FujiFilm Finepix F810 Brochure & Specs

F U N C T I O N S
Viewfinder Window
AF Assist Illuminator
Self-timer Lamp
Shutter Button
Flash Control Sensor
DC IN 5V (Power Input)
Lens/Lens Cover
USB Socket/Cradle
Battery Cover/
Battery Compartment/ Connection/A/V OUT
xD-Picture Card™ Slot (Audio Visual Output)
S P E C I F I C A T I O N S
DIGITAL CAMERA FinePix F810
Number of effective pixels* 6.3 million pixels
CCD sensor 1/1.7-inch Super CCD HR
[Number of total pixels: 6.63 million pixels]
Number of recorded pixels Still image:
• Standard mode: 4048 3040 (12.3 million)/2848 2136/2048 1536/1600 1200/640 480 pixels
• Widescreen mode: 3968 2232 (8.9 million)/3200 1800/2304 1296/2048 1152/768 432 pixels
Movie:
• Standard mode: 640 480/320 240 pixels (30 frames/sec., with monaural sound)
• Widescreen mode: 640 360/320 184 pixels (30 frames/sec., with monaural sound)
Storage media xD-Picture Card™ (16MB to 512MB)
File format Still image: CCD-RAW/ JPEG (Exif Ver 2.2**)
Movie: AVI (Motion JPEG), WAV
[Design rule for Camera File system compliant/DPOF-compatible]
Number of images /recording time
Still image
Standard mode (4:3 Format) Widescreen mode (16:9 Format)
Mode/Quality
CCD-RAW 12M 12M 6M 3M 2M 0.3M 8M 8M 6M 3M
Fine Normal Fine Normal
Number of
4048 3040 4048 3040 4048 3040 2848 2048 1600 640 3968 3968 3200 2304
recorded pixels
DPC-16 (16MB) 1 3 6 10 19 25 122 4 8 10 20
DPC-32 (32MB) 2 6 12 20 40 50 247 8 17 22 41
DPC-64 (64MB)
4 12 26 42 81 101 497 18 36 44 84
DPC-128 (128MB) 9 26 52 84 162 204 997 36 72 89 169
DPC-256 (256MB) 19 52 105 169 325 409 1997 73 146 179 339
DPC-512 (512MB) 39 105 211 339 651 818 3993 146 292 358 679
Movie
Standard mode (4:3 Format) Widescreen mode (16:9 Format)
Mode/Quality
640 320 640
DPC-16 (16MB) Approx. 18 sec. Approx. 26 sec. Approx. 18 sec. Approx. 34 sec.
Approx. 36 sec. Approx. 54 sec. Approx. 36 sec. Approx. 70 sec.
DPC-32 (32MB)
DPC-64 (64MB) Approx. 73 sec. Approx. 109 sec. Approx. 73 sec. Approx. 141 sec.
DPC-128 (128MB) Approx. 147 sec. Approx. 219 sec. Approx. 147 sec. Approx. 283 sec.
Approx. 296 sec. Approx. 7.3 min. Approx. 296 sec. Approx. 9.4 min.
DPC-256 (256MB)
DPC-512 (512MB) Approx. 9.8 min. Approx. 14.6 min. Approx. 9.8 min. Approx. 18.9 min.
The number of images and recording time will vary slightly depending on the type of subject.
Lens Fujinon 4 × optical zoom lens, F2.8 – F5.6
Lens focal length 7.2 – 28.8 mm. Equivalent to 32.5 – 130 mm (STD)/ 35.5 – 142 mm
(WIDE) on a 35 mm camera
Focus Auto focus (Area, Multi, Center) / Manual focus
AF assist illuminator incorporated
Focus distance Normal: 60 cm /2.0 ft. to infinity
Macro: Approx. 7.5 cm – 80 cm /3.0 in. – 2.6 ft.
Shutter speed 3 sec. – 1/2000 sec. depending on the shooting mode
Aperture F2.8 – F8 (1/3EV step) at Wide-angle, F5.6 – F11 (1/3EV step) at Telephoto
Sensitivity Auto: Equivalent to ISO 80 – 640 (depending on the conditions)
Manual: Equivalent to ISO 80/100/200/400/800 (Resolution fixed at
3M /2M/0.3M for shots taken at ISO800)
Exposure control 64-zone TTL metering-multi, spot, average
Exposure modes Programmed AE, Aperture Priority AE, Shutter Priority AE, Manual
White balance Automatic
Manual [Fine, Shade, Fluorescent light (Daylight), Fluorescent light
(Warm White), Fluorescent light (Cool White), Incandescent light], Custom
Viewfinder Real-image optical viewfinder, approx. 77% coverage
LCD monitor 2.1-inch Widescreen CG silicon TFT (173,000 pixels) approx. 100%
coverage
Flash Auto flash using flash control sensor
Effective range: Wide angle (0.3 m – 4.0 m/1.0 ft – 13.1 ft)
Telephoto (0.6 m – 2.5 m/2.0 ft – 8.2 ft)
Flash mode: Auto, Red-eye Reduction, Forced Flash, Suppressed Flash,
Slow Synchro, Red-eye Reduction + Slow Synchro
Self-timer Approx. 2 or 10 sec. delay
Video output NTSC /PAL selectable
Digital interface USB 2.0 (High speed)
Terminal Multiple Connecter (for included USB & A/V cable, PictureCradle),
Power input socket
Power source NP-40 battery (710mAh, included) or AC power adapter (included)
Dimensions 109.5 (W) 54.0 (H) 29.0 (D) mm /4.3(W) 2.1(H) 1.1(D) in.
