Summary of Contents for ViewSonic PJ655D
- Page 1 PJ655D User Guide Guide de l’utilisateur Bedienungsanleitung Guía del usuario Guida dell'utente Användarhandbok Käyttöopas...
-
Page 2: Table Of Contents
Limited Warranty ....................38 Power Cord Safety Guidelines ................3 . 9 FCC Information ....................40 Compliance Information for Canada ..............40 Compliance Information for European Countries ..........40 User Information for All Countries ..............40 V iewSonic PJ655D 01/15/04 A... -
Page 3: For Your Records
DPMS and DDC are trademarks of VESA. PS/2, VGA and XGA are registered trademarks of International Business Machines Corporation. Disclaimer: ViewSonic Corporation shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from furnishing this material, or the performance or use of this product. -
Page 4: Usage Notice Precautions
Usage Notice Precautions Follow all warnings, precautions and maintenance as recom- mended in this user’s guide to maximize the life of your unit. Warning- Do not look into the lens. The bright light may hurt your eyes. Warning- To reduce the risk of fire or electric shock, do not expose this product to rain or moisture. - Page 5 Use abrasive cleaners, waxes or solvents to clean the unit. Use under the following conditions: - Extremely hot, cold or humid environment. - In areas susceptible to excessive dust and dirt. - Near any appliance generating a strong magnetic field. - Place in direct sunlight. V iewSonic PJ655D...
-
Page 6: Introduction
User friendly multilingual on-screen display menu Advanced electronic keystone correction and high quality full screen re-scaling image User friendly control panel Luxurious carrying case included SXGA compression and VGA, SVGA re-sizing 250 Watts user replaceable UHP AC lamp Mac compatible V iewSonic PJ655D... -
Page 7: Package Overview
S-Video Cable Audio Cable Jack/RCA Composite Video Cable DVI to D-15 Cable Remote Mouse Y Cable RS232 Cable Soft Case Remote Control with Quick S tart Guide Mouse Function and Laser Pointer ViewSonic Battery x 2 CD-Wizard V iewSonic PJ655D... -
Page 8: Product Overview
Product Overview Main Unit Panel Control Power Connector Power Switch Connection Ports Focus Ring Zoom Lens Zoom Ring Speaker Remote Control Receiver Elevator Button 10. Elevator Foot... -
Page 9: Panel Control
Panel Control Lamp Warning LED Temperature Warning LED Volume Mute Menu (On/Off) Four Directional Select Keys Enter Zoom Re-sync 10. Source 11. Power /Standby V iewSonic PJ655D... -
Page 10: Connection Ports
S-Video Input Connector Audio Input for DVI DVI Input Connecter Audio Input for Computer PC Analog Signal/HDTV/Component Video Connector Audio Output Connector 10. Monitor Loop-through Connector 11. Remote Mouse Input Connector 12. Power Switch 13. Power Connector V iewSonic PJ655D... -
Page 11: Remote Control With Mouse Function & Laser Pointer
V iewSonic PJ655D remote control and do not point the laser light into anyone’s eyes. This remote control contains a Class II laser product. -
Page 12: Installation
1024 X 768 resolution. Make sure timing of the display mode is compatible with the projector. Refer to the “Compatibility Modes” section on page 36. V iewSonic PJ655D... -
Page 13: Powering On/Off The Projector
If you connect multiple sources at the same time, use the “Source” button on the Remote Control or Panel Control to switch. Power / Standby vTurn on the projector first and then the computer. Power Switch Lens cap V iewSonic PJ655D... -
Page 14: Powering Off The Projector
Temperature” on the on-screen display. The projector will automatically shut itself down. Under normal conditions, the projector can be switched on again for your presentation. If the problem persists, you should contact your local dealer or our service center. V iewSonic PJ655D... -
Page 15: Adjusting The Projected Image
To lower the projector: 1. Press the elevator button. 2. Lower down the projector, then release the button to lock the elevator foot into position. Ž 3. Use to fine-tune tilt-adjustment. Elevator Button Elevator Foot V iewSonic PJ655D... -
Page 16: Adjusting The Projector Zoom/Focus
" 2 " 0 " 0 " 8 " 6 " 2 " 4 " 0 " 0 " 0 " 0 " 0 " 0 " 0 " 0 " 8 " 6 ' 4 . V iewSonic PJ655D... -
Page 17: User Controls
User Controls Panel Control & Remote Control There are two ways for you to control the functions: Remote Control and Panel Control. Panel Control Remote Control Use the Remote Control Power / Standby Refer to the “Power On/Off the Projector” section on page 11~12. - Page 18 Zoom In Press “in” button of zoom function to magnifies an image up to a factor of 32 times on the projection screen. Zoom Out Press “out” button of zoom function to diminishes the zoom in image. V iewSonic PJ655D...
