- Page 1 Synology DiskStation DS3018xs Hardware Installation Guide...
-
Page 2: Table Of Contents
Table of Contents Chapter 1: Before You Start Package Contents Synology DiskStation at a Glance Safety Instructions Chapter 2: Hardware Setup Tools and Parts for Drive Installation Install Drives Start Up Your DiskStation Add a RAM Module on DiskStation Attach M2D17 Adapter Card to DiskStation... -
Page 3: Package Contents
Chapter Before You Start Thank you for purchasing this Synology product! Before setting up your new DiskStation, please check the package contents to verify that you have received the items below. Also, make sure to read the safety instructions carefully to avoid harming yourself or damaging your DiskStation. -
Page 4: Synology Diskstation At A Glance
Connect external hard drives, USB printers, or other USB devices to the Rear USB 3.0 Port DiskStation here. Expansion Port Connect Synology Expansion Unit to the DiskStation here. For more information about Synology Expansion Unit supported by your DiskStation, please visit www.synology.com. 4 Chapter 1: Before You Start... -
Page 5: Safety Instructions
Safety Instructions Keep away from direct sunlight and away from chemicals. Make sure the environment does not experience abrupt changes in temperature or humidity. Place the product right side up at all times. Do not place near any liquids. Before cleaning, unplug the power cord. Wipe with damp paper towels. Do not use chemical or aerosol cleaners. -
Page 6: Chapter 2: Hardware Setup
Chapter Hardware Setup Tools and Parts for Drive Installation • A screwdriver (only for 2.5" drives) www.synology.com • At least one 3.5” or 2.5” SATA drive (please visit for compatible drive models.) Warning: If you install a drive that contains data, the system will format the drive and erase all existing data. Please back up any important data before installation. - Page 7 3 Load drives in the drive trays. • For 3.5” drives: Remove the fastening panels from the sides of the drive tray. Place the drive in the drive tray. Then insert the fastening panels to secure the drive in place. •...
- Page 8 4 Insert the loaded hard drive tray into the empty hard drive bay. Note: Make sure the tray is pushed in all the way. Otherwise, the drive might not be able to function properly. 5 Press the handle in flush with the front panel to hold the hard drive tray in place. 6 Insert the hard drive tray key into the hard drive tray lock, turn the key clockwise (to the "I"...
-
Page 9: Start Up Your Diskstation
Start Up Your DiskStation 1 Use the LAN cable to connect the DiskStation to your switch, router or hub. 2 Connect one end of the AC power cord to the power port of the DiskStation, and the other to the power outlet. 3 Press the power button. -
Page 10: Add A Ram Module On Diskstation
6 Reconnect the cables you removed in step 1, and then press and hold the power button to turn on your DiskStation. Synology will not provide complete product warranty or technical support if non-Synology RAM modules are used for memory upgrade. 10 Chapter 2: Hardware Setup... -
Page 11: Attach M2D17 Adapter Card To Diskstation
To make sure DiskStation recognizes the new memory capacity: 1 Install DiskStation Manager (DSM). (See the next chapter for more information.) 2 Log in to DSM as admin or a user belonging to the administrators group. 3 Check Total Physical Memory Control Panel >... - Page 12 3 Add M.2 SSD to M2D17 adapter card: a Insert M.2 SSD into the slot. Make sure the card is fully inserted. b Tighten the SSD with a screw. c Repeat previous two steps if installing another optional SSD is needed. Slot numbereds are shown as below. 4 Install the M2D17 adapter card: a Remove the screw that secures the adapter slot’s cover.
-
Page 13: Add A Network Interface Card
2 Remove the 6 screws that secure the main unit, and then pull the top cover in the direction as illustrated below. For more information about supported 10GbE or Gigabit network interface cards, please visit www.synology.com. 13 Chapter 2: Hardware Setup... - Page 14 3 Remove the expansion slot shield: a Remove the screw that secures the adapter slot’s cover. b Remove the adapter slot’s cover. 4 Install the network interface card: a Align the card’s connectors with the adapter slot, and insert the card into the slot. b Use two fingers with firm, even pressure to push down on the card and the bracket.
