- Page 1 LED TV LF58** www.lg.com ENERGY AV MODE INPUT SAVING FLASHBK LIST MARK MUTE MENU INFO Q.MENU ENTER BACK EXIT L/R SELECT FREEZE RATIO (M4 X L20) P/No: MFL68887802 (1502-REV00) Printed in Korea...
- Page 2 English User Guide Français Guide de l'utilisateur Português Manual do Utilizador...
- Page 5 H/P OUT ANTENNA / CABLE IN VIDEO AUDIO MONO VIDEO AUDIO...
- Page 6 ENERGY AV MODE INPUT SAVING FLASHBK LIST MARK MUTE MENU INFO Q.MENU ENTER BACK EXIT L/R SELECT FREEZE RATIO...
- Page 7 32LF581B-TF 32LF581D-TF (mm) 732 x 481 x 207 732 x 437 x 55.5 (mm) (kg) ) (kg)
- Page 9 OWNER’S MANUAL Safety and Reference LED TV* * Disclaimer LG LED TV applies LCD screen with LED backlights. Please read this manual carefully before operating your set and retain it for future reference. www.lg.com *MFL68662412* P/NO : MFL68662412 (1505-REV01) Printed in Korea...
- Page 10 India region only. ATTENTION: This product is qualified for the BEE Star rating in the ‘Home’ Mode. The Objectives of Star Labeling Program is designed to promote energy efficient products and practices. When the television is initially set up, it is designed to meet the BEE Star Labeling requirements while maintaining optimum picture quality. • ...
-
Page 11: Safety Instructions
Safety instructions Please read these safety precautions carefully before using the product. WARNING Make sure to connect Mains cable to compliant AC mains socket with Grounded earth pin. (Except for devices which are not grounded on earth.) Otherwise possibility you may be electrocuted or injured. Do not place the TV and/or remote control in the following environments: • ... - Page 12 Do not drop the product or let it fall over when connecting external Do not drop metallic objects such as coins, hair pins, chopsticks or wire devices. Otherwise, this may result in injury or damage to the product. into the product, or inflammable objects such as paper and matches. Children must pay particular attention.
- Page 13 Only use the attachments / accessories specified by the manufacturer. Only use an authorized AC adapter and power cord approved by LG Electronics. Otherwise, this may result in fire, electric shock, malfunction or product deformation. When installing the antenna, consult with a qualified service technician.
- Page 14 We recommend that you maintain a distance of at least 2 to 7 times Do not turn the product On/Off by plugging-in or unplugging the power the diagonal screen size when watching TV. If you watch TV for a long plug to the wall outlet.
- Page 15 Do not press strongly upon the panel with a hand or sharp object such When moving or unpacking the product, work in pairs because the as nail, pencil or pen, or make a scratch on it, as it may cause damage product is heavy.
- Page 16 Preparing NOTE • Image shown may differ from your TV. • Your TV’s OSD (On Screen Display) may differ slightly from that You may find different brightness and color of the panel depending on shown in this manual. your viewing position(left/right/top/down). • ...
-
Page 17: Separate Purchase
Magic Remote Wi-Fi/Bluetooth Dongle LG Audio Device * You can use the Magic Remote and LG Audio Device(Wireless) only • Hold the top and bottom of the TV frame firmly. Make sure not to when you are using the Wi-Fi/Bluetooth Dongle. -
Page 18: Using The Joystick Button
Using the joystick button Mounting on a table (Image shown may differ from your TV.) (Image shown may differ from your TV.) You can simply operate the TV functions, pressing or moving the joystick 1 Lift and tilt the TV into its upright position on a table. button up, down, left or right. -
Page 19: Mounting On A Wall
We recommend the use • Use the screws and wall mounts that meet the VESA standard. Any of LG’s wall mount bracket. LG’s wall mount bracket is easy to move with damages or injuries by misuse or using an improper accessory are cables connected. -
Page 20: Connections (Notifications)
Connections (notifications) Remote control Connect various external devices to the TV and switch input modes to (Depending on model) select an external device. For more information of external device’s The descriptions in this manual are based on the buttons on the remote connection, refer to the manual provided with each device. -
Page 21: Open Source Software Notice Information
Clears on-screen displays and returns to TV viewing. LG Electronics will also provide open source code to you on CD-ROM Coloured buttons These access special functions in some menus. for a charge covering the cost of performing such distribution (such... -
Page 22: Troubleshooting
Troubleshooting Operating Temperature 0 °C to 40 °C Operating Humidity Less than 80 % Environment Cannot control the TV with the remote control. condition Storage Temperature -20 °C to 60 °C • Check the remote control sensor on the product and try again. Storage Humidity Less than 85 % • ... -
Page 23: Environmental Information
5. To locate a nearest collection centre or call for pick-up (limited area only) for disposal of this appliance, please contact Toll Free No. 1800-180-9999 for details. All collection centre and pick up facilities are done by third parties whith LG Electronics India Pvt. Ltd. merely as a facilitator. For more... - Page 24 (Only DTV) Record the model number and serial number of the TV. Refer to the label on the back cover and quote this information to your dealer when requiring any service. MODEL SERIAL...
