VG3448
Display
User Guide
IMPORTANT: Please read this User Guide to obtain important information on installing and using your product in
a safe manner, as well as registering your product for future service. Warranty information contained in this User
Guide will describe your limited coverage from ViewSonic® Corporation, which is also found on our web site at
http://www.viewsonic.com in English, or in specific languages using the Regional selection box in the upper right
corner of our website. "Antes de operar su equipo lea cu idadosamente las instrucciones en este manual"
Model No. VS17740
P/N: VG3448

Advertisement

Table of Contents
loading

Related Manuals for ViewSonic VG3448

Summary of Contents for ViewSonic VG3448

  • Page 1 Warranty information contained in this User Guide will describe your limited coverage from ViewSonic® Corporation, which is also found on our web site at http://www.viewsonic.com in English, or in specific languages using the Regional selection box in the upper right corner of our website.
  • Page 2 As a world-leading provider of visual solutions, ViewSonic® is dedicated to exceeding the world’s expectations for technological evolution, innovation, and simplicity. At ViewSonic®, we believe that our products have the potential to make a positive impact in the world, and we are confident that the ViewSonic® product you have chosen will serve you well.

  • Page 3: Safety Precautions

    Do not place any heavy objects on the device or connection cables. • If smoke, an abnormal noise, or a strange odor is present, immediately turn the device off and call your dealer or ViewSonic®. It is dangerous to continue using the device. •...
  • Page 4 • When connecting to a power outlet, DO NOT remove the grounding prong. Please ensure grounding prongs are NEVER REMOVED. • Protect the power cord from being treaded upon or pinched, particularly at the plug, and at the point where it emerges from the equipment.

  • Page 5: Table Of Contents

    Contents Safety Precautions ............3 Introduction ..............7 Package Contents ....................7 Product Overview ....................8 Initial Setup ..............9 Installing the Stand ....................9 Wall Mounting ......................12 Using the Security Slot ..................14 Making Connections ..........15 Connecting to Power ....................15 Connecting External Devices ................16 HDMI Connection ....................
  • Page 6 Appendix ..............45 Specifications ......................45 Glossary ........................47 Troubleshooting ....................52 Maintenance......................54 General Precautions ....................54 Cleaning the Screen ....................54 Cleaning the Case ....................54 Regulatory and Service Information ......55 Compliance Information ..................55 FCC Compliance Statement ................... 55 Industry Canada Statement ................... 55 CE Conformity for European Countries ..............

  • Page 7: Introduction

    Introduction Package Contents • Monitor • Power cord • Video cable • USB cable • Quick start guide NOTE: The power cord and video cables included in your package may vary depending on your country. Please contact your local reseller for more information.

  • Page 8: Product Overview

    Product Overview Front View Display screen Power button (ViewMode) NOTE: For more information about the 1 (ViewMode)/2/3/4/5 key and its functions, refer to “Hot Keys” on page 25. Rear View USB Downstream Security Slot USB Downstream DisplayPort USB Upstream AC IN jack HDMI ports miniDP port...

  • Page 9: Initial Setup

    Initial Setup This section provides detailed instructions for setting up your monitor. NOTE: The monitor comes packaged in a user friendly box to make installation easy. Installing the Stand 1. Place the box on a flat, stable surface and open the front flap of the box to reveal the contents.
  • Page 10 4. Align and slide the upper hooks of the monitor stand into the stand mounting slots as shown in the illustration below: NOTE: Ensure the stand is secure and the quick release tab positively clicks into place.
  • Page 11 5. Using the stand’s handle, lift the device out of the box and into its upright position on a flat, stable surface. NOTE: Always place the device on a flat, stable surface. Failure to do so may cause the device to fall and damage the device and/or result in personal injury.

  • Page 12: Wall Mounting

    Wall Mounting Refer to the table below for the standard dimensions for wall mount kits. Maximum Hole pattern Interface Pad Screw Specification Loading (W x H) (W x H x D) Hole & Quantity M4 x 10 mm 14 kg 100 x 100 mm 115 x 115 x 2.6 mm Ø...
  • Page 13 5. Attach the mounting bracket to the VESA mounting holes at the rear of the device. Then secure it with four (4) screws (M4 x 10 mm). 100 mm 6. Follow the instructions that come with the wall mounting kit to mount the monitor onto the wall.

