SPECTRA PowerTwin
Panel‐PC E3950/N4200
Apollo Lake with standard
Displays
USER MANUAL
Version 1.0 – September 2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PowerTwin PSH10-E3950C9 and is the answer not in the manual?

Questions and answers

Related Manuals for Spectra PowerTwin PSH10-E3950C9

Summary of Contents for Spectra PowerTwin PSH10-E3950C9

  • Page 1 SPECTRA PowerTwin  Panel‐PC E3950/N4200  Apollo Lake with standard Displays USER MANUAL Version 1.0 – September 2018...
  • Page 2 SPECTRA PowerTwin  Panel‐PC E3950/N4200  Apollo Lake with sunreadable Displays USER MANUAL Version 1.0 – September 2018...

  • Page 3: Table Of Contents

    3.1 Removing the Top Cover .……...…………………………..…………... 38 3.2 Installing a Half Size Mini PCIe Card ………………………………..39 3.3 Installing a Full Size Mini PCIe Card ………………..……………..40 3.4 Installing Antennas …………………………………..….……………..41 3.5 Installing a SO-DIMM ……………………………………..…….…..43 Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...
  • Page 4 Digital I/O (DIO) Hardware Specification ……….….…………………. 81 Chapter 6 Optional Module Pin Definitions and Settings Location of the Connectors and Switches ……………..…………….. 84 Installing a CFM-IGN Power Ignition Module …………..……………. 84 Installing a CFM-PoE Control Module ………………..………………. 86 Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...

  • Page 5: Preface

    2018/09/11 Copyright Notice © 2018 by Spectra GmbH & Co. KG. All rights are reserved. No parts of this manual may be copied, modified, or reproduced in any form or by any means for commercial use without the prior written permission of Spectra GmbH &...

  • Page 6: Product Warranty Statement

    (such as a fuse, battery, etc.), are not warranted Before sending your product in, you will need to fill in a Spectra RMA Request Form and obtain a RMA number from us. Please go to www.spectra.de/RMA...

  • Page 7: Technical Support And Assistance

    This indication alerts operators to an operation that, if not strictly observed, may result in safety hazards to personnel or damage to equipment. This indication provides additional information to complete a task easily. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...

  • Page 8: Safety Precaution

     The equipment has been dropped and damaged.  The equipment has obvious signs of breakage. 14. CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...

  • Page 9: Package Contents

    Before installation, please ensure all the items listed in the following table are included in the package. Item Description Q’ty Panel PC Utility DVD Driver Screw Pack Panel Mounting Kit Power Terminal Block Connector Remote Power On/Off Terminal Block Connector DIO Terminal Block Connector Thermal Pad (for CPU Thermal Block) Note: Notify your sales representative if any of the above items are missing or damaged. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...

  • Page 10: Ordering Information

    Spectra PowerTwin  10.4" TFT‐LCD 1500nits Sunlight Readable Touch Panel PC with Intel® Atom®  PSH10‐E3950CO9 E3950 Quad Core Processor and P‐Cap. Touch & optical bonding Spectra PowerTwin  12.1" TFT‐LCD 1500nits Sunlight Readable Touch Panel PC with Intel® Atom®  PS12‐E3950CO9 E3950 Quad Core Processor and P‐Cap. Touch & optical bonding Spectra PowerTwin  15" TFT‐LCD 1600nits Sunlight Readable Touch Panel PC with Intel® Atom®  PS15‐E3950CO9 E3950 Quad Core Processor and P‐Cap. Touch & optical bonding Spectra PowerTwin  17" TFT‐LCD 1500nits Sunlight Readable Touch Panel PC with Intel® Atom®  PS17‐E3950CO9 E3950 Quad Core Processor and P‐Cap. Touch & optical bonding Spectra PowerTwin  19" TFT‐LCD 1600nits Sunlight Readable Touch Panel PC with Intel® Atom®  PS19‐E3950CO9 E3950 Quad Core Processor and P‐Cap. Touch & optical bonding Upon Request Spectra PowerTwin with Pentium N4200 CPU Spectra PowerTwin without Touchscreen Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...

  • Page 11: Optional Accessories And Modules

    N ° 151304 (43 x 36 mm) PT‐PN4‐CFM‐PoE02 CFM Module with PoE Control Function, Individual Port 25.5W N ° 156452 N ° 155629 Adapter AC/DC 12V 5A 60W, GST60A12‐CIN, wide temp (‐30 ° C ~ +70 ° C), level VI N ° 155057 Adapter AC/DC 24V 5A 120W, GST120A24‐CIN, wide temp (‐30 ° C ~ +70 ° C), level VI Adapter AC/DC 24V 9.2A 220W, GST220A24‐CIN, wide temp (‐30 ° C ~ +70 ° C), level  Upon request VI (For Spectra PowerTwin PS19‐xxx only) Uni‐Rack Mount kit Universal Rack Mount Kit Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...

  • Page 12: Chapter 1 Product Introductions

    Chapter 1 Product Introductions...

  • Page 13: Overview

    Comparing with regular standalone panel PCs, it is more flexible and reduces maintenance cost dramatically. Featuring with rigorous industrial protections, wide range operating temperature (-20°C to 70°C), IP65 dust/waterproof front panel, and wide range DC power input (9 to 48VDC), Spectra PowerTwin PSE3950/N4200 Series is appropriate for harsh environments and critical applications.

  • Page 14: Product Pictures

    • Designed with Aluminum Die-casting Front Frame • True Flat IP65 Front Panel Protection • Supports CDS Technology, Ignition Sensing and Power over Ethernet • Supports Panel / VESA / Rack Mounting • Supports Optical Bonding Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...

