Brigantia 24-DVRS25N-2 User's Installation, Operation And Maintenance Manual

Vented room heater (direct vent)

Advertisement

Quick Links

WARNING: If the information in this manual is
not followed exactly, a fire or explosion may
result causing property damage, personal
injury or loss of life.
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance.
WHAT TO DO IF YOU SMELL GAS:
Do not try to light any appliance.
Do not touch any electrical switch; do not use
any phone in your building.
Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
If you cannot reach your gas supplier, call the fire
department.
Installation and service must be performed by a
qualified installer, service agency or the gas
supplier.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
24-DVRS25N-2
Gas Fired Vented Room
Heater (Direct Vent)
SERIAL NUMBERS 300143 AND HIGHER
U
SERS'
O
PERATION and
M
AINTENANCE
7116 Beatty Dr
Mission, BC V2V 6B4
Canada
I
NSTALLATION
M
This appliance may be installed in an aftermarket
permanently located, manufactured home (USA
only) or mobile home, where not prohibited by
local codes.
This appliance is only for use with the type
of gas indicated on the rating plate. This
appliance is not convertible for use with other
gases, unless a certified kit is used.
*Conversion kit required for Propane use
Tested and
listed by
LABTEST Certification Inc
Richmond, British Columbia
ANSI Z21.88-2009/CSA 2.33-2009
ANUAL
200-0324
June 2015

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 24-DVRS25N-2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Brigantia 24-DVRS25N-2

  • Page 1 24-DVRS25N-2 Gas Fired Vented Room Heater (Direct Vent) SERIAL NUMBERS 300143 AND HIGHER SERS’ NSTALLATION PERATION and AINTENANCE ANUAL This appliance may be installed in an aftermarket permanently located, manufactured home (USA WARNING: If the information in this manual is...
  • Page 2 STATE OF MASSACHUSETTS REQUIREMENTS 5.08: Modifications to NFPA-54, Chapter 10 (2) Revise 10.8.3 by adding the following additional requirements: (a) For all side wall horizontally vented gas fueled equipment installed in every dwelling, building or structure used in whole or in part for residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than seven (7) feet above finished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall be satisfied:...
  • Page 3  Electronic Control System The 24-DVRS25N-2 uses a gas control valve that is operated a Multifunction Remote Control. It can be used as either an Intermittent Pilot or Standing Pilot system.
  • Page 4: Table Of Contents

    TABLE OF CONTENTS Caution and Safety Instructions Appliance Certification, Installation Codes and Specifications Rating Plate Appliance Dimensions and Framing Dimensions Installation Instructions 9 - 11 Clearance to Combustibles, Mantle Clearances, Nailing Flanges Venting Instructions 13 - 17 Wiring Schematics Gas Connections Checking Inlet/Outlet gas pressures, Adjusting Pilot and Convertible Pilot Orifice Contemporary Panels Component Removal - Door Removal, Surround Clip Installation...
  • Page 5: Caution And Safety Instructions

    24-DVRS25N-2 CAUTION FOR YOUR SAFETY - Do not install or operate your Brigantia 24-DVRS25N-2 without reading and understanding this manual. Any installation or operational deviation from this instruction manual voids the Archgard Industries Warranty and may prove hazardous. This appliance must be installed by a qualified gas installer and the installation must conform to the installation codes.
  • Page 6: Appliance Certification, Installation Codes And Specifications

    24-DVRS25N-2 APPLIANCE CERTIFICATION This appliance was listed by LABTEST Certification Inc to the following USA and Canadian gas appliance standards. - ANSI Z21.88-2009/CSA 2.33-2009 Vented Gas Fireplace Heaters - CAN/CGA-2.17-M91, Gas-Fired Appliances for Use at High Altitudes -CSA P.4.1-09 testing method for measuring annual fireplace efficiency.
  • Page 7: Rating Plate

    24-DVRS25N-2 RATING PLATE DO NOT REMOVE THIS LABEL NG / NATURAL # de série Serial # LP / PROPANE NE PAS ENLEVER CETTE ÉTIQUETTE 24-DVRS25N-2 MODEL / MODÈLE: LISTED VENTED GAS FIREPLACE HEATER and GAS-FIRED APPLIANCES FOR USE AT HIGH ALTITUDES.
  • Page 8: Appliance Dimensions And Framing Dimensions

    24-DVRS25N-2 APPLIANCE DIMENSIONS Surround Installed Surround Removed...
  • Page 9: Installation Instructions

