- Page 1 SPECTRA POWERTWIN Panel‐PC E3950/N4200 Apollo Lake with sunreadable Displays USER MANUAL Version 1.60 – September 2020...
-
Page 2: Table Of Contents
1.1 Overview ………………………………………….……………….…….. 12 1.2 Highlights ………………………………………….…………………….. 12 1.3 Product Pictures ..…………………………….…………………………. 13 1.4 Key Feature ……..…………………………….…………………………. 13 1.5 Hardware Specification ………………………….…………………..…..14 1.5.1 PowerTwin P08C-AL-SR……………….……....………….… 1.5.2 ............… 16 PowerTwin PH10C-AL-SR 1.5.3 PowerTwin PH12C-AL-SR…………………....………….. . … 1.5.4 ………………….. - Page 3 Digital I/O (DIO) Hardware Specification ……….….…………………. 83 Chapter 6 Optional Module Pin Definitions and Settings Location of the Connectors and Switches ……………..…………….. 86 Installing a CFM-IGN Power Ignition Module …………..……………. 86 Installing a CFM-PoE Control Module ………………..………………. 88 Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays...
-
Page 4: Preface
2020/09/21 Copyright Notice © 2019 by Spectra GmbH & Co. KG. All rights are reserved. No parts of this manual may be copied, modified, or reproduced in any form or by any means for commercial use without the prior written permission of Spectra GmbH &... -
Page 5: Product Warranty Statement
(such as a fuse, battery, etc.), are not warranted Before sending your product in, you will need to fill in a Spectra RMA Request Form and obtain a RMA number from us. Please go to www.spectra.de/RMA... -
Page 6: Technical Support And Assistance
This indication alerts operators to an operation that, if not strictly observed, may result in safety hazards to personnel or damage to equipment. This indication provides additional information to complete a task easily. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays... -
Page 7: Safety Precaution
The equipment has been dropped and damaged. The equipment has obvious signs of breakage. 14. CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays... -
Page 8: Package Contents
Before installation, please ensure all the items listed in the following table are included in the package. Item Description Q’ty Panel PC Utility DVD Driver Screw Pack Panel Mounting Kit Power Terminal Block Connector Remote Power On/Off Terminal Block Connector DIO Terminal Block Connector Thermal Pad (for CPU Thermal Block) Note: Notify your sales representative if any of the above items are missing or damaged. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays... -
Page 9: Ordering Information
Ordering Information Model No. Product Description Spectra PowerTwin 8.4" TFT‐LCD 1600nits Sunlight Readable Touch Panel PC with Intel® Atom® P08C‐AL‐SR E3950 Quad Core Processor and P‐Cap. Touch Spectra PowerTwin 8.4" TFT‐LCD 1600nits Sunlight Readable Touch Panel PC with Intel® Pentium® P08C‐ALN42‐SR N4200 Quad Core Processor and P‐Cap. Touch Spectra PowerTwin 10.4" TFT‐LCD 1500nits Sunlight Readable Touch Panel PC with Intel® Atom® PH10C‐AL‐SR E3950 Quad Core Processor, P‐Cap. Touch Spectra PowerTwin 10.4" TFT‐LCD 1500nits Sunlight Readable Touch Panel PC with Intel® PH10C‐ALN42‐SR Pentium® N4200 Quad Core Processor, P‐Cap. Touch 12.1" TFT‐LCD 1500nits Sunlight Readable Touch Panel PC with Intel® Atom® Spectra PowerTwin PH12C‐AL‐SR E3950 Quad Core Processor, P‐Cap. Touch Spectra PowerTwin 12.1" TFT‐LCD 1500nits Sunlight Readable Touch Panel PC with Intel® PH12C‐ALN42‐SR Pentium® N4200 Quad Core Processor, P‐Cap. Touch Spectra PowerTwin 15" TFT‐LCD 1600nits Sunlight Readable Touch Panel PC with Intel® Atom® P15C‐AL‐SR E3950 Quad Core Processor, P‐Cap. Touch Spectra PowerTwin ... -
Page 10: Optional Accessories And Modules
