Multi-language preinstalled hard disk unit (13 pages)
Summary of Contents for Digital Electronics PS-3650A Series
Page 1
HDD drive with Microsoft corporation's preinstalled Windows XP operating system, as well as other driver and utility software. These items are used when operating Pro-face's Compact Panel Computer PS-3650A Series unit, hereafter referred to collectively as the "PS-A". Corresponding models: PS3650A-T41, PS3651A-T41 The following trade names are registered trademarks of the following companies.
Page 2
- Restricted Functionality. You are licensed to use the SOFTWARE to provide only the limited functionality (specific tasks or processes) for which the DEVICE has been designed and marketed by Digital Electronics Corporation. This license specifically prohibits any other use of the software programs or functions, or inclusion of additional software programs or functions that do not directly support the limited functionality on the DEVICE.
Page 3
- NO WARRANTIES FOR THE SOFTWARE. THE SOFTWARE is provided “AS IS” and with all faults. THE ENTIRE RISK AS TO SATISFACTORY QUALITY, PERFORMANCE, ACCURACY, AND EFFORT (INCLUDING LACK OF NEGLIGENCE) IS WITH YOU. ALSO, THERE IS NO WARRANTY AGAINST INTERFERENCE WITH YOUR ENJOYMENT OF THE SOFTWARE OR AGAINST INFRINGEMENT.
Page 4
SOFTWARE. - Recovery Media. If SOFTWARE is provided by Digital Electronics Corporation on separate media and labeled “Recovery Media” you may use the Recovery Media solely to...
Page 5
SOFTWARE. To be valid, the label must be affixed to the DEVICE, or appear on Digital Electronics Corporation’s software packaging. If you receive the label separately other than from Digital Electronics Corporation, it is invalid. You should keep the label on the DEVICE or packaging to prove that you are licensed to use the SOFTWARE.
Page 6
DMC Corporation Mouse Emulation Software (TSC-1310D/DD) Software License Agreement Before unsealing and using this product, please read the following license agreement carefully: This license agreement regarding the following software product (hereinafter called “product”) is concluded between you the individual or entity licensing the product (hereinafter called (“licensee”) and DMC Co., Ltd.
Page 7
Termination of the right of use (1) The licensee can at any time terminate the right to use the product by expunging or destroying the product and all the copied contents. (2) When a licensee contravenes these license contents, DMC can notify the licensee of termination of the right to use the product.
Page 8
Phone: +81-240-27-4030 Fax: +81-240-27-4025 IN-fINITY soft Keyclick32 Digital Electronics Corporation shall be in no case liable for any loss or damages to you or any third party whatsoever arising from any faulty performance of IN-fINITY soft, nor shall be responsible to correct such error of the software program in question.
Safety Cautions • Be sure to check that the PS-A unit’s power is disconnected before installing the unit, in order to prevent an electrical shock. • Do not attempt to modify or open the HDD unit, since it can cause a shock or fire. •...
Package Contents Please check that the following items are all included in your package. ® Windows XP Multi-Language Recovery DVD (1) Preinstalled HDD unit (1) Attachment Screws (4) Installation Guide (1) (This Guide) Installation Guide Instructions for Using the Hard Disk (1) Symantec Ghost EULA (1) Instructions for...
Hardware Specifications Features Capacity 40GB Average Seek Time 12msec (TYP) At Startup : 5.0W (MAX) Power Consumption Read/Write : 1.8/1.8W (TYP) During Wait : 0.2W(TYP) Interface PATA 5 years, or 20,000 operating hours, Operation Lifetime whichever comes first Weight Approx. 200g •...
Installation Be sure to use the following installation procedures to insure that the HDD unit is correctly installed. The Installation location will differ, depending on the type of PS-A unit you are using. • Shock Danger! Be sure to disconnect the PS-A unit from its power supply prior to installing the HDD unit.
Page 13
(3) Unscrew the screws (4), which are seen on the left figure, and remove the Expansion Board Base. (4) Remove the IDE cover and plug the HDD unit cable connector in the IDE’s interface (Seen the figure on the left). IDE I/F (5) Install the HDD unit like the left figure, and fix it with the screws (4)
When attaching the HDD to the PS-3651A (1) Turn off the power switch of the PS-A unit, remove the power cable. Put the PS-A on the horizontal place while the display side of it is downside. (2) Unscrew the screws (3) of the IDE cover and remove the IDE cover.
Page 15
• The following explanation uses the PS-A unit's factory settings. (1) Install the HDD unit in the PS-A. 2 Installation (If the HDD unit is already installed, this step is not necessary.) (2) Connect a keyboard to the PS-A. (3) Right after turn the PS-A unit’s power ON, keep on pressing [F2] key. The Setup utility will start.
Page 16
OS Setup Software Included ® Your Windows XP Multi-Language preinstalled hard disk unit contains the following software. ® • Microsoft corporation's Windows XP Professional for Embedded OS • DMC Corporation's Mouse Emulation Software (TSC-1310D/DD) • IN-fINITY soft's Keyboard Emulator KeyClick32 •...
Page 17
(9) The [Who will use this computer?] will appear. Up to 5 names can be entered for a user's name. After entering the user's name, click [Next] to continue. (10) The [Thank you!] screen will appear. Click [Finish] to complete the setting. (11) The [Setting] dialog box will appear and initial setting will be automatically made.
Page 18
HDD Recovery Procedure • After performing hard disk recovery, the PS-A unit’s hard disk is returned to its factory shipped condition. • For recovery, USB DVD-ROM drive on the market and USB keyboard are required. ® Use the following steps used to recover the Windows XP Multi-Language Preinstalled Hard Disk.
Page 19
HDD unit data to either floppy disks, or other type of suitable magnetic media is strongly recommended. Note Please be aware that Digital Electronics Corporation shall not be held liable by the user for any damages, losses, or third party claims arising from the uses of this product.