  • Page 15: Hardware Specification

    1.5 Hardware Specification 1.5.1 Spectra PowerTwin PSH10-E3950C (N4200) Display Storage • LCD Size: 10.4" (4:3) • 1x 2.5” HDD/SSD Drive Bay (SATA 3.0) • Max. Resolution: 1024 x 768 • 1x mSATA Socket (SATA 3.0, Shared by Mini-PCIe • Brightness (cd/m2): 1500 Socket) •...
  • Page 16 • Vibration: Operating, 1.5 Grms, 5-500 Hz, 3 Axes • Windows® 10 (w/ SSD, according to IEC60068-2-64) • Linux: Supports by project • IP Level: IP 65 Compliant Front Panel • EMC: CE, FCC Class A Dimension Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...
  • Page 17 1.5.2 Spectra PowerTwin PS12-E3950C (N4200) Display Storage • LCD Size: 12.1" (4:3) • 1x 2.5” HDD/SSD Drive Bay (SATA 3.0) • Max. Resolution: 1024 x 768 • 1x mSATA Socket (SATA 3.0, Shared by Mini-PCIe • Brightness (cd/m2): 1500 Socket) •...
  • Page 18 • Vibration: Operating, 1.5 Grms, 5-500 Hz, 3 Axes • Windows® 10 (w/ SSD, according to IEC60068-2-64) • Linux: Supports by project • IP Level: IP 65 Compliant Front Panel • EMC: CE, FCC Class A Dimension Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...
  • Page 19 1.5.3 Spectra PowerTwin PS15-E3950C (N4200) Display Storage • LCD Size: 15" (4:3) • 1x 2.5” HDD/SSD Drive Bay (SATA 3.0) • Max. Resolution: 1024 x 768 • 1x mSATA Socket (SATA 3.0, Shared by Mini-PCIe • Brightness (cd/m2): 1600 Socket) •...
  • Page 20 • Vibration: Operating, 1.5 Grms, 5-500 Hz, 3 Axes • Windows® 10 (w/ SSD, according to IEC60068-2-64) • Linux: Supports by project • IP Level: IP 65 Compliant Front Panel • EMC: CE, FCC Class A Dimension Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...
  • Page 21 1.5.4 Spectra PowerTwin PS17-E3950C (N4200) Display Storage • LCD Size: 17" (5:4) • 1x 2.5” HDD/SSD Drive Bay (SATA 3.0) • Max. Resolution: 1280 x 1024 • 1x mSATA Socket (SATA 3.0, Shared by Mini-PCIe • Brightness (cd/m2): 1500 Socket) •...
  • Page 22 • Vibration: Operating, 1.5 Grms, 5-500 Hz, 3 Axes • Windows® 10 (w/ SSD, according to IEC60068-2-64) • Linux: Supports by project • IP Level: IP 65 Compliant Front Panel • EMC: CE, FCC Class A Dimension Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...
  • Page 23 1.5.5 Spectra PowerTwin PS19-E3950C (N4200) Display Storage • LCD Size: 19" (5:4) • 1x 2.5” HDD/SSD Drive Bay (SATA 3.0) • Max. Resolution: 1280 x 1024 • 1x mSATA Socket (SATA 3.0, Shared by Mini-PCIe • Brightness (cd/m2): 1600 Socket) •...
  • Page 24 • Vibration: Operating, 1.5 Grms, 5-500 Hz, 3 Axes • Windows® 10 (w/ SSD, according to IEC60068-2-64) • Linux: Supports by project • IP Level: IP 65 Compliant Front Panel • EMC: CE, FCC Class A Dimension Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...

  • Page 25: System I/O

    LAN port Used to connect the system to a local area Remote Power On/Off Terminal Block network Used to plug a remote power on/off terminal block Used to connect an analog VGA monitor Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...

  • Page 26: Side (Left)

    The Digital I/O terminal block supports 4 Used to connect a speaker digital input and 4 digital output USB 3.0 port Antenna Hole Used to connect USB 3.0/2.0/1.1 device Used to install an antenna jack Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...

  • Page 27: Top

    1.6.5 Top VESA Mounting Hole These are mounting holes for VESA mount (75x75mm and 100x100mm) Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...
  • Page 28 Chapter 2 System Pin Definitions and Settings...

  • Page 29: Settings

    1 2 3 1 2 3 Open Short All pins are open Pins 1 and 2 are short Pins 2 and 3 are short 2.2 Location of the Connectors, Jumpers and Switches 2.2.1  Top View Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...

  • Page 30: Bottom View

    2.2.2 Bottom View Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...

  • Page 31: Connector / Jumper / Switch Definition

    Mini PCI-Express / mSATA Socket Power1 / Power2 +5V / +12V Power Output POE_PH2 POE Board to Board Connector IGN_PH3 IGN Board to Board Connector PWR_SW1 Power Switch LVDS_OUT1 LVDS Connector SATA1 SATA with Power Connector Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...

  • Page 32: Definition Of Switches

    BL_UP2 : Backlight Decrease Switch Definition Push Backlight Decrease BL_PWR1 : Backlight Power On / Off Switch Definition Push Power on / off switching RESET1 : System Reset Button Switch Definition Push Reset System Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...
  • Page 33 ON (Default) ON (Default) COM4 SW2: COM1~2 with Power Select Location Function DIP1 DIP2 0V (RI) ON (Default) ON (Default) COM1 Location Function DIP3 DIP4 0V (RI) ON (Default) ON (Default) COM2 Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...

  • Page 34: Definition Of Connectors

    PERN0 (USB3RN0) 3.3V / SATARP0 1.5V 3.3V PERP0 (USB3RP0) CLKREQ# / SATARN0 SIM_VCC SIM_DATA +1.5V REFCLK- SIM_CLK SMB_CLK +1.5V PETN0 (USB3TN0) REFCLK+ / SATATN0 SIM_Reset SMB_DATA PETP0 (USB3TP0) / SATATP0 SIM_VPP +3.3V USB_D- Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...
  • Page 35 3.3V USB_D+ 3.3V PERST# 23 PERN0 / SATARP0 41 3.3V 1.5V +3.3VAUX CLKREQ# 25 PERP0 / SATARN0 43 +1.5V REFCLK- SMB_CLK +1.5V REFCLK+ PETN0 / ATATN0 SMB_DATA PETP0 / SATATP0 +3.3V USB_D- Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...
  • Page 36 Steady Green 1Gbps Network Link No Activity Steady Orange 100Mbps Network Link 10Mbps Network Link DIO1: Digital Input / Output Connector Connector Type: Terminal Block 1X10 10-pin, 3.5mm pitch Definition Definition XCOM+ XCOM- Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...
  • Page 37 LED1: Power / HDD Access LED Status LED Status LED Color POWER Green Yellow POWER1 / 2 : Power Connector Connector Type: 1x4 4-pin Wafer, 2.0mm pitch Definition Pin 1 +12V PWR_SW2: Power On/Off Connector Definition PWR_SW (Note: Please do not apply power to the pins. This port is used to connect a switch.) Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...

  • Page 38: Chapter 3 System Setup

    Chapter 3 System Setup...

  • Page 39: Removing The Top Cover

    1. Loosen the 8 screws of front and rear panel, then place them aside . 2. Remove the cover from the chassis. 3. Place the top cover gently. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...

  • Page 40: Installing A Half Size Mini Pcie Card

    2. Use provided two screws on bracket to fasten the module and bracket together. 3. Tilt the Mini PCIe module at 45 degree angle and insert it to the slot until the gold-pated connector of module contacted firmly with the slot. 45° Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...

  • Page 41: Installing A Full Size Mini Pcie Card

    1. Locate the Mini PCIe slot. 2. Tilt the Mini PCIe module at 45 degree angle and insert it to the slot until the gold-pated connector of module contacted firmly with the slot. 45° Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...

