LG LA62 Series Owner's Manual
Hide thumbs
Also See for LA62 Series:
- Owner's manual (555 pages) ,
- Owner's manual (54 pages) ,
- Owner's manual (60 pages)
Related Manuals for LG LA62 Series
Summary of Contents for LG LA62 Series
- Page 1 OWNER’S MANUAL LED TV *LG LED TV applies LCD screen with LED backlights. Please read this manual carefully before operating your set and retain it for future reference. LA62** LN54** LP36** LP62** www.lg.com...
-
Page 2: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS INSTALLATION PROCEDURE LICENSES ASSEMBLING AND PREPARING OPEN SOURCE SOFTWARE NOTICE Unpacking Separate purchase IR CODES Parts and buttons Lifting and moving the TV EXTERNAL CONTROL DEVICE Setting up the TV SETUP - Attaching the stand Mounting on a table RS-232C Setup Mounting on a wall... -
Page 3: Installation Procedure
INSTALLATION PROCEDURE / ASSEMBLING AND PREPARING NOTE Image shown may differ from your TV. Your TV’s OSD (On Screen Display) may differ slightly from that shown in this manual. The available menus and options may differ from the input source or product model that you are using. New features may be added to this TV in the future. - Page 4 ASSEMBLING AND PREPARING Remote control and Owner’s manual Cable holder Power Cord batteries (AAA) (Depending on model) (Depending on model) (See p.20, 21) (See p.13) Stand Screws Stand Screws Desk-mount Screw Power cable holder/ 7EA, M4 x 14 8EA, M4 x 14 (Only 32/39/42/47LN54**, bolt (Only LN54**, LP36**,...
- Page 5 ASSEMBLING AND PREPARING NOTE Antenna Isolator Installation Guide - Use this to install TV in a place where there is a voltage difference between TV Set and GND of antenna signal. » If there is a voltage difference between TV Set and GND of antenna signal, the antenna contact might be heated and excessive heat might cause an accident.
-
Page 6: Separate Purchase
Separate purchase Separate purchase items can be changed or modified for quality improvement without any notification. Contact your dealer to buy these items. These devices only work with certain models. LG Audio device Compatibility LN54**, LP36**, LP62** LG Audio device •... -
Page 7: Parts And Buttons
Buttons Screen SETTINGS INPUT Speakers Remote control sensor LG Logo light Button Description Scrolls through the saved programmes. Adjusts the volume level. Selects the highlighted menu option or confirms an input. Accesses the main menu, or saves your input and exits the menus. -
Page 8: Lifting And Moving The Tv
ASSEMBLING AND PREPARING Lifting and moving the TV When transporting a large TV, there should be at least 2 people. Please note the following advice to prevent the When transporting the TV by hand, hold the TV as TV from being scratched or damaged and for safe shown in the following illustration. -
Page 9: Setting Up The Tv
ASSEMBLING AND PREPARING Setting up the TV Image shown may differ from your TV. Attaching the stand LA62** LN54**, LP36**, LP62** M4 x 14 M4 x 14 4 EA Stand Body Stand Body Stand Base Stand Base M4 x 14 M4 x 14 4 EA... -
Page 10: Mounting On A Table
ASSEMBLING AND PREPARING Attaching the TV to a table CAUTION (Only 39/42/47LN54**, 42/47LP36**, 42/47/55LP62**) Image shown may differ from your TV. When attaching the stand to the TV set, place the The TV must be attached to desk so it cannot be screen facing down on a cushioned table or flat pulled in a forward/backward direction, potentially surface to protect the screen from scratches. - Page 11 ASSEMBLING AND PREPARING Adjusting the angle of the TV to suit view Securing the TV to a wall (Only 32LN54**, 32LP36**, 32LP62**, LA62**) (This feature is not available for all models.) Swivel 15 degrees to the left or right and adjust the angle of the TV to suit your view.
