  • Page 1 SC 4000 Series 2008.02.20 Trademarks All brand and products names are trademarks or registered trademarks of their respective companies. For this manual is subject to change without notice...
  • Page 3 Preface © Copyright 2007 © All Rights Reserved. The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or...
  • Page 4 Do not leave this equipment in a non-temperature controlled environment; storage temperatures below 4°C (39°F) or above 35°C (95°F) may damage the unit. electric shock, which could cause personal injury, please follow all safety notices. The symbols shown are used in your documentation and on your equipment to indicate safety hazards.
  • Page 5 Outside the U.S.A. and Canada, the plug must be rated for 250 VAC, 2.5 amp minimum, and must display an international agency approval marking. The cord must be suitable for use in the end-user’s country. Consult your dealer or the local electrical authorities if you are unsure of the type of power cord to use in your country.
  • Page 6 Use only shielded I/O cables to connect I/O devices to this equipment. You are cautioned the changes or modifications not expressly approved by the party responsible for compliance could void your authority to use the equipment. This device complies with Part 15 of the FCC Rules.
  • Page 7 European Union CE Marking Declaration This product has been tested and found to comply with the EMC requirement subject to the EU directive for CE marking. CE Declaration of Conformity For the following equipment: Tablet PC 0984 Is herewith confirmed to comply with the requirements set out in the Council Directive on the Approximation of the Laws of the Member States relating to Electromagnetic Compatibility (89/336/EEC), Low-voltage...
  • Page 8 Inside the buildings with a power (WORSE *) maximum of 100 MW on all the frequency band 2400-2483,5 MHz, Outside the buildings with a power (WORSE *) maximum of 100 MW on the part 2400-2454MHz and with a power (WORSE *) maximum of 10 MW on the part 2454-2483MHz...

  • Page 9: Table Of Contents

    Table of Content 1: B HAPTER EFORE TART HAT TO DO EFORE 2: I ...3 HAPTER NTRODUCTION NTRODUCING YOUR OMPUTER ETTING TO OMPUTER 3: G HAPTER ETTING TARTED ...11 ETTING P THE OMPUTER NSERTING AND EMOVING THE ONNECTING THE OMPUTER TO AN ...15 SING THE TAND...
  • Page 10 9: T HAPTER ROUBLESHOOTING ENERAL ARDWARE ROBLEMS A: S ...63 PPENDIX PECIFICATION viii ...57 OSSIBLE AUSE AND OLUTION ..57...

  • Page 11: Chapter 1: Before You Start

    Before You Start This manual will help you get the most from your computer. If you are a less experienced user, you should read through the manual carefully before using your computer. Rapid changes in temperature such as those from the cold outdoors to a warm office would not be suitable for your system.
  • Page 12 Allow sufficient air circulation around the computer when you are working indoors Try to keep the system components from being destroyed if it is over heated Do not block the ventilation opening Do not place your computer in direct sunlight Your computer will run well under most conditions but avoid extreme temperatures and humidity levels.

  • Page 13: Chapter 2: Introduction

    Introduction Your computer features the latest advances in portable computing technology. The computer modular design provides maximum expandability without compromising portability. disassemble the Tablet PC and we will not be responsible for any damage caused by this action. The computer comes securely packaged in a shipping carton.

  • Page 14: Computer

    Do not throw the packaging materials away. You may need them later if you have to ship the computer. some of the features mentioned in this manual might not be included on your computer or may differ slightly. Battery Indicator Battery Indicator (Charging: Orange, Full w/ DC: Green, Full w/o DC: OFF) Wireless Indicator...
  • Page 15 HDD Indicator HDD Accessing (Blinking: Green color) Built-in Camera This is where the built-in camera located where you can use for any video conferencing application Rotation Screen/Vista Flip 3D LED Button This button will let you execute the Rotation Screen and Vista Flip 3D application.
  • Page 17 Finger Print Application The Tablet PC is equipped with the finger print application for security reason. Ventilation Opening Please don’t block this opening that serve as cooling purpose for the system. DC IN Jack Plug the AC adapter into this jack. PCMCIA or Express Card This compartment contains the system PCMCIA or...
  • Page 18 Scroll Application Use this dial jog to scroll up and down just like the way you use the application in scrolling up and down arrow key and Enter key of an ordinary keyboard. Power Slide Latch Slide this latch to power on the Tablet PC.
  • Page 19 in Plug and Play technology. Ethernet / LAN Port When using a LAN, please use an EMI Shielding Cable to minimize an interference when transmitting. Pen Compartment Secures the pen to the system. Battery Latch Slide this latch to release the battery.
  • Page 20 Memory Slot Compartment This serve as compartment for your system memory. Docking Port Use this port to connect to the system docking station. Wireless Module (MiniPCI-E Slot) This compartment is for your Wireless Module. Battery Compartment This serve as compartment for the battery.