Weight 200g /7.1oz. (excluding batteries and media)
Mode Dial
Viewfinder Lamp
Flash
Viewfinder
Microphone
Flash Pop-up Button
C-AF Button
Continuous Shooting
Button
Speaker
Exposure
Compensation
Button
Socket
LCD Monitor
4 Direction Button
(Macro/Flash/Photometry Button)
Socket
Camera functions
Digital zoom ratio at Shooting/Playback mode
Mode Standard mode (4:3 Format) Widescreen mode (16:9 Format)
File size
4048 3040 2848 2048 1600 640 3968
Shooting
– 1.4 2.0 2.5 6.3 –
Playback 30.0 21.1 15.2 11.9 4.7 22.0
AF assist illuminator Effective range: Up to approx. 1.8 m (wide angle) depending on subject
Shooting modes Normal: Auto, Scene Position (Portrait, Landscape, Sports, Night Scene)
Continuous: 1. Top-4 (max. 3 frames/sec., up to 4 frames)
2. Final- 4 (max. 3 frames/sec., up to 4 frames)
3. Long-period [max. 1.6 frames /sec., up to 40 frames.
Only at 2M mode (1600 1200 / 2048 1152 pixels)]
Color modes STANDARD/CHROME/B&W
Voice memo Up to 30 sec. WAV format
Playback Single frame (with max. 30 Playback zoom), 12 Multi-frame,
×
Displayed by day sorting
2M 0.3M
Accessories included 16 MB xD-Picture Card™, Li-ion battery NP-40,
AC Power Adapter AC-5VW, Hand strap, USB cable, A/Vcable,
2048 768
PictureCradle, CD-ROM (USB driver, FinePixViewer,
22 109 ImageMixer VCD2 for FinePix, RAW File Converter LE)
44 220
* Number of effective pixels: The number of pixels on the image sensor which receive input
90 442 light through the optical lens, and which are effectively reflected
181 886 in the final output data of the still image.
** Exif 2.2 is a newly revised digital camera file format that contains
362 1775
a variety of shooting information for optimal printing.
725 3549
®
Windows XP compatible World standard PictBridge compatible
320
Specifications are subject to change without notice.
O P T I O N A L A C C E S S O R I E S
xD-Picture Card TM
DPC - 16 (16MB)
DPC 32 (32MB)
-
DPC 64 (64MB)
-
DPC - 128 (128MB)
DPC 256 (256MB)
-
DPC - 512 (512MB)
Battery Charger
BC 65
-
Charges in approx.
90 minutes,
The NP-40 battery
adapter is included.
Image Memory
Card Reader
DPC - R1
(USB)
TM
xD-Picture Card
USB Drive
DPC-UD1
Microsoft, Windows, and Windows logo are trademarks, or registered trademarks of Microsoft Corporation in the United
States and/or other countries. Macintosh and Mac OS are trademarks of Apple Computer, Inc., registered in the U.S. and
other countries. All other trademarks are the property of their respective holders.
For more information on the full range of Fujifilm digital products, please visit
http://home.fujifilm.com
our Website:
Ref. No. EB-400E (SK ・ 04 ・ 06 ・ F1120 ・ F9711) Printed in Japan © 2004 Fuji Photo Film Co., Ltd.
STD/WIDE Switch
Photo Mode Button
Power Switch
(Photography mode/
Playback mode/Power OFF)
Zoom Button
Strap Mount
Command Dial
DISP/BACK Button
MENU/OK Button
Simulated LCD display image
3200 2304 2048 768
1.2 1.7 1.9 5.2
17.8 12.8 11.4 4.3
Rechargeable
Lithium - ion
Battery
NP 40
-
PC Card Adapter
DPC AD
-
Soft Case
SC - FX701
Waterproof Case
WP-FX701
1 2.3
M ZOOM
6.3 1 .2
M sec.
WIDE
(4048 3040)
4
Effective Recording Optical Fast
LCD
6.3
Pixels Pixels Start-up
Digital
(in STD mode)