-
Page 12: Mounting On A Wall
TV to other building materials, please contact qualified children, can be avoided by taking simple personnel. precautions such as: LG recommends that wall mounting be performed by a » Using cabinets or stands recommended by qualified professional installer. the manufacturer of the television. -
Page 13: Tidying Cables
Gather and bind the cables with the Cable Holder. Use an authorized LG wall mount and contact the local dealer or qualified personnel. Do not over tighten the screws as this may cause damage to the TV and void your warranty. -
Page 14: Making Connections
MAKING CONNECTIONS MAKING CONNECTIONS Antenna connection Connect the TV to a wall antenna socket with an RF This section on MAKING CONNECTIONS cable (75 Ω). mainly uses diagrams for the LN54** models. Connect various external devices to the TV and switch input modes to select an external device. -
Page 15: Hdmi Connection
MAKING CONNECTIONS DVI to HDMI connection HDMI connection Transmits the digital video and audio signals from an Transmits the digital video signal from an external device to the TV. Connect the external device and the TV with external device to the TV. Connect the external device the DVI-HDMI cable as shown. -
Page 16: Component Connection
MAKING CONNECTIONS Composite connection Component connection Transmits analog video and audio signals from an Transmits analog video and audio signals from an external device to the TV. Connect the external device external device to the TV. Connect the external device and the TV with the composite cable as shown. -
Page 17: Rgb-Pc Connection
MAKING CONNECTIONS RGB-PC connection Audio connection Transmits the video signal from PC to the TV. To You may use an optional external audio system instead transmit an audio signal, connect an audio cable. of the built-in speaker. (Only LP62**) NOTE If you use an optional external audio device AUDIO IN (RGB/DVI) -
Page 18: External Speaker Out
MAKING CONNECTIONS External speaker out Speaker output setup Connecting External Speaker. Connect the external speaker to the Speaker output(STEREO) jack on the TV. (Only LP62**) Control port for Speaker out DOWN EXTERNAL SPEAKER OUT SPEAKER OUT SPEAKER VOLUME CONTROL VOLUME (*Not Provided) CONTROL RIGHT... -
Page 19: Network Connection
MAKING CONNECTIONS Network Connection Headphone connection (Only LP62**) Transmits the headphone signal from the TV to an external device. Connect the external device Connecting to a Wired Network and the TV with the headphone. This TV can be connected to a local area network (LAN) (Only LP62**) via the LAN port. -
Page 20: Remote Control
REMOTE CONTROL REMOTE CONTROL The descriptions in this manual are based on the buttons on the remote control. Please read this manual carefully and use the TV correctly. To replace batteries, open the battery cover, replace batteries (1.5 V AAA) matching the ends to the label inside the compartment, and close the battery cover. - Page 21 REMOTE CONTROL (Only LP62**, LA62**) (POWER) Turns the TV on or off. ꕊ ENERGY SAVING Adjusts the brightness of the screen to reduce energy consumption. ENERGY AV MODE INPUT AV MODE Selects an AV mode. INPUT Changes the input source. SAVING TV/RAD Selects Radio, TV and DTV programme.
-
Page 22: Maintenance & Troubleshooting
MAINTENANCE / TROUBLESHOOTING MAINTENANCE Cleaning your TV Clean your TV regularly to keep the best performance and to extend the product lifespan. CAUTION Make sure to turn the power off and disconnect the power cord and all other cables first. When the TV is left unattended and unused for a long time, disconnect the power cord from the wall outlet to prevent possible damage from lightning or power surges. -
Page 23: Caution For Using Ezsign 2.0
CAUTION FOR USING EZSIGN 2.0 CAUTION FOR USING EZSIGN 2.0 Only LN549E Do not remove a USB drive while data is being copied. It can corrupt the data and EzSign may not work properly. While loading a USB device or dongle, your TV may function slower than normal. While EzSign contents is running, the movie with internal subtitles is not supported in USB mode. -
Page 24: Specifications
SPECIFICATIONS SPECIFICATIONS Product specifications may be changed without prior notice due to upgrade of product functions. For the power supply and power consumption, refer to the label attached to the product. 32LP36** 42LP36** 47LP36** MODELS 32LP360H-TA 42LP360H-TA 42LP360H-TA Dimensions With stand (mm) 738.0 x 497.0 x 207.0 968.0 x 629.0 x 236.0 1080.0 x 694.0 x 264.0... - Page 25 SPECIFICATIONS Environment Operating Temperature 0 °C to 40 °C condition Operating Humidity Less than 80 % Storage Temperature -20 °C to 60 °C Storage Humidity Less than 85 % Digital TV Analogue TV New Zealand, Television System DVB-T PAL/SECAM-B/G/D/K, PAL-I Singapore BG : VHF/UHF 1 to 69, CATV 01 to 47 Programme Coverage...