  • Page 14: Using The Security Slot

    Using the Security Slot To help prevent the device from being stolen, use a security slot locking device to secure the device to a fixed object. Below is an example of setting up a security slot locking device on a table.

  • Page 15: Making Connections

    Making Connections This section guides you on how to connect the monitor with other equipment. Connecting to Power 1. Connect the power cord to the AC IN jack at the rear of the device. 2. Connect the power cord plug to a power outlet.

  • Page 16: Connecting External Devices

    Connecting Txternal Devices HDMI Connection Connect one end of an HDMI cable to the HDMI port of your monitor. Then connect the other end of the cable to the HDMI port of your computer. NOTE: The monitor is equipped with two HDMI 1.4 ports.

  • Page 17: Displayport And Minidp Connection

    DisplayPort and miniDP Connection Connect one end of a DisplayPort cable to the DisplayPort or miniDP port. Then connect the other end of the cable to the DisplayPort or miniDP port of your computer. NOTE: To connect the monitor to the Thunderbolt port (v. 1&2) on you Mac, connect the miniDP end of the “miniDP to DisplayPort cable”...

  • Page 18: Usb Connection

    USB Connection Connect one end of a USB cable to a USB port of the monitor. Then connect the other end of the cable to a USB port of your computer. NOTE: The monitor supports two (2) types of USB ports. When making the connection(s), observe the following guidelines: •...

  • Page 19: Using The Monitor

    Using the Monitor Adjusting the Viewing Angle For optimal viewing, you can adjust the viewing angle using any of the following methods: Height Adjustment Lower or raise the monitor to the desired height (0 to 130 mm). NOTE: When adjusting, press down firmly along the adjustment track.

  • Page 20: Tilt Angle Adjustment

    Tilt Angle Adjustment Tilt the monitor forwards or backwards to the desired viewing angle (-5° to 40°). NOTE: • When adjusting, support the stand firmly with one hand while tilting the monitor forwards or backwards with the other hand. • The monitor must be lifted to the highest position, then it can support 40°...

  • Page 21: Swivel Angle Adjustment

    Swivel Angle Adjustment Swivel the monitor to the left or right for the desired viewing angle (60°).

  • Page 22: Turning The Device On/Off

    Ourning the Device Nn/Nff 1. Plug the power cord into a power outlet. 2. Press the Power button to turn on the device. 3. To turn the device off, press the Power button again. NOTE: The device will still consume some power as long as the power cord is connected to the power outlet.

  • Page 23: Using The Control Panel Keys

    Using the Control Panel Keys Use the control panel keys to access the Quick Menu, activate Hot Keys, navigate the On-Screen Display (OSD) Menu, and change the settings. (ViewMode) Quick Menu Press the 2/3/4/5 key to activate the Quick Menu. Viewmode Contrast/Brightness Input Select...
  • Page 24 Select Menu Input Select Select the input source. HDMI 1 HDMI 2 DisplayPort miniDP Main Menu Enter the On-Screen Display (OSD) Menu. VG3448 Input Audio Adjust ViewMode Color Adjust Manual Image Setup Menu Select Adjust HDMI 1 HDMI 2...

  • Page 25: Hot Keys

    Hot Keys Hot Keys When the On-Screen Display (OSD) Menu is off, you can quickly access special functions by using the control panel keys. When the OSD menu is off, you can quickly access special func�ons by using the control panel keys. Hot Keys NOTE: Some func�ons involve a combina�on of two keys.
  • Page 26 OSD Locked OSD Locked Description 2 + 4 Press and hold the keys to lock/unlock the Power button. 1 + 3 Press the keys to unlock/lock the Power bu�on. When the menu appears on the screen, continue holding both keys When the menu appears on the screen, press and hold both keys for 10 seconds to for 10 seconds to lock/unlock the Power button.

