- Page 1 KILO ® KILO6KHD™ 8x32 mm and 10x32 mm LASER RANGEFINDER WITH BALLISTIC DATA XCHANGE™ OPERATOR’S MANUAL...
-
Page 2: Table Of Contents
Changing Modes Of Operation Programming Sequence BaseMap™ Frequently Asked Questions (FAQ) Specifications SIG SAUER Electro-Optics Infinite Guarantee /Limited Lifetime Warranty ® Please visit sigsauer com for Operator’s Manual downloads, or download to your Smart device with the SIG BDX App... -
Page 3: Introduction
Laser Rangefinder. The KILO6K™ is part ® of a new, advanced family of rangefinders from SIG SAUER that features Low Energy Bluetooth with embedded Applied Ballistics Ultralight and the free downloadable SIG™ BDX App as part of SIG SAUER’s new Ballistic Data Xchange™ technology. All of SIG SAUER’s rangefinders feature... -
Page 4: Contents
CONTENTS: • KILO6K™ Rangefinding Binocular • CR2 Battery (1) • Premium Binocular Harness / Carry Pouch • Quick Start Guide • Ballistic Group Card... -
Page 5: Key Features
KEY FEATURES: • SIG SAUER’S Patent Pending Ballistic Data Xchange™ Technology utilizes, low energy Bluetooth with embedded Applied Ballistics Ultralight (BDX-U), supports Applied Ballistics External (BDX-X) and works with the free BDX™ App to sync custom gun profiles and environmental conditions to your KILO and pair ®... -
Page 6: Product Identification
PRODUCT IDENTIFICATION: A Power / Range Button B Eyecup / Diopter Focus Adjustment C Mode Button D Harness Attachment Point E Battery Compartment... - Page 7 GEN II LIGHTWAVE™ DSP TECHNOLOGY SIG SAUER’s proprietary Gen II Lightwave DSP engine leverages HyperScan – an advanced power management technique that provides the fastest refresh rate in scan mode (4 times per second) even at distances up to a mile. Our DSP engine uses the latest generation field programmable gate array (FPGA) running sophisticated signal processing algorithms to reduce false positives while finding weak or distant targets.
- Page 8 When combined with one of SIG SAUER’s BDX enabled riflescopes, the user ranges a target and the firing solution is instantly shared with the BDX riflescope where the...
- Page 9 QuickBOND™ allows you to quickly bond your KILO to a SIERRA™ riflescope. On the SIERRA ® riflescope, insert the batteries and turn on to illumination setting 1. Then turn on the KILO by pressing and releasing the RANGE button Press and hold down both the RANGE and MODE buttons for at least three seconds while looking through the KILO at the display Once the display in the rangefinder reads “BOND”...
-
Page 10: General Operation
GENERAL OPERATION Your rangefinder provides 4 modes of operation: AMR, LOS, BDX-U (AB Ultralite), and BDX-X. AMR and LOS will be explained in the section When BDX-U is selected the user can pair the KILO with a nearby smartphone where the BDX App should already be installed The user ®... - Page 11 MODES OF OPERATION - ANGLE MODIFIED RANGE (AMR) AND LINE OF SIGHT (LOS) Angle modified range is the equivalent horizontal range to the target and is comparable to the “horizontal leg” of a triangle. AMR is also known as “rifleman’s rule” and uses the LOS range and angle of incline to calculate the horizontal distance the projectile travels between shooter and target AMR is very accurate for shorter distances (i e <...
- Page 12 ANGLE MODIFIED RANGE Example: LOS range of 500 yards at 30’ decline is equivalent to an AMR range of 433 yards...
- Page 13 APPLIED BALLISTICS ULTRALIGHT (BDX-U) Your rangefinder has an embedded ballistics solver developed by SIG SAUER, Applied Ballistics and nVisti By pairing your KILO with the free BDX App you can enter custom ballistics ® information for up to 25 bullet profiles and sync one at a time to your KILO. The active ballistic...
- Page 14 Example: LOS range = 568.6 yards with 0.308 Barnes Elevation adjustment = 18.19 MOA Up Windage adjustment = 7.59 MOA Right...
- Page 15 PROJECTED, SEGMENTED ORGANIC LIGHT EMITTING DIODE (OLED) DISPLAY A Aiming Feature B Elevation and Wind Hold Direction Indicator C Target and Ranging Mode D BDX Mode Indicator E Battery State Indicator F 5 Character 7- Segment Display G Range Unit of Measure H Holdover Unit of Measure I Angle of Incline J Bluetooth Connection Indicator...
- Page 16 SAFETY AND OPERATION PROCEDURES The KILO is classified as a Class 1M product. ® WARNING LASER • DO NOT PRESS THE RANGE BUTTON WHILE AIMING AT THE HUMAN EYE OR WHILE LOOKING INTO THE TRANSMITTING OPTICS ON THE OBJECTIVE SIDE. •...