  • Page 42: Installing Antennas

    3. Press down the module and use the two screws to fix the module. 3.4 Installing Antennas 1. Remove the antenna hole covers at front panel. 2. Have antenna jack penetrate through the hole. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...
  • Page 43 3. Put on washer and fasten the nut with antenna jack. 4. Assemble the antenna and antenna jack together. 5. Attach the RF connector at another end of cable onto the module. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...

  • Page 44: Installing A So-Dimm

    2. Tilt the SODIMM module at a 45 degree angle and insert it to SODIMM socket until the gold-pated connector of module contacted firmly with the socket. 45° 3. Press the module down until its fixed firmly by the two locking latches on each side. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...

  • Page 45: Installing Cpu Thermal Pad

    3.6 Installing CPU Thermal Pad 1. Place the thermal pad on the CPU heatsink . 3.7 Installing the Top Cover 1. Put on the cover. 2. Fasten the 8 screws to fix the cover. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...

  • Page 46: Installing A Sata Hard Drive

    3.8 Installing a SATA Hard Drive 1. Loosen 2 screws on front panel to remove cover plate. 2. Turn over the unit to have the bottom side face up and loosen 1 screw. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays...
  • Page 47 4 provided screws to assemble HDD and HDD bracket together. 5. Align the HDD bracket with the entrance of HDD bay. And insert the HDD bracket until the connector of HDD contact the SATA connector firmly. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...

  • Page 48: Installing A Sim Card

    3.9 Installing a SIM Card 1. Loosen 2 screws on front panel to remove cover plate. 2. SIM card slot is at the front panel of the system. 3. Insert the SIM card. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...

  • Page 49: Connecting With Cs Display Module

    2. Turn over the unit to have the bottom side face up, loosen the 2 screws of the module connector bracket. The photos shows the male connector (on display module) and female connector (on PC module) Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...
  • Page 50 3. Connect the module. 4. Fasten the 6 screws to fix the PC module on the display module. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...

  • Page 51: Vesa Mount

    1. The following picture uses a panel PC (PE3950/N4200 Module +display module) as a demonstration. To attach the panel PC to a VESA stand, please fasten eight screws as indicated to fix it on the stand. PE3950/N4200 + display module VESA stand Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...

  • Page 52: Panel Mount

    3.12 Panel Mount Accessories provided are as follows. Mounting Kits Panel Mount PPC Before assembly, please prepare panel mount PPC and customer’s fixture. Panel Mount with customer’s fixture (Front View) Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...
  • Page 53 2. All mounting kits displayed are to be inserted into holes. 3. Installation preparation and steps. LVDS connector Panel mount side view with LVDS connector Before Mounting Kits are installed of Sunreadable series Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...
  • Page 54 STEP 1 Position panel mount kits STEP 2 Insert the panel mounting kit into bottom hole STEP 3 Slide the kit toward back Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...
  • Page 55 Tighten the screw forward until the front screw just touches the surface 4. Apply all mount kits to the rest of holes. And you have completed the panel mount installation, as shown below. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays...

  • Page 56: Chapter 4 Bios Setup

    Chapter 4 BIOS Setup...

  • Page 57: Bios Introduction

    ( ↑↓ ) to highlight the field and press <Enter> to call up the sub-menu. Then you can use the control keys to enter values and move from field to field within a sub-menu. If you want to return to the main menu, just press the <Esc >. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays...

  • Page 58: Main Setup

    ■ System Date Set the date. Please use <Tab> to switch between date elements. ■ System Time Set the time. Please use <Tab> to switch between time elements. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...

  • Page 59: Advanced Setup

    4.3 Advanced Setup This section allows you to configure and improve your system and allows you to set up some system features according to your preference. 4.3.1 ACPI Settings Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...

  • Page 60: F81866 Super Io Configuration

    Enables or disables Lock Legacy Resources. 4.3.2 F81866 Super IO Configuration Set Parameters of Serial Ports. User can Enable/Disable the serial port and Select an optimal settings for the Super IO Device Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...
  • Page 61 ■ Watch Dog Mode [Sec] Allows to set watchdog timer unit <Sec> or <Min>. ■ Watch Dog Timer [0] Allows you to set watchdog timer’s value in the range of 0 to 255. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...

  • Page 62: Hardware Monitor

    4.3.3 Hardware Monitor This screen displays the current status of all monitored hardware devices/components such as voltages, temperatures and all fans’ speeds. 4.3.4 S5 RTC Wake Settings Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...

  • Page 63: Serial Port Console Redirection

    [Dynamic Time]: Sets a increase minute(s) from current time to wake system from 4.3.5 Serial Port Console Redirection ■ Console Redirection [Disabled] Allow users to enable or disable COM1, COM2, COM3, COM4 console redirection function. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...

  • Page 64: Cpu Configuration

    Enables or disables Intel Virtualization Technology. Virtualization enhanced by Intel Virtualization Technology will allow a platform to run multiple operating systems and applications in independent partitions. With virtualization, one computer system can function as multiple virtual systems. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...

  • Page 65: Network Stack Configuration

    4.3.7 Network Stack Configuration ■ Network Stack [Disabled] Enables or disables UEFI Network Stack. 4.3.8 CSM Configuration This option controls legacy/UEFI ROMs priority. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...
  • Page 66 [UEFI]: Enables UEFI option ROM only. [Legacy]: Enables legacy option ROM only. ■ Other PCI devices [Do not launch] Allows users to determine option ROM execution policy for devise other than network, storage, or video. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...

  • Page 67: Usb Configuration

    Enables or disables XHCI (USB3.0) hand-off function. Use this feature as a workaround for operating systems without XHCI hand-off support. ■ USB Mass Storage Driver Support [Enabled] Enables or disables USB mass storage driver support. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...

  • Page 68: Chipset Setup

    4.4 Chipset Setup This section allows you to configure chipset related settings according to user’s preference. 4.4.1 North Bridge This section provides information on the installed memory size and memory/onboard graphics- related configuration options. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...

  • Page 69: South Bridge

    ■ Amplifier Function [Enabled] Enables or disables Amplifier Function. ■ PSE Enable Selection [Enabled] Enables or disables PSE (Power Sourcing Equipment). ■ LAN1 [Enabled] Enables or disables LAN1 Controller. ■ LAN2 [Enabled] Enables or disables LAN2 Controller. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...