- Page 19 Press “Menu” to open the on-screen display (OSD) menus and press key to select menu items . To exit OSD, press the “Menu” button again. The projector will save any change you made automatically. Mute Use to mute sound. Volume Increases/decreases speaker volume. V iewSonic PJ655D...
-
Page 20: On-Screen Display Menus
“Enter” button after all/part of the items have been modified. Press “Enter” button to confirm, and the screen will be back to the main menu at once. Only key is enabled now. To exit the OSD, press the “Menu” button again. V iewSonic PJ655D... -
Page 21: Image-I (Computer Mode)
Use the white segment control to set the white peaking level of DMD chip. 0 stands for minimal peaking, and 10 stands for maximum peaking. If you prefera stronger image, adjust toward the minimum setting. For a smooth and more natural image, adjust toward the minimum setting. V iewSonic PJ655D... -
Page 22: Image-I (Video Mode)
Tint The tint adjusts the color balance of red and green. Press the to increase the amount of green in the image. Press the to increase the amount of red in the image. V iewSonic PJ655D... - Page 23 Video mode Language Management Image-II Audio Image-I White Segment Brightness Image-I Contrast Tint (Video mode) Color Sharpness Sharpness Adjusting the sharpness of the image. Press the to decrease the sharpness. Press the to increase the sharpness. V iewSonic PJ655D...
-
Page 24: Image-Ii (Computer Mode)
Press the to move the image right. Vertical Position Press the to move the image up. Press the to move the image down. vReset : Reset items include both Image-I and Image-II settings. V iewSonic PJ655D... -
Page 25: Image-Ii (Video Mode)
“2”. With the higher temperature, the screen looks colder; with the lower temperature, the screen looks warmer. Reset Choose “Yes” to return the display parameters back to factory default. vReset : Reset items include both Image-I and Image-II settings. V iewSonic PJ655D... -
Page 26: Audio
Press the to increase the bass. Stereo / Mono Mono : Mono sound effect. Stereo : Stereo sound effect. Mute Choose the left icon to turn mute on. Choose the right icon to turn mute off. V iewSonic PJ655D... -
Page 27: Language
Computer / Video mode Image-I Image-II Audio Language Management Language Language You can display the multilingual OSD menu . Use the key to select your prefered language. vThe OSD does not include a PIP menu under Video mode. V iewSonic PJ655D... -
Page 28: Management (Computer Mode)
Image Mode There are 4 factory presets optimized for various types of images. Film : For home theater. Video : For video mode. Graphics : For graphics. PC : For computer or notebook. V iewSonic PJ655D... - Page 29 Lamp Reset Reset the lamp setting only when the new lamp is replaced. Signal Type Select signal type between RGB and YPbPr sources. vThe OSD does not include a PIP menu under Video mode. V iewSonic PJ655D...
-
Page 30: Management (Video Mode)
Image Mode There are 4 factory presets optimized for various types of images. Film : For home theater. Video : For video mode. Graphics : For graphics. PC : For computer or notebook. V iewSonic PJ655D... - Page 31 Choose this function to show or to hide warning message when the changing lamp message is displayed. The message will show up 30 hours before end of life. Lamp Reset Reset the lamp setting only when the new lamp is replaced. V iewSonic PJ655D...
