- Page 1 LED TV Installation manual Thank you for purchasing Samsung product. To receive more service, please register your product at www.samsung.com/register Model Serial No.
- Page 2 Failing to maintain proper ventilation may result in a fire or problems with the product caused by an increase in its internal temperature. ✎ When using a stand or wall-mount, use parts provided by Samsung Electronics only. ✎ Using parts provided by another manufacturer may cause difficulties with the product or result in injury caused by the product falling.
-
Page 3: Table Of Contents
Contents y Accessories ..................................4 y Installing the LED TV Stand ............................5 y Assembling the swivel stand (Depending on models) ..................8 y Using the TV's Controller ............................10 y The Connection Panel ..............................11 y Using the TV's remote Controller ..........................16 y Connecting the TV to the Lodgenet game controller or a STB of a SI vendor ........... -
Page 4: Accessories
Accessories ✎ Please make sure the following items are included with your LED TV. If any items are missing, contact your dealer. ✎ The items’ color and shape may vary, depending on the model. ✎ The parts for the stand are listed under Stand Components on the following page. List of Parts Safety Guide / Quick Setup Guide Remote Control &... -
Page 5: Installing The Led Tv Stand
Installing the LED TV Stand Components When installing the stand, use the provided components and parts. ◆ HG32NE460F X 8 (M4 X L12) (coarse thread) Stand Guide Stand Screws X 4 (M4 X L12) (coarse thread) ATTENTION DO NOT USE DO NOT USE DO NOT CHEMICALS... - Page 6 ◆ HG50NE460H X4 (M4 X L12) 1 EA 2 EA (1L, 1R) Stand Guide Stand Screws X4 (M4 X L12) English...
- Page 7 ◆ HG32NE470F/HG32NE477F/HG50NE470H/HG50NE477H/HG50NE478H 50” 4 EA: M4 X L12 (fine thread) 4 EA: M4 X L12 1 EA 1 EA 32” 8 EA: M4 X L12 (coarse thread) 50” 4 EA: M4 X L12 (coarse thread) Stand Guide Stand Screws Security Screws ✎...
-
Page 8: Assembling The Swivel Stand (Depending On Models)
Assembling the swivel stand (Depending on models) You can configure these stands so that the TVs swivel 20 degrees left and right, 60 degrees left and right, or 90 degrees left and right using the BRACKET HOLDER SWIVEL. 20° swivel To configure the TV so that it swivels 20°... - Page 9 Hotel Mount Kit Bolt + Nut Short Bolt (2EA) Long Bolt (2EA) Nut (2EA) Washer (2EA) Affix the stand to a flat surface such as a dresser Bottom top, desk top, or entertainment center as shown. WARNING: To prevent injury, you must attach this TV securely to the floor, a table, a dresser top, etc. with the Hotel Mount Kit as described in these instructions.
-
Page 10: Using The Tv's Controller
Using the TV's Controller The TV’s Controller on the bottom right side of the TV, lets you control the TV without the remote control. Control Menu : Turns the TV on or off. : Changes channels. : Adjusts the volume. : Displays and selects the available video sources. -
Page 11: The Connection Panel
The Connection Panel NE460 HDMI IN 2 (DVI) (5V 0.5A) /CLONING HDMI IN 1 (ARC) EX-LINK AV IN ANT IN AUDIO OUT AIR/CABLE NE473 English... - Page 12 NE470/NE477 HDMI IN 2 (DVI) (5V 0.5A) /CLONING HDMI IN 1 (ARC) DATA EX-LINK AV IN ANT IN AUDIO OUT AIR/CABLE NE478 HDMI IN 2 (DVI) GAME (5V 0.5A) CONTROL /CLONING DATA HDMI IN 1 (ARC) EX-LINK AV IN ANT IN AUDIO OUT AIR/CABLE ✎...
- Page 13 VIDEO / L-AUDIO-R – Connect a VIDEO cable to an appropriate external A/V device such a VCR, DVD, or Camcorder. – Connect audio cables to "L-AUDIO-R" on your TV and the other ends to corresponding audio out jacks on the A/V device.
- Page 14 Display Modes You can also select one of the standard resolutions listed in the Resolution column. The TV will automatically adjust to the resolution you choose. After connecting a computer to the TV, set the screen resolution for the TV on the computer. The optimal resolution is 1920 x 1080 @ 60 Hz.
- Page 15 ✎ Optimal resolution is 1920 x 1080 @ 60 Hz. Horizontal Vertical Frequency Pixel Clock Sync Polarity Frequency Display Mode Display Format (Hz) (MHz) (H / V) (kHz) 720 x 400 70Hz 31.469 70.087 28.322 640 x 480 67Hz 35.000 66.667 30.240 832 x 624...
