Mounting the Unit on a
Wall
You can mount the unit on a wall.
Notes
• Prepare screws (not supplied) that are
suitable for the wall material and
strength. As a plasterboard wall is
especially fragile, attach the screws
securely in the wall beam. Install the
speakers horizontally, hung by screws in
studs in a continuous flat section of the
wall.
• Have the installation done by a Sony
dealer or licensed contractor and pay
special attention to safety during the
installation.
• Sony shall not be held responsible for
accidents or damage caused by improper
installation, insufficient wall strength,
improper screw installation or natural
disaster, etc.
16
GB
1
Fix the wall mounting brackets
(supplied) to the bracket fixing
holes on the bottom of the unit
with the screws (supplied) so that
the surface of each wall mounting
bracket is as shown in the
illustration.
Fix the two wall mounting brackets
to the left and right fixing holes on
the bottom of the unit.
Wall mounting brackets (supplied)
2
Prepare screws (not supplied) that
are suitable for the holes on the
wall mounting bracket.
More than 30 mm
Hole on the wall mounting bracket
Screw (supplied)
4 mm
4.6 mm
10 mm