  • Page 70: South Cluster Configuration

    4.4.3 South Cluster Configuration ■ PCI Express Configuration Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...
  • Page 71 Configuration options: [Auto] [Gen1] [Gen2]. ■ SATA Devices SATA Port 0  Port 0 [Enabled] Enables or disables SATA Port 0. SATA Port 1  Port 1 [Enabled] Enables or disables SATA Port 1. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...
  • Page 72 [Last state]: Enters to the last power state before a power failure sables.  Wake On Lan [Enabled] Enables or disables Wake On LAN (WOL) function.  BIOS Lock [Disabled] Enables or disables BIOS the SC BIOS Lock enable feature. It is required to be enabled to  ensure SMM protection of flash. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...

  • Page 73: Security Setup

    Allows you to set Administrator Password to control access to the BIOS Setup utility. ■ User Password Allows you to set User Password to control access to the system at boot and to the BIOS Setup utility. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...

  • Page 74: Boot Setup

    Allows you to enable or disable Fast Boot function. If enabled, system boots with initialization of a minimal set of devices required to launch active boot option. ■ Hard Drive BBS Priority Allows you to set the order of the legacy devices in this group. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...

  • Page 75: Save & Exit

    This item allows you to save the changes done so far as user defaults. ■ Restore User Defaults This item allows you to restore the user defaults to all the setup options. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...

  • Page 76: Chapter 5 Product Application

    Chapter 5 Product Application Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...

  • Page 77: Digital I/O (Dio) Application

    To disable configuration, write exit entry key 0xAA to the index port. Following is an example to enable configuration and to disable configuration by using debug. -o 4e 87 -o 4e 87 (enable configuration) -o 4e aa (disable configuration) Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...
  • Page 78 5.1.1.3 Relative Registers To program the F81866A configuration registers, see the following configuration procedures. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...
  • Page 79 //Set (bit 4~7) = 0 to select GP 74~77 as Input mode <input Value> WriteByte(AddrPort, 0x82) // Select configuration register 82h ReadByte(DataPort, Value) // Read bit 4~7(0xFx)= GP74 ~77 as High <Leave the Extended Function Mode> WriteByte(AddrPort, 0xAA) Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...
  • Page 80 //Set (bit 0~3) = 1 to select GP 80 ~83 as Output mode <Output Value> WriteByte(AddrPort, 0x89) // Select configuration register 89h WriteByte(DataPort, Value) // Set bit 0~3=(0/1) to output GP 80~83 as Low or High <Leave the Extended Function Mode> WriteByte(AddrPort, 0xAA) Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...
  • Page 81 7 6 5 4 3 2 1 0 = DO4 = DI4 ‐ ‐ ‐ ‐ 1 0 0 0 value 1 0 0 0 ‐ ‐ ‐ ‐ value (Base Address +2) (Base Address +3) (0xA02) (0xA03) Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...

  • Page 82: Digital I/O (Dio) Hardware Specification

    - DO Signal have to pull up resistor to XCOM+ for external device, the resistance will affect the pull up current - Signal High Level : Pull up resistor to XCOM+ - Signal Low Level : = XCOM- - Sink Current: 1A (Max) Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...
  • Page 83 DIO1: Digital Input / Output Connector Connector Type: Terminal Block 1X10 10-pin, 3.5mm pitch Definition Definition XCOM+ XCOM- Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...

  • Page 84: Chapter 6 Optional Module Pin Definitions And Settings

    Chapter 6 Optional Module Pin Definitions and Settings Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...

  • Page 85: Location Of The Connectors And Switches

    CFM Module with PoE Control Function, Individual Port 25.5W 6.2 Installing a CFM‐IGN Power Ignition Module 1. Locate the IGN connector on system motherboard as indicated. 2. Insert CFM-IGN module vertically to the female connector on the system’s mainboard, and fasten 2 screws to fix it. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...
  • Page 86 0 second 1 minute 5 minutes 10 minutes 30 minutes 1 hour 2 hours Reserved (0 second) 24V_12V_1: 12V / 24V Car Battery Switch Definition 24V Car Battery Input 12V Car Battery Input Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...

  • Page 87: Installing A Cfm-Poe Control Module

    1. Locate the PoE connector on system motherboard as indicated. 2. Insert the female connector of CFM-PoE module to the male connector on system motherboard. 3. Turn over the heatsink and paste the thermal pad onto the marked by red squares. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...
  • Page 88 4. Paste the heatsink onto the CFM-PoE module carefully and fasten 2 screws to fix it. 5. Paste the thermal pads onto the heatsink and coil carefully. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + Sunreadable Displays September 2018...
  • Page 89 Spectra GmbH & Co. KG Spectra GmbH & Co. KG Spectra (Schweiz) AG Mahdenstr. 3 Gewerbepark Ost 1 Flugplatzstr. 5 72768 Reutlingen 4621 Sipbachzell (Wels) 8404 Winterthur Germany Austria Switzerland Phone Phone Phone +49 (0) 7121 1432-10 +43 (0) 7240 20190...
  • Page 90 2.2 Location of the Connectors, Jumpers and Switches .…..…………..42 2.2.1 Top View ..……………………………….…………………………42 2.2.2 Bottom View ..…………………………………………………….. 43 2.3 Connector / Jumper / Switch Definition ..………….…….………..44 2.4 Definition of Switches ..……….……………........45 2.5 Definition of Connectors ……….……..………........47 Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...
  • Page 91 Digital I/O (DIO) Hardware Specification ……….….…………………. 95 Chapter 6 Optional Module Pin Definitions and Settings Location of the Connectors and Switches ……………..…………….. 98 Installing a CFM-IGN Power Ignition Module …………..……………. 98 Installing a CFM-PoE Control Module ………………..………………. 100 Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...

  • Page 92: Preface

    2018/09/07 Copyright Notice © 2018 by Spectra GmbH & Co. KG. All rights are reserved. No parts of this manual may be copied, modified, or reproduced in any form or by any means for commercial use without the prior written permission of Spectra GmbH &...

  • Page 93: Product Warranty Statement

    (such as a fuse, battery, etc.), are not warranted Before sending your product in, you will need to fill in a Spectra RMA Request Form and obtain a RMA number from us. Please go to www.spectra.de/RMA...

  • Page 94: Technical Support And Assistance

    This indication alerts operators to an operation that, if not strictly observed, may result in safety hazards to personnel or damage to equipment. This indication provides additional information to complete a task easily. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...

  • Page 95: Safety Precaution

     The equipment has been dropped and damaged.  The equipment has obvious signs of breakage. 14. CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...

  • Page 96: Package Contents

    Before installation, please ensure all the items listed in the following table are included in the package. Item Description Q’ty Panel PC Utility DVD Driver Screw Pack Panel Mounting Kit Power Terminal Block Connector Remote Power On/Off Terminal Block Connector DIO Terminal Block Connector Thermal Pad (for CPU Thermal Block) Note: Notify your sales representative if any of the above items are missing or damaged. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...