-
Page 16: Using The Tv's Remote Controller
Using the TV's remote Controller ✎ This remote control has Braille points on the Power, Channel, Volume, and Enter buttons and can be used by visually impaired persons. ✎ The button names above may differ from the actual names. Turns the TV on and off. Display and select the available video sources. - Page 17 Installing batteries (Battery size: AAA) Rear of the Remote ✎ After you have installed the batteries, use a screwdriver to screw in the screw that holds the battery cover closed. Installing Batteries into the Remote (battery size: AAA) Match the polarity of the batteries to the symbol in the batter compartment. ✎...
-
Page 18: Connecting The Tv To The Lodgenet Game Controller Or A Stb Of A Si Vendor
Connecting the TV to the Lodgenet game controller or a STB of a SI vendor HE470/HE477/HE473 TV Rear Panel ETH MODEM Data Cable 1. Connect the DATA jack of the TV to the ETH MODEM jack of the STB (SBB) with the Data cable. ✎... - Page 19 Contact your nearest dealer or your SI Vendor to buy the data cable not included in the TV. Confirm the code on the Code Label Note the labeled end. Note the labeled end. SI Vendor Cable code Pin assign Remark Samsung BN39-00865B Enseo Guest-Tek NXTV BN39-01011B nStreams BN39-01110A BN39-01011C ✎...
-
Page 20: Connecting A Pillow Speaker
– This speaker is only compatible with a specified IR code. You can change the code in the Hospital mode setup menu. – The TV gives priority to the Samsung remote control over the pillow speaker's wired remote control. – Option: Channel Menu Display. -
Page 21: Connecting The Audio Output To An Audio Amplifier
Connecting the Audio Output to an Audio Amplifier TV Rear Panel AUDIO IN AUDIO OUT Audio Amplifier 1 Stereo cable 1. Connect the AUDIO OUT port of the TV to the Audio In port of an audio amplifier with a stereo cable. (Stereo cable not provide) English... -
Page 22: Connecting The Mediahub Hd
Connecting the MediaHub HD Output to any external source connected to MediaHub HD on the hotel desk. (Inlay sample may vary depending on the model.) MediaHub HD Rear HDMI RS/232 TV Rear Panel HDMI IN 2 (DVI) 2 HDMI cable (5V 0.5A) (5V 0.5A) /CLONING... -
Page 23: Connecting The Rjp (Remote Jack Pack)
HDMI IN port of the TV to the HDMI port of the RJP. 4. Connect the EX-LINK port of the TV to the RS/232 port of the RJP. ✎ This Samsung TV is compatible with the TeleAdapt TA-7610 RJP only. English... - Page 24 y RJP (Remote Jack Pack): The RJP is a hardware module that has different Audio Video inputs (A/V, Audio, PC and HDMI) and corresponding outputs. The corresponding outputs are connected from the RJP to the TV. The RJP communicates with the TV via RS232. The RJP communicates with the TV by sending messages regarding Active/ Inactive sources.
-
Page 25: Setting The Hotel Option Data
After a menu appears, follow these general directions to navigate and change values: – Use the Up and Down arrow buttons on the Samsung remote to move from menu item to menu item. – Press the ENTERE or Left or Right arrow buttons to select a menu item. The screen displays that menu item only. - Page 26 478 y Standalone mode : TV works alone, without an SI STB or SBB. models) y Interactive mode: Samsung / OCC / MTI / Nstreams / Enseo / Cardinal / Guestek / (Samsung SeaChange / MDC / Innvue SI Vendor...
- Page 27 Menu Item initial Value Description Gives you direct, immediate access to some of the Channel menu functions on the user Channel Setup Channel menu such as Auto Program, Antenna selection, etc. The Channel Editor lets you edit the channels stored in the TV's memory. Using Channel Editor you can: y Change the channel numbers and names, and sort the channels in your desired channel number order.
- Page 28 CZ: the type of Zenith IR Code and 12V Vcc y CP: the type of Philips IR Code and 5V Vcc Pillow y CS: the type of Samsung IR Code and 12V Vcc Speaker Select the speaker where the TV sound is outputted.
- Page 29 Hospitality Logo DL … y BMP or AVI files only. y Max file size: BMP - 960 X 540. AVI - 30MB. y The file can only be named samsung.bmp or samsung.avi. Logo Display Time … Hospitality Logo Display Time (3/5/7 seconds).
- Page 30 Pro:Idiom encryption. If your broadcasting system does not have a problem, contact Samsung Service. If STB SI Vendor Setting appears to have failed and communication with the SI STB or SBB has failed, first check your SI STB or SBB.
- Page 31 Using the Sports(or Soccer) Mode Sports(or Soccer) Mode t MENU m → Applications → Sports(or Soccer) Mode → ENTER ✎ This mode provides optimized condition for watching sports games. y a (Zoom): Pause playback and divide the picture into 9 parts. Select a part to zoom it in. Press this button again to resume.