  • Page 27: Configuring The Settings

    3440 X 1440 @ 60Hz 3440 X 1440 @ 60Hz Key Guide 1. Press the 2/3/4/5 key to activate the Quick Menu. Then press the 4 key to display the OSD Menu. VG3448 Input Audio Adjust ViewMode Color Adjust Manual Image...
  • Page 28 3. Press the 1 (ViewMode) or 2 key to select the desired menu option. Then press the 3 key to enter the sub-menu. VG3448 Input Audio Adjust ViewMode Color Adjust Manual Image Setup Menu Select Adjust Volume Mute 3440 X 1440 @ 60Hz 4.
  • Page 29 NOTE: Certain menu option adjustments do not require the user to press the 3 key to confirm the selection. Follow the key guide that appears on the bottom of the screen to select the option or make adjustments. VG3448 VG3448 Input...

  • Page 30: On-Screen Display (Osd) Menu Tree

    On-Screen Display (OSD) Menu Tree Main Menu Sub-menu Menu Nption Input Select HDMI 1 HDMI 2 DisplayPort miniDP Audio Adjust Volume (-/+, 0~100) Mute...
  • Page 31 Main Menu Sub-menu Menu Nption ViewMode Office Text CUSTOM 1/2/3 Low Input Lag Black (-/+, Stabilization 0/10/20/30/40/50/ 60/70/80/90/100) Advanced DCR (-/+, 0/25/50/75/100) Response Standard Time Advanced Ultra Fast (-/+, 0~100) Green (-/+, 0~100) Blue (-/+, 0~100) Cyan (-/+, 0~100) Magenta (-/+, 0~100) Yellow...
  • Page 32 Main Menu Sub-menu Menu Nption ViewMode Movie Mono Game FPS 1 FPS 2 MOBA Color Adjust Contrast/ Contrast (-/+, 0~100) Brightness Brightness (-/+, 0~100) Color Bluish Temperature Cool Native Warm User Color (-/+, 0~100) Green (-/+, 0~100) Blue (-/+, 0~100) Color Space Auto Color Range...
  • Page 33 Main Menu Sub-menu Menu Nption Manual Auto Image Adjust Image Adjust Horizontal (-/+, 0~100) Size H./V. Position Horizontal Position (-/+, 0~100) Vertical Position (-/+, 0~100) Fine Tune (-/+, 0~100) Sharpness (-/+, 0~100) Aspect Ratio 16:9 Full Screen...
  • Page 34 Main Menu Sub-menu Menu Nption Manual Overscan Image Adjust Blue Light (-/+, 0~100) Filter Setup Menu Language English Français Deutsch Español Italiano Suomi Русский Türkçe 日本語 한국어 繁體中文 简体中文 Česká Svenska Resolution Notice Information OSD Timeout (-/+, 5/15/30/60) Background Power Indicator Auto Power...
  • Page 35 Main Menu Sub-menu Menu Nption Setup Menu Sleep 30 Minutes 45 Minutes 60 Minutes 120 Minutes ECO Mode Standard Optimize Conserve DisplayPort DDC/CI Auto Detect USB Hub On, while power saving Off, while power saving All Recall...