  • Page 97: Ordering Information

    Spectra PowerTwin  19" TFT‐LCD SXGA 5:4 Modular Touch Panel PC with Intel® Atom® E3950 Quad  P19‐E3950R9‐S Core Processor and Resistive 5‐wire Touch Spectra PowerTwin  15.6" TFT‐LCD WXGA 16:9 Modular Touch Panel PC with Intel® Atom® E3950  PW15‐E3950C9 Quad Core Processor and P‐Cap. Touch Spectra PowerTwin  15.6" TFT‐LCD WXGA 16:9 Modular Touch Panel PC with Intel® Atom® E3950  PW15‐E3950R9‐S Quad Core Processor and Resistive 5‐wire Touch Spectra PowerTwin  21.5" TFT‐LCD Full HD 16:9 Modular Touch Panel PC with Intel® Atom® E3950  PW21‐E3950C9 Quad Core Processor and P‐Cap. Touch 21.5" TFT‐LCD Full HD 16:9 Modular Touch Panel PC with Intel® Atom® E3950  Spectra PowerTwin  PW21‐E3950R9‐S Quad Core Processor and Resistive 5‐wire Touch Upon Request Spectra PowerTwin with Pentium N4200 CPU Spectra PowerTwin without Touchscreen Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...

  • Page 98: Optional Accessories And Modules

    Optional Modules & Accessories Model No. Description PB‐3000A‐IGN CFM Module with Power Ignition Sensing Control Function, 12V/24V Selectable  N ° 151304 (43 x 36 mm) PT‐PN4‐CFM‐PoE02 CFM Module with PoE Control Function, Individual Port 25.5W N ° 156452 N ° 155629 Adapter AC/DC 12V 5A 60W, GST60A12‐CIN, wide temp (‐30 ° C ~ +70 ° C), level VI N ° 155057 Adapter AC/DC 24V 5A 120W, GST120A24‐CIN, wide temp (‐30 ° C ~ +70 ° C), level VI Uni‐Rack Mount kit Universal Rack Mount Kit Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...

  • Page 99: Chapter 1 Product Introductions

    Chapter 1 Product Introductions...

  • Page 100: Overview

    Comparing with regular standalone panel PCs, it is more flexible and reduces maintenance cost dramatically. Featuring with rigorous industrial protections, wide range operating temperature, IP65 dust/waterproof front panel, and wide range DC power input (9 to 48VDC), Spectra PowerTwin PE3950/N4200 Series is appropriate for harsh environments and critical applications.

  • Page 101: Product Pictures

    • 2x Full Size Mini-PCIe, 1x 2.5” SATA Drive Bay, 1x mSATA Socket • Designed with Aluminum Die-casting Front Frame • True Flat IP65 Front Panel Protection • Supports CDS Technology, Ignition Sensing and Power over Ethernet • Supports Panel / VESA Mounting Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...

