PS-2000B Series Windows
Multi Language Preinstalled
The PS-2000B Series Windows
is a set that includes the HDD drive with Microsoft corporation's preinstalled
®
Windows
XP operating system, as well as other driver and utility software used
when operating Pro-face's PS-2000B Series computers, hereafter referred to col-
lectively as the "PS-B".
Corresponding models: PS-2000B Series units
The following trade names are registered trademarks of the following companies.
®
Pro-face
: Digital Electronics Corporation (in Japan and other countries)
®
Windows
XP: Microsoft
Symantec Ghost
IMPORTANT - Read Prior to Opening and Operating
This HDD unit contains a preinstalled version of Windows
Be sure to read and agree with all conditions stated herein prior to using this
product. If you do not agree to all the conditions stated in this agreement,
please return the entire product.
COA Data
* This Installation Guide is an important part of this product. Be sure to keep it in an easy to
find location.
Hard Disk Unit
Installation Guide
®
XP Multi Language Preinstalled Hard Disk Unit
®
Corporation
TM
Symantec Corporation
:
-1-
®
XP
®
XP Professional.
Advertisement
Table of Contents
Related Manuals for Digital Electronics PS-2000B Series
Summary of Contents for Digital Electronics PS-2000B Series
- Page 1 ® Windows XP operating system, as well as other driver and utility software used when operating Pro-face's PS-2000B Series computers, hereafter referred to col- lectively as the "PS-B". Corresponding models: PS-2000B Series units The following trade names are registered trademarks of the following companies.
- Page 2 Processor Limit. You may use the software with no more than two (2) processors at any one time. 2. ADDITIONAL LICENSING REQUIREMENTS AND/OR USE RIGHTS. a. Specific Use. Digital Electronics Corporation designed this device for a specific use. You may only use the software for that use.
- Page 3 For more information, see the software documentation or contact Digital Electronics Corporation. Except and only to the extent permitted by applicable law despite these limitations, you may not: • work around any technical limitations in the software; • reverse engineer, decompile or disassemble the software;...
- Page 4 If you have questions about the MPEG-4 visual standard, please contact MPEG LA, L.L.C., 250 Steele Street, Suite 300, Denver, CO 80206; www.mpegla.com. 4. PRODUCT SUPPORT. Contact Digital Electronics Corporation for support options. Refer to the support number provided with the device.
-
Page 5: Safety Cautions
Safety Cautions WARNINGS WARNINGS • Be sure to check that the PS-B’s power is disconnected be- fore installing the unit, in order to prevent an electrical shock. • Do not attempt to modify or open the HDD unit, since it can cause a shock or fire. -
Page 6: Package Contents
Package Contents Please check that the following items are all included in your package. ® Windows XP Multi Language Recovery CD (6) Preinstalled HDD unit Symantec Ghost EULA (1) Attachment Screws (4) Installation Guide (this guide) Pro-face has taken the utmost care to ensure the quality of this product when it was shipped, however, should, for any reason, problems or damage have oc- curred during shipping, please contact your Pro-face representative immediately for service. - Page 7 Environment Operating Temperature C to 50 Storage Temperature C to +60 10%RH to 85%RH (no condensation) Ambient Humidity Wet bulb temperature: 29 C or less Noise Resistance Noise Voltage: 1500Vp-p Pulse Width: 50ns, 500ns, 1 µ s (via Noise Simulator) Electrostatic Discharge Immunity Vibration Resistance 4.9m/s...
-
Page 8: Installation
Installation Use the following steps to install the HDD unit in the PS-B. WARNINGS WARNING Shock Danger! Be sure to unplug the PS-B unit from its power supply prior to installing the HDD unit. Since the HDD unit is a precision instrument that has a low resis- tance to shocks, be sure it is neither hit by nor pressed strongly against another object when installing it. - Page 9 You can also remove only the maintenance cover and install the HDD unit. To do this, please perform the following steps. Cover 1) Loosen the two (2) maintenance cover attachment screws. Screws 2) Tilt the maintenance cover up as shown by arrow a and lift it out in the direction shown by arrow b (see diagram).
- Page 10 IDE I/F 1 3) Insert the HDD unit's cable connector completely into IDE I/F 1. Front of PS-B unit 4) Attach the HDD unit using the four (4) attachment screws. (See diagram) The torque should be 0.5 to 0.6 N•m. 5) Replace the PS-B unit's cover and reattach all four (4) attachment screws.
-
Page 11: Hardware Setup
Hardware Setup The HDD unit's installation and system data settings are as follows. 1) Install the HDD unit in the PS-B. Refer to 2 Installation for details. If the HDD unit is already installed, this step is not necessary. 2) Connect a Display and PS/2 keyboard to the PS-B. •... - Page 12 OS Setup Software Included ® Your Windows XP Multi Language preinstalled hard disk unit contains the following software. ® • Microsoft corporation's Windows XP Professional for Embedded OS • Pro-face's PS-B utility software and drivers ® Windows XP Setup Procedure ®...
- Page 13 After entering the user's name, click [Next] to continue. 10)The [Thank you!] screen will appear. Click [Finish] to complete the setting. As for how to change BIOS Setting, refer to the PS-2000B Series ® User Manual. After changing the BIOS, restart the Windows make the setting following the instructions shown on the screen.
- Page 14 HDD Recovery Procedure • After performing hard disk recovery, the PS-B unit’s hard disk is returned to its factory shipped condition. • For recovery, the following things are required; The PS-B unit, HDD to be recovered, a CD-ROM drive (PSB-CD/FD01 or a commercial USB-type CD-ROM drive), and a PS/2 keyboard.
- Page 15 9. After the recovery operation finishes, Symantec Ghost finishes and the following message will appear. After the message appears, turn off the power supply of the unit. "Please turn off the computer." 10. After turning on the power supply once again, push the [F2] key to go to the BIOS Setup Screen.
- Page 16 Note Please be aware that Digital Electronics Corporation shall not be held liable by the user for any damages, losses, or third party claims arising from the uses of this product. Digital Electronics Corporation 8-2-52 Nanko Higashi, Suminoe-ku, Osaka 559-0031, Japan URL: http://www.pro-face.com/...
