OPERATION
MANUAL
USF-105AS
Universal System Frame
USF-105PS
Power Supply Unit
st
1
Edition - Rev. 2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the USF-105PS and is the answer not in the manual?

Questions and answers

Related Manuals for FOR-A USF-105PS

Summary of Contents for FOR-A USF-105PS

  • Page 1 OPERATION MANUAL USF-105AS Universal System Frame USF-105PS Power Supply Unit Edition - Rev. 2...
  • Page 2 Precautions Important Safety Warnings [Power] Operate unit only at the specified supply voltage. Caution Disconnect the power cord via the power plug only. Do not pull on the cable portion. Do not place or drop heavy or sharp-edged objects on the power cord. A damaged cord can cause fire or electrical shock hazards.
  • Page 3 [Circuitry Access] Do not remove covers, panels, casing, or access the circuitry with power applied to the unit. Turn the power off and disconnect the power cord prior to removal. Internal servicing / adjustment of unit should only be performed by qualified personnel. Do not touch any parts / circuitry with a high heat factor.
  • Page 4 DVD-ROM Operation Manual (PDF) Install this unit into slot 5 if 12G-SDI module is Air duct unit installed. Setup Guide  USF-105PS Option ITEM REMARKS USF-105PS Redundant Power Supply Unit AC Cable 1 set (Includes an AC cord retaining clip)

  • Page 5: Table Of Contents

    9-3. Network Tab ..........................27 9-4. SNMP Tab ..........................30 9-5. Utility Tab ..........................32 10. About SNMP .............................34 11. Specifications and Dimensions ......................36 11-1. Specifications ..........................36 11-1-1. USF-105AS ........................36 11-1-2. USF-105PS ........................36 11-2. External Dimensions .......................37 11-2-1. USF-105AS ........................37 11-2-2. USF-105PS ........................37...

  • Page 6: Prior To Starting

    The USF-105AS is a low cost and space saving Universal System Frame that can be freely configured. Up to 5 modules can be installed into one USF frame. Dual, redundant power supplies can be configured by adding an optional USF-105PS power unit, improving operation safety.

  • Page 7: Installing The Ac Cord Retention Clip

    2. Installing the AC Cord Retention Clip Secure the AC cord with the supplied ladder strap/retention clip assembly to prevent accidental removal from the unit.  Installing the clip Wrap the retention clip around the AC cord (with the anchor of the ladder strap toward the unit.) Insert the anchor into the hole next to the AC IN socket.

  • Page 8: Part Descriptions

    Lower the environmental temperature to continue operation. FAN1 FAN2 Cooling fans. Operation status can be monitored by WebGUI Status Tab. Refer to Sec.9-1. “Status Tab.” FAN3 FAN4 DC 1 and DC 2 become functional when a USF-105PS power supply option is installed.

  • Page 9: Opening And Closing The Front Panel

    3-2. Opening and Closing the Front Panel IMPORTANT The front panel may be difficult to open if the USF frame is placed on a desk, and may be damaged if it is forced to open. Perform the following steps after setting the frame in a rack. Loosen the two thumbscrews on the front panel by turning them counterclockwise.

  • Page 10: Front Interior

    DC power supply shutting down if either power unit fails. The dedicated and optional USF-105PS power supply units are the same configuration, and can be exchanged. Refer to Sec. 6. "Installing or Replacing a Power Supply Unit” for installation details.

  • Page 11: Power Supply

    3-5. Power Supply When the front switch of the USF-105PS power supply unit is turned off, the DC supply to USF-105AS is disconnected. Redundant operation is available by installing an optional USF-105PS power supply unit. On/Off switch of On/Off switch of Power Supply Unit 2 Power Supply Unit 1 (When USF-105PS option is installed.)

  • Page 12: Fan

    3-7. Fan Fan unit prevents overheating from internal heat generation, pulling air through the front panel and out the rear and right side panels. Do not block the fan vents. (Rear Panel) (Front Panel) Air Flow Diaram 3-8. Internal SDI Bus The USF-105AS frame provides 4 slot grouping internal SDI bus which allows SDI signals to be transferred bi-directionally.

