- Page 1 COUNTER SERIES OWNERS MANUAL AND INSTALLATION INSTRUCTIONS MODEL # TC36-6 (shown) MODEL # TCHP36SU-6 (shown) MODEL # TC36G (shown) MODEL # TC36RB (shown) LISTED Made in U.S.A...
-
Page 2: Introduction/ Safety Precautions
INTRODUCTION/ SAFETY PRECAUTIONS Thank you for choosing your new THERMA-TEK Equipment. Our Products are designed to be safe and reliable when properly cared for and used reasonably. Your service agency or dealer recommends periodic inspections. Installation, maintenance, and repairs should be performed by your local authorized service agency. -
Page 3: Installation And Safety Guidelines
National Fuel Code ANSI Z223.1 (latest edition). All THERMA-TEK appliances are shipped with a gas pressure regulator packed with the unit. All units are adjusted, tested, and inspected at the factory prior to shipment. -
Page 4: Air Supply And Ventilation
INSTALLATION AND SAFETY GUIDELINES CLEARANCES • The unit must be kept clear of all combustibles. • The unit must be installed with the 4” legs supplied for proper operation. • Minimum clearance from combustible construction: Side Back o Open top 12”... -
Page 5: Manual Shut-Off Valve
INSTALLATION AND SAFETY GUIDELINES GAS CONNECTION The gas supply (service) line must be at least the same size or larger than the inlet line of the appliance. CHEFTECH counter equipment is supplied with a ¾” NPT Schedule 40 inlet. Sealant on all pipe joints must be resistive to LP gas. -
Page 6: Initial Start-Up
INITIAL START-UP All THERMA-TEK appliances are adjusted and tested before leaving the factory. Adjustments and calibrations may be necessary upon installation to meet local conditions, low gas characteristics; problems caused by rough handling or vibration during shipping, and are to be performed only by qualified service personnel. -
Page 7: Before Use
OPERATING INSTRUCTIONS BEFORE USE All units are wiped clean with solvents at the factory to remove any visible signs of dirt, oil or grease remaining from the manufacturing process. Open Tops & Broilers The Top grates should be removed and washed before use. With these removed it will be possible to remove plastic ties holding the burners in place for shipment. -
Page 8: Care And Cleaning
CARE AND CLEANING Any piece of equipment works better and lasts longer when properly maintained. Cooking equipment is no exception. Your THERMA-TEK appliance must be kept clean during the workday and thoroughly cleaned at the end of the day. OPEN TOP •... -
Page 9: Troubleshooting
Check calibration. HOW TO OBTAIN SERVICE For warranty service, contact your local THERMA-TEK authorized service agency. Provide him or her with the Model #, Serial #, date of installation, and a brief description of the problem. If you need assistance locating the authorized service agency in your area, contact your local dealer. - Page 10 HOT PLATE (Counter Series)
- Page 11 Qty Required Item Number Part No. Description 12" 24" 36" 48" 60" 72" 31038-01 Front Panel 12" 31038-02 Front Panel 24" 31038-03 Front Panel 36" 31038-04 Front Panel 48" 31038-05 Front Panel 60" 31038-06 Front Panel 72" 30103-01 Front Rail W/A 12" 30103-02 Front Rail W/A 24"...
- Page 12 GRIDDLE (Counter Series)
- Page 13 Qty Required Item Number Part No. 12" 24" 36" 48" 60" 72" Description 31 038-01 Fro nt P anel 1 2" 31 038-02 Fro nt P anel 24" 31 038-03 Fro nt P anel 36" 31 038-04 Fro nt P anel 48" 31 038-05 Fro nt P anel 60"...
- Page 14 BROILER (Counter Series)
- Page 15 Qty Required Item Number Part No. Description 12" 24" 36" 48" 60" 72" 31038-01 Front Panel 12" 31038-02 Front Panel 24" 31038-03 Front Panel 36" 31038-04 Front Panel 48" 31038-05 Front Panel 60" 31038-06 Front Panel 72" 30103-01 Front Rail W/A 12" 30103-02 Front Rail W/A 24"...
- Page 16 PRICES: All prices are subject to change without notice. Prices do not include sales or any other local state tax. All prices are in U.S. Dollars. TERMS: Net 30 days subject to Therma-Tek credit department approval. All amounts past due are subject to 1 1⁄2% per month service charge LIMITED WARRANTY: TWO (2) YEAR PARTS AND LABOR FOR U.S.