-
Page 32: Pip (Computer Mode)
Choose the PIP screen position on the display screen. Horizontal Position Press the to move the image left. Press the to move the image right. Vertical Position Press the to move the image up. Press the to move the image down. V iewSonic PJ655D... -
Page 33: Appendix Troubleshooting
Verify that the resolution setting is less than or equal to 1024 x 768 resolution. If the projector is still not projecting the whole image, you will also need to change the monitor display you are using. Refer to the following steps. V iewSonic PJ655D... - Page 34 Change the monitor color setting from your computer. Problem : Image has vertical flickering bar Use “Frequency” to make an adjustment. Check and reconfigure the display mode of your graphic card to make it compatible with the product. V iewSonic PJ655D...
- Page 35 When the lamp reaches its end of life, it will burn out and may make a loud popping sound. If this happens, the projector will not turn back on until the lamp module has been replaced. To replace the lamp, follow the procedures in the “Changing the Lamp”. V iewSonic PJ655D...
-
Page 36: Changing The Lamp
The bulb may shatter 6. Remove the cover. and cause injury if it is 7. Remove the 2 screws from the lamp module.Ž dropped. 8. Pull out the lamp module. To replace the lamp module, reverse the previous steps. V iewSonic PJ655D... -
Page 37: Specifications
- 10.9 x 8.9 x 3.3 inches (277 x 225 x 85 mm) Environmental - Operating Temperature: 41 F~95 F (5 C~ 35 Humidity: 80% maximum - Storage Temperature: 14 F~140 F (-10 C~60 Humidity: 80% maximum Safety Regulation - FCC Class B,CE Class B,VCCI-II,UL,cUL,TÜV,CCC, V iewSonic PJ655D... -
Page 38: Compatibility Modes
Compatibility Modes (ANALOG) (DIGITAL) Mode Resolution V.Frequency H.Frequency V.Frequency H.Frequency (Hz) (kHz) (Hz) (kHz) " " " " Remark : “ ” compression computer image. V iewSonic PJ655D... -
Page 39: Customer Support
Malaysia/Thailand F: 65 273 1566 viewsonic.com Other Asia/Pacific viewsonic.com.tw T: 886 2 2246 3456 service@sd. countries F: 886 2 8242 3668 viewsonic.com South Africa viewsonic.com/asia T: 886 2 2246 3456 service@sd. F: 886 2 8242 3668 viewsonic.com ViewSonic PJ655D... -
Page 40: Limited Warranty
GDPDJHV VR WKH DERYH OLPLWDWLRQV DQG H[FOXVLRQV PD\ QRW DSSO\ WR \RX 6DOHV RXWVLGH WKH 86$ DQG &DQDGD )RU ZDUUDQW\ LQIRUPDWLRQ DQG VHUYLFH RQ 9LHZ6RQLF SURGXFWV VROG RXWVLGH RI WKH 86$ DQG &DQDGD FRQWDFW 9LHZ6RQLF RU \RXU ORFDO 9LHZ6RQLF GHDOHU Projector Warranty (V3.0) Release Date: May 1, 2002 ViewSonic PJ655D... -
Page 41: Power Cord Safety Guidelines
HAR-Certified, and a special mark that will appear on the outer sheath, or on the insulation of one of the inner conductors. If you have any questions concerning which proper power cord to use, please consult with the dealer from whom you have purchased the product. ViewSonic PJ655D... -
Page 42: Fcc Information
The device complies with the requirements of the EEC directive 89/336/EEC as amended by 92/ 31/EEC and 93/68/EEC Art.5 with regard to “Electromagnetic compatibility,” and 73/23/EEC as amended by 93/68/EEC Art.13 with regard to “Safety.” User Information for all Countries NOTICE: Use the cables which are included with the projector or specified. ViewSonic PJ655D... - Page 43 ® ViewSonic Corporation...