Optional Modules & Accessories Model No. Description CFM Module with Power Ignition Sensing Control Function, 12V/24V Selectable PB‐3000A‐IGN (43 x 36 mm) PT‐PN4‐CFM‐PoE02 CFM Module with PoE Control Function, Individual Port 25.5W Power Adapter, Adapter AC/DC 12V 5A 60W, GST60A12‐CIN1, wide temp(‐30 ° C ~ +70 ° C), Level VI 60W/12V, 3pin Power Adapter, Adapter AC/DC 24V 5A 120W, GST120A24‐CIN, wide temp (‐30 ° C ~ +70 ° C), level VI 120W/24V, 3pin Adapter AC/DC 24V 9.2A 220W, GST220A24‐CIN, wide temp (‐30 ° C ~ +70 ° C), level Upon request VI (For PowerTwin P19 only) Universal Mount Kit Universal 19" Rack Mount Kit for Industrial Panel PC & Industrial Monitor for PowerTwin 19" Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays... -
Page 11: Chapter 1 Product Introductions
Chapter 1 Product Introductions... -
Page 12: Overview
PCs, it is more flexible and reduces maintenance cost dramatically. Featuring with rigorous industrial protections, wide range operating temperature (-20°C to 70°C), IP65 dust/waterproof front panel, and wide range DC power input (9 to 48VDC), Spectra PowerTwin P-AL-SR Series is appropriate for harsh environments and critical applications. -
Page 13: Product Pictures
• Designed with Aluminum Die-casting Front Frame • True Flat IP65 Front Panel Protection • Supports CDS Technology, Ignition Sensing and Power over Ethernet • Supports Panel / VESA / *Rack Mounting (*with optional mounting kit) Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays... -
Page 14: Hardware Specification
1.5 Hardware Specification 1.5.1 PowerTwin P08C-AL-SR Display Storage • LCD Size: 8.4" (4:3) • 1x 2.5” HDD/SSD Drive Bay (SATA 3.0) • Max. Resolution: 800 x 600 • 1x mSATA Socket (SATA 3.0, Shared by Mini-PCIe • Brightness (cd/m2): 1600 Socket) •... - Page 15 • Vibration: Operating, 1.5 Grms, 5-500 Hz, 3 Axes Operating System (w/ SSD, according to IEC60068-2-64) • Windows® 10 • IP Level: IP 65 Compliant Front Panel • Linux: Supports by project • EMC: CE, FCC Class A Dimension Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays...
-
Page 16: Powertwin Ph10C-Al-Sr
• 1x ATX Power On/Off Button • 1x Reset Button • 1x AT/ATX Mode Switch • 1x Clear CMOS Switch • 1x Remote Power On/Off Connector, 2-pin Terminal Block • 8x Isolated DIO (4x DI/4x DO), 10-Pin Terminal Block Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays... - Page 17 • Vibration: Operating, 1.5 Grms, 5-500 Hz, 3 Axes Operating System (w/ SSD, according to IEC60068-2-64) • Windows® 10 • IP Level: IP 65 Compliant Front Panel • Linux: Supports by project • EMC: CE, FCC Class A Dimension Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays...
-
Page 18: Powertwin Ph12C-Al-Sr
• 1x ATX Power On/Off Button • 1x Reset Button • 1x AT/ATX Mode Switch • 1x Clear CMOS Switch • 1x Remote Power On/Off Connector, 2-pin Terminal Block • 8x Isolated DIO (4x DI/4x DO), 10-Pin Terminal Block Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays... - Page 19 • Vibration: Operating, 1.5 Grms, 5-500 Hz, 3 Axes Operating System (w/ SSD, according to IEC60068-2-64) • Windows® 10 • IP Level: IP 65 Compliant Front Panel • Linux: Supports by project • EMC: CE, FCC Class A Dimension Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays...
-
Page 20: Powertwin P15C-Al-Sr
• 1x ATX Power On/Off Button • 1x Reset Button • 1x AT/ATX Mode Switch • 1x Clear CMOS Switch • 1x Remote Power On/Off Connector, 2-pin Terminal Block • 8x Isolated DIO (4x DI/4x DO), 10-Pin Terminal Block Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays... - Page 21 • Vibration: Operating, 1.5 Grms, 5-500 Hz, 3 Axes Operating System (w/ SSD, according to IEC60068-2-64) • Windows® 10 • IP Level: IP 65 Compliant Front Panel • Linux: Supports by project • EMC: CE, FCC Class A Dimension Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays...