- Page 17 OPERATION The KILO6K™ is designed to get you up and running without the typical complexity of buried menus and programming modes. The rangefinders come out of box in the following configuration and can also be configured with the free BDX App: A Angle Modified Range (equivalent horizontal range) B Best Target (rangefinder returns the best or most likely target, not the first or last) C Illumination control (AUTO)
- Page 18 SET UP Installing the Battery Remove the battery cap by turning the cap in a counterclockwise direction Insert (1) CR2 Primary Lithium battery (+) terminal side first. The (–) terminal should be facing out. Place the cap onto the (–) battery terminal and reinstall the battery cap by turning the cap in the clockwise direction CAUTION BE CAREFUL TO NOT CROSS-THREAD THE CAP...
- Page 19 After installation of the battery and depressing the RANGE button, the status of the rangefinder is displayed:...
-
Page 20: Attaching The Harness
ATTACHING THE HARNESS Attach the harness to the binocular by taking the small connector straps and looping them through the attachment points on both sides of the binocular Next connect the shoulder straps to the upper buckles on the binocular pouch and place over your head Connect the lower back straps to the lower buckles on the binocular pouch and adjust straps to a comfortable fit. - Page 21 DIOPTER ADJUSTMENT The KILO6K™ features two diopter adjustments One for the internal OLED display (right) and one for distant targets (left) Press the RANGE button to turn on the bino - the display should be visible in the right channel Closing your left eye and adjust the diopter on the right channel to focus the display Next, locate a distant target with your binocular using the center focus knob to bring the target image into focus...
-
Page 22: Eyecup Adjustment
EYECUP ADJUSTMENT The KILO6K™ features dual eyecups with 3 position detents for individual adjustment Each eyecup rotates approximately 90 degrees counter clockwise for three different adjustment heights For users with glasses, the cups will usually remain fully bottomed out For users without eyeglasses or to minimize glare adjust the eyecups for best image and eye relief by rotating the cups counter clockwise to one of the three positions... -
Page 23: Display Information
DISPLAY INFORMATION The display shows you the center aiming circle, the unit of measure (Y), Angle Modified Range mode (AMR) and the remaining battery status The display will remain active for up to 30 seconds, or whatever time-out has been set within in the SIG BDX App You can then press the RANGE button to determine range to target If you press the RANGE button while the rangefinder is off and continue to hold the RANGE button down, the rangefinder will automatically switch into SCAN mode within 1 second. -
Page 24: Changing Modes Of Operation
HyperScan MODE While the rangefinders support single button push ranging operation, it is highly recommended that you push and hold the RANGE button down to activate HyperScan mode This mode allows you to scan targets at 4X/second which significantly improves ranging performance at extreme distances. As the ranging distances are updated very quickly in HyperScan mode, once you release the RANGE button the last acquired distance will be displayed When ranging distant targets in HyperScan mode, the display may update between no result and a distant range By using RangeLock technology the... -
Page 25: Programming Sequence
RANGEFINDER CONFIGURATION PROGRAMMING SEQUENCE Note – By using the free SIG BDX App you can easily program and configure your rangefinder. 1. Mode Selection (AMR, LOS, BDX-U or BDX-X) To enter programming mode, press and release the RANGE button to wake-up the rangefinder. Once the display is visible, press and hold the MODE button for 2 seconds –... - Page 26 2. Target Selection FIRST, BEST, LAST, XR or FOG should be flashing. You can toggle between target modes by pressing and releasing the RANGE button. Confirm your selection by pressing and releasing the MODE button which will save your setting and index to the next setting for configuration. If you do not press and release the MODE button the rangefinder will save your selection and turn off.
- Page 27 4. Unit of Measure Selection (Y or M) Your current selection will be flashing (Yards is default). You can toggle between Y or M by pressing and releasing the RANGE button. Confirm your selection by pressing and releasing the MODE button which will save your setting and index to the next setting for configuration. If you do not press and release the MODE button the rangefinder will save your selection and turn off.
- Page 28 6. QuickBOND ® The last selection is QuickBOND - bond will be flashing. You can turn ON or OFF QuickBOND by pressing and releasing the RANGE button. Confirm your selection by pressing and releasing the MODE button which will save your setting and return to ready to range If you do not press and release the MODE button the rangefinder will save your selection and turn off.
- Page 29 BALLISTICS DATA XCHANGE – DOWNLOADING AND CONFIGURING THE FREE BDX APP In this section you will download the BDX App, pair the App with your KILO and create a custom ® bullet profile. 1. Turn Bluetooth on Check in Settings on your Android or iOS device to make sure that Bluetooth is on If Bluetooth is off, switch it on.
