Microsemi PD-5524G Midspan
PD-5524G
PD-RPS-450
User Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PD-5524G and is the answer not in the manual?

Questions and answers

Related Manuals for Microsemi PD-5524G

Summary of Contents for Microsemi PD-5524G

  • Page 1 Microsemi PD-5524G Midspan PD-5524G PD-RPS-450 User Guide...
  • Page 2 Microsemi reserves the right to make changes to products and to their specifications as described in this document, at any time, without prior notice. Do not photocopy or reproduce this material without permission.

  • Page 3: Table Of Contents

    4.3 Rack Mounting Brackets ................15 4.4 Installation Factors ..................15 4.5 Connecting Ethernet Cables ................. 16 4.6 Connecting Power Cables ................16 Copyright © July, 2011 Microsemi Page 3 CPG – PoE BU Rev.A02 One Enterprise Aliso Viejo, CA 92656 USA...
  • Page 4 8.2 Power Backup ....................25 8.3 Connectors....................26 8.4 Connecting Backup and Redundancy Connectors ........27 8.5 Power Backup and Power Redundancy Indications ........29 Copyright © July, 2011 Microsemi Page 4 CPG – PoE BU Rev.A02 One Enterprise Aliso Viejo, CA 92656 USA...

  • Page 5: Front Material

    1 Front Material 1.1 Model Numbers Definition:  PD-5524G/ACDC/M: 4 Pairs AC and DC Input Family Where: o AC: Midspan has AC input o DC: Midspan has DC input, current sharing, and power backup features between two Midspans o M: Midspan includes PowerView Pro (refer to Section ‎ 7 ) o F: Midspan enabled full power on all ports ...

  • Page 6: Safety Information

    When disposing this product, follow all local laws and regulations.  "DATA" and "DATA & POWER" ports of the Power over Ethernet Midspan, are shielded RJ-45 data sockets. They Copyright © July, 2011 Microsemi Page 6 CPG – PoE BU Rev.A02 One Enterprise Aliso Viejo, CA 92656 USA...

  • Page 7: Power Cord

    Type SV or SJ Three-conductor  Cord set must have a rated current capacity of at least 10A for PD-5524G/ACDC/M, The attachment plug must be an earth-grounding type with a NEMA 5-15P (15A, 125V) or NEMA 6-15P (15A, 250V) configuration.
  • Page 8 Neutral and connected directly to ground. Power over Ethernet Midspan is covered by General Approval NS/G/12345/J/100003, for indirect connection to a public telecommunications system. Copyright © July, 2011 Microsemi Page 8 CPG – PoE BU Rev.A02 One Enterprise Aliso Viejo, CA 92656 USA...

  • Page 9: About The Power Over Ethernet Midspan

    10/100/1000BaseTx Ethernet network, over TIA/EIA-568 category 5/5e/6 cabling. 5524G can provide up to 30W (or 36W in Extra Power mode). RPS family can provide backup or additional power to PD-5524G products. Power over Ethernet Midspan normally powers devices that are Power over Ethernet enabled or are equipped to receive power over Ethernet.

  • Page 10: 10/100/1000Base-Tx Ports Definition

     2-wire pairs (pins 1/2 and 3/6) (10/100Base-T)  PD-5524G series carry DC power over 4-wire pairs (pins 4/5, 7/8 and pins 1/2, 3/6) Power over Ethernet Midspan is not a repeater; therefore maximum distance from Ethernet switch must not exceed 100 meters (328 ft).

  • Page 11: Indicators

    ‎ receiving AC power. For additional information refer to Table 3 -1. 3.2.2 Port Indications The following sections detail PD-5524G port indicators. 3.2.2.1 PD-5524G Midspan Series: One bi-color indicator (green and yellow) per port displays port status:  Green indicates terminal unit (PD) has been identified as "Power over Ethernet Enabled";...

  • Page 12: Connectors

    (only if voltage range) should be taken power whenever possible. backup is connected) ‎ Table 3 -2: Port Status PD-5524G Midspan Port LED Port Load Port Voltage Color Conditions Power to port is Inactive load or disconnected. No DC voltage unplugged port present on port output lines.
  • Page 13 Each data port is configured, as shown in Figure Through” ports for all data pins (pins 1, 2, 3, 6, 4, 5, 7, and 8). Make sure you are using cabling of Category 5 or higher. Copyright © July, 2011 Microsemi Page 13 CPG – PoE BU Rev.A02...

  • Page 14: Power Over Ethernet Midspan Installation

    Switch’s data output terminals are connected to Midspan. Midspan delivers power over 4-wire twisted pairs (pins 7/8, 4/5 and pins 1/2, 3/6) in PD-5524G series of Category 5 cabling, without degrading data quality. Most installations require Midspan to be rack-mounted.

  • Page 15: Rack Mounting Brackets

    Therefore, install equipment in an environment compatible with Copyright © July, 2011 Microsemi Page 15 CPG – PoE BU Rev.A02 One Enterprise Aliso Viejo, CA 92656 USA...

