Specifications:
(typical)
Power Supply Voltage:
IR Frequency range supported:
Maximum number of targets:
Maximum distance to emitters:
Specifications subject to change without notice.
CHANNEL VISION
Limited Warranty
Channel Vision Technology will repair or replace any defect in
material or workmanship which occurs during normal use of this
product with new or rebuilt parts, free of charge in the USA, for two
years from the date of original purchase. This is a no hassle warranty
with no mail in warranty card needed. This warranty does not cover
damages in shipment, failures caused by other products not supplied
by Channel Vision Technology, or failures due to accident, misuse,
abuse, or alteration of the equipment. This warranty is extended only
to the original purchaser, and a purchase receipt, invoice, or other
proof of original purchase date will be required before warranty
repairs are provided.
Mail in service can be obtained during the warranty period by calling
(800) 840-0288 toll free. A Return Authorization number must be
obtained in advance and can be marked on the outside of the shipping
carton.
This warranty gives you specific legal rights and you may have other
rights (which vary from state to state). If a problem with this product
develops during or after the warranty period, please contact Channel
Vision Technology, your dealer or any factory-authorized service
center.
12 VDC
30 kHz - 56 kHz
16
500 ft.
500-073 rev E
C
H A N N E L
V
I S I O N
P-1205
IR distribution hub
C
H A N N E L
234 Fischer Avenue Costa Mesa, CA 92626
(714) 424-6500 (800) 840-0288 (714) 424-6510 fax
·
www.channelvision.com email: sales @ channelvision.com
·
© 2004 Channel Vision Technology
TM
V
I S I O N
TM
·
·
Advertisement
Table of Contents
Related Manuals for Channel Vision P-1205
Summary of Contents for Channel Vision P-1205
- Page 1 Specifications subject to change without notice. CHANNEL VISION Limited Warranty Channel Vision Technology will repair or replace any defect in material or workmanship which occurs during normal use of this product with new or rebuilt parts, free of charge in the USA, for two years from the date of original purchase.
-
Page 2: Mounting Options
IR zones: Some IR systems, including the P-1205, are capable of creating zones that only repeat the IR signals that are picked up by a particular receiver (or group of receivers). This is useful when there are multiple devices from the same manufacturer, such as satellite decoders, that are operated with the same remote control. - Page 3 6 sources. C-1201 ... IR receiver connecting block. Allows 8 IR receivers to be connected in parallel so that one set of wires can be connected to the P-1205 C-1201 How IR repeating works The IR receiver is wired to...
- Page 4 The IR receiver is placed outside the cabinet so that the remote control can be point directly at it. It will detect the IR signals and route to the P-1205, which in turn sends them to the emitter outputs.
