ELECTRO-OPTICS
ZULU3™ shown
ZULU
™
BINOCULARS
OWNERS MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZULU and is the answer not in the manual?

Questions and answers

Related Manuals for Sig Sauer ZULU

Summary of Contents for Sig Sauer ZULU

  • Page 1 ELECTRO-OPTICS ZULU3™ shown ZULU ™ BINOCULARS OWNERS MANUAL...

  • Page 2: Table Of Contents

    Introduction ..........3 ZULU Binoculars utilize category-leading features like high quality glass, fully multi-coated lenses and phase coated prisms to provide maximum brightness, contrast and optimal resolution.

  • Page 3: Contents

    • Close bridge design • Close bridge design • Phase coated Abbe-Koenig prisms • SHR Phase coated BAK4 Prisms • ZULU Binocular • HDX (ED High Definition & HT High • HD High Definition Glass • Eyepiece and Objective Lens Covers Transmittance) glass •...

  • Page 4: Product Identification

    sigoptics.com PRODUCT IDENTIFICATION: A- Eye Lens B- Diopter Ring C- Dataplate (model, magnification, FOV) D- Focus Wheel E- Strap Attachment F- Objective Lens G- Tripod Adapter Cover (select models) ZULU7™ shown...

  • Page 5: Operation

    3. Adjust the center focus wheel (located between the two barrels) until the image presented to your left eye is clear and sharp. SIG SAUER binoculars feature eyecups you can twist, or push up and down to accommodate the eye relief distance required when wearing eyeglasses.

  • Page 6: Interpupillary Distance Of Binoculars

    sigoptics.com Interpupillary distance of binoculars CLEANING Interpupillary distance means interocular distances between the right and left eyes. • You can clean the fully armored body by simply wiping off any accumulated dirt or dust. 1. Set the distance between the centers of the right and left ocular lenses of the binoculars to your •...

  • Page 7: Specifications

    sigoptics.com ZULU3 SPECIFICATIONS ZULU5 SPECIFICATIONS Model/Magnification Model/Magnification 8x32mm 10x32mm 8x42mm 10x42mm Eye Relief Eye Relief 14.5mm 14.5mm 17mm 15mm Exit Pupil Exit Pupil 4.0mm 3.2mm 5.3mm 4.2mm Linear FOV FT at 1000 yards Linear FOV FT at 1000 yards 393 ft 341 ft 393 ft 315 ft...
  • Page 8 sigoptics.com ZULU7 SPECIFICATIONS ZULU9 SPECIFICATIONS Model/Magnification Model/Magnification 8x32mm 10x42mm 15x56mm 9x45mm 11x45mm Eye Relief Eye Relief 20mm 17mm 15.5mm 17.3mm 16.7mm Exit Pupil Exit Pupil 5.3mm 4.2mm 3.7mm 5.0mm 4.1mm Linear FOV FT at 1000 yards Linear FOV FT at 1000 yards 378 ft 341 ft 225 ft...

  • Page 9: Sig Sauer Electro-Optics Infinite Guarantee

    • No Charge We will repair or replace your SIG SAUER product in the event it becomes damaged or defective, at no If you ever have a problem, no matter the cause, we promise to take care of you when it counts.
  • Page 10 sigoptics.com NOTES:...
  • Page 11 FOR PRODUCT SERVICE ON THIS MODEL, PLEASE CALL 603-610-3000 19861 SW 95th Avenue, Portland, OR 97062 USA sigoptics.com P/N 7400229-01 R00...
