1x4 HDMI TRUE 4K@60 SPLITTER
© 2015 Avenview Inc. All rights reserved.
The contents of this document are provided in connection with Avenview Inc. ("Avenview") products. Avenview makes no representations or
warranties with respect to the accuracy or completeness of the contents of this publication and reserves the right to make changes to specifications
and product descriptions at any time without notice. No license, whether express, implied, or otherwise, to any intellectual property rights is granted
by this publication. Except as set forth in Avenview Standard Terms and Conditions of Sale, Avenview assumes no liability whatsoever, and claims any
express or implied warranty, relating to its products are is strictly prohibited.
Control Your Video...
W/ EDID & HD Support
VIDEO WALLS
VIDEO PROCESSORS
VIDEO MATRIX SWITCHES
EXTENDERS
SPLITTERS
CABLES & ACCESSORIES
Model #: SPLIT-HDM2-T4K-4/8
WIRELESS
Advertisement
Table of Contents
Related Manuals for Avenview SPLIT-HDM2-T4K-4/8
Summary of Contents for Avenview SPLIT-HDM2-T4K-4/8
- Page 1 No license, whether express, implied, or otherwise, to any intellectual property rights is granted by this publication. Except as set forth in Avenview Standard Terms and Conditions of Sale, Avenview assumes no liability whatsoever, and claims any...
- Page 2 Product Application & Market Sectors Corporate House Of Worship Military Residential Education Industrial Medical Aviation www.avenview.com...
-
Page 3: Table Of Contents
2.2 BEfORE INSTAllATION ........................4 2.2 CABlE SpECIfICATION ........................5 2.3 ApplICATION DIAGRAM ........................6 2.4 pANEl DESCRIpTION ........................7 ..............7 2.4.1 INpuT pANEl (SplIT-HDM2-T4K-4) BACk pANEL 2.4.2 INpuT pANEl (SPLIT-HDM2-T4K-4) fRONT pANEl ..............7 INSTAllATION (SPLIT-HDM2-T4K-4) ....................8 GENERAl TROuBlESHOOTING ..................... 9 SpECIfICATIONS ..........................10 www.avenview.com Page 3... -
Page 4: Getting Started
Have the module checked by a qualified service engineer before using it again. Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the device before cleaning. www.avenview.com Page 1... -
Page 5: Regulatory Notices Federal Communications Commission (Fcc)
DO NOT TAMpER WITH THE uNIT. DOING SO WIll VOID THE WARRANTy AND CONTINuED uSE Of THE pRODuCT. THE VIDEO BOARDS ARE VERy SENSITIVE TO STATIC. plEASE ENSuRE If RACk MOuNTED OR INSTAllED ON A SuRfACE, IT SHOulD BE IN A GROuNDED ENVIROMENT. www.avenview.com Page 2... -
Page 6: Introduction
INTRODuCTION The Avenview SPLIT-HDM2-T4K-4 4/8 port HDMI Splitter can support the new industry of video signals 4K@60 and UHD. This device allows the INpuT (source as 4K GPU graphic card or UHD Digital Player) to be duplicated onto 4 4K@60 or UHD displays. Supporting both video and audio signal simultaneously reproducing the same quality via HDMI cable with EDID management. -
Page 7: Package Contents
• use the DC power adapter with correct specifications supplied with the unit. If the improper power supply is used, this may result in malfunction of the unit and may cause fire. • Do not twist or pull by force the ends of the HDMI cable. It can cause malfunction. www.avenview.com Page 4... -
Page 8: Cable Specification
Molded 24k Gold Plated HDMI male connectors on each end Available in 7 colors for easy cable identification • X-tra Flex CL3 rated jacket for easy installation • Up to 32 audio channels and 21:9 aspect ratio • RoHS Certified • Lifetime Warranty www.avenview.com Page 5... -
Page 9: Application Diagram
ApplICATION DIAGRAM www.avenview.com Page 6... -
Page 10: Panel Description
B- EDID HD(1080p@30)/1080i@60/720p@60)-24bit 2D & LPCM7.1ch/Dolby Digital C - EDID HD(1080p@30/1080i@60/720p@60) - 24bit 2D & 2ch audio D - Auto EDID analysis learning mode E - Learn EDID from output1(DEFAULT) F - Learn EDID from output 4 POWER JACK: Power Soucre connection www.avenview.com Page 7... -
Page 11: Installation (Split-Hdm2-T4K-4)
INSTAllATION (SplIT-HDM2-T4k-4) To setup the Avenview SplIT-HDM2-T4K-4 please follow the steps below to experience the best results: Please ensure the connecting devices are powered off before proceeding. 2. Connect the HDMI video source to the INpuT(HDMI IN)- Example Bluray or 4K Digital player or Camera Connect (4) four HDMI cables to the desired HDMI Displays Please ensure all connections are seated securely and placed in the corresponding connections. -
Page 12: General Troubleshooting
Please ensure your source device and the displays are fully compatible before attempting to connect and provide a full solution. Extended display identification data EDID Readers -Monitor Asset Manager -http://www.entechtaiwan.com/util/moninfo.shtm High-bandwidth Digital Content Protection (HDCP) Compliance with source and display. www.avenview.com Page 9... -
Page 13: Specifications
POWER SUPPLY 5V / 2A DC (uS/Eu standards, CE/fCC/ul certified) POWER CONSUMPTION 1.6 Watt (max) Environmental OPERATING TEMPERATURE 32˚ ~ 104˚F (0˚ to 40˚C) STORAGE TEMPERATURE -4˚ ~ 140˚F (-20˚ ~ 60˚C) RELATIvE HUMIDITY 20~90% RH (non-condensing) www.avenview.com Page 10... - Page 14 PARTS: During the Warranty Period of of THREE (3) YEARS, Avenview will supply new or rebuilt replacements in exchange for defective parts of the product(s) at no cost if the product(s) is determined to have abide by Avenview’s published guidelines. Cost of Parts applicable to product(s) after Warranty Period. For part(s) costs, please contact support@avenview.com.
- Page 15 Disclaimer While every precaution has been taken in the preparation of this document, Avenview Inc. assumes no liability with respect to the operation or use of Avenview hardware, software or other products and documentation described herein, for any act or omission of Avenview concerning such products or this documentation, for any interruption of service, loss or interruption of business, loss of anticipatory profits, or for punitive, incidental or consequential damages in connection with the furnishing, performance, or use of the Avenview hardware, software, or other products and documentation provided herein.