    Construct the opening to dimensions shown: The following section describes in detail the requirements for framing for the 26 1/2” wide x 39 1/2” model 24-DVRS25N-2. high X 5 1/2” deep 10” 254 mm Note: Framing should be constructed Unit must be min 4” up...
  • Page 10 24-DVRS25N-2 Installation Instructions Cont. Install the inside portion of the wall thimble and seal the entire inside with a high temperature sili- cone sealant. This is critical to prevent cold drafts. See figure 4 Install the nailing flanges provide by screwing them to the side of the outer shell using the hole required for the facing material.
  • Page 11 999-DV-HTC is required. Electrical Requirements The Brigantia 24-DVRS25N-2 requires 120v for the operating system. There is a factory installed electrical box to accommodate the connections. (see wiring diagram pg. 18) The fireplace comes complete with a battery back-up system that will operate the fireplace for a limited time in the event of a power outage.
  • Page 12: Clearance To Combustibles, Mantle Clearances, Nailing Flanges

    24-DVRS25N-2 Nailing Flanges Install the nailing flanges provided, by screwing them to the side of the outer shell using the appropriate holes for the facing material. Place the fireplace into the framed opening and secure the nailing flanges to the wall.
  • Page 13: Venting Instructions

    24-DVRS25N-2 Installation Instructions Cont. VENTING Clearance to combustibles The following clearances must be maintained around the vent pipe: Vertical runs: 1” Horizontal runs: 2” on top, 1” sides and bottom IMPORTANT: This appliance venting system is a sealed system (DV), which means that all combus- tion air is supplied from outdoors and the combustion products are exhausted to the outdoors.
  • Page 14 24-DVRS25N-2 Installation Instructions Cont. Horizontal Wall Vent Terminations When the termination is to be attached to vinyl siding apply a bead of non-hardening mastic around the The position of the horizontal vent termination outside edge to form a seal between the standoff must be positioned in such a way as to meet all and the terminal.
  • Page 15 24-DVRS25N-2 Installation Instructions Cont. Pitch (Ratio) ‘X’ Vertical Cap Installations Always maintain a 1” clearance around the vent pipe (vertical) and on horizontal venting 2” clearance on the 0/12 - 2/12 4” top of the vent, when passing through ceilings, walls,...
  • Page 16 24-DVRS25N-2 Installation Instructions Cont. Figure 22 – Vent Termination Locations Horizontal Installation Do not install above a meter/regulator assembly within 3 The horizontal run must have a 1/4” rise per foot and must meet feet (90 cm) horizontally from the centerline of the meter/ regulator.
  • Page 17 24-DVRS25N-2 Installation Instructions Cont. Venting Chart Maximum Total NG Venting Length Restrictor Maximum total venting allowed is 45’. Maxi- Setting #3 mum vertical vent is 35’. Maximum horizontal vent is 20’. Minimum 7’ vertical vent rise re- quired for maximum 20’ horizontal vent run.
  • Page 18: Wiring Schematics

    24-DVRS25N-2 WIRING SCHEMATICS INSTALLATION NOTE The SIT Control Module is powered by 120V with an internal transformer for the valve. This is pre-wired to the factory installed electrical box for the electrician. Some jurisdictions may require you install a service switch in the factory supplied electrical box or a remote location.
  • Page 19: Gas Connections

    24-DVRS25N-2 GAS CONNECTIONS Before connecting the appliance to the gas supply line, double check that the appliance you have purchased is designed for the gas type you are using. The gas type markings are located on the certification label and also on the appliance’s gas valve.
  • Page 20: Checking Inlet/Outlet Gas Pressures, Adjusting Pilot And Convertible Pilot Orifice

    24-DVRS25N-2 CHECKING INLET AND OUTLET GAS PRESSURE 1. Remove the surround. 2. The pressure test taps are located on the valve. The taps are located in the gas valve front face. The inlet is marked ‘IN’ and the outlet is marked ‘OUT’. See Fig.1.
  • Page 21: Contemporary Panels

    24-DVRS25N-2 Contemporary Panels Place side panels in the firebox with notches facing forward as shown above. Place rear panel into the back of the firebox. Insert the top arch by carefully sliding one end, into one of the notches on the left or right side to get it aligned with the other notch.
  • Page 22: Component Removal - Door Removal, Surround Clip Installation

    24-DVRS25N-2 Component Removal NOTE: Do not remove any components while the appliance is hot. Door Removal Release the latch located on the bottom of door. Pull forward and down Remove the door by pulling the bottom out to 30 de- grees and lift upward to release the 2 latches at the top of the door.
  • Page 23: Safety Barrier Installation

    24-DVRS25N-2...
  • Page 24: Final Installation Check And Initial Operation

    24-DVRS25N-2 FINAL INSTALLATION CHECK Each Brigantia Gas Fireplace is checked and tested at the factory prior to being packaged and shipped to our dealers and finally installed in your home. Brigantia recommends that before leaving this unit with the customer, the installer must ensure that the appliance is firing correctly and that the electrical system is in working order.
  • Page 25: Lighting Instructions On Rating Plate