  • Page 36: Menu Options

    1. Press the 2/3/4/5 key to activate the Quick Menu. Then press the 4 key to display the OSD Menu. 2. Press the 1 (ViewMode) or 2 key to select Input Select. Then press the 3 key to enter the Input Select menu. VG3448 Input Audio Adjust ViewMode...
  • Page 37 1. Press the 2/3/4/5 key to activate the Quick Menu. Then press the 4 key to display the OSD Menu. 2. Press the 1 (ViewMode) or 2 key to select Audio Adjust. Then press the 3 key to enter the Audio Adjust menu. VG3448 ViewMode Color Adjust Manual Image...
  • Page 38 1. Press the 2/3/4/5 key to activate the Quick Menu. Then press the 4 key to display the OSD Menu. 2. Press the 1 (ViewMode) or 2 key to select ViewMode. Then press the 3 key to enter the ViewMode menu. VG3448 Input Audio Adjust ViewMode...
  • Page 39 1. Press the 2/3/4/5 key to activate the Quick Menu. Then press the 4 key to display the OSD Menu. 2. Press the 1 (ViewMode) or 2 key to select Color Adjust. Then press the 3 key to enter the Color Adjust menu. VG3448 Input Audio Adjust ViewMode...
  • Page 40 Menu Nption Description Color Temperature Select the color temperature setting. • Bluish: Set the color temperature to 9300K. • Cool: Set the color temperature to 7500K • Native: Default color temperature. Recommended for regular use. • Warm: Set the color temperature to 5000K. •...
  • Page 41 1. Press the 2/3/4/5 key to activate the Quick Menu. Then press the 4 key to display the OSD Menu. 2. Press the 1 (ViewMode) or 2 key to select Manual Image Adjust. Then press the 3 key to enter the Manual Image Adjust menu. VG3448 ViewMode Color Adjust Manual Image...
  • Page 42 1. Press the 2/3/4/5 key to activate the Quick Menu. Then press the 4 key to display the OSD Menu. 2. Press the 1 (ViewMode) or 2 key to select Setup Menu. Then press the 3 key to enter the Setup Menu menu. VG3448 ViewMode Color Adjust Manual Image...
  • Page 43 Menu Nption Description Language Select an available language for the OSD Menu. Resolution Notice Enable this option to allow the system to inform users that the current viewing resolution is not the correct native resolution. Resolution Notice For best picture quality, change resolution to 3440 x 1440 Clear Disable...
  • Page 44 Menu Nption Description DDC/CI Enable this option to allow the monitor control via the graphics card. Auto Detect Automatically detect the input signal. USB Hub Toggle On or Off while power saving. All Recall Resets all settings to their default values.

  • Page 45: Appendix

    Appendix Specifications Item Category Specifications Type TFT, Active Matrix 3440 X 1440 LCD; 0.2325 (H)mm x 0.2325(V)mm pixel pitch Display Size 87 cm, 34" (34” viewable) Color Filter RGB vertical stripe Glass Surface Anti-Glare type, 3H hard coating, Haze 25 Input Signal Video Sync TMDS digital (100 Ω)
  • Page 46 Do not set the graphics card in your computer to exceed these timing modes; doing so may result in permanent damage to the display. Please use the power adapter from ViewSonic® or an authorized source only. Maximum power consumption with max luminance, and USB/Speaker active.

  • Page 47: Glossary

    Auto Image Adjust Automatically adjusts the screen image for an ideal viewing experience. Black Stabilization ViewSonic’s Black stabilization provides heightened visibility and detail by brightening dark scenes. Blue Light Filter Adjusts the filter that blocks high-energy blue light for a more comfortable viewing experience.
  • Page 48 Color Range The monitor can detect the input signal color range automatically. You can manually change the color range options to fit the correct color range if the colors are not displayed correctly. Nptions Description Auto The monitor automatically recognizes the color format and black and white levels.
  • Page 49 Information Displays the timing mode (video signal input) coming from the graphics card in the computer, the LCD model number, the serial number, and the ViewSonic® website URL. See your graphics card’s user guide for instructions on changing the resolution and refresh rate (vertical frequency).
  • Page 50 OSD Pivot Sets the monitor’s On-Screen Display (OSD) Menu display direction. Nptions Description 0° Sets the OSD Menu without pivot. +90° Sets the OSD Menu +90° pivot. -90° Sets the OSD Menu -90° pivot. Overscan Refers to a cropped image on your monitor’s screen. A setting on your monitor zooms in on movie content, so that you cannot see the outermost edges of the film.
  • Page 51 ViewMode ViewSonic®’s unique ViewMode feature offers “Game,” “Movie,” “Web,” “Text,” and “Mono” presets. These presets are specifically designed to deliver an optimized viewing experience for different screen applications. YUV Color Space YUV color space is used for color image and video processing; taking into account properties of the human eye that allow for reduced bandwidth of chroma components without perceptual distortion.

  • Page 52: Troubleshooting

    • Connect the monitor to another computer. • If you have an older graphics card, contact ViewSonic® for a non-DDC adapter. Screen image is too • Adjust brightness and contrast settings via the OSD light or dark Menu.
  • Page 53 Problem or Issue Possible Solutions The screen appears • Make sure the “Blue Light Filter” is Off. yellow The OSD Menu • Check whether the OSD Menu is locked. If yes, does not appear press and hold the 2 and 3 key for 10 seconds. on the screen/the •...