  • Page 102: Hardware Specification

    1.5 Hardware Specification 1.5.1 Spectra PowerTwin P08-E3950R (N4200) R Display Storage • LCD Size: 8.4" (4:3) • 1x 2.5” HDD/SSD Drive Bay (SATA 3.0) • Max. Resolution: 800 x 600 • 1x mSATA Socket (SATA 3.0, Shared by Mini-PCIe • Brightness (cd/m2): 400 Socket) •...
  • Page 103 • Vibration: Operating, 1.5 Grms, 5-500 Hz, 3 Axes • Windows® 10 (w/ SSD, according to IEC60068-2-64) • Linux: Supports by project • IP Level: IP 65 Compliant Front Panel • EMC: CE, FCC Class A Dimension Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...
  • Page 104 • Backlight MTBF: 50000 hrs. (LED Backlight) • 1x SIM Socket • Supports Control Function Module (CFM) Touch Technology • Resistive 5-wire Touch for Spectra PowerTwin - Optional CFM IGN Module for Power Ignition PH10-xxxxR Only Function • Projected Capacitive Touch for Spectra PowerTwin...
  • Page 105 • Vibration: Operating, 1.5 Grms, 5-500 Hz, 3 Axes • Windows® 10 (w/ SSD, according to IEC60068-2-64) • Linux: Supports by project • IP Level: IP 65 Compliant Front Panel • EMC: CE, FCC Class A Dimension Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...
  • Page 106 • Backlight MTBF: 50000 hrs. (LED Backlight) • 1x SIM Socket • Supports Control Function Module (CFM) Touch Technology • Resistive 5-wire Touch for Spectra PowerTwin P10- - Optional CFM IGN Module for Power Ignition xxxxR Only Function • Projected Capacitive Touch for Spectra PowerTwin...
  • Page 107 • Vibration: Operating, 1.5 Grms, 5-500 Hz, 3 Axes • Windows® 10 (w/ SSD, according to IEC60068-2-64) • Linux: Supports by project • IP Level: IP 65 Compliant Front Panel • EMC: CE, FCC Class A Dimension Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...
  • Page 108 • Backlight MTBF: 50000 hrs. (LED Backlight) • 1x SIM Socket • Supports Control Function Module (CFM) Touch Technology • Resistive 5-wire Touch for Spectra PowerTwin P12- - Optional CFM IGN Module for Power Ignition xxxxR Only Function • Projected Capacitive Touch for Spectra PowerTwin...
  • Page 109 • Vibration: Operating, 1.5 Grms, 5-500 Hz, 3 Axes • Windows® 10 (w/ SSD, according to IEC60068-2-64) • Linux: Supports by project • IP Level: IP 65 Compliant Front Panel • EMC: CE, FCC Class A Dimension Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...
  • Page 110 • Backlight MTBF: 50000 hrs. (LED Backlight) • 1x SIM Socket • Supports Control Function Module (CFM) Touch Technology • Resistive 5-wire Touch for Spectra PowerTwin P15- - Optional CFM IGN Module for Power Ignition xxxxR Only Function • Projected Capacitive Touch for Spectra PowerTwin...
  • Page 111 • Vibration: Operating, 1.5 Grms, 5-500 Hz, 3 Axes • Windows® 10 (w/ SSD, according to IEC60068-2-64) • Linux: Supports by project • IP Level: IP 65 Compliant Front Panel • EMC: CE, FCC Class A Dimension Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...
  • Page 112 • Backlight MTBF: 50000 hrs. (LED Backlight) • 1x SIM Socket • Supports Control Function Module (CFM) Touch Technology • Resistive 5-wire Touch for Spectra PowerTwin P17- - Optional CFM IGN Module for Power Ignition xxxxR Only Function • Projected Capacitive Touch for Spectra PowerTwin...
  • Page 113 • Vibration: Operating, 1.5 Grms, 5-500 Hz, 3 Axes • Windows® 10 (w/ SSD, according to IEC60068-2-64) • Linux: Supports by project • IP Level: IP 65 Compliant Front Panel • EMC: CE, FCC Class A Dimension Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...
  • Page 114 1.5.8 Spectra PowerTwin P17-E3950 (N4200) Display Storage • LCD Size: 17" (5:4) • 1x 2.5” HDD/SSD Drive Bay (SATA 3.0) • Max. Resolution: 1280 x 1024 • 1x mSATA Socket (SATA 3.0, Shared by Mini-PCIe • Brightness (cd/m2): 350 Socket) •...
  • Page 115 • Vibration: Operating, 1.5 Grms, 5-500 Hz, 3 Axes • Windows® 10 (w/ SSD, according to IEC60068-2-64) • Linux: Supports by project • IP Level: IP 65 Compliant Front Panel • EMC: CE, FCC Class A Dimension Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...
  • Page 116 • Backlight MTBF: 50000 hrs. (LED Backlight) • 1x SIM Socket • Supports Control Function Module (CFM) Touch Technology • Resistive 5-wire Touch for Spectra PowerTwin P19- - Optional CFM IGN Module for Power Ignition xxxxR Only Function • Projected Capacitive Touch for Spectra PowerTwin...
  • Page 117 • Vibration: Operating, 1.5 Grms, 5-500 Hz, 3 Axes • Windows® 10 (w/ SSD, according to IEC60068-2-64) • Linux: Supports by project • IP Level: IP 65 Compliant Front Panel • EMC: CE, FCC Class A Dimension Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...
  • Page 118 1.5.10 Spectra PowerTwin P19-E3950 (N4200) Display Expansion • LCD Size: 19" (5:4) • 2x Full-size Mini-PCIe Socket • Max. Resolution: 1280 x 1024 • 1x SIM Socket • Brightness (cd/m2): 350 • Supports Control Function Module (CFM) • Contrast Ratio: 1000 : 1 Technology •...
  • Page 119 • Vibration: Operating, 1.5 Grms, 5-500 Hz, 3 Axes • Windows® 10 (w/ SSD, according to IEC60068-2-64) • Linux: Supports by project • IP Level: IP 65 Compliant Front Panel • EMC: CE, FCC Class A Dimension Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...
  • Page 120 • Backlight MTBF: 50000 hrs. (LED Backlight) • 1x SIM Socket • Supports Control Function Module (CFM) Touch Technology • Resistive 5-wire Touch for Spectra PowerTwin - Optional CFM IGN Module for Power Ignition PW15-xxxxR Only Function • Projected Capacitive Touch for Spectra PowerTwin...
  • Page 121 • Vibration: Operating, 1.5 Grms, 5-500 Hz, 3 Axes • Windows® 10 (w/ SSD, according to IEC60068-2-64) • Linux: Supports by project • IP Level: IP 65 Compliant Front Panel • EMC: CE, FCC Class A Dimension Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...
  • Page 122 • Backlight MTBF: 50000 hrs. (LED Backlight) • 1x SIM Socket • Supports Control Function Module (CFM) Touch Technology • Resistive 5-wire Touch for Spectra PowerTwin - Optional CFM IGN Module for Power Ignition PW21-xxxxR Only Function • Projected Capacitive Touch for Spectra PowerTwin...
  • Page 123 • Vibration: Operating, 1.5 Grms, 5-500 Hz, 3 Axes • Windows® 10 (w/ SSD, according to IEC60068-2-64) • Linux: Supports by project • IP Level: IP 65 Compliant Front Panel • EMC: CE, FCC Class A Dimension Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...
  • Page 124 1.5.13 Spectra PowerTwin PW21-E3950 (N4200) Display Expansion • LCD Size: 21.5" (16:9) • 2x Full-size Mini-PCIe Socket • Max. Resolution: 1920 x 1080 • 1x SIM Socket • Brightness (cd/m2): 300 • Supports Control Function Module (CFM) • Contrast Ratio: 5000 : 1 Technology •...
  • Page 125 • Vibration: Operating, 1.5 Grms, 5-500 Hz, 3 Axes • Windows® 10 (w/ SSD, according to IEC60068-2-64) • Linux: Supports by project • IP Level: IP 65 Compliant Front Panel • EMC: CE, FCC Class A Dimension Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...

  • Page 126: System I/O

    LAN port Used to connect the system to a local area Remote Power On/Off Terminal Block network Used to plug a remote power on/off terminal block Used to connect an analog VGA monitor Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...

  • Page 127: Side (Left)

    The Digital I/O terminal block supports 4 Used to connect a speaker digital input and 4 digital output USB 3.0 port Antenna Hole Used to connect USB 3.0/2.0/1.1 device Used to install an antenna jack Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...

  • Page 128: Top

    1.6.5 Top VESA Mounting Hole These are mounting holes for VESA mount (75x75mm and 100x100mm) Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...
  • Page 129 Chapter 2 System Pin Definitions and Settings...

  • Page 130: Settings

    1 2 3 1 2 3 Open Short All pins are open Pins 1 and 2 are short Pins 2 and 3 are short 2.2 Location of the Connectors, Jumpers and Switches 2.2.1  Top View Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...

  • Page 131: Bottom View

    2.2.2 Bottom View Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...

  • Page 132: Connector / Jumper / Switch Definition

    Mini PCI-Express / mSATA Socket Power1 / Power2 +5V / +12V Power Output POE_PH2 POE Board to Board Connector IGN_PH3 IGN Board to Board Connector PWR_SW1 Power Switch LVDS_OUT1 LVDS Connector SATA1 SATA with Power Connector Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...

  • Page 133: Definition Of Switches

    BL_UP2 : Backlight Decrease Switch Definition Push Backlight Decrease BL_PWR1 : Backlight Power On / Off Switch Definition Push Power on / off switching RESET1 : System Reset Button Switch Definition Push Reset System Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...
  • Page 134 ON (Default) ON (Default) COM4 SW2: COM1~2 with Power Select Location Function DIP1 DIP2 0V (RI) ON (Default) ON (Default) COM1 Location Function DIP3 DIP4 0V (RI) ON (Default) ON (Default) COM2 Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...

