Channel Vision Stereo Receiver Installation Instructions Manual page 6

Splitter/Home Run Design
Cable or
Antenna
3102 Filter
28.5dB
Channel Vision
MULTI ROOM VIDEO TECHNOLOGY
CVT - 15PIA
HS-2
18dB
50'
18dB
100'
6dB Attenuator 3dB Attenuator
11dB
10dB
TV
TV
Bypass Cable Box Converter
HS-2
CVT 3UB/UHF
HS-2
Eliminated if cable
box will pass
modulated channels RF In
Cable Box
VCR
RF In A/V In
TV
Cable Box Combiner Kit
Cable Box
Bypass cable box if
modulated channel
won't pass through the
cable box.
A/V Source
RF Out
28.5dB
CVT 1UB/UHF-II
25dB
Basic design
18dB
for home runs
HS-4
to close TVs.
18dB
150' 150'
12dB 12dB
TV
TV
Hookup with stereo
receiver, Stereo VCR
Cable or
Antenna
and Cable Box
3102 Filter
Converter and use
your stereo receiver for
Channel Vision
MULTI ROOM VIDEO TECHNOLOGY
CVT - 15PIA
RF Out
A/V Out
RF In
A/V Out A/V In
Stereo Receiver
HS-2T
HS-2T
Large design
application with
minimal loss for
the trunk line,
tap pulls part of
the signal and
attenuates a
portion (6dB,
9dB, 12dB,
16dB, 20dB).
Laser Disk Player
Channel Vision
MULTI ROOM VIDEO TECHNOLOGY
CVT - 15PIA
Five channels
total, four for
individual
camera channel
and one
Cable or
channel for the
Antenna
quad channel.
Tap System
RF Out
Cable or
Antenna
CVT 1UB/UHF-II
22.5dB
22.5dB
HS-2
19dB
Channel Vision
MULTI ROOM VIDEO TECHNOLOGY
CVT - 15PIA
Channel Vision
MULTI ROOM VIDEO TECHNOLOGY
CVT - 15PIA
34dB
Stereo Loop Through
Cable or
Antenna
Camera
VCR
CVT 3UB/UHF
HS-2
HS-4
TV TV TV
All Sources Channel-Selectable at all Television Sets
Loop Through Quad
QUAD
LOOP THRU
CVT 2UB/UHF-II CVT 3UB/UHF
HS-2
50'
32dB
9dB
23dB
TAP
31dB
TV 100'
27dB
10dB
17dB
TAP
26dB
TV 100'
22dB
10dB
12dB
TAP
21dB
50'
TV
19dB
10dB
9dB
TAP
18dB
50'
TV
16dB
3dB Attenuator
13dB
TV
Stereo Loop Kit w/ "Y"
Connectors
TV
Home Theater or Receiver, Stereo
TV and/or Stereo Speakers
Camera
Camera
Camera
Camera
TV