- Page 26 SPECIFICATIONS HDMI/DVI-DTV supported mode Component port connecting information (Only LP62**) Horizontal Vertical Resolution Component ports on the TV Frequency (kHz) Frequency (Hz) 720x480 31.469 59.94 31.5 720x576 31.25 Video output ports on DVD player 1280x720 37.5 44.96 59.94 1920x1080 33.72 59.94 Signal Component...
-
Page 27: Licenses
LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping and handling) upon email request to opensource@lge.com. This offer is... -
Page 28: Ir Codes
IR CODES IR CODES This feature is not available for all models. Code Function Note (Hexa) Remote control Button (Power On/Off) (POWER) TV/RAD Remote control Button Remote control Button SUBTITLE Remote control Button AV MODE RATIO Remote control Button INPUT Remote control Button 10-19 Number Key 0-9... -
Page 29: External Control Device Setup
EXTERNAL CONTROL DEVICE SETUP EXTERNAL CONTROL DEVICE SETUP RS-232C Setup RS-232C Configurations Connect the RS-232C (serial port) input jack to an external control device (such as a computer or an A/ 7-Wire Configurations ( Standard RS-232C cable ) V control system) to control the product’s functions externally. -
Page 30: Communication Parameters
EXTERNAL CONTROL DEVICE SETUP Communication Parameters Baud rate: 9600 bps (UART) Communication code: ASCII code Data length: 8 bits Use a crossed (reverse) cable. Parity : None Stop bit: 1 bit Command reference list (Depending on model) DATA DATA COMMAND1 COMMAND2 (Hexadeci- COMMAND1 COMMAND2... -
Page 31: Transmission / Receiving Protocol
EXTERNAL CONTROL DEVICE SETUP Transmission / Receiving Protocol Transmission [Command1][Command2][ ][Set ID][ ][Data][Cr] [Command 1] : First command to control the TV.(j, k, m or x) [Command 2] : Second command to control the TV. [Set ID] : You can adjust the set ID to choose desired monitor ID number in option menu. Adjustment range is 1 to 99. - Page 32 EXTERNAL CONTROL DEVICE SETUP 01. Power (Command: k a) 04. Volume Mute (Command: k e) ► To control volume mute on/off. ► To control Power On/Off of the set. You can also adjust mute using the MUTE button on remote Transmission[k][a][ ][Set ID][ ][Data][Cr] control.
- Page 33 EXTERNAL CONTROL DEVICE SETUP 09. Tint (Command: k j) 14. Bass (Command: k s) ► To adjust the screen tint. ► To adjust bass. You can also adjust tint in the PICTURE menu. You can also adjust bass in the AUDIO menu. Transmission [k][j][ ][Set ID][ ][Data][Cr] Transmission [k][s][ ][Set ID][ ][Data][Cr] Data Red : 00 to Green : 64...
- Page 34 EXTERNAL CONTROL DEVICE SETUP 18. Auto Configure(Command: j u) 23. Input select (Command: x b) (Main Picture Input) ► To adjust picture position and minimize image shaking auto- ► To select input source for main picture. matically. It works only in RGB (PC) mode. Transmission [j][u][ ][Set ID][ ][Data][Cr] Transmission [x][b][ ][Set ID][ ][Data][Cr] Data 01: To set...
- Page 35 (Only DTV) Record the model number and serial number of the TV. Refer to the label on the back cover and quote this information to your dealer when requiring any service. MODEL SERIAL...
