Summary of Contents for Samsung HW-KM38
- Page 1 HW-KM38 Wireless Subwoofer (PS-WK360) Wireless Receiver Module (SWA-8000S) User manual Wireless Audio - Soundbar Imagine the possibilities Thank you for purchasing this Samsung product. To receive more complete service, please register your product at www.samsung.com/register...
-
Page 2: Getting Started
Hold the control of your Soundbar in the palm of your You can connect a Bluetooth device to the Soundbar hand with an Android smart device and the Samsung and enjoy music with high quality stereo sound, all Audio Remote app. This convenient app lets you control... -
Page 3: Safety Information
GETTING STARTED SAFETY INFORMATION ● The following also applies to the Wireless Subwoofer (PS-WK360) and the SWA-8000S. SAFETY WARNINGS TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER (OR BACK). NO USER-SERVICEABLE PARTS ARE INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. This symbol indicates that high voltage is present inside. - Page 4 GETTING STARTED FCC NOTE (for U.S.A): Important Safety Instructions Class B FCC Statement Read these operating instructions carefully before using the unit. Follow all the safety instructions listed below. Keep these The included module(s) has been tested and found operating instructions handy for future reference. to comply with the limits for a Class B digital device, Read these instructions.
- Page 5 GETTING STARTED PRECAUTIONS 2.7 inch 3.9 inch 3.9 inch 3.9 inch Ensure that the AC power supply in your house complies with the power requirements listed on the identification sticker located on the bottom of your product. Install your product horizontally, on a suitable base (furniture), with enough space around it for ventilation (3~4 inches).
-
Page 6: Table Of Contents
GETTING STARTED CONTENTS GETTING STARTED 26 FUNCTIONS Features Input Mode Safety Information Bluetooth What’s Included Software Update DESCRIPTIONS 31 TROUBLESHOOTING Front / Right Side Panel Troubleshooting Bottom Panel 32 APPENDIX Remote Control Specifications 13 INSTALLATION Installing the Soundbar Figures and illustrations in this User Manual are Installing the Wall Mount provided for reference only and may differ from actual Connecting the Subwoofer and the... -
Page 7: What's Included
(AH61-04114A) ● The appearance of the accessories may differ slightly from the illustrations above. ● The Micro USB to USB adapter is sold separately. To purchase, contact a Samsung Service Center or Samsung Customer Care. ● For more information about the power supply and power consumption, refer to the label attached to the product. -
Page 8: Descriptions
DESCRIPTIONS DESCRIPTIONS FRONT / RIGHT SIDE PANEL (Volume) Button Controls the volume level. The numeric value of the volume level appears in the front panel display. (Source) Button Right Side Selects the D.IN, AUX, BT, TV, or USB input. ● While the unit is powered on, pressing the (Source) button for more than 3 seconds sets the button to act as the (Mute) button. -
Page 9: Bottom Panel
DESCRIPTIONS BOTTOM PANEL DIGITAL AUDIO IN (OPTICAL) (Micro USB Port) Connect to the digital (optical) output of an You can play the music from USB memory external device. device if connecting Micro USB memory device or Micro USB to USB adapter cable (not supplied). -
Page 10: Remote Control
MUSIC, CLEAR VOICE, SPORTS, MOVIE, and NIGHT MODE - depending on the content you want to listen to. Select the STANDARD mode if you want to enjoy the original sound. ● Soundbar is a Samsung proprietary name. ● Operate the TV using the TV's remote control. - Page 11 5KHz and 10KHz are selectable and each can be adjusted to a setting between -6 and +6. • To adjust the woofer level using the Samsung Audio Remote mobile app, press the [, ] buttons to decrease or increase the woofer level within 3 seconds of pressing the WOOFER button.
-
Page 12: Installation
INSTALLATION + Controlling the Soundbar using Your TV Remote Control 1. Press and hold the SOUND button for more than 5 seconds while the Soundbar is turned on. 2. "ON - TV REMOTE" appears on the Soundbar's display. 3. In the TV's menu, set the TV speaker to external speaker. ●... -
Page 13: Installing The Soundbar
INSTALLATION INSTALLATION INSTALLING THE SOUNDBAR INSTALLING THE WALL MOUNT + Installation Precautions ● Install on a vertical wall only. ● For the installation, avoid a location with high temperature or humidity, or a wall that cannot sustain the weight of the set. - Page 14 INSTALLATION Center Line 2. Align the Wall Mount Guide's Center Line with the center of your TV (if you are mounting the Soundbar below your TV), and then fix the Wall Mount Guide to the wall using tape. ● If you are not mounting below a TV, place the Center Line in the center of the installation area. 3.
- Page 15 INSTALLATION 5. Push a screw (not supplied) through each Holder-Screw, and then screw each screw firmly into a support screw hole. 6. Use the two Screws (M4 x L14) to attach both Bracket-Wall Mount L and R to the Soundbar's bottom. For a proper fit, make sure to align the bumps on the Soundbar to the holes on the brackets.
- Page 16 INSTALLATION 7. Install the Soundbar with the attached Bracket-Wall Mounts by hanging the Bracket-Wall Mounts on the Holder-Screws on the wall. ● Slightly tilt the Soundbar to insert both Holder-Screw heads into the Bracket-Wall Mount holes. Push the Soundbar in the direction of the arrow to make sure both sides are firmly fixed.
- Page 17 INSTALLATION DETACHING THE SOUNDBAR FROM THE WALL 1. To separate the Soundbar from the wall, push it in the direction of the arrow, tilt the Soundbar slightly, and then pull it away from the wall as shown. ● Do not hang onto the installed unit and avoid striking or dropping the unit. ●...