-
Page 15: Replace System Fan
Replace System Fan Your DiskStation will beep if either of the system fans is not working. Follow the steps below to replace the malfunctioning fan with a good one. To replace the system fan: 1 Shut down your DiskStation and disconnect all cables to prevent any possible damages. 2 Fans are numbered as follows: 3 Remove the 4 screws that secure the fan panel. - Page 16 c Remove the 4 screws that secure the malfunctioning fan, and then remove the fan. 5 Install the new fan: a Replace the malfunctioning fan with a good one (with the fan cable within the fan pointing at the bottom-left corner), and then tighten the 4 screws to secure the new fan.
- Page 17 b Connect the 2 fan cables to the connectors located near the bottom of the fan socket, and then replace the fan panel. 6 Replace and tighten the 4 screws you removed in step 3. 7 Reconnect the cables you removed in step 1, and then press and hold the power button to turn on your DiskStation.
-
Page 18: Chapter 3: Install Dsm On Diskstation
Chapter Install DSM on DiskStation After hardware setup is finished, please install DiskStation Manager (DSM) – Synology’s web-based operating system – on your DiskStation. Install DSM with Web Assistant Your DiskStation comes with a built-in tool called Web Assistant that helps you download the latest version of DSM from the Internet and install it on your DiskStation. - Page 19 • Storage Temperature: -5 to 140˚F (-20 to 60˚C) • Relative Humidity: 5% to 95% RH Note: Model specifications are subject to change without notice. Please refer to www.synology.com for the latest information. Support for exFAT can be enabled by purchasing and downloading exFAT Access in Package Center.
-
Page 20: Appendix B: Led Indicator Table
Please try to restart your DiskStation or re-insert the drive(s), and then run the HDD/SSD manufacturer's diagnostic tool to check the health status of the drive(s). If you can log into DSM, please run the built-in S.M.A.R.T. test to scan the drive(s). If the problem remains unresolved, please contact Synology... - Page 21 IMPORTANT–READ CAREFULLY: THIS END USER LICENSE AGREEMENT ("EULA") IS A LEGAL AGREEMENT BETWEEN YOU (EITHER AN INDIVIDUAL OR A LEGAL ENTITY) AND SYNOLOGY, INC. ("SYNOLOGY") FOR THE SYNOLOGY SOFTWARE INSTALLED ONTO THE SYNOLOGY PRODUCT PUCHASED BY YOU (THE “PRODUCT”), OR LEGALLY DOWNLOADED FROM WWW.SYNOLOGY.COM, OR ANY OTHER CHANNEL PROVIDED BY SYNOLOGY...
- Page 22 Section 15. Termination. Without prejudice to any other or other legal action or proceeding to enforce rights or rights, Synology may terminate this EULA if you do not abide remedies under this EULA, the prevailing party will be by the terms and conditions contained herein. In such event,...
- Page 23 SYNOLOGY, INC. LIMITED PRODUCT WARRANTY THIS LIMITED WARRANTY ("WARRANTY") APPLIES TO THE PRODUCTS (AS DEFINED BELOW) OF SYNOLOGY, INC. AND ITS AFFILIATES, INCLUDING SYNOLOGY AMERICA CORP, (COLLECTIVELY, "SYNOLOGY"). YOU ACCEPT AND AGREE TO BE BOUND BY THE TERMS OF THIS WARRANTY BY OPENING THE PACKAGE CONTAINING AND/OR USING THE PRODUCT.
- Page 24 DAMAGES. the Product specifications; (b) has been repaired, modified or altered by anyone other than Synology or its agent or Limitation of Liability. SYNOLOGY'S AND ITS designee; (c) has been in any way misused, abused, or SUPPLIERS' LIABILITY ARISING OUT OF OR RELATING damaged;...
- Page 25 Nothing in this Section shall be deemed to prohibit or restrict arbitration and will not be conducted on a class-wide or class Synology from seeking injunctive relief or seeking such other action basis. The arbitration shall be held in King County, rights and remedies as it may have at law or equity for any Washington, U.S.A.
- Page 26 FCC Declaration of Conformity This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
