nOTE: Use a high quality bar and chain oil for proper saw
chain and bar lubrication. As a temporary substitute, a non-
detergent SAE30 weight motor oil can be used. The use of
a vegetable based bar and chain oil is recommended when
pruning trees. Mineral oil is not recommended because it
may harm trees. Never use waste oil or very thick oil. These
may damage your chain saw.

Filling the Oil Reservoir

1. Unscrew counterclockwise and then remove the oil cap
. Fill the reservoir with the recommended bar and
16
chain oil until the oil level has reached the top of the oil
level indicator 10 .
2. Refit the oil cap and tighten clockwise.
3. Periodically switch the chain saw off and check the oil
level indicator to ensure the bar and chain are being
properly oiled.
Fig. G
10
Transporting Chain Saw (Fig. A, H)
• Always remove the battery from the tool and cover the
guide bar 4 with the guide bar cover
when transporting the saw.
• Engage chain brake by pushing chain brake / front hand
guard 3 forward.
Fig. H

OPERATION


WARNING: To reduce the risk of serious personal
injury, turn unit off and remove the battery pack
before making any adjustments or removing/
installing attachments or accessories. An
accidental start-up can cause injury.

Installing and Removing the Battery Pack

(Fig. I)
nOTE: For best results, make sure your battery pack is
fully charged.
To install the battery pack 14
battery pack with the rails inside the tool's handle and slide
it into the handle until the battery pack is firmly seated in
the tool and ensure that it does not disengage.
16
11 (see Figure H)
11
into the tool handle, align the
To remove the battery pack from the tool, press the release
button 15 and firmly pull the battery pack out of the tool
handle. Insert it into the charger as described in the charger
section of this manual.
Fig. I
Proper Hand Position (Fig. A, J)

WARNING: To reduce the risk of serious personal injury,
Always use proper hand position as shown.

WARNING: To reduce the risk of serious personal injury,
always hold securely in anticipation of a sudden reaction.
Proper hand position requires the left hand on the front
handle 13 , with the right hand on the rear handle
Fig. J
13
Operating the Chain Saw (Fig. A)

WARNING: Read and understand all instructions.
Failure to follow all instructions listed below
may result in electric shock, fire and/or serious
personal injury.
• Guard Against Kickback which can result in
severe injury or death. See general Power Tool
safety Warnings and Causes and Operator
Prevention of Kickback and Kickback safety
Features, to avoid the risk of kickback.
• Do not overreach. Do not cut above chest height.
Make sure your footing is firm. Keep feet apart.
Divide your weight evenly on both feet.
• Use a firm grip with your left hand on the front
handle 13 and your right hand on the rear
English
15
14
12 .
