Channel Vision TE110DS White Paper

White Paper
TE110DS manual override switch
In some cases, customers may require a manual button or switch that allows them to activate their doorstrike
without using the TE110DS. The diagram below shows one possible wiring schematic to accomplish this.
House
Telephones
Telephone
Service
Provider
Power Line Tel
Strike duration
Seconds S1 S2 S3
3 off
5 off
8 off
off
15
20 on
on
40
on
120
on
240
TE110
Standard push button
provides momentary
contact closure
Use a standard pushbutton or any device that will provide a
momentary contact closure and wire it across the 'Strike'
terminals on the TE110DS. When the button is pressed, power
will be delivered to the strike mechanism causing it to activate
Intercom
S4 S5 S6
On 5 Yes #
off off Off 3 No *
off on
on off
on on
off off
off on
on off
on on
C
H A N N E L
TE110DS
House
Intercom
Strike
Door strike
Mechanism
(NOT SOLD BY CHANNEL VISION)
V
I S I O N
Door strike
power supply
(NOT SOLD BY CHANNEL VISION)
CHANNEL VISION
Costa Mesa CA 92626 Costa Mesa CA 92626
1-800-840-0288
www.channelvision.com
Title
TE110DS manual override
switch
Size File Name File Name
A
TE110DS_pushbutton override
Scale Sheet
na of
1
1
TM
Date
09/04
