Summary of Contents for NEFF G 14 Series
- Page 1 FREEZER en Instruction for Use G..14.. G..24..
-
Page 2: Table Of Contents
en Table of Contents Safety and warning information ... 3 Freezing and storing food ....11 Information concerning disposal ..6 Freezing fresh food ......11 Scope of delivery ........6 Super freezing ........12 Room temperature, ventilation Thawing frozen food ......13 and cavity depth ........ -
Page 3: Safety And Warning Information
switch off the appliance and enTable of Contentse n I n s t r u c t i o n f o r U s e ■ Safety and warning pull out the mains plug, information inform customer service. ■ The more refrigerant an Before you switch ON the appliance contains, the larger... - Page 4 Keep plastic parts and the Important information when ■ door seal free of oil and using the appliance grease. Otherwise, parts and Never use electrical ■ door seal will become appliances inside the porous. appliance (e.g. heater, electric Never cover or block the ice maker, etc.).
- Page 5 Do not store bottled or General regulations ■ canned drinks (especially The appliance is suitable carbonated drinks) in the for freezing food, freezer compartment. Bottles ■ and cans may burst! for making ice. ■ Never put frozen food straight This appliance is intended for ■...
-
Page 6: Information Concerning Disposal
Warning Information concerning Redundant appliances disposal 1. Pull out the mains plug. 2. Cut off the power cord and discard * Disposal of packaging with the mains plug. The packaging protects your appliance 3. Do not take out the trays from damage during transit. -
Page 7: Room Temperature, Ventilation And Cavity Depth
Cavity depth Room temperature, A cavity depth of 560 mm ventilation and cavity is recommended for the appliance. If the cavity depth is smaller – at least depth 550 mm – the energy consumption increases slightly. Ambient temperature The appliance is designed for a specific Installation location climate class. -
Page 8: Connecting The Appliance
Connecting Getting to know your the appliance appliance After installing the appliance, wait at least 1 hour until the appliance is switched on. During transportation the oil in the compressor may have flowed into the refrigeration system. Before switching on the appliance for the first time, clean the interior of the appliance (see chapter “Cleaning the appliance”). -
Page 9: Switching The Appliance On
Controls Switching Fig. " the appliance on Temperature controller Fig. " Is used to set the freezer compartment temperature. Press the On/Off button 2, the button is On/Off button lit. The temperature alarm is switched off by pressing the alarm button 4. The Serves to switch the whole alarm display 5 lights up until appliance on and off. -
Page 10: Alarm Function
Alarm function Usable capacity Information on the usable capacity can Temperature alarm be found inside your appliance on the rating plate. Fig. ( The temperature alarm switches on if the freezer compartment is too warm and the frozen food is at risk of thawing. Fully utilising the freezer volume The alarm may switch on without any... -
Page 11: Max. Freezing Capacity
Max. freezing capacity Freezing fresh food Information about the max. freezing Freeze fresh and undamaged food only. capacity within 24 hours can be found To retain the best possible nutritional on the rating plate. Fig. ( value, flavour and colour, vegetables should be blanched before freezing. -
Page 12: Super Freezing
Packing frozen food Super freezing To prevent food from losing its flavour or drying out, place in airtight containers. Food should be frozen solid as quickly 1. Place food in packaging. as possible in order to retain vitamins, nutritional value, appearance and flavour. 2. -
Page 13: Thawing Frozen Food
Ice cube tray Thawing frozen food Fig. % Depending on the type and application, 1. Fill the ice cube tray ¾ full of drinking select one of the following options: water and place in the freezer compartment. at room temperature ■... -
Page 14: Switching Off And Disconnecting The Appliance
Switching off and Defrosting disconnecting the Note appliance Approx. 4 hours before defrosting the appliance, switch on super freezing so that the food drops to a very low Switching the appliance off temperature and can therefore be stored Fig. " at room temperature for a longer period. -
Page 15: Cleaning The Appliance
Cleaning the appliance Tips for saving energy Install the appliance in a dry, well ■ Caution ventilated room! The appliance should not be installed in direct sunlight Do not use abrasive, chloride or acidic ■ or near a heat source (e.g. radiator, cleaning agents or solvents. -
Page 16: Operating Noises
Preventing noises Operating noises The appliance is not level Please align the installation cavity with a spirit level. To do this, use the height- Quite normal noises adjustable feet of the cavity or place Droning something underneath. Motors are running (e.g. refrigerating Containers or storage areas wobble units, fan). -
Page 17: Customer Service
Fault Possible cause Remedial action Warning signal sounds, To switch off the warning signal and “Alarm” display lights up. the flashing display, press the Alarm button 4. Fig. "/5 Appliance is open. Close the appliance. The freezer compartment Ventilation openings have Ensure that there is adequate ventilation. - Page 19 "...
- Page 20 &...
- Page 21 *9000874710* 9000874710 (9901)
