- Page 1 User Manual NPS-30W Gigabit PoE Supply...
- Page 2 This user manual is protected by copyright. The user manual must not be duplicated, reproduced, microfilmed or translated, nor must it be converted to be saved and processed in IT systems, neither in the form of excerpts nor in full, without the express written authorization of Neutrik. Copyright by: © Neutrik® AG...
-
Page 3: Table Of Contents
5.3.2 Daisy-chaining ..........14 5.4 Accessories assembly instructions ......15 5.4.1 Mounting brackets NA-MB-KIT ..... 15 5.4.2 Rack panel NRP1RU-2A ......... 16 5.5 Trussmount for Neutrik Network Devices NA-TM- KIT ................17 6 After Operation ............18 6.1 Dismounting devices ........... 18 6.2 Transporting ............ -
Page 4: About This Document
Pass this user manual on to every user, e.g., by lending it, or to the future owner of the product. If this user manual is lost or damaged, a copy of it can be downloaded from the Neutrik's website (www.neutrik.com). -
Page 5: Explanation Of Symbols
About this Document 1.3 Explanation of symbols Uniform safety instructions, symbols, terms and abbreviations were used to make this user manual easier to understand. The following symbols designate instructions that are not relevant to safety, but make the operating manual easier to understand. The preconditions for an action are depicted with this symbol. -
Page 6: Safety
Consult the dealer or an experienced radio/TV technician for help. • w NOTE Changes or modifications made to this equipment not expressly approved by Neutrik may void the FCC authorization to operate this equipment. User Manual – Gigabit PoE Supply NPS-30W | BDA 579 V2 2020/06... -
Page 7: Declaration Of Conformity
2.3.1 Declaration of conformity The device meets all the relevant EU directives and therefore has the CE and EAC marking. The Declaration of Conformity may be viewed at https://www.neutrik.com/en/support/downloads. 2.4 Important safety instructions Avoid property damage to the Gigabit PoE Supply due to unsuitable operating and environmental conditions: Never immerse in water. -
Page 8: Components And Accessories
Components and Accessories 3 Components and Accessories The device and the accessories can be ordered separately. Pos. Description Item no. Gigabit PoE Supply NPS-30W NPS-30W Mounting brackets NA-MB-KIT (Kit includes 2 brackets, 2 fixing screws, 2 torx screws and 2 spacers) Rack panel NRP1RU-2A Removable rubber protection... -
Page 9: Description Of The Product
Description of the Product 4 Description of the Product 4.1 What is the Gigabit PoE Supply? The Gigabit PoE Supply is a Gigabit power supply intended to provide power to devices over ethernet. It is a passive power supply, meaning that power-negotiation is not supported and power is delivered at all times. -
Page 10: Overview Rear
Description of the Product 4.3.2 Overview rear Pos. Description Pos. Description Data in connection (RJ45) Power LED Used for the unpowered data transmission Indicates that the unit is powered between Gigabit PoE Supply and a network LED lights up green: Unit is powered. •... -
Page 11: Operation
Check the packaging and the Gigabit PoE Supply for visible damage. When visible damage to the packaging and/or delivered parts is detected: Contact the salesperson or Neutrik sales partner. Do not use damaged devices under any circumstances. 5.2 Connecting devices with the Gigabit PoE Supply The Gigabit PoE Supply is installed as a midspan device between the PoE powered device and a Ethernet device without power output. -
Page 12: Applications
Operation Front Rear NPS-30W Gigabit PoE Supply Power IN www.neutrik.com 5.3 Applications User Manual – Gigabit PoE Supply NPS-30W | BDA 579 V2 2020/06... -
Page 13: Power And Data Redundancy
Operation w NOTE Risk of device damage! Do not combine NPS-30W Gigabit PoE Supply with other PoE Supplies, as this can cause a damage due to different pin assignment. 5.3.1 Power and Data Redundancy Example using NA2-IO-DPRO For Power and Data Redundancy, 2 NPS-30W PoE Supplies are required. 5.3.2 Daisy-chaining SECONDARY PRIMARY... -
Page 14: Accessories Assembly Instructions
Operation Up to 4 NA2-IO-DPRO can be daisy chained with one NPS-30W. Example using NA2-IO-DPRO and NA2-IO-DLINE 5.4 Accessories assembly instructions SECONDARY/FEEDTHROUGH PRIMARY NA2-IO-DPRO NPS-30W FEEDTHROUGH 100 / 240 V DPRO controller PRIMARY PRIMARY Switch NA2-IO-DPRO NA2-IO-DLINE Data only Power only Dante ready Power + Data mixing desk... -
Page 15: Mounting Brackets Na-Mb-Kit
Operation w NOTE Use only original Neutrik screws to prevent damage to the device. 5.4.1 Mounting brackets NA-MB-KIT The mounting brackets make it possible to mount the device in floor boxes, underneath tables, etc. Scope of delivery Assembly of the mounting brackets... -
Page 16: Rack Panel Nrp1Ru-2A
Operation 5.4.2 Rack panel NRP1RU-2A Scope of delivery 1 rack panel Assembling the rack panel Prepare the following tools: Crosshead screwdriver Remove the 4 screws on the front of the device. Remove the rubber protection. Place the device in the rack panel. Fix the device with the four screws. -
Page 17: Trussmount For Neutrik Network Devices Na-Tm-Kit
Operation 5.5 Trussmount for Neutrik Network Devices NA-TM-KIT Scope of Delivery 4 cross screws 2 fixing screws 2 safety frames 1 yoke mount Assembling the trussmount Prepare the following tools: Crosshead screwdriver Remove the rubber protection. Use the existing screws (M3 x 6 mm) to install the safety frame. -
Page 18: After Operation
The Gigabit PoE Supply does not contain any parts that can be maintained or repaired by the user. Only have the Gigabit PoE Supply repaired by a specialist dealer authorized by Neutrik. Check the Gigabit PoE Supply regularly for visible damage to the housings, controls, connections, cables and plugs. -
Page 19: Disposal
After Operation 6.6 Disposal Dispose of the Gigabit PoE Supply and accessories in accordance with the applicable local regulations. Never dispose of electrical devices or electrical accessories such as cables, plugs, batteries or components with household wastes under any circumstances. Dispose of packaging and packaging elements in accordance with the applicable local regulations. -
Page 20: Appendix
• PoE Injector: typically a single port device for powering 1 PD. These exist with classification (active) or without (passive). Neutrik's NPS-30W is a passive PoE injector. The term class refers to a maximal power output (see table below). User Manual – Gigabit PoE Supply NPS-30W | BDA 579 V2 2020/06... -
Page 21: Poe Standards
Appendix 7.2.2 PoE Standards These standards are part of IEEE 802.3 general standards. 802.3 af – defines PoE classes 0-3. 802.3 at – uses the same classes, but introduces class 4 as well. 802.3 bt – uses the same classes as 802.3 af and 802.3 at, but introduces class 5 to 8 as well. 7.2.3 Classes and discovery process Discovery is a process of PSE, determining the power requirements of the PD. - Page 22 User Manual – Gigabit PoE Supply NPS-30W | BDA 579 V2 2020/06...
