creating machine vision

Instructions for Use

DL30x90-IR850/24V

LED area light, diffuse illumination,

Luminous colour: Infrared - 850 nm

999.995.554.10-en-1.0

VISION & CONTROL

Table of Contents

Need help?

Do you have a question about the DL30x90-IR850/24V and is the answer not in the manual?

Questions and answers

Summary of Contents for Vision & Control DL30x90-IR850/24V

Page 1 VISION & CONTROL Instructions for Use Instructions for Use DL30x90-IR850/24V DL30x90-IR850/24V LED area light, diffuse illumination, LED area light, diffuse illumination, Luminous colour: Infrared - 850 nm Luminous colour: Infrared - 850 nm 999.995.554.10-en-1.0 © Vision & Control GmbH 2019...
Page 2 Impress Publisher / Manufacturer Vision & Control GmbH Mittelbergstraße 16 98527 Suhl, Germany Telephone: +49 (0) 3681 7974-0 Telefax: +49 (0) 3681 7974-33 www.vision-control.com Name of the document 999.995.554.10-en-1.0 Date of first issue 2019-05-25 Date modified 2019-11-01 Copyright © Vision & Control GmbH 2019 Copyright It is forbidden to pass this document on to third parties, reproduce and communicate its contents in as far as this has not been expressly authorized.
Page 3 Validity These instructions for use are valid for the following device: Device Order no. DL30x90-IR850/24V 1-21-704 Product Identification Designation Description LED area light, diffuse illumination 30x90 Dimensions light-emitting surface: 90 mm x 30 mm IR850 Wavelength: Infrared - 850 nm...
Page 4: Table Of Contents
DL30x90-IR850/24V Table of Contents TABLE OF CONTENTS 1 Information about the Instructions of Use..........6 1.1 Intended Use....................6 1.2 Improper Use....................7 1.3 Qualified Personnel..................7 1.4 Warranty and Liability...................8 2 Safety......................9 2.1 Presentation of Safety Instructions.............. 9 2.2 Safe Handling of the Device..............10 3 Scope of Delivery and Accessories............
Page 6: Information About The Instructions Of Use
DL30x90-IR850/24V Information about the Instructions of Use 1 INFORMATION ABOUT THE INSTRUCTIONS OF This document contains technical information, important instructions for correct installation, commissioning and use, as well as product information which were up-to-date at the time of going to press.
Page 7: Improper Use
DL30x90-IR850/24V Information about the Instructions of Use 1.2 Improper Use All unintended use and all device-related activities not described in these instructions of use is to be deemed as unauthorised misuse outside the legal limits of indemnity of the manufacturer.
Page 8: Warranty And Liability
DL30x90-IR850/24V Information about the Instructions of Use 1.4 Warranty and Liability The contents of this document have been checked carefully and correspond to current legislation and best practise at the time of going to press. However, the manufacturer shall not be liable for any damage arising from the use of this edition of the manual, and rejects any warranty derived therefrom.
Page 9: Safety
DL30x90-IR850/24V Safety 2 SAFETY 2.1 Presentation of Safety Instructions Each safety instruction is introduced by a key word and colour highlighted. The key word indicates the degree of danger. The danger and its cause are described, and then the measures to prevent conceivable consequences of the danger.
Page 10: Safe Handling Of The Device
DL30x90-IR850/24V Safety 2.2 Safe Handling of the Device Read the following applicable safety instructions carefully and completely. Follow the instructions for your own safety, the safety of other people, and to avoid damage to the device and the connected technical equipment. Hazards going beyond the general safety instructions are referred to separately at the relevant points in this manual.
Page 11: Scope Of Delivery And Accessories
DL30x90-IR850/24V Scope of Delivery and Accessories 3 SCOPE OF DELIVERY AND ACCESSORIES 3.1 Scope of Delivery Designation Quantity Device DL30x90-IR850/24V Instructions for Use DL30x90-IR850/24V 3.2 Accessories Connection cable M5, 4-pin Designation Description Order no. Cable with M5 socket, Connection cable with 4-pin M5 socket...
Page 12 DL30x90-IR850/24V Scope of Delivery and Accessories Mounting systems Designation Description Order no. AL/DL30x30 - mounting for defined or rotatable and swiveling 1-18-070 mounting of AL/DL30x30-series, AL/DL30x90-series, incl. fixing screws 999.995.554.10-en-1.0 © Vision & Control GmbH 2019...
Page 13: Device Description
DL30x90-IR850/24V Device Description 4 DEVICE DESCRIPTION 4.1 Device Views Image 1: Device view Light-emitting surface 2 x M3 mounting hole, depth 6 mm (on both sides) 4-pin M5 connector Casing 4 x M3 mounting hole, depth 6 mm (on both sides) ©...
Page 14: Notices On The Device
DL30x90-IR850/24V Device Description 4.2 Notices on the device Following instructions are provided on the device: Type plate Pin assignment Type plate Type.: XXXXXXXXX No.: TTTJJNNN Image 2: Type plate Manufacturer information Device designation Serial number CE marking 999.995.554.10-en-1.0 © Vision & Control GmbH 2019...
Page 15: Technical Data