  • Page 54: Maintenance

    • ViewSonic® does not recommend the use of any ammonia or alcohol-based cleaners on the display screen or case. Some chemical cleaners have been reported to damage the screen and/or case of the monitor. • ViewSonic® will not be liable for damage resulting from use of any ammonia or alcohol-based cleaners.

  • Page 55: Regulatory And Service Information

    Regulatory and Service Information Compliance Information This section addresses all connected requirements and statements regarding regulations. Confirmed corresponding applications shall refer to nameplate labels and relevant markings on the unit. FCC Compliance Statement This device complies with part 15 of FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 56: Declaration Of Rohs Compliance

    Ohe following information is only for TU-member statesE The mark shown to the right is in compliance with the Waste Electrical and Electronic Equipment Directive 2012/19/EU (WEEE). The mark indicates the requirement NOT to dispose of the equipment as unsorted municipal waste, but use the return and collection systems according to local law.

  • Page 57: Indian Restriction Of Hazardous Substances

    Schedule 2 of the Rule. Product Disposal at End of Product Life ViewSonic® respects the environment and is committed to working and living green. Thank you for being part of Smarter, Greener Computing. Please visit the ViewSonic®...

  • Page 58: Copyright Information

    ENERGY STAR® is a registered trademark of the U.S. Environmental Protection Agency (EPA). As an ENERGY STAR® partner, ViewSonic® Corporation has determined that this product meets the ENERGY STAR® guidelines for energy efficiency. Disclaimer: ViewSonic® Corporation shall not be liable for technical or editorial errors or omissions contained herein;...

  • Page 59: Customer Service

    For technical support or product service, see the table below or contact your reseller. NOTE: You will need the product’s serial number. Country/ Region Website Country/ Region Website Asia Pacific & Africa Australia www.viewsonic.com/au/ Bangladesh www.viewsonic.com/bd/ www.viewsonic.com.cn www.viewsonic.com/hk/ 中国 (China) 香港 (繁體中文) Hong Kong (English) www.viewsonic.com/hk-en/ India www.viewsonic.com/in/...

  • Page 60: Limited Warranty

    How long the warranty is effectiveE ViewSonic® displays are warranted for between 1 and 3 years, depending on your country of purchase, for all parts including the light source and for all labor from the date of the first consumer purchase.
  • Page 61 (e) the serial number of the product. • Take or ship the product, freight prepaid, in the original container to an authorized ViewSonic® service center or ViewSonic®. • For additional information or the name of the nearest ViewSonic® service center, contact ViewSonic®. Limitation of implied warrantiesE...
  • Page 62 Exclusion of damages: ViewSonic’s liability is limited to the cost of repair or replacement of the product. ViewSonic® shall not be liable for: • Damage to other property caused by any defects in the product, damages based upon inconvenience, loss of use of the product, loss of time, loss of...

  • Page 63: Mexico Limited Warranty

    If a product proves to be defective in material or workmanship during the warranty period, ViewSonic® will, at its sole option, repair or replace the product with a like product. Replacement product or parts may include remanufactured or refurbished parts or components &...
  • Page 64 Exclusion of damages: ViewSonic®’s liability is limited to the cost of repair or replacement of the product. ViewSonic® shall not be liable for: • Damage to other property caused by any defects in the product, damages...
  • Page 65 Name, address, of manufacturer and importers: México, Av. de la Palma #8 Piso 2 Despacho 203, Corporativo Interpalmas, Col. San Fernando Huixquilucan, Estado de México Tel: (55) 3605-1099 http://www.viewsonic.com/la/soporte/index.htm NÚMERO GRATIS DE ASISTENCIA TÉCNICA PARA TODO MÉXICO: 001.866.823.2004 Hermosillo: Villahermosa: Distribuciones y Servicios Computacionales SA de CV.
  • Page 66 C0 M91 Y72 K24 Process Color C0 M0 Y0 K100 Process Color C0 M91 Y72 K24 Process Color Pantone Black C Spot Color Pantone 187 C Spot Color...