    24-DVRS25N-2 LIGHTING INSTRUCTIONS ON RATING PLATE...
  • Page 26: First Fire And Lighting Instructions (Caution)

    24-DVRS25N-2 FIRST FIRE When operated for the first few times, the appliance will emit some odor and fumes. This is due to the heat from the appliance evaporating the oils and solvents used in fabricating the appliance. Close off the room to the rest of the house and open all windows. Keep the room well ventilated, as smoke alarm may sound.
  • Page 27: Remote Control Setup And Operation

    24-DVRS25N-2 REMOTE CONTROL SETUP AND OPERATION...
  • Page 28 24-DVRS25N-2 REMOTE CONTROL SETUP AND OPERATION, cont. Not available on this unit...
  • Page 29 24-DVRS25N-2 REMOTE CONTROL SETUP AND OPERATION, cont.
  • Page 30 24-DVRS25N-2 REMOTE CONTROL SETUP AND OPERATION, cont. Note: When the fireplace is started in Smart Thermostat mode, the fan will come on 5min after ignition and shut down 12min after fire is turned off...
  • Page 31 24-DVRS25N-2 REMOTE CONTROL SETUP AND OPERATION, cont.
  • Page 32 24-DVRS25N-2 REMOTE CONTROL SETUP AND OPERATION, cont. The unit is shipped from the factory with the ability for IPI/CPI selection active. To disable the Continuous Pilot selection ability, cut one of the wires (blue or white) shown in the picture and cap...
  • Page 33 24-DVRS25N-2 REMOTE CONTROL SETUP AND OPERATION, cont.
  • Page 34: Maintenance And Cleaning The Appliance

    Regularly:  Frequent cleaning of the ceramic glass is required. Brigantia recommends using a good quality “gas fireplace” glass cleaner that is available at any hearth retail location. DO NOT CLEAN WHILE HOT.
  • Page 35: Conversion Kit Instructions

    24-DVRS25N-2 CONVERSION KIT INSTRUCTIONS IMPORTANT: This fireplace is Natural gas ready. If converting to LP gas, follow instructions below WARNING: This conversion kit shall be installed by a qualified service agency in accordance with the manufacturers instructions and all applicable codes and requirements of the authority having jurisdiction. If the information in these instructions is not followed exactly, a fire, explosion or productions of carbon mon- oxide may result, causing property damage, personal injury or loss of life.
  • Page 36 24-DVRS25N-2 CONVERSION KIT INSTRUCTIONS CONT. VALVE CONVERSION...
  • Page 37 24-DVRS25N-2 CONVERSION KIT INSTRUCTIONS CONT. Complete the Conversion Fill out and attach conversion label to the fireplace near the valve Change Rating Plate to show new fuel configuration Reinstall the Burner, burner cover and glass media by reversing the removal process.
  • Page 38: Servicing Under Warranty

    24-DVRS25N-2 SERVICING UNDER WARRANTY Before servicing, read the terms and conditions of the Brigantia warranty at the back of the manual. Contact the authorized Brigantia dealer where you purchased the appliance from and provide them with details of the problem, along with the initial installation information (from the front of this manual).
  • Page 39: Replacement Parts List

    24-DVRS25N-2 REPLACEMENT PARTS LIST Item # Item Description Unit 200-0324 Owner’s Manual 308-6011 SIT Pro Flame II Electronic Control Module 308-6014 SIT Pro Flame II Handheld Transmitter 308-6017 SIT 885 Gas Valve c/w Step Motor 308-6012 Module Main Wiring Harness (5 wire)
  • Page 40: Frequently Asked Questions

    Q. How do I care for my gold/nickel plated trims. A. Brigantia recommends a cleaning with a damp cloth. DO NOT use chemical cleaners as they may harm the finish, and void your warranty. NOTE: If the top louvers, or top overlay starts to discolor, check the door gasket seal and replace if necessary.
  • Page 41: Notes

    24-DVRS25N-2 NOTES...
  • Page 42: Warranty

    This Limited Warranty is made by Archgard Industries, hereinafter referred to as “Brigantia”. Brigantia warrants to the original purchaser of an Brigantia gas burning fireplace (s) that the product will be free of defects in materials and workmanship under normal use and ser- vice, for a “lifetime”.
  • Page 43 POSTAGE WARRANTY REGISTRATION BRIGANTIA FIREPLACES 7116 BEATTY DRIVE MISSION, B.C. CANADA V2V 6B4 FOLD DOWN AT LINE FOLD DOWN AT LINE & TAPE CLOSED 24-DVRS25N-2 Model # : Serial #: Date Installed: yyyy Name: Address: City: State/Prov: ZIP: Phone: ( _____ ) Dealer's Name &...
  • Page 44 ARCHGARD FIREPLACES 7116 Beatty Drive Mission, B.C. V2V 6B4 Canada Website: www.archgard.com...