  • Page 16: Connecting Ethernet Cables

    4.6 Connecting Power Cables When using an AC source to power Midspan, plug in the provided power cord to back AC connector. Copyright © July, 2011 Microsemi Page 16 CPG – PoE BU Rev.A02 One Enterprise Aliso Viejo, CA 92656 USA...

  • Page 17: Powering Up The Unit

    Power indicator remains lit in green; port indicators are off. Ports are now ready (enabled) for normal operation. If LEDs are not lit, refer to Troubleshooting on page 18. Copyright © July, 2011 Microsemi Page 17 CPG – PoE BU Rev.A02...

  • Page 18: Troubleshooting

     Ethernet cable to PD is connected to DATA & POWER port.  Cable pairs are attached to their corresponding ports. Copyright © July, 2011 Microsemi Page 18 CPG – PoE BU Rev.A02 One Enterprise Aliso Viejo, CA 92656 USA...

  • Page 19: Troubleshooting Steps

    RJ-45 connection. 7. Verify port shutdown command was not issued via Web management. Copyright © July, 2011 Microsemi Page 19 CPG – PoE BU Rev.A02 One Enterprise Aliso Viejo, CA 92656 USA...
  • Page 20 Midspan or on another one. If it works, there is probably a faulty port or faulty RJ-45 connection. Copyright © July, 2011 Microsemi Page 20 CPG – PoE BU Rev.A02 One Enterprise Aliso Viejo, CA 92656 USA...

  • Page 21: Specifications

    Storage Temperature -20 to +70°C (-4° to 158°F) Humidity 10 to 90% (non-condensing) 6.3 Electrical Specifications Parameter PD-5524G & PD-RPS-450 AC Input Voltage 100 to 240 VAC at 50/60Hz Input Current @ 100 VAC 5.5A max Input Current @ 240 VAC 2.75A max...
  • Page 22 PD-5524G, Parameter PD-RPS-450 DC Input Rated 53-57 Voltage Input DC Maximum Current Copyright © July, 2011 Microsemi Page 22 CPG – PoE BU Rev.A02 One Enterprise Aliso Viejo, CA 92656 USA...

  • Page 23: Microsemi's Powerview Pro

    7 Microsemi’s PowerView Pro Microsemi’s PowerView Pro is a secure remote management system offering real time monitoring and control, with graphical representation, status indicators, and alarms. PowerView Pro manages Midspans via an Internet browser interface or via a Network Management System (NMS).
  • Page 24  Multi-manager capabilities  Event and performance data recording  Runs on a PC platform with Windows graphic user interface (GUI) Copyright © July, 2011 Microsemi Page 24 CPG – PoE BU Rev.A02 One Enterprise Aliso Viejo, CA 92656 USA...

  • Page 25: Power Backup And Power Redundancy Connection

     Power Backup 8.1 Power Redundancy Microsemi's power redundancy mode is available in 5524G Midspan. This mode enables internal power supply backup for two Midspans connected to each other. This mode provides seamless failover between two Midspans. If one of the two Midspans' internal power supplies fails, failure is detected automatically and working power supply provides power to Midspan.

  • Page 26: Connectors

    PD-55XXG/ACDC/M PD-RPS-450 8.3 Connectors Power backup and power redundancy connectors are located on the back side of the Midspan. PD-5524G power backup and power redundancy have two connectors ‎ (see Figure 8 -1):  Power Backup and Power Redundancy Control Signal connector, RPS COM D-Sub: 15 pins, 3 rows female connector.

  • Page 27: Connecting Backup And Redundancy Connectors

    Terminal Block Sharing Control Signal Earth Ground Connection Connector Connection Figure ‎ 8 -1: PD-5524G Rear Panel Connectors 8.4 Connecting Backup and Redundancy Connectors WARNING: Before connecting one Midspan to another, disconnect both Midspans from AC main. Implement Power Backup and Power Redundancy modes by using PD- RPS-Cables Cable kit which includes DC Cable and RPS COM.
  • Page 28 If Power Indicator LED is not lit, refer to Troubleshooting on page 18. Note: ‎ RPS functionality can be monitored via NMS as described in Section Copyright © July, 2011 Microsemi Page 28 CPG – PoE BU Rev.A02 One Enterprise Aliso Viejo, CA 92656 USA...

  • Page 29: Power Backup And Power Redundancy Indications

    WA-0792-00N WA-0791-00N Figure ‎ 8 -2: PD-5524G Rear Panel connections 8.5 Power Backup and Power Redundancy Indications For information on NMS configuration refer to PowerView Pro user guide, catalog number 056-0051-06. During Power Backup and Power Redundancy, NMS View-Status window displays 'Power Source Status' field.
  • Page 30 Midspan provides another power fail indication via Midspan's Power Indicator LED; whenever unit's internal power supply fails, Power Indicator LED blinks once every second (Green LED). Unit Main LED Figure ‎ 8 -4: PD-5524G Front Panel LED Indication Copyright © July, 2011 Microsemi Page 30 CPG –...
  • Page 31 Microsemi If the recipient of this document has entered into a disclosure agreement with Microsemi, then the terms of such Agreement will also apply . This document and the information contained herein may not be modified, by any person other than authorized personnel of Microsemi.