-
Page 25: External Control Device Setup
OWNER’S MANUAL EXTERNAL CONTROL DEVICE SETUP Please read this manual carefully before operating the set and retain it for future reference. www.lg.com... -
Page 26: Key Codes
KEY CODES kEy CODES • This feature is not available for all models. Code Code Function Note Function Note (Hexa) (Hexa) CH +, PR + R/C Button List R/C Button CH -, PR - R/C Button Exit R/C Button Volume + R/C Button PIP(AD) R/C Button... - Page 27 (TV) (PC) • LGTV supports PL2303 chip-based (Vendor ID : 0x0557, Product ID : 0x2008) USB to serial converter RS-232C IN which is not made nor provided by LG. (CONTROL & SERVICE) (PC) (TV) • It can be purchased from computer stores that carry accessories for IT support professionals.
- Page 28 EXTERNAL CONTROL DEVICE SETUP (TV) (PC) (TV) (PC) Phone jack Type RS-232C IN • You need to purchase the phone-jack to RS-232 cable required for the connection between the PC and (CONTROL & SERVICE) (PC) (TV) the TV, which is specified in the manual. RS-232C IN (CONTROL &...
- Page 29 EXTERNAL CONTROL DEVICE SETUP Communication Parameters • Baud rate : 9600 bps (UART) • Stop bit : 1 bit • Data length : 8 bits • Communication code : ASCII code • Parity : None • Use a crossed (reverse) cable. Command reference list (Depending on model) DATA...
- Page 30 EXTERNAL CONTROL DEVICE SETUP Transmission / Receiving Protocol Transmission [Command1][Command2][ ][Set ID][ ][Data][Cr] [Command 1] : First command to control the TV. (j, k, m or x) [Command 2] : Second command to control the TV. [Set ID] : You can adjust the [Set ID] to choose desired monitor ID number in option menu. Adjustment range in TV is 1 to 99.
- Page 31 EXTERNAL CONTROL DEVICE SETUP * Commands may work differently depending on model and signal. 01. Power (Command: k a) Ack [d][ ][Set ID][ ][OK/NG][Data][x] ► To control Power *On or Off of the set. * In case of video mute on only, TV will display On Transmission[k][a][ ][Set ID][ ][Data][Cr] Screen Display(OSD).
- Page 32 EXTERNAL CONTROL DEVICE SETUP Data Min : 00 to Max : 64 * (Depending on model) Ack [i][ ][Set ID][ ][OK/NG][Data][x] 14. Bass (Command: k s) 09. Tint (Command: k j) ► To adjust Bass. ► To adjust the screen tint. You can also adjust in the AUDIO menu.
- Page 33 EXTERNAL CONTROL DEVICE SETUP Set ID = All = 00 5th Band 20(decimal) Data 00 & 01 = Channel Data is 10 = 00 0a Acknowledgement [v][ ][Set ID][ ][OK/NG][Data][x] Data 02 = Analog Antenna TV = 00 Result = ma 00 00 0a 00 * It depends on model, and can adjust when sound mode is EQ adjustable value.
- Page 34 EXTERNAL CONTROL DEVICE SETUP Number Data 05 = Digital Antenna TV = 02 - 22 : Antenna TV (DTV) – Don’t Use Physical Total = ma 00 00 00 11 00 01 02 Channel Number - 26 : Cable TV (CADTV) - Don’t Use Physical 2.
- Page 35 11 11 EXTERNAL CONTROL DEVICE SETUP 24. Input select (Command: x b) (Main Picture Input) ► To select input source for main picture. Transmission [x][b][ ][Set ID][ ][Data][Cr] Data X : don’t care 00 : DTV 01 : CADTV 02 : Satellite DTV 10 : ATV Ack [t][ ][Set ID][ ][OK][Data00][Data01][Data02] ISDB-BS (Japan)
- Page 36 EXTERNAL CONTROL DEVICE SETUP 27. Auto Configure (Command: j u) (Depending on model) ► To adjust picture position and minimize image shaking automatically. It works only in RGB (PC) mode. Transmission [j][u][ ][Set ID][ ][Data][Cr] Data 01 : To set Ack [u][ ][Set ID][ ][OK/NG][Data][x]...