-
Page 22: Powertwin P17C-Al-Sr
• 1x ATX Power On/Off Button • 1x Reset Button • 1x AT/ATX Mode Switch • 1x Clear CMOS Switch • 1x Remote Power On/Off Connector, 2-pin Terminal Block • 8x Isolated DIO (4x DI/4x DO), 10-Pin Terminal Block Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays... - Page 23 • Vibration: Operating, 1.5 Grms, 5-500 Hz, 3 Axes Operating System (w/ SSD, according to IEC60068-2-64) • Windows® 10 • IP Level: IP 65 Compliant Front Panel • Linux: Supports by project • EMC: CE, FCC Class A Dimension Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays...
-
Page 24: Powertwin P19C-Al-Sr
• 1x ATX Power On/Off Button • 1x Reset Button • 1x AT/ATX Mode Switch • 1x Clear CMOS Switch • 1x Remote Power On/Off Connector, 2-pin Terminal Block • 8x Isolated DIO (4x DI/4x DO), 10-Pin Terminal Block Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays... - Page 25 • Vibration: Operating, 1.5 Grms, 5-500 Hz, 3 Axes Operating System (w/ SSD, according to IEC60068-2-64) • Windows® 10 • IP Level: IP 65 Compliant Front Panel • Linux: Supports by project • EMC: CE, FCC Class A Dimension Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays...
-
Page 26: System I/O
COM 1 supports RS232/422/485 serial device LAN port Used to connect the system to a local area Remote Power On/Off Terminal Block network Used to plug a remote power on/off terminal block Used to connect an analog VGA monitor Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays... -
Page 27: Side (Left)
Used to connect a speaker Digital I/O Terminal Block The Digital I/O terminal block supports 4 Antenna Hole digital input and 4 digital output Used to install an antenna jack USB 3.0 port Used to connect USB 3.0/2.0/1.1 device Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays... -
Page 28: Top
1.6.5 Top VESA Mounting Hole These are mounting holes for VESA mount (75x75mm and 100x100mm) Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays... - Page 29 Chapter 2 System Pin Definitions and Settings...
-
Page 30: Settings
1 2 3 1 2 3 Open Short All pins are open Pins 1 and 2 are short Pins 2 and 3 are short 2.2 Location of the Connectors, Jumpers and Switches 2.2.1 Top View Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays... -
Page 31: Bottom View
2.2.2 Bottom View Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays... -
Page 32: Connector / Jumper / Switch Definition
Mini PCI-Express / mSATA Socket Power1 / Power2 +5V / +12V Power Output POE_PH2 POE Board to Board Connector IGN_PH3 IGN Board to Board Connector PWR_SW1 Power Switch LVDS_OUT1 LVDS Connector SATA1 SATA with Power Connector Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays... -
Page 33: Definition Of Switches
Backlight Increase BL_UP2 : Backlight Decrease Switch Definition Push Backlight Decrease BL_PWR1 : Backlight Power On / Off Switch Definition Push Power on / off switching RESET1 : System Reset Button Switch Definition Push Reset System Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays... - Page 34 DIP6 0V (RI) ON (Default) ON (Default) COM4 SW2: COM1~2 with Power Select Location Function DIP1 DIP2 0V (RI) ON (Default) ON (Default) COM1 Location Function DIP3 DIP4 0V (RI) ON (Default) ON (Default) COM2 Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays...
-
Page 35: Definition Of Connectors
RESERVED PERST# PERN0 (USB3RN0) 3.3V / SATARP0 1.5V 3.3V PERP0 (USB3RP0) CLKREQ# / SATARN0 SIM_VCC SIM_DATA +1.5V REFCLK- SIM_CLK SMB_CLK +1.5V PETN0 (USB3TN0) REFCLK+ / SATATN0 SIM_Reset SMB_DATA PETP0 (USB3TP0) / SATATP0 SIM_VPP +3.3V USB_D- Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays... - Page 36 Definition WAKE# 3.3V 3.3V USB_D+ 3.3V PERST# 23 PERN0 / SATARP0 41 3.3V 1.5V +3.3VAUX CLKREQ# 25 PERP0 / SATARN0 43 +1.5V REFCLK- SMB_CLK +1.5V REFCLK+ PETN0 / ATATN0 SMB_DATA PETP0 / SATATP0 +3.3V USB_D- Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays...
