- Page 1 User's Manual Energy Meter with Limiter Model KLW203 mini, midi, strong Software version 1.2 WOZNIAK RC TECH www.wozniakrctech.com form: 2019/02/001#0 Rev. 1.1...
-
Page 2: Table Of Contents
Table of Contents 1.Safety Precautions.....................2 2.Introduction.......................3 3.Specifications......................4 4.Getting started......................5 5.Menu..........................6 6.Limiter........................7 7.Warranty........................7 Copyright © 2019 by Klaudiusz Woźniak Vcc. All rights reserved. No part of this manual may be reproduced or transmitted in any form or by an means, analog, digital, electronic or mechanical, including imaging, photocopying and recording, for any purpose other than the purchaser's personal use without the written permission of Klaudiusz Woźniak Vcc. -
Page 3: Introduction
2. Introduction Energy Meter and Limiter KLW203 was designed for R/C boats with special needs such as high current consumption, water resistance. During production we use potting process, a complete electronic assembly is filled in a vacuum with a solid compound. The device maintains high measurement accuracy even after sinking. -
Page 4: Specifications
3. Specifications General specifications table: Battery voltage: 0 – 45 VDC Supply current: 16 mA Measured energy: 0 - 357 Wh Energy resolution: 0,1 Wh Energy accuracy: +/- 1 % Sampling frequency: 333 Hz Starting current threshold I 0 – 5 A (midi, strong), 0 – 2 A (mini) Ramp time t 0 - 30 s Throttle minimum Th... -
Page 5: Getting Started
4. Getting started 4.1. Making connections The current is measured by BLACK cable, current flow from ESC- to B- cable. ● Connect this cable between battery negative and ESC negative terminal. The voltage is measured by RED B+ cable. Connect this cable to battery positive ●... -
Page 6: Menu
5. Menu Push button Hold button Software version Last result Energy[Wh] Energy [Wh] Energy reset Energy limit[Wh] MODE/+ Voltage [V] Maximum current Current [A] reset Maximum current [A] MODE/+ Energy limit[Wh] Set energy limit MODE/+ no. 1 Choose energy limit MODE/+ Set energy limit MODE/+... -
Page 7: Limiter
6. Limiter Limiter counts energy when current is greater than set in Starting current threshold, so you can skip energy counting while the model is being prepared for start. Limiter after reach the programmed limit of energy reduce the throttle demand to the ESC. The parameters of the reduction are programmable. -
Page 8: Warranty
7. Warranty This device is covered by a 24-month manufacturer's warranty. At the time of any problems with proper functioning, first contact the store where the product was purchased, showing the purchase receipt, accurately describing the symptoms noted. The defects discovered during the guarantee period will be free of charge removed within 14 working days from the date of delivery to the manufacturer and the warranty period is extended by the repair duration.
