USER GUIDE
SAFETY • INSTALLATION & INTEGRATION • OPERATING INSTRUCTIONS • MAINTENANCE • SERVICE
CONTROL FUNCTION GUIDE
FUNCTION
ON/OFF
Toggle lights
Adjust temperature
View temperature in unit
Toggle between F/C
DOOR ALERT NOTIFICATION
When the door is left open for more than 5 minutes:
•
An audible tone will sound for several seconds every
minute.
•
"dr" will appear in display.
Close door to silence alert and reset.
VIEWING ACTUAL TEMPERATURE
In viewing temperature in these modes any offsets are
taken into account. This means that if you place a therm-
istor in a known temperature, let's say ice water, it may
not read the 32°F that you would assume. If the control
offset was preset at -3°F while you placed the thermistor
in an icebath, the actual thermistor reading when viewing
actual temperature would read 35°F. In the unit this would
cause the cabinet to push itself 3° cooler. To view pure
thermistor readings you must go into the service menu
and choose the correct option.
To view the thermistor temperature, push and release the
up and down keys. The display will show the corrected
refrigerator temperature.
COMMAND
Press
and release
Press
and release
Press
or
and release
Press
or
to adjust set point
temperature
Press
to change zones
Press
or
to adjust set point
temperature
Press
to confirm and exit
Press
together and release
and
Hold
and
for 5 seconds
DISPLAY/OPTIONS
Unit will immediately turn ON or OFF.
Leave interior light on for 3 hours.
The zone you are setting will have its light turned on
(top zone first).
Display will show the set temperature.
Light will switch from top zone to the bottom zone.
Display will show the set temperature.
The display will flash and then toggle from set point
to temperature in unit. The temperature shown will
correspond to the illuminated zone.
The display will change units.
SHOWROOM MODE
This mode is designed to show units in a display environ-
ment. When in this mode the only functions will be the
control and cabinet lights. The compressor, fans, etc. will
not operate. To enter/exit this mode hold the light key
and the power key for 5 seconds. The display will flash
once and beep and the degree symbol will begin to flash.
When the degree symbol is flashing the unit will allow the
use of the control for demonstrations. The unit can be left
in this mode indefinitely.
SERVICE MODE
This mode has options available for service diagnostics.
To enter the mode hold the hidden key for 10 seconds.
The display will show "0." When in this mode use the up
and down arrows to select the desired option. The LIGHT
key is the ENTER key and will initiate the function. If
changing a setting, you must press the LIGHT key again
to retain the changed setting. To exit the service mode
scroll to option "0" and press the LIGHT key. After five
minutes of not touching any keys the mode will also exit
automatically.
u-line.com
Control Operation - Service 2