- Page 37 Data Activity Steady Green 1Gbps Network Link No Activity Steady Orange 100Mbps Network Link 10Mbps Network Link DIO1: Digital Input / Output Connector Connector Type: Terminal Block 1X10 10-pin, 3.5mm pitch Definition Definition XCOM+ XCOM- Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays...
- Page 38 LED1: Power / HDD Access LED Status LED Status LED Color POWER Green Yellow POWER1 / 2 : Power Connector Connector Type: 1x4 4-pin Wafer, 2.0mm pitch Definition Pin 1 +12V PWR_SW2: Power On/Off Connector Definition PWR_SW (Note: Please do not apply power to the pins. This port is used to connect a switch.) Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays...
-
Page 39: Chapter 3 System Setup
Chapter 3 System Setup... -
Page 40: Removing The Top Cover
1. Loosen the 8 screws of front and rear panel, then place them aside . 2. Remove the cover from the chassis. 3. Place the top cover gently. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays... -
Page 41: Installing A Half Size Mini Pcie Card
2. Use provided two screws on bracket to fasten the module and bracket together. 3. Tilt the Mini PCIe module at 45 degree angle and insert it to the slot until the gold-pated connector of module contacted firmly with the slot. 45° Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays... -
Page 42: Installing A Full Size Mini Pcie Card
3.3 Installing a Full Size Mini PCIe Card 1. Locate the Mini PCIe slot. 2. Tilt the Mini PCIe module at 45 degree angle and insert it to the slot until the gold-pated connector of module contacted firmly with the slot. 45° Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays... -
Page 43: Installing Antennas
3. Press down the module and use the two screws to fix the module. 3.4 Installing Antennas 1. Remove the antenna hole covers at front panel. 2. Have antenna jack penetrate through the hole. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays... - Page 44 3. Put on washer and fasten the nut with antenna jack. 4. Assemble the antenna and antenna jack together. 5. Attach the RF connector at another end of cable onto the module. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays...
-
Page 45: Installing A So-Dimm
2. Tilt the SODIMM module at a 45 degree angle and insert it to SODIMM socket until the gold-pated connector of module contacted firmly with the socket. 45° 3. Press the module down until its fixed firmly by the two locking latches on each side. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays... -
Page 46: Installing Cpu Thermal Pad
3.6 Installing CPU Thermal Pad 1. Place the thermal pad on the CPU heatsink . 3.7 Installing the Top Cover 1. Put on the cover. 2. Fasten the 8 screws to fix the cover. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays... -
Page 47: Installing A Sata Hard Drive
3.8 Installing a SATA Hard Drive 1. Loosen 2 screws on front panel to remove cover plate. 2. Turn over the unit to have the bottom side face up and loosen 1 screw. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays... - Page 48 4 provided screws to assemble HDD and HDD bracket together. 5. Align the HDD bracket with the entrance of HDD bay. And insert the HDD bracket until the connector of HDD contact the SATA connector firmly. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays...
-
Page 49: Installing A Sim Card
3.9 Installing a SIM Card 1. Loosen 2 screws on front panel to remove cover plate. 2. SIM card slot is at the front panel of the system. 3. Insert the SIM card. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays... -
Page 50: Connecting With Powertwin Display Module
2. Turn over the unit to have the bottom side face up, loosen the 2 screws of the module connector bracket. The photos shows the male connector (on display module) and female connector (on PC module) Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays... - Page 51 3. Connect the module. 4. Fasten the 6 screws to fix the PC module on the display module. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays...
-
Page 52: Vesa Mount
1. The following picture uses a panel PC (PC module + PowerTwin Display) as a demonstration. To attach the panel PC to a VESA stand, please fasten eight screws as indicated to fix it on the stand. PC module PowerTwin display VESA stand Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays... -
Page 53: Panel Mount
3.12 Panel Mount Accessories provided by Spectra are as follows. Mounting Kits Panel Mount PPC Before assembly, please prepare panel mount PPC and customer’s fixture. Panel Mount with customer’s fixture (Front View) Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays... - Page 54 2. All mounting kits displayed are to be inserted into holes. 3. Installation preparation and steps. LVDS connector Panel mount side view with LVDS connector Before Mounting Kits are installed of PowerTwin series Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays...
- Page 55 STEP 1 Position panel mount kits STEP 2 Insert the panel mounting kit into bottom hole STEP 3 Slide the kit toward back Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays...