- Page 32 Logo File Format – The TV supports only BMP and AVI format. – The file name must be samsung.bmp or samsung.avi. – The maximum resolution of the BMP format is 960 x 540. – The maximum file size for AVI format is 30MB.
- Page 33 USB Cloning The USB Cloning function lets you download user-configured settings (Picture, Sound, Input, Channel, Setup, and Hotel Setup) from one TV to a USB device, and then upload these settings from the USB device to other TV sets. This lets you create a standard file of settings and distribute that standard file to all the TVs in your facility.
- Page 34 Settings Cloned in the Hotel Menu Menu Item Cloning Support Hospitality Mode SI Vendor Power On Channel Power On Channel Num Power On Channel Type Power On Volume Power On Volume Num Min Volume Max Volume Power On Source Power On Option Channel Setup Channel Editor Mixed Channel Map...
- Page 35 PI AES Data PI AES Log View PI AES Log Self Diagnosis for TV Self Diagnosis for HTV SW Update Service Pattern ATV Cable AGC Gain DTV Open Cable AGC Gain Sound Bar Out Contact Samsung Standby LED TV reset English...
- Page 36 Multi Code Remocon A Multi Code Remocon is a special remote which is designed to control multiple TVs. This function is useful where there is more than one TV in a location. You can control up to 10 TVs with a different ID code of each remote with no conflicts between the TVs. ID numbers are displayed on each TV's OSD.
- Page 37 Setting Auto Initialize When you clone settings from one TV to another, you clone both the guest side menu and hotel side menu settings: Picture, Sound, Input, Channel, Setup, and Hotel Setup. This lets you set nearly all of the menu values on your hospitality TVs to the same, standard settings.
- Page 38 TV resets all values to their DTV OpenCable AGC Gain Default factory defaults and then Done Sound Bar Out Contact Samsung displays the Hospital Plug Standby LED & Play menu. Go to the first Complete cloning TV Reset Hospital Plug & Play screen and next below.
- Page 39 – If you select Standalone setup from the “Select Hospital TV Mode” OSD, the “Select Menu Language” OSD appears. – Initially highlighted: English – Display time: OSD time out and operation are the same as Samsung’s consumer TV models. – If you press the Enter key, the “Picture Mode” OSD appears. ◆ Configure your TV OSD –...
- Page 40 USB Software Upgrade Method Samsung may offer upgrades to the TV’s SW in the future. Please contact the Samsung Hospitality Hot line at the last page to receive information about downloading upgrades and using a USB drive to update the SW by connecting the USB drive containing the upgrade to the USB port located on the TV.
- Page 41 Samsung Sound-Bars and Hospitality TVs – Samsung Sound-Bars and hospitality TVs support the ARC feature in HDMI 1.4. If you connect a compatible Samsung Sound-Bar to a compatible Samsung hospitality TV using a single HDMI cable, guests can listen to the TV's sound through the Sound-Bar.
- Page 42 Channel Bank Editor (Smoovie TV Only) The Channel Bank Editor in conjunction with the SMOOVIE remote lets you control the channels guests have access to. The Channel Bank Editor provides three Banks of channels and lets you select which channels will be available from each bank.
- Page 43 Information About SMOOVIE Remote Controls Channel Bank Editor Bank1 (0) Bank2 (0) Bank3 (0) Registered ----- (Air) ----- (Air) ----- (Air) ----- (Air) ----- (Air) ----- (Air) ----- (Air) ----- (Air) ----- (Air) 63-1 SY5000 Select All Items On Column Deselect All Items On Column Select Return...
- Page 44 Channel Editor The Channel Editor lets you edit the channels stored in the TV's memory. Using Channel Editor you can: – Change the channel numbers and names, and sort the channels in your desired channel number order. – Apply the video mute to channels you select. The video mute blanks out the video from a channel and outputs only the sound while displaying a speaker icon on the screen.
- Page 45 The picture below shows a sample Channel Editor screen. ----- (Air) 20-2 ----- (Air) ----- (Air) 50-1 CH 50.1 50-2 CH 50.2 50-3 CH 50.3 50-4 CH 50.4 51-1 KUSI-HD ----- (Cable) ----- (Cable) ----- (Cable) HDMI1 HDMI2/DVI HDMI3 y a Indicates an analog channel. y Channels without an a are digital channels.
- Page 46 When you press the TOOLS button, the following menu is available. 20-2 ----- (Air) 50-1 CH 50.1 50-3 CH 50.3 51-1 KUSI-HD ----- (Cable) HDMI1 HDMI3 y Edit Channel Number Use Edit Channel Number to change the channel number of a channel you select. To change a channel number, follow these steps: Edit Channel Number 1.
