BlackVue Power Magic Ultra Battery User Manual page 8

2. For a hardwired installation using a hardwiring power cable:
a. Plug the hardwiring power cable into the Ultra Battery's DC in port.
b. Referring to your vehicle Owner's Manual, identify a Switched (accessory power) fuse of more than 20A in your
interior fuse panel. Typical examples are the cigarette lighter and car stereo fuse slots.
Caution
If you connect the Ultra Battery to a Constant Power (BATT) fuse it may result in depletion of your vehicle's
battery.
c. Remove the identified Switched fuse and match its type with one of the 3 fuse taps.
d. Insert the ACC wire into the connector end of the fuse tap. Use a crimping tool or pliers to crimp the connector onto
the wire.
8
BLACKVUE
OFF
Expansion Dashcam
Cigarette Hardwire DC in
XT60
Hardwiring
power cable
Ground wire
(ring)
To Ultra Battery