  • Page 13: Alarm Connector

    3-9. ALARM Connector Matching connector 9-pin D-sub male *Using inch screws 9-pin D-sub female ALARM Connector Assignment Table (9-pin D-sub female) Signal Signal Details ALARM 1 ALARM 2 ALARM 3 ALARM 1 to 6 functions assigned through WebGUI setting page. Refer to Sec.

  • Page 14: Usf Module Installation

    4. USF Module Installation USF Modules can be installed into any free slot if there are no installation slot limitations. Refer to the "Installation Slots for Front and Rear Modules" in the USF-105AS Setup Guide for installation slot limitation. When installing 12G-SDI supported modules (marked with *), install the supplied air duct unit into Slot 5.

  • Page 15: Installing A Usf Front Module

    4-2. Installing a USF Front Module IMPORTANT Make sure to install the front module after installing the rear module. Slot 1 is the top slot in the right block of the front panel. Refer to Sec. 3-4. "Slot Number” Set the front module on the guide rail and carefully insert the front module slowly. Guide Rail Guide Rail Guide Rail...

  • Page 16: Replacing A Usf Module

    5. Replacing a USF Module Follow the procedure described below to remove and replace a defective USF Module. Since no electrical components are mounted on most USF rear modules, it is possible to recover proper operation by replacing front modules. IMPORTANT When both front and rear module are to be replaced, make sure to replace the rear module after pulling out the front module.

  • Page 17: Installing Or Replacing A Power Supply Unit

    6. Installing or Replacing a Power Supply Unit The procedure for installing a USF-105PS Optional Redundant Power Supply Unit into a USF frame is described as follows. Power supply unit replacement can be performed in the same manner. To avoid electric shock, make sure to ground the grounding terminal before operation or pull out the AC cable from the outlet.

  • Page 18: Removing A Power Supply Unit

    6-2. Removing a Power Supply Unit Open the front panel. (Refer to Sec. 3-2. “Opening the Front Panel.”) Shut down to remove the Power Supply. (See figure below.) Grab the power supply handle and slowly pull out the power supply. (See figure below.) Power Supply 2 Power Supply 1 switch...

  • Page 19: Control Module

    7. Control Module Make sure to shut down the power when replacing the control module. 7-1. Internal Control Module Settings Open the front panel and pull the module out using the handle. Micro SD Connector Handle Switch S1 CPU reset switch. Not used normally. Switch S3 Reset switch for the built-in hub.
  • Page 20  DS2 Settings Factory Setting Descriptions Off: Front Panel Open warning alarm is enabled. On: Front Panel Open warning alarm is disabled. Off: Normal use. On: The USF-105AS starts with default network settings. If you forgot your USF frame IP address, you can connect to the web browser using the default IP address (LAN1: 192.168.0.10, LAN A: 172.16.0.10).

  • Page 21: Web Control

    8. Web Control USF-105AS operation can be monitored by a web browser or SNMP Manager via a PC-network connection. Power supply and fan states can be displayed by opening the USF-105AS WebGUI from a web browser. Control and monitoring of the modules (*1) installed in USF-105AS can be done via WebGUI.
  • Page 22  Connection Example AC100-240V 50/60Hz IN LAN1 LED Lit Green: Connected GENLOCK Flashing Orange: Transmitting and receiving data USF-105AS Rear panel Web Browser SNMP Manger IMPORTANT LAN1 Default Gateway is fixed to the LAN A internal port. So it is not possible to directly access USF-105AS Web GUI from LAN A port.

  • Page 23: Lan A Port

    8-1-2. LAN A Port LAN A port functions via the built-in USF-105AS router in which network addresses are translated and IP packets are passed to an appropriate application. Therefore, USF modules that are installed into USF-105AS and respectively have IP addresses can be set in the WebGUI and their states can be monitored through SNMP via a single port (LAN A).

  • Page 24: Usf-105As Webgui

    9. USF-105AS WebGUI Module status web browser display settings are different between LAN1 and LAN A.  Displaying the web browser from LAN 1 Open the web browser on the PC connected to LAN 1, then input the address http://192.168.0.10/ (factory default setting).
  • Page 25 Power Unit 1 Status and Power Unit 2 Status indicate the respective power supply mounting and operational states. A red flashing LED indicates abnormal power output or inoperative fan being detected. * If USF-105PS is not installed, Power Unit 2 Status is not displayed.  Unit Information Serial No.

