- Page 1 ANI-9251RX HDCP 2.2 & HDMI 2.0 Extender with OAR / Audio Insertion For use with the ANI-1082UHD A-NeuVideo.com Frisco, Texas 75034 (469) 277-7606 AUDIO / VIDEO MANUFACTURER...
- Page 2 SAFETY INFORMATION To ensure the best results from this product, please read this manual and all other documentation before operating your equipment. Retain all documentation for future reference. Follow all instructions printed on unit chassis for proper operation. To reduce the risk of fire, do not spill water or other liquids into or on the unit, or operate the unit while standing in liquid. Make sure power outlets conform to the power requirements listed on the back of the unit.
-
Page 3: Table Of Contents
NEUVIDEO TABLE OF CONTENTS CONTENTS INTRODUCTION & CONTENTS ...........1 SAFETY PRECAUTIONS FEATURES ..................2 Please read all instructions before attempting to unpack, install or SPECIFICATIONS .................3 operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this OPERATION CONTROLS &... -
Page 4: Features
NEUVIDEO FEATURES FEATURES • HDCP 1.4/HDCP 2.2 and HDMI 2.0 compliant • HDMI with 3D, 4K2K@60Hz support and DVI Compliant • 6G HDMI video (3840x2160 YUV444) input is supported • Simultaneous transmission of uncompressed data over a single CAT5e/6/7 cable up to 328ft/100M at 1080p and 230ft/70M at 4K2K@60Hz •... -
Page 5: Specifications
NEUVIDEO SPECIFICATIONS Specifications • Input Ports: • CAT5e/6/7 (RJ45) PoH • IR In • Optical In • Output Ports: • HDMI • IR Out 2 • Other Ports: • LAN (RJ45) • RS-232 (Phoenix Connector) • Update slide switch • Video Bandwidth: 340MHz / 10.2Gbps • HDMI Resolutions: •... -
Page 6: Operation Controls & Functions
NEUVIDEO Operation controls & Functions Front Panel POWER LED: This power LED will illuminate when receiving power from the transmitter. OPTICAL IN: Connects with an optical audio source as an optical audio return which sends audio to the Transmitter. IR IN 1: IR IN 1 is considered an IR receiver which connects to the supplied IR Receiver cables for IR signal reception. -
Page 7: Definitions & Ir Pin Assignment
NEUVIDEO Definitions / IR CABLE D-Sub 9 Pin Definitions DEFINE TX / RX DEFINE TX / RX DEFINE TX / RX TxD / RxD RxD / TxD CAT5e/6/7 Cable Specification CABLE TYPE RANGE PIXEL CLOCK RATE VIDEO DATA RATE SUPPORTED VIDEO FORMATS CAT5e/6/7 328ft (100M) ≤225MHz... -
Page 8: Connection & Installation
NEUVIDEO CONNECTION AND INSTALLATION CONNECTION AND INSTALLATION... - Page 9 THIS PAGE IS INTENTIONALLY LEFT BLANK.
- Page 10 THIS PAGE IS INTENTIONALLY LEFT BLANK.
- Page 11 THIS PAGE IS INTENTIONALLY LEFT BLANK.
- Page 12 BY, THROUGH OR UNDER A-NeuVideo, INC (COLLECTIVELY, THE “PRODUCT”). By using installing or using the Product, you unconditionally signify your agreement to these Terms and Conditions. If you do not agree to these Terms and Conditions, do not use the Product and return the Product to A-NeuVideo, Inc. at the return address set forth on the Product’s packing label at your expense.