  • Page 135: Definition Of Connectors

    PERN0 (USB3RN0) 3.3V / SATARP0 1.5V 3.3V PERP0 (USB3RP0) CLKREQ# / SATARN0 SIM_VCC SIM_DATA +1.5V REFCLK- SIM_CLK SMB_CLK +1.5V PETN0 (USB3TN0) REFCLK+ / SATATN0 SIM_Reset SMB_DATA PETP0 (USB3TP0) / SATATP0 SIM_VPP +3.3V USB_D- Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...
  • Page 136 3.3V USB_D+ 3.3V PERST# 23 PERN0 / SATARP0 41 3.3V 1.5V +3.3VAUX CLKREQ# 25 PERP0 / SATARN0 43 +1.5V REFCLK- SMB_CLK +1.5V REFCLK+ PETN0 / ATATN0 SMB_DATA PETP0 / SATATP0 +3.3V USB_D- Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...
  • Page 137 Steady Green 1Gbps Network Link No Activity Steady Orange 100Mbps Network Link 10Mbps Network Link DIO1: Digital Input / Output Connector Connector Type: Terminal Block 1X10 10-pin, 3.5mm pitch Definition Definition XCOM+ XCOM- Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...
  • Page 138 LED1: Power / HDD Access LED Status LED Status LED Color POWER Green Yellow POWER1 / 2 : Power Connector Connector Type: 1x4 4-pin Wafer, 2.0mm pitch Definition Pin 1 +12V PWR_SW2: Power On/Off Connector Definition PWR_SW (Note: Please do not apply power to the pins. This port is used to connect a switch.) Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...

  • Page 139: Chapter 3 System Setup

    Chapter 3 System Setup...

  • Page 140: Removing The Top Cover

    1. Loosen the 8 screws of front and rear panel, then place them aside . 2. Remove the cover from the chassis. 3. Place the top cover gently. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...

  • Page 141: Installing A Half Size Mini Pcie Card

    2. Use provided two screws on bracket to fasten the module and bracket together. 3. Tilt the Mini PCIe module at 45 degree angle and insert it to the slot until the gold-pated connector of module contacted firmly with the slot. 45° Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...

  • Page 142: Installing A Full Size Mini Pcie Card

    1. Locate the Mini PCIe slot. 2. Tilt the Mini PCIe module at 45 degree angle and insert it to the slot until the gold-pated connector of module contacted firmly with the slot. 45° Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...

  • Page 143: Installing Antennas

    3. Press down the module and use the two screws to fix the module. 3.4 Installing Antennas 1. Remove the antenna hole covers at front panel. 2. Have antenna jack penetrate through the hole. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...
  • Page 144 3. Put on washer and fasten the nut with antenna jack. 4. Assemble the antenna and antenna jack together. 5. Attach the RF connector at another end of cable onto the module. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...

  • Page 145: Installing A So-Dimm

    2. Tilt the SODIMM module at a 45 degree angle and insert it to SODIMM socket until the gold-pated connector of module contacted firmly with the socket. 45° 3. Press the module down until its fixed firmly by the two locking latches on each side. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...

  • Page 146: Installing Cpu Thermal Pad

    3.6 Installing CPU Thermal Pad 1. Place the thermal pad on the CPU heatsink . 3.7 Installing the Top Cover 1. Put on the cover. 2. Fasten the 8 screws to fix the cover. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...

  • Page 147: Installing A Sata Hard Drive

    3.8 Installing a SATA Hard Drive 1. Loosen 2 screws on front panel to remove cover plate. 2. Turn over the unit to have the bottom side face up and loosen 1 screw. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays...
  • Page 148 4 provided screws to assemble HDD and HDD bracket together. 5. Align the HDD bracket with the entrance of HDD bay. And insert the HDD bracket until the connector of HDD contact the SATA connector firmly. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...

  • Page 149: Installing A Sim Card

    3.9 Installing a SIM Card 1. Loosen 2 screws on front panel to remove cover plate. 2. SIM card slot is at the front panel of the system. 3. Insert the SIM card. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...

  • Page 150: Connecting With Display Module

    2. Turn over the unit to have the bottom side face up, loosen the 2 screws of the module connector bracket. The photos shows the male connector (on display module) and female connector (on PC module) Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...
  • Page 151 3. Connect the module. 4. Fasten the 6 screws to fix the PC module on the display module. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...

  • Page 152: Vesa Mount

    1. The following picture uses a panel PC (PE3950/N4200 series+ display module) as a demonstration. To attach the panel PC to a VESA stand, please fasten eight screws as indicated to fix it on the stand. PE3950/N4200  series display module VESA stand Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...

  • Page 153: Panel Mount

    3.12 Panel Mount Accessories provided are as follows. Mounting Kits Panel Mount PPC Before assembly, please prepare panel mount PPC and customer’s fixture. Panel Mount with customer’s fixture (Front View) Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...
  • Page 154 2. All mounting kits displayed are to be inserted into holes. 3. Installation preparation and steps. LVDS connector Panel mount side view with LVDS connector Before Mounting Kits are installed of Display series Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...
  • Page 155 STEP 1 Position panel mount kits STEP 2 Insert the panel mounting kit into bottom hole STEP 3 Slide the kit toward back Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...
  • Page 156 Tighten the screw forward until the front screw just touches the surface 4. Apply all mount kits to the rest of holes. And you have completed the panel mount installation, as shown below. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays...

  • Page 157: Chapter 4 Bios Setup

    Chapter 4 BIOS Setup...

  • Page 158: Bios Introduction

    ( ↑↓ ) to highlight the field and press <Enter> to call up the sub-menu. Then you can use the control keys to enter values and move from field to field within a sub-menu. If you want to return to the main menu, just press the <Esc >. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays...

  • Page 159: Main Setup

    ■ System Date Set the date. Please use <Tab> to switch between date elements. ■ System Time Set the time. Please use <Tab> to switch between time elements. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...

  • Page 160: Advanced Setup

    4.3 Advanced Setup This section allows you to configure and improve your system and allows you to set up some system features according to your preference. 4.3.1 ACPI Settings Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...

  • Page 161: F81866 Super Io Configuration

    Enables or disables Lock Legacy Resources. 4.3.2 F81866 Super IO Configuration Set Parameters of Serial Ports. User can Enable/Disable the serial port and Select an optimal settings for the Super IO Device Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...
  • Page 162 ■ Watch Dog Mode [Sec] Allows to set watchdog timer unit <Sec> or <Min>. ■ Watch Dog Timer [0] Allows you to set watchdog timer’s value in the range of 0 to 255. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...

  • Page 163: Hardware Monitor

    4.3.3 Hardware Monitor This screen displays the current status of all monitored hardware devices/components such as voltages, temperatures and all fans’ speeds. 4.3.4 S5 RTC Wake Settings Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...

  • Page 164: Serial Port Console Redirection

    [Dynamic Time]: Sets a increase minute(s) from current time to wake system from 4.3.5 Serial Port Console Redirection ■ Console Redirection [Disabled] Allow users to enable or disable COM1, COM2, COM3, COM4 console redirection function. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...

  • Page 165: Cpu Configuration

    Enables or disables Intel Virtualization Technology. Virtualization enhanced by Intel Virtualization Technology will allow a platform to run multiple operating systems and applications in independent partitions. With virtualization, one computer system can function as multiple virtual systems. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...