- Page 30 2. Download the BDX App from the App Store / Google Play Store ® Go to the App Store or the Google Play store and download the SIG SAUER BDX App Search for the word SIG SAUER or BDX...
- Page 31 3. Launch the free SIG SAUER BDX App and Pair with your KILO (Enter your ® ® PIN code) On your smartphone, open the BDX App, click on PAIRING, turn on your KILO by pressing and releasing the RANGE button and then press “Scan for Devices” on the App. Your KILO should be listed below the KILO icon and “Select Device”.
- Page 32 Make sure your KILO stays on during the pairing process by periodically pressing and releasing ® the RANGE button You will be prompted to look through your KILO for a PIN number Type this PIN number into the open dialogue box within the App The PIN in your KILO and the PIN entered on your smartphone must match Press OK to complete the pairing operation You will now see your KILO ID in blue listed below the KILO icon You can now exit this screen If you enter the incorrect PIN code you can restart this process over again If you encounter any...
- Page 33 Pairing ® You may be prompted to update the software on your KILO These software updates are mandatory and allow SIG SAUER to ensure that your BDX App and KILO perform optimally ® Most updates take less than 1 minute Ensure that your KILO is turned on and that your...
- Page 34 4. Configure up to 25 custom bullet profiles The BDX App allows you to create and modify up to 25 profiles. From the home screen of the ® App touch PROFILES. Only one profile can be active at any time and is denoted by the BDX Icon in blue to the right of the screen.
- Page 35 After selecting a bullet manufacturer, select the actual bullet you intend to use Once selected you will return to the Gun Profile page where you will need to click on the sync icon to the right to activate this profile. In this example the new profile is called “.223 Sierra” – be sure to activate this profile.
- Page 36 RANGEFINDER HEADS-UP DISPLAY (HUD) From the home screen of your BDX App select RANGEFINDERS to display the HUD The HUD ® displays all range, environmental and ballistic information and allows you to configure your KILO ® KILO ID and Status Grey = disconnected / Blue = connected Help and Settings menu Back to Home Screen...
- Page 37 KILO SETTINGS ® From the Settings menu you can fully configure the following: 1 Rangefinder Mode (AMR, LOS, BDX-U, BDX-X) 2 Target Mode (FIRST, BEST, LAST, XR, FOG) 3 Brightness (AUTO or 1 – 9 manual) 4 Range Units (Yards or Meters) 5 Sleep Time (30, 60, 120 or 180 seconds) 6 Sight Units (MOA or MRAD) 7 Battery Saver (On or Off)
- Page 38 TEMPERATURE AND ALTITUDE Your KILO® has onboard environmental sensors and when calculating ballistic solutions will by default use the onboard sensors However, you can manually override the onboard sensors using the BDX App > RANGEFINDER page. The BDX App can pull temperature and altitude from the closest weather station If you are not in cell phone range, you can manually update these values by touching on the white numbers in each field and manually updating these environmental conditions...
- Page 39 MUZZLE VELOCITY (MV) CALIBRATION The most important input for calculating accurate Applied Ballistics solutions is getting your MV correct. You need to either chronograph your firearm or use the embedded MV Calibration routine built into the BDX App To use the MV Calibration routine make sure your scope is ®...
- Page 40 MUZZLE VELOCITY (MV) CALIBRATION – (CONTINUED) Now enter the elevation offset between point of impact and point of aim and select CONFIRM. In this example the 3 shot group was 7 inches low A new MV of 2477 fps was calculated Select YES to confirm and this MV will now be used for ballistic solutions going forward.
- Page 41 CONFIGURING GLOBAL SETTINGS IN THE BDX ® From the Home Screen of the BDX App you can configure Global Settings. Any field that is in white can be changed by touching on the unit of measure and toggling between values The help menu is available to assist you.
- Page 42 PAIRING A KESTREL 5700 ELITE WITH THE KILO6K™ Using the RANGE / MODE buttons on your KILO or the BDX App, put the KILO in BDX-X (AB External) mode This allows the KILO to be discoverable by the Kestrel or Garmin BDX-X will be displayed in the KILO AB External will be displayed in the App Close the BDX App Next, turn on your Kestrel Follow the instructions for the Kestrel to turn on the Bluetooth radio and connect devices to the Kestrel (https://kestrelinstruments.com/support/manuals-...
-
Page 43: Basemap
BASEMAP™ To connect your KILO to your BaseMap app, first, open BaseMap. Tap on Tools in the lower right. Tap on BaseMap Connect in the upper right. Turn on Bluetooth, if needed, and tap on your rangefinder in the available devices menu. -
Page 44: Frequently Asked Questions (Faq)
KILO Relaunch the App, turn on your KILO and repeat the Pairing instructions in this manual Q: I can’t locate the BDX App on the Apple or Android Stores. A: Search for SIG SAUER or BDX at the store. - Page 45 Q: My battery drains too fast. A: Most rangefinders will provide over 4000 individual range calculations using a fresh CR2 primary lithium battery Your KILO exceeds this specification. When heavily using SCAN mode the battery ® may appear to drain faster since your KILO is ranging 4x per second in HyperScan mode This is normal operation but you should keep a spare CR2 battery when heading out to remote locations Your KILO now features Battery Saver mode which can be enabled in the RANGEFINDER >...