  • Page 21: Chapter 3: Getting Started

    Getting Started Remove the computer from its package. Insert the battery pack into the computer so the pack can start charging. Connect the computer to an external power source. Turn on the computer. the front side of the battery is facing the top side of the system as shown in the illustration.
  • Page 22 Slide the battery latch as shown in the illustration Lift up the battery from the compartment. Pull out the battery away from its compartment.

  • Page 23: Connecting The Computer To An External Power Source

    To connect the computer to an external AC power source using the AC adapter: Plug the AC adapter cable into the AC power connector on the computer. Plug one end of the power cord into an electrical outlet and the other end into the AC adapter.
  • Page 24 to your computer, please do not use inferior extension cords. An AC adapter comes with your computer. Never use a different kind of adapter to power the computer or other electrical devices. Whenever possible, keep the AC adapter plugged into the computer and an electrical outlet to recharge the battery.

  • Page 25: Using The Stand

    The Tablet PC also provides you with a simple stand that you can use on a trip.

  • Page 27: Chapter 4: Using The Computer

    Using the Computer You can connect an external monitor through the VGA out port. ’ ’ The computer provides you with special hot keys to execute all the major functions that you like to run on your computer. twice until an orange light will lit up all these four LED button.
  • Page 28 Rotation Screen/Vista Flip 3D LED Button Use your fingertip to tap this LED button once to convert your screen display into landscape and portrait view. Your screen display will start rotating at 90 degrees clockwise angle until you prefer what angle that most suited for you to view.

  • Page 29: T B P System

    From the “Control Panel” scroll down to locate the “Tablet PC Settings” icon. Click on the “Buttons” tab. You can now change the control keys by clicking on the “Change” tab. Before using the computer on battery power for the first time, disconnect the power adapter and check the battery status icon on the Windows Toolbar to make sure the battery is fully charged.

  • Page 30: Automatic Battery Pack Charging Function

    Before using the battery pack for the first time, the Smart Battery IC within the battery pack should be calibrated in order to get accurate reporting of the remaining battery life status. To calibrate the battery pack, follow the instructions below: Turn the computer off.

  • Page 31: Using The Mobility Center

    Windows Vista has an applet in the Control Panel that will display an icon in the Windows taskbar indicating when the computer is running on battery power or is attached to the AC adapter. This applet also displays a meter that indicates how much charge is remaining in the battery.
  • Page 32 can be accessed from this menu. The brightness can be adjusted using the selection provided by the Mobility Center. Use can scroll to the right direction to increase your display brightness or scroll to the left direction to decrease the brightness. The volume can be adjusted using the selection provided by the Mobility Center.
  • Page 33 This application lets you turn on the wireless application in your system. As previously mentioned in rotating your screen display, this function is also use to rotate your screen the same as you are tapping the This function detects on the external display connected to your Tablet PC for dual screen display purposes.

  • Page 34: Pen Calibration

    If your cursor pointer does not function well, you can select the “Calibrate” function available in this system. From the “Control Panel” scroll down to locate the “Tablet PC Settings” icon. Click on the “Calibrate” tab. This setting will enable you to adjust the screen orientation.
  • Page 35 Use your pen to tap on the four corners that appears on the screen.

  • Page 37: Chapter 5: Using The Docking Station (Optional )

    Using the Docking Station (Optional) (1) Docking Port This connector is used to connect the computer when you are using any external additional peripherals to operate on your computer.

  • Page 38: Rear View

    DC IN Jack Plug the AC adapter into this jack. VGA Out Port Use this connect to connect an external monitor. USB Port Your computer includes two Universal Serial Bus (USB) 2.0 ports. USB2.0 is the latest development in Plug and Play technology.

