is cut. >>> Make sure that the water inlet tap is open. •... - Page 40 Troubleshooting • Rinse aid is not sufficient. >>> Check the rinse aid indicator and add rinse aid if necessary. Increase the rinse aid setting if there is enough amount of rinse aid in the machine. • Machine is unloaded right after the programme is over. >>> Do not unload your machine right after washing process is completed.
- Page 41 Troubleshooting Since the salt granules that will remain under the lid will dissolve during prewash, causing the lid loosen, check the lid once again at the end of the programme. There is a different odour in the machine A new machine has a peculiar odour. It will fade out after a couple of washes. •...
- Page 42 Troubleshooting Detergent remains in detergent dispenser. • Detergent dispenser was damp when adding detergent. >>> Make sure that the detergent dispenser is dried well prior to filling it with detergent. • Detergent is added long before the washing process. >>> Pay attention to add detergent shortly before start-up of the washing.
- Page 43 Troubleshooting A smear remains on glasses that resembles milk stain which can not be removed when wiped by hand. A bluish / rainbow appearance occurs when the glass is pointed to light. • Excessive rinse aid is used. >>>Lower rinse aid setting. Clean the spilled rinse aid when adding rinse aid.