- Page 47 The external sources of this TV are displayed in the last page of the Channel Editor menu as shown in the example below. In the example, there are four external sources connected to the TV, HDMI1, HDMI2(DVI), HDMI3 and AV. –...
-
Page 48: Installing The Wall Mount
When installing a wall mount kit, we recommend you fasten all four VESA screws. y If you want to install a wall mount kit that attaches to the wall using two top screws only, be sure to use a Samsung wall mount kit that supports this type of installation. -
Page 49: Securing The Tv To The Wall
Securing the TV to the Wall Caution Pulling, pushing, or climbing onto the TV may cause the TV to fall. In particular, ensure that your children do not hang over or destabilize the TV; doing so may cause the TV to tip over, resulting in serious injuries or death. Follow all safety precautions provided on the included Safety Flyer. -
Page 50: Anti-Theft Kensington Lock
Refer to the manual provided with the Kensington Lock for additional information on proper use. The Kensington Lock is not supplied by Samsung. ✎ Please find the “K” icon on the rear of the TV. A Kensington slot is beside the “K”... -
Page 51: Specifications And Other Information
Specifications and Other Information Specifications Model Name HG32NE460F HG50NE460H Display Resolution 1360 x 768 1920 x 1080 Screen Size 32” Class 50” Class (Diagonal) (31.5” measured diagonally) (49.5” measured diagonally) Sound (Output) 5W x 2 10W x 2 Dimensions (W x D x H) Body 745.4 x 69.0 x 442.2 mm 1140.8 x 72.9 x 662.3 mm... - Page 52 Supported Video Formats File Extention Container Video Codec Resolution Frame rate(fps) Bit rate(Mbps) Audio Codec DivX 3.11/4.x/5.x/6.x Dolby Digital MPEG4 SP/ASP 1920 x 1080 LPCM *.avi / *.mkv H.264 BP/MP/HP ADPCM *.asf / *.wmv Motion JPEG 640 x 480 (IMA, MS) *.mp4 / *.3gp Window Media Video v9 *.vro / *.mpg...
- Page 53 Supported Subtitle Formats y Internal Name Container Format y External Xsub Picture Format Name File extension SubStation Alpha Text Format MPEG-4 timed text .ttxt Advanced Text Format SubStation Alpha SAMI .smi SubRip Text Format SubRip .srt MPEG-4 timed text Text Format SubViewer .sub Micro DVD...
- Page 54 The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries. Open Source License Notice Open Source used in this product can be found on the following webpage. (http://opensource.samsung.com) Open Source License Notice is written only English. English...
-
Page 55: Dimensions
Dimensions Front view / Side view HG32NE460F (Unit: mm) 745.4 699.7 394.3 433.9 442.2 484.7 57.3 163.4 69.0 HG50NE460H (Unit: mm) 1140.8 1097.8 1037.1 618.4 662.3 685.2 41.6 72.9 187.5 English... - Page 56 HG32NE473F (Unit: mm) 745.4 699.7 394.3 442.2 69.0 HG32NE470F/HG32NE477F HG50NE470H/HG50NE477H/HG50NE478H (Unit: mm) HG32NE470F 745.4 699.7 394.3 442.2 484.2 57.3 69.0 192.6 HG32NE477F HG50NE470H HG50NE477H 1140.8 1097.8 618.4 662.3 713.1 41.6 72.9 226.5 HG50NE478H English...
- Page 57 Rear view HG50NE460H/HG50NE470H/HG50NE477H/HG50NE478H (unit: mm) 229.7 223.7 203.9 200.0 200.0 789.4 HG32NE460F/HG32NE470F/HG32NE477F/HG32NE473F (unit: mm) 101.4 106.1 111.9 503.8 100.0 100.0 English...
- Page 58 Stand base view HG32NE460F 311.4 163.4 124.2 163.4 311.4 30.0 HG50NE460H 142.6 158.0 187.5 English...
- Page 59 HG32NE470F/HG32NE477F 451.3 192.6 123.2 451.3 192.6 55.9 135.0 R9.50(mm) R3.75(mm) 152.0 HG50NE470H/HG50NE477H/HG50NE478H 556.5 226.5 174.1 556.5 226.5 67.0 135.0 R9.50(mm) R3.75(mm) 152.0 English...
- Page 60 (SAMSUNG) products, and the requirements, conditions, exclusions and limitations contained herein, SAMSUNG will additionally provide Warranty Repair Service in the United States on SAMSUNG products purchased in Canada, and in Canada on SAMSUNG products purchased in the United States, for the warranty period originally specified, and to the Original Purchaser only.
- Page 61 Contact SAMSUNG WORLD WIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. Samsung Hospitality Hotline 1-866-sam4biz (US) 1-800-749-0205 (CANADA) 1-800-726-7864 (MEXICO) Web site: http://www.samsung.com/us/business © 2017 Samsung Electronics America, Inc...