  • Page 39: Side View

    Headphone Jack The stereo headphone jack (3.5-mm diameter) is where you connect the headphones or external speakers. USB Port Your computer includes two Universal Serial Bus (USB) 2.0 ports. USB2.0 is the latest development in Plug and Play technology.

  • Page 40: Connecting The Tablet Pc To The Docking Station

    Align the Tablet PC with its edge aligning to the two edges on the docking station Push back the Tablet PC with its connector directly connecting to the connector on the docking station. When operating your Tablet PC with the docking station installed, the power is supplied by the docking station’s power supply.

  • Page 41: Chapter 6: Upgrading Your System

    Upgrading Your System Turn your computer to let the bottom panel facing you. Locate the RAM compartment which is shown on the illustration. Unlock the two screws that attached to it. Lift up and remove the RAM compartment door. Use your left and right thumb to unlock the two...

  • Page 42: Upgrading The Wireless Module

    latches (shown in the illustration) to release the RAM. The RAM will be lifted once it is release in 15 degree angle. Pull out the RAM from its slot. Turn your computer to let the bottom panel facing you. Locate the MiniPCI card compartment which is shown on the illustration.

  • Page 43: Upgrading Your Hard Disk Drive

    Lift up and remove the MiniPCI card compartment door. Carefully release the card by unlocking the two connector Pull out the card away from its connector.
  • Page 44 We are not guarrantee 100% of market items can be support at T22x models of Tablet PC.

  • Page 45: Chapter 7: Trusted Platform Module

    Trusted Platform Module Trusted Platform Module (TPM) chips installed in each personal computer effecting anonymous internet use. This chip using the TPM technology may be used to make online transactions such as banking and shopping more secure, reducing identity theft and online fraud. The TPM, which is a processor chip sets as a discrete device, stores encryption keys in what’s been called an electronic, hardware-based lockbox.
  • Page 46 Connect USB keyboard first. While system boots at this screen, press F2 to enter BIOS Configuration Menu At TPM sets enable & activate TPM，...
  • Page 47 Save & Restart Confirm open the TPM...
  • Page 48 Help file location Help file contents...

  • Page 49: Efs (Encrypt File System )

    This function is not support for WINDOWS VISTA HOME PREMIUM, VISTA HOME BASIC AND XP HOME VERSION This application is used to prevent the transferring of file folder from your original computer to another computer. Right click on your mouse right button and select the “Encrypt”...
  • Page 50 Select the “Apply changes to this folder, subfolders and files” and click the “OK” tab. Select on the folder that you wish to change. A window will be displayed on your screen denying any access to the folder that you wish to change.

  • Page 51: Personal Secure Drive

    This application prevents the transferring of the HDD files being shown on another computer appearing as hidden files. You can create your own files you save and set security for any unauthorized use. Since it is protected on a TPM application, the security is higher than those you save using any software application for security purposes.

  • Page 52: Tpm Recovery

    There are some certain circumstances to execute this application: Unable to use the TPM properly, re-change the TPM application. Re-change the TPM chips due. TPM loses all security information Press the TPM icon. The screen will enter the “Infineon Security Platform Installation Wizard”.
  • Page 53 Select the “Security Platform restoration from a Backup Archieve” item and click on the “Next” tab. Select the “New Trusted Platform Module” item and click on the “Next” button.
  • Page 54 Click on the “Browse” tab and select the “SPSystemBacktup” item and click on the “Open” tab. Enter your new password.
  • Page 55 Click on the “Browse” tab and select the “SPEmRec Token” item and click on the “Next” tab.
  • Page 56 Confirm your password for the selected “Token” and click on the “Next” tab. The item is selected and click on the “Next” tab.
  • Page 57 Select on the password for the “Basic User” and click on the “Next” tab. Click on the “OK” tab.
  • Page 58 Click on the “Next” tab to complete the process. The Security Platform is ready to use.