  • Page 26: Alarm Tab

    9-2. Alarm Tab Clicking an Alarm tab opens a window on the web browser as shown below. Clicking Refresh allows you to update the window contents. Item Function(Default) Description Alarm 1 Alarm 2 Assigns a function for each alarm terminal. Alarm 3 A function is selected from the list below.

  • Page 27: Network Tab

    Sets the TCP/UDP port number through which Control Base Port 57000 Remote Control Unit made by FOR-A accesses to the external LAN A. Example 1: To Display Slot 1 Module on the Web Browser by Addressing. When the HTTP Base Port setting is 55000, input http://172.16.0.10:55001/ in the address bar of the web browser to display the Slot 1 module WebGUI.
  • Page 28 Example 3: To Control Slot 1 Module by Remote Control Connection. When the Control Base Port setting is 57000, input 172.16.0.10 for the IP address. Input 57001 for the port number. Similarly, input 57002 for the port number of Slot 2. IMPORTANT Multiple port numbers for HTTP Base Port/ SNMP Base Port/ Control Base Port, are used in order to prevent system glitches from occurring when a PC connects to and control multiple...
  • Page 29  Controlling the PC via LAN1  Controlling the PC via LAN A Input the same address.

  • Page 30: Snmp Tab

    9-4. SNMP Tab Clicking SNMP Tab opens the following page on the web browser. Clicking also opens the same page. IMPORTANT In order to confirm changes in SNMP Tab, click Apply then restart the USF-105AS.  SNMP Settings This page allows you to apply various settings to monitor USF-105AS by SNMP manager. ...
  • Page 31  Trap Settings Click This window allows you to set various trap transmission from USF-105AS to SNMP Manager. Clicking Refresh allows you to update the window contents.  Unit Trap Settings Item Default Settings Description Enable: If the community names set on Read Authentication Disable Only1, 2/ Read/Write1, 2 are different from...

  • Page 32: Utility Tab

    9-5. Utility Tab Clicking the Utility tab opens the window as shown below on the web browser.  System Restart Execute System Restart when network settings or SNMP settings are changed. The following confirmation window appears when Restart is clicked. Other tab windows cannot be accessed until this window is closed.
  • Page 33  Slot Name Any name can be given to modules installed into Slots 1 to 5. Input names in Slot1 to Slot5 and click Apply. Example Input FS1 to FS5 in Slot1 to Slot5 box respectively and click Apply. The set names are displayed next to respective modules in the left pane.

  • Page 34: About Snmp

    10. About SNMP The USF-105AS can be remotely monitored using an SNMP monitoring system that supports SNMPv2C. MIB (Management Information Base) files, required for SNMP monitoring system, can be downloaded from WebGUI. Refer to Sec. 9-4. "SNMP Tab" for details on downloading MIB files and SNMP settings. ...
  • Page 35 TRAP Object group Item Name Object name in MIB file Value Type Function OID : 1.3.6.1.4.1.20175.1.349.1.13.1.  Slot number inserted usf105ASSlotNumber 1. a INTEGER 0:moduleIn  Module Slot inserted status usf105ASSlotStatus 2. a INTEGER 1:noModule Information OCTET Slot installed module name usf105ASSlotModuleName ********** 3.

  • Page 36: Specifications And Dimensions

    Dimensions 444 (W) x 44 (H) x 403 (D) mm Weight 5.6 kg (USF-105PS not included) Consumables (in constant operating 24 hours a day at normal temperature) Power supply unit: Replace every 5 years Cooling fan: Replace every 6 years 11-1-2.

  • Page 37: External Dimensions

    11-2. External Dimensions 11-2-1. USF-105AS (All dimensions in mm.) UNIVERSAL SYSTEM FRAME USF-105S POWER LOCK LOCK ALARM DC 1 DC 2 TEMP 11-2-2. USF-105PS (All dimensions in mm.) 261.5...
  • Page 38 Warning This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
  • Page 39 2 Executive Drive, Suite 670, Fort Lee Executive Park, Fort Lee, NJ 07024, USA Tel: +1 201 944 1120 Fax: +1 201 944 1132 FOR-A Corporation of America Distribution & Service Center 2400 N.E. Waldo Road, Gainesville, FL 32609, USA Tel: +1 352 371 1505...