-
Page 18: Connecting The Subwoofer And The Swa-8000S
CONNECTIONS ● Do not connect the power cord of this product or your TV to a wall outlet until all connections between components are complete. ● Before moving or installing this product, be sure to turn off the power and disconnect the power cord. CONNECTING THE SUBWOOFER AND THE SWA-8000S CONNECTING THE SUBWOOFER AND THE SWA-8000S... - Page 19 CONNECTIONS 3. Press the button on your remote control for 5 seconds while the main unit is turned OFF. 4. The ID SET message appears on the display of the main unit for a short period of time, and then disappears. 5.
-
Page 20: Connecting To A Tv
CONNECTIONS CONNECTING TO A TV ● Important: Before you begin, put the battery into the remote. See page 12 for instructions. CONNECTING TO A TV USING A DIGITAL OPTICAL CABLE Optical Cable OPTICAL OUT DIGITAL AUDIO IN (OPTICAL) DIGITAL AUDIO IN (OPTICAL) DC 19V DIGITAL AUDIO IN... -
Page 21: Tv Soundconnect
CONNECTIONS TV SOUNDCONNECT You can enjoy TV sound through your Soundbar when it is connected to a Samsung TV that supports the TV SoundConnect function. Connect 1. Turn on the TV and Soundbar. 2. Press the button on the main unit’s right side or the SOURCE button on the remote control to select the TV mode. - Page 22 • ON - BLUETOOTH POWER : The Soundbar turns on and off when you turn the TV on or off. • OFF - BLUETOOTH POWER : The Soundbar only turns off when you turn the TV off. ● This function is supported by some Samsung TVs released from 2013 on.
-
Page 23: Connecting To External Devices
CONNECTIONS CONNECTING TO EXTERNAL DEVICES OPTICAL OR ANALOG AUDIO CABLE This unit comes equipped with one digital optical in jack and one analog audio (AUX) in jack, giving you two ways to connect it to external devices. Audio Cable (not supplied) AUX OUT AUX IN Optical Cable... -
Page 24: Usb
2.0 USB jack (Type A) on the other end to the micro USB jack on your Soundbar. ● The Micro USB to USB adapter cable is sold separately. To purchase, contact a Samsung Service Center or Samsung Customer Care. - Page 25 CONNECTIONS ● File Format Type Compatibility list: Extension Codec Sampling Rate Bitrate MPEG 1 Layer2 16KHz ~ 48KHz 80kbps~320kbps MPEG 1 Layer3 16KHz ~ 48KHz 80kbps~320kbps *.mp3 MPEG 2 Layer3 16KHz ~ 48KHz 80kbps~320kbps MPEG 2.5 Layer3 16KHz ~ 48KHz 80kbps~320kbps Wave_Format_MSAudio1 16KHz ~ 48KHz...
-
Page 26: Functions
FUNCTIONS FUNCTIONS INPUT MODE (Source) button on the main unit’s right side or the SOURCE button on the remote control to select Press the the mode you want. Right Side of the Soundbar Input mode Display D.IN Optical Digital input AUX input BLUETOOTH mode TV SoundConnect... -
Page 27: Bluetooth
3. Select the Stereo headset menu on the Bluetooth device. • You will see a list of scanned devices. 4. Select "[AV] Samsung Soundbar Kxxx K-Series" from the list. • When the Soundbar is connected to the Bluetooth device, it will display [Bluetooth device name] BT on the front display. - Page 28 ● Once the set has been paired with a device, if the soundbar is in DIN, AUX, or USB mode and you select “[AV]samsung soundbar Kxxx K-ser" from your Bluetooth device's list, the set will automatically change to BT mode.
- Page 29 Market search : Samsung Audio Remote + Launching the Samsung Audio Remote App To launch and use the Samsung Audio Remote app, touch the Audio Remote icon on your smart device, and then follow the directions on the screen. ● The Samsung Audio Remote app is only compatible with Android mobile phones and mobile devices...
-
Page 30: Software Update
Note that if there are multiple update files, you must load them onto the USB device singly and use them to update the firmware one file at a time. Please visit samsung.com or contact the Samsung call center to receive more information about downloading update files. -
Page 31: Troubleshooting
Refer to the table below if this product does not function properly. If the problem you are experiencing is not listed below or if the instructions below do not help, turn off the product, disconnect the power cord, and contact Samsung Electronics at 1-800-SAMSUNG (1-800-726-7864). -
Page 32: Appendix
Design and specifications are subject to change without prior notice. Nominal specification Samsung Electronics Co., Ltd reserves the right to change the specifications without notice. Weight and dimensions are approximate. Dispose unwanted electronics through an approved recycler. To find the nearest recycling location, go to our website: www.samsung.com/recyclingdirect or call (877) 278 - 0799. - Page 33 ● If you have a problem with this product, we strongly recommend you read the appropriate section of this manual, review the Troubleshooting section on page 31, visit the Support page for your product at www.samsung.com, or call Samsung Product Support (1-800-726-7864) to find an answer before you contact a service center for a repair.
- Page 34 To receive warranty service, the purchaser must contact SAMSUNG for problem determination and service procedures. Warranty service can only be performed by a SAMSUNG authorized service center. The original dated bill of sale must be presented upon request as proof of purchase to SAMSUNG or SAMSUNG's authorized service center. Transportation of the product to and from the service center is the responsibility of the purchaser.
- Page 35 Pine Brook, New Jersey 07058 QUESTIONS OR COMMENTS? COUNTRY CALL OR VISIT US ONLINE AT WRITE Samsung Electronics America, Inc. 1-800-SAMSUNG IN THE US www.samsung.com/us/support 85 Challenger Road (726-7864) Ridgefield Park, NJ 07660 ©2018 Samsung Electronics Co.,Ltd. All rights reserved...