- Page 56 STEP 4 Tighten the screw forward until the front screw just touches the surface 4. Apply all mount kits to the rest of holes. And you have completed the panel mount installation, as shown below. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays...
- Page 57 Chapter 4 BIOS Setup...
-
Page 58: Chapter 4 Bios Setup
( ↑↓ ) to highlight the field and press <Enter> to call up the sub-menu. Then you can use the control keys to enter values and move from field to field within a sub-menu. If you want to return to the main menu, just press the <Esc >. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays... -
Page 59: Main Setup
Use arrow keys to move among the items and press <Enter> to accept or enter a sub-menu. ■ System Date Set the date. Please use <Tab> to switch between date elements. ■ System Time Set the time. Please use <Tab> to switch between time elements. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays... -
Page 60: Advanced Setup
4.3 Advanced Setup This section allows you to configure and improve your system and allows you to set up some system features according to your preference. 4.3.1 ACPI Settings Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays... -
Page 61: F81866 Super Io Configuration
■ Lock Legacy Resources [Enabled] Enables or disables Lock Legacy Resources. 4.3.2 F81866 Super IO Configuration Set Parameters of Serial Ports. User can Enable/Disable the serial port and Select an optimal settings for the Super IO Device Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays... - Page 62 Enables or disables watch dog function. ■ Watch Dog Mode [Sec] Allows to set watchdog timer unit <Sec> or <Min>. ■ Watch Dog Timer [0] Allows you to set watchdog timer’s value in the range of 0 to 255. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays...
-
Page 63: Hardware Monitor
4.3.3 Hardware Monitor This screen displays the current status of all monitored hardware devices/components such as voltages, temperatures and all fans’ speeds. 4.3.4 S5 RTC Wake Settings Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays... -
Page 64: Serial Port Console Redirection
[Dynamic Time]: Sets a increase minute(s) from current time to wake system from 4.3.5 Serial Port Console Redirection ■ Console Redirection [Disabled] Allow users to enable or disable COM1, COM2, COM3, COM4 console redirection function. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays... -
Page 65: Cpu Configuration
Enables or disables Intel Virtualization Technology. Virtualization enhanced by Intel Virtualization Technology will allow a platform to run multiple operating systems and applications in independent partitions. With virtualization, one computer system can function as multiple virtual systems. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays... -
Page 66: Network Stack Configuration
4.3.7 Network Stack Configuration ■ Network Stack [Disabled] Enables or disables UEFI Network Stack. 4.3.8 CSM Configuration This option controls legacy/UEFI ROMs priority. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays... - Page 67 [UEFI]: Enables UEFI option ROM only. [Legacy]: Enables legacy option ROM only. ■ Other PCI devices [Do not launch] Allows users to determine option ROM execution policy for devise other than network, storage, or video. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays...
-
Page 68: Usb Configuration
Enables or disables XHCI (USB3.0) hand-off function. Use this feature as a workaround for operating systems without XHCI hand-off support. ■ USB Mass Storage Driver Support [Enabled] Enables or disables USB mass storage driver support. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays... -
Page 69: Chipset Setup
4.4 Chipset Setup This section allows you to configure chipset related settings according to user’s preference. 4.4.1 North Bridge This section provides information on the installed memory size and memory/onboard graphics- related configuration options. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays... -
Page 70: South Bridge
■ Amplifier Function [Enabled] Enables or disables Amplifier Function. ■ PSE Enable Selection [Enabled] Enables or disables PSE (Power Sourcing Equipment). ■ LAN1 [Enabled] Enables or disables LAN1 Controller. ■ LAN2 [Enabled] Enables or disables LAN2 Controller. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays... -
Page 71: South Cluster Configuration
4.4.3 South Cluster Configuration ■ PCI Express Configuration Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays... - Page 72 Allows you to select PCI Express port speed. Configuration options: [Auto] [Gen1] [Gen2]. ■ SATA Devices SATA Port 0 Port 0 [Enabled] Enables or disables SATA Port 0. SATA Port 1 Port 1 [Enabled] Enables or disables SATA Port 1. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays...
- Page 73 [Last state]: Enters to the last power state before a power failure sables. Wake On Lan [Enabled] Enables or disables Wake On LAN (WOL) function. BIOS Lock [Disabled] Enables or disables BIOS the SC BIOS Lock enable feature. It is required to be enabled to ensure SMM protection of flash. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays...