  • Page 166: Network Stack Configuration

    4.3.7 Network Stack Configuration ■ Network Stack [Disabled] Enables or disables UEFI Network Stack. 4.3.8 CSM Configuration This option controls legacy/UEFI ROMs priority. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...
  • Page 167 [UEFI]: Enables UEFI option ROM only. [Legacy]: Enables legacy option ROM only. ■ Other PCI devices [Do not launch] Allows users to determine option ROM execution policy for devise other than network, storage, or video. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...

  • Page 168: Usb Configuration

    Enables or disables XHCI (USB3.0) hand-off function. Use this feature as a workaround for operating systems without XHCI hand-off support. ■ USB Mass Storage Driver Support [Enabled] Enables or disables USB mass storage driver support. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...

  • Page 169: Chipset Setup

    4.4 Chipset Setup This section allows you to configure chipset related settings according to user’s preference. 4.4.1 North Bridge This section provides information on the installed memory size and memory/onboard graphics- related configuration options. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...

  • Page 170: South Bridge

    ■ Amplifier Function [Enabled] Enables or disables Amplifier Function. ■ PSE Enable Selection [Enabled] Enables or disables PSE (Power Sourcing Equipment). ■ LAN1 [Enabled] Enables or disables LAN1 Controller. ■ LAN2 [Enabled] Enables or disables LAN2 Controller. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...

  • Page 171: South Cluster Configuration

    4.4.3 South Cluster Configuration ■ PCI Express Configuration Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...
  • Page 172 Configuration options: [Auto] [Gen1] [Gen2]. ■ SATA Devices SATA Port 0  Port 0 [Enabled] Enables or disables SATA Port 0. SATA Port 1  Port 1 [Enabled] Enables or disables SATA Port 1. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...
  • Page 173 [Last state]: Enters to the last power state before a power failure sables.  Wake On Lan [Enabled] Enables or disables Wake On LAN (WOL) function.  BIOS Lock [Disabled] Enables or disables BIOS the SC BIOS Lock enable feature. It is required to be enabled to  ensure SMM protection of flash. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...

  • Page 174: Security Setup

    Allows you to set Administrator Password to control access to the BIOS Setup utility. ■ User Password Allows you to set User Password to control access to the system at boot and to the BIOS Setup utility. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...

  • Page 175: Boot Setup

    Allows you to enable or disable Fast Boot function. If enabled, system boots with initialization of a minimal set of devices required to launch active boot option. ■ Hard Drive BBS Priority Allows you to set the order of the legacy devices in this group. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...

  • Page 176: Save & Exit

    This item allows you to save the changes done so far as user defaults. ■ Restore User Defaults This item allows you to restore the user defaults to all the setup options. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...

  • Page 177: Chapter 5 Product Application

    Chapter 5 Product Application Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...

  • Page 178: Digital I/O (Dio) Application

    To disable configuration, write exit entry key 0xAA to the index port. Following is an example to enable configuration and to disable configuration by using debug. -o 4e 87 -o 4e 87 (enable configuration) -o 4e aa (disable configuration) Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...
  • Page 179 5.1.1.3 Relative Registers To program the F81866A configuration registers, see the following configuration procedures. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...
  • Page 180 //Set (bit 4~7) = 0 to select GP 74~77 as Input mode <input Value> WriteByte(AddrPort, 0x82) // Select configuration register 82h ReadByte(DataPort, Value) // Read bit 4~7(0xFx)= GP74 ~77 as High <Leave the Extended Function Mode> WriteByte(AddrPort, 0xAA) Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...
  • Page 181 //Set (bit 0~3) = 1 to select GP 80 ~83 as Output mode <Output Value> WriteByte(AddrPort, 0x89) // Select configuration register 89h WriteByte(DataPort, Value) // Set bit 0~3=(0/1) to output GP 80~83 as Low or High <Leave the Extended Function Mode> WriteByte(AddrPort, 0xAA) Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...
  • Page 182 7 6 5 4 3 2 1 0 = DO4 = DI4 ‐ ‐ ‐ ‐ 1 0 0 0 value 1 0 0 0 ‐ ‐ ‐ ‐ value (Base Address +2) (Base Address +3) (0xA02) (0xA03) Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...

  • Page 183: Digital I/O (Dio) Hardware Specification

    - DO Signal have to pull up resistor to XCOM+ for external device, the resistance will affect the pull up current - Signal High Level : Pull up resistor to XCOM+ - Signal Low Level : = XCOM- - Sink Current: 1A (Max) Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...
  • Page 184 DIO1: Digital Input / Output Connector Connector Type: Terminal Block 1X10 10-pin, 3.5mm pitch Definition Definition XCOM+ XCOM- Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...

  • Page 185: Chapter 6 Optional Module Pin Definitions And Settings

    Chapter 6 Optional Module Pin Definitions and Settings Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...

  • Page 186: Location Of The Connectors And Switches

    CFM Module with PoE Control Function, Individual Port 25.5W 6.2 Installing a CFM‐IGN Power Ignition Module 1. Locate the IGN connector on system motherboard as indicated. 2. Insert CFM-IGN module vertically to the female connector on the system’s mainboard, and fasten 2 screws to fix it. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...
  • Page 187 0 second 1 minute 5 minutes 10 minutes 30 minutes 1 hour 2 hours Reserved (0 second) 24V_12V_1: 12V / 24V Car Battery Switch Definition 24V Car Battery Input 12V Car Battery Input Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...

  • Page 188: Installing A Cfm-Poe Control Module

    1. Locate the PoE connector on system motherboard as indicated. 2. Insert the female connector of CFM-PoE module to the male connector on system motherboard. 3. Turn over the heatsink and paste the thermal pad onto the marked by red squares. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...
  • Page 189 4. Paste the heatsink onto the CFM-PoE module carefully and fasten 2 screws to fix it. 5. Paste the thermal pads onto the heatsink and coil carefully. Spectra GmbH & Co. KG User Manual ‐ Spectra PowerTwin P  Version 1.0 vertrieb@spectra.de Apollo Lake + standard Displays September 2018...
  • Page 190 Spectra GmbH & Co. KG Spectra GmbH & Co. KG Spectra (Schweiz) AG Mahdenstr. 3 Gewerbepark Ost 1 Flugplatzstr. 5 72768 Reutlingen 4621 Sipbachzell (Wels) 8404 Winterthur Germany Austria Switzerland Phone Phone Phone +49 (0) 7121 1432-10 +43 (0) 7240 20190...

This manual is also suitable for:

Powertwin ps15-e3950c9Powertwin psh10-e3950co9Powertwin ps12-e3950c9Powertwin ps12-e3950co9Powertwin ps15-e3950co9Powertwin ps17-e3950co9 ... Show all

Table of Contents