- Page 46 Q: When using AB External on my KILO I can no longer see the rangefinder information on the HUD in the BDX App. A: If your KILO and a Kestrel are actively paired (sending / receiving information) the BDX App cannot be connected and paired to your KILO at the same time Q: My KILO is set to AB External but isn’t displaying holdover information.
- Page 47 THIS PAGE INTENTIONALLY LEFT BLANK...
-
Page 48: Specifications
SPECIFICATIONS KILO6K™ 8x32 mm / 10x32 mm Magnification 8x / 10x Objective Clear Aperture 32 mm Close Focus Distance 10 m Eye Relief 17 5 mm / 15 5 mm Angular (FOV) 7 6° / 6 3° FOV @ 100 yds 40/33 ft Laser Divergence 1 60 x 0 1 MRAD... - Page 49 A – 5 4 in / 137 mm B – 5 4 in / 137 mm (8x32) 5 24 in / 133 mm (10x32) C – 2 2 in / 56 mm...
- Page 50 WARNING LASER CLASS 1M LASER PRODUCT. INVISIBLE LASER RADIATION. DO NOT VIEW DIRECTLY WITH OPTICAL INSTRUMENTS (BINOCULARS OR TELESCOPES) This product complies with 21 CFR 1040 10 and 1040 11 except for conformance with IEC 60825-1 Ed 3, as described in Laser Notice No 56, dated May 8, 2019 FCC ID: SH6MDBT50Q IC: 8017A-MDBT50QU Pp <...
- Page 51 • Reorient or relocate the receiving antenna • Increase the separation between this product and the receiver • Connect the equipment to an alternative outlet or receiver • Consult a technician Shielded interference cable must be used with the equipment in order to comply with the limits for a digital device pursuant to Subpart B of Part 15 of FCC Rules Specifications and designs are subject to change without any notice or obligation on the part of the manufacturer...
- Page 52 FCC STATEMENT: This device complies with Part 15 of the FCC rules Operation is subject to the following two conditions: • This device may not cause harmful interference, and • This device must accept any interference received, including interference that may cause undesired operation Changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment...
- Page 53 This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications However, there is no guarantee that interference will not occur in a particular installation If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:...
- Page 54 INDUSTRY CANADA: This device complies with Industry Canada licence RSS standard(s) Operation is subject to the following two conditions: • This device may not cause interference, and • This device must accept any interference, including interference that may cause undesired operation of the device Le present appareil est conforme aux CNR d’Industrie Canada applicable aux appareil radio exempts de licence...
- Page 55 WARNING: CANCER AND REPRODUCTIVE HARM—www.P65warnings.ca.gov...
-
Page 56: Sig Sauer Electro-Optics Infinite Guarantee ® /Limited Lifetime Warranty
SIG SAUER Electro-Optics had to earn the right to wear that badge and the Infinite Guarantee has your back, forever Period... - Page 57 OR FITNESS FOR A PARTICULAR PURPOSE, ARE EXPRESSLY DISCLAIMED REPAIR, ALTERATION, OR REPLACEMENT AS PROVIDED HEREIN IS YOUR EXCLUSIVE REMEDY FOR ANY DEFECTIVE PRODUCT IN NO EVENT SHALL SIG SAUER OR ANY COMPANY AFFILIATED WITH SIG SAUER BE LIABLE FOR ANY SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES OF ANY KIND ARISING...
- Page 58 For a period of five (5) years from the date of manufacture, SIG SAUER agrees to correct any defect in these components by repair, adjustment, or replacement, at SIG SAUER’s option, with the same or comparable quality components (or by replacing...
- Page 59 THIS WARRANTY APPLIES TO COMMERCIAL CUSTOMERS ONLY, AND DOES NOT APPLY TO GOVERNMENT, MILITARY, LAW ENFORCEMENT, OR NON-US CUSTOMERS NON-US COMMERCIAL CUSTOMERS MUST PURCHASE PRODUCT THROUGH AN AUTHORIZED SIG SAUER DEALER WITHIN THEIR COUNTRY OF RESIDENCE FOR THIS WARRANTY TO APPLY...
- Page 60 All trademarks, service marks, trade names, trade dress, product names and logos appearing in this manual are the property of their respective owners. No trademark or service mark appearing in this manual may be used without written consent of the mark’s owner. ©2022 SIG SAUER, Inc. All rights reserved. AN ISO 9001:2015 REGISTERED COMPANY...