-
Page 74: Security Setup
Allows you to set Administrator Password to control access to the BIOS Setup utility. ■ User Password Allows you to set User Password to control access to the system at boot and to the BIOS Setup utility. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays... -
Page 75: Boot Setup
Allows you to enable or disable Fast Boot function. If enabled, system boots with initialization of a minimal set of devices required to launch active boot option. ■ Hard Drive BBS Priority Allows you to set the order of the legacy devices in this group. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays... -
Page 76: Save & Exit
■ Save as User Defaults This item allows you to save the changes done so far as user defaults. ■ Restore User Defaults This item allows you to restore the user defaults to all the setup options. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays... -
Page 77: Product Application
Chapter 5 Product Application... -
Page 78: Digital I/O (Dio) Application
To disable configuration, write exit entry key 0xAA to the index port. Following is an example to enable configuration and to disable configuration by using debug. -o 4e 87 -o 4e 87 (enable configuration) -o 4e aa (disable configuration) Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays... - Page 79 5.1.1.3 Relative Registers To program the F81866A configuration registers, see the following configuration procedures. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays...
- Page 80 //Set (bit 4~7) = 0 to select GP 74~77 as Input mode <input Value> WriteByte(AddrPort, 0x82) // Select configuration register 82h ReadByte(DataPort, Value) // Read bit 4~7(0xFx)= GP74 ~77 as High <Leave the Extended Function Mode> WriteByte(AddrPort, 0xAA) Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays...
- Page 81 //Set (bit 0~3) = 1 to select GP 80 ~83 as Output mode <Output Value> WriteByte(AddrPort, 0x89) // Select configuration register 89h WriteByte(DataPort, Value) // Set bit 0~3=(0/1) to output GP 80~83 as Low or High <Leave the Extended Function Mode> WriteByte(AddrPort, 0xAA) Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays...
- Page 82 7 6 5 4 3 2 1 0 = DO4 = DI4 ‐ ‐ ‐ ‐ 1 0 0 0 value 1 0 0 0 ‐ ‐ ‐ ‐ value (Base Address +2) (Base Address +3) (0xA02) (0xA03) Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays...
-
Page 83: Digital I/O (Dio) Hardware Specification
- DO Signal have to pull up resistor to XCOM+ for external device, the resistance will affect the pull up current - Signal High Level : Pull up resistor to XCOM+ - Signal Low Level : = XCOM- - Sink Current: 1A (Max) Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays... - Page 84 DIO1: Digital Input / Output Connector Connector Type: Terminal Block 1X10 10-pin, 3.5mm pitch Definition Definition XCOM+ XCOM- Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays...
-
Page 85: Chapter 6 Optional Module Pin Definitions And Settings
Chapter 6 Optional Module Pin Definitions and Settings... -
Page 86: Location Of The Connectors And Switches
CFM Module with PoE Control Function, Individual Port 25.5W 6.2 Installing a CFM‐IGN Power Ignition Module 1. Locate the IGN connector on system motherboard as indicated. 2. Insert CFM-IGN module vertically to the female connector on the system’s mainboard, and fasten 2 screws to fix it. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays... - Page 87 Pin 4 Definition 0 second 1 minute 5 minutes 10 minutes 30 minutes 1 hour 2 hours Reserved (0 second) 24V_12V_1: 12V / 24V Car Battery Switch Definition 24V Car Battery Input 12V Car Battery Input Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays...
-
Page 88: Installing A Cfm-Poe Control Module
1. Locate the PoE connector on system motherboard as indicated. 2. Insert the female connector of CFM-PoE module to the male connector on system motherboard. 3. Turn over the heatsink and paste the thermal pad onto the marked by red squares. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays... - Page 89 4. Paste the heatsink onto the CFM-PoE module carefully and fasten 2 screws to fix it. 5. Paste the thermal pads onto the heatsink and coil carefully. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerTwin PE3950/PN4200 Apollo + sunreadable Displays...
- Page 90 Spectra GmbH & Co. KG Spectra GmbH & Co. KG Spectra (Schweiz) AG Mahdenstr. 3 Gewerbepark Ost 1 Flugplatzstr. 5 72768 Reutlingen 4621 Sipbachzell (Wels) 8404 Winterthur Germany Austria Switzerland Phone Phone Phone +49 (0) 7121 1432-10 +43 (0) 7240 20190...