  • Page 59: Chapter 8: Finger Print

    Finger Print The system’s Fingerprint application offers a secure and convenient system for managing your passwords and providing your sensitive data for confidentiality through file encryption. From “Start”, click on the “Control Panel” and select the “User Account and Family Safety” , and then select “User Account”...
  • Page 60 Choose “Create a password for your account”...
  • Page 61 Enter your password. From your system screen, click on the fingerprint icon to activate the application and setting your password.
  • Page 62 Click on the “Next” button. Select the “I accept the terms in the license agreement”, Click on the “Next” button.
  • Page 63 After select install path, Click on the “Next” button. Input User name, Click on the “OK” button.
  • Page 64 Select on the finger that you will set for your fingerprint identification. Swipe your finger to set the fingerprint.
  • Page 65 the sensor to achieve the best contact. Start swiping your finger from the bend closest to the fingertip. Do not lift your finger as you swipe over the sensor. You will be allowed to perform the test 5 times. Complete the setting, must to restart the system Help file location Position your finger to the center of...
  • Page 66 Help file contents...

  • Page 67: Troubleshooting

    Troubleshooting This chapter describes locating and solving problems that you may encounter while using your computer. A few common hardware problems and suggested solutions are presented in the table below: An error occurs during program currently being used. Press the SAS key of your Tablet PC. Solution: An error with the Windows OS.
  • Page 68 Solution: Adjust the LCD brightness. Press the Mobility Center button and click on Brightness Up or Brightness Down. Solution: Connect the computer to an external power source immediately. Solution: Press and hold the power button for 4~6 seconds until the system shutdown manually. The system will turn after connecting the AC adapter, this indicates the battery is in low status.
  • Page 69 Solution: The reason may be caused by channel interference, change the channel of the AP and reconnect. Solution: Account for Internet service provider (ISP) is not properly configured. Ask for your ISP assistance. Solution: Check the device driver is properly installed. Check that the device driver is properly installed.
  • Page 70 If you still have a problem after reading the preceding section, the next step is to contact your dealer. Your dealer can determine if the problem is something that requires the computer to be taken to the shop. Before you call your dealer, however, please have the following information available: Solution: How is your computer configured? Your dealer...
  • Page 71 As a special reminder, be sure not to put the computer inside the carry bag that has stain in sending the computer for repair ’ ’ Solution: Malfunction of external memory or internal memory – an error will occur during saving into the system memory, it will not execute normal operation External peripheral connected to the system not compatible –...
  • Page 73 Specification Core 2 Duo (ULV)-- 533 MHz FSB, 2M L2 Cache (U7500 /1.06G) Micro-FCBGA onboard Heat Sink with PWM FAN Maximum 1 FAN 945GM +ICH7-M GMA 950 Integrated 945GM (Simultaneous and multi-monitor ) High Definition Audio 2x SODIMM Slot, Double channel, DDR2 533/667...
  • Page 74 4GB Maximum (1GB default) BIOS includes System & Video Boot from USB Plug & Play APM 1.2 ACPI 2.0 Re-chargeable Lithium Ion Battery Pack (Prismatic Cell) 3S2P -- 45W 60GB~120GB 2.5” 9.5mm height 5400 RPM SATA Ultra DMA 12.1” XGA TFT (1024*768) Brightness (cd/㎡) : 220 nits (typ) Sun-Light readable LCD Option 1.3 M USB Camera Buit in...
  • Page 75 Intel® PRO/Wireless 3945 ABG Network Connection(Mini-PCIe) or others compatible wireless LAN cards. 10/100/1000 Fast-Ethernet (RJ45) --- Giga Lan Upgrade USB Blue Tooth 2.0 Module build in Resistive touch screen w/o Plam rejection Digitizer TPM 1.2 1 x DC-IN Jack 1 x Headphone Jack (3.5mm) 1x Stereo Mic Jack 2 x 4-pin USB 2.0 Port 1 x Cardbus PC Card or new card...
  • Page 76 Battery Indicator (Charging : Orange, Full w/ DC : Green, Full w/o DC : OFF) HDD Accessing (Blinking in Green) Wireless Status (ON : Blue) Bluetooth* 1 Wireless* 2 Slide SW for Power SAS (Ctrl+Alt+Del) Internet Explorer Mobility Center Rotation Wireless &...
  • Page 77 AC 100~240Volt, 60-65W 3S2P -- 45W Smart Charger Support for ACPI 2.0 About 310 * 250 mm, thickness = 21.8mm 3.4 Lbs –1.56 kg VESA Mounting Hole (75*75 or 100*100) Pen holder Simple Stand (Use VESA Hole) AC-DC Adapter 65W Carry Bag Quick Guide (Other language Verison Provide by Customer)