DL30x90-IR850/24V Technical Data 5 TECHNICAL DATA 5.1 General Parameters Parameter Characteristic Housing material Aluminium, black anodised Optical material PMMA Housing dimensions 95 mm x 35 mm x 23 mm (without connector) Dimensions light-emitting surface 90 mm x 30 mm Weight...
Page 16: Electrical Parameters
DL30x90-IR850/24V Technical Data 5.2 Electrical Parameters Parameter Operating voltage U 18 V 24 V 30 V Power consumption at U = 24 V DC 3.4 W Switch input ON/ Input voltage OFF 2.7 V Input current OFF 0 mA 2 mA Input voltage ON 3.7 V...
Page 17: Photometric Parameters
DL30x90-IR850/24V Technical Data 5.3 Photometric Parameters Parameter Peak wavelength λ 860 nm peak Centroid Wavelength λ 850 nm centroid Spectral bandwidth Δλ 30 nm Continuous operation, switchable Radiance 105 W/(m²sr) Spectral Emission 1000 Wavelength [nm] Image 3: Spectral emission © Vision & Control GmbH 2019...
Page 18: Conditions For Operation, Storage And Transport
DL30x90-IR850/24V Technical Data 5.4 Conditions for Operation, Storage and Transport Store and transport the device in shock-proof box, if possible in the original packaging. For accessories, connected devices and components observe the specific information in the associated instructions for use.
Page 19: Technical Drawings
DL30x90-IR850/24V Technical Data 5.5 Technical Drawings Image 4: Technical drawings (dimensions in mm) © Vision & Control GmbH 2019 999.995.554.10-en-1.0...
Page 20: Commissioning
DL30x90-IR850/24V Commissioning 6 COMMISSIONING 6.1 Unpacking 1. Lift the cardboard, together with the device, out of the carton. 2. Fold out the tucked in sides on the bottom of the cardboard. Loosening the film and forming an insertion pocket. 3. Remove the device out of the insertion pocket.
Page 21: Mounting The Device
DL30x90-IR850/24V Commissioning 6.2 Mounting the Device NOTICE Installation and connection operations may only be performed in the off and de-energised state. To mount the device, tapped holes are located at the sides. Image 5: Mounting holes 2 x M3 tapped hole (on both sides)
Page 22: Connecting
DL30x90-IR850/24V Commissioning 6.3 Connecting NOTICE Installation and connection operations may only be performed in the off and de-energised state. NOTICE Cable damage • Comply with the specified minimum bending radius. • Cables must generally be mounted with a strain relief clamp.
Page 23: Pin Assignment
DL30x90-IR850/24V Commissioning 6.3.1 Pin assignment Use the M8 connector to connect the device according to the pin assignment. Pin assignment Connection diagram Image 6: M5 4-pin male plug ON/OFF Core colour Signal Description BN (brown) Operating voltage WH (white) Do not use...
Page 24: Operation
DL30x90-IR850/24V Operation 7 OPERATION CAUTION Physiological effects by flashing lights • Working under flashing lights can cause effects such as headache, nausea, or epileptic seizures. • Avoid exposure to certain kinds of flashing lights or stroboscopes. • Wear protective goggles.
Page 25: Making Operational Readiness
DL30x90-IR850/24V Operation 7.1 Making Operational Readiness The device is switched on by applying the operating voltage. The device is switched off by disconnecting it from the operating voltage supply. 7.2 Operating Modes The integrated controller supports the following operating modes: •...
Page 26 DL30x90-IR850/24V Operation Switching behaviour Continuous operation, Continuous operation switchable Shutter Lighting Switching signal Exposure time of the camera Power-on time Delay time Delay time 150 µs Power-on time 150 µs ∞ 999.995.554.10-en-1.0 © Vision & Control GmbH 2019...
Page 27: Maintenance And Service
DL30x90-IR850/24V Maintenance and Service 8 MAINTENANCE AND SERVICE 8.1 Maintenance The device is maintenance-free. Depending on the operating environment, it may have to be cleaned. The housing can be cleaned according to the conditions applicable to the given protection class.
Page 28: Service
DL30x90-IR850/24V Maintenance and Service 8.2 Service Technical Support Please contact our technical support if you have any technical questions concerning our products. We will be glad to be of service: Monday to Thursday 8:00 to 17:00, and Friday 8:00 to 15:00.
Page 29: Disposal
DL30x90-IR850/24V Disposal 9 DISPOSAL The device and its accessories and packaging must be sent to environmentally compatible recycling. Do not throw electrical devices or tools into the household waste! According to European Directive 2012/19/EU on waste electrical and electronic equipment and its implementation in national law, unusable electric tools must be collected separately, and sent to environmentally compatible recycling.
Page 30: Eu Declaration Of Conformity
D-98527 Suhl, Germany Representative: Dr. Jürgen Geffe, Managing director We, Vision & Control GmbH Suhl, declare that the product described below – Designation: DL30x90-IR850/24V – Order no.: 1-21-704 has been manufactured in accordance with the following standards and normative documents: •...
Page 32 Vision & Control GmbH Mittelbergstraße 16 98527 Suhl, Germany Telephone +49 (0) 3681 7974-0 Telefax: +49 (0) 3681 7974-33 Vision & Control GmbH...
