- Page 1 Air conditioner User manual AJ***NBNDEH • Thank you for purchasing this Samsung air conditioner. • Before operating this unit, please read this user manual carefully and retain it for future reference. DB68-07757A-01...
-
Page 2: Table Of Contents
Business users should contact their supplier and check the terms and conditions of the purchase contract. This product and its electronic accessories should not be mixed with other commercial wastes for disposal. For information on Samsung’s environmental commitments and product-specific regulatory obligations, e.g. REACH, WEEE, Batteries, visit : samsung.com/uk/aboutsamsung/samsungelectronics/corporatecitizenship/data_corner.html... -
Page 3: Safety Information
If you have any questions, call your nearest contact centre or find help and information online at www.samsung.com. WARNING Hazards or unsafe practices that may result in severe personal injury or death. - Page 4 Safety Information The installation of this appliance must be performed by a qualified technician or service company. • Failing to do so may result in electric shock, fire, explosion, problems with the product, or injury. Install a switch and circuit breaker dedicated to the air conditioner. •...
- Page 5 CAUTION Install your appliance on a level and hard floor that can support its weight. • Failing to do so may result in abnormal vibrations, noise, or problems with the product. Install the drain hose properly so that water is drained correctly. •...
- Page 6 Safety Information FOR USING WARNING If the appliance is flooded, please contact your nearest service centre. • Failing to do so may result in electric shock or fire. If the appliance generates a strange noise, a burning smell or smoke, unplug the power plug immediately and contact your nearest service centre.
- Page 7 After unpacking the air conditioner, keep all packaging materials well out of the reach of children, as packaging materials can be dangerous to children. • If a child places a bag over its head, it may result in suffocation. Do not touch the front panel with your hands or fingers during the heating operation.
- Page 8 Safety Information CAUTION Do not place objects or devices under the indoor unit. • Water dripping from the indoor unit may result in fire or property damage. Check that the installation frame of the outdoor unit is not broken at least once a year.
- Page 9 This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance.
-
Page 10: At A Glance
Indoor Unit Overview The indoor unit and its display may look slightly different from the illustration shown below, depending on the model and the panel type. 01 Display Indication Function On/Off operation indicator Removing frost indicator Timer indicator Filter cleaning indicator Remote control sensor 02 Air flow blade/Air outlet (inside) / Wind-Free panel... -
Page 11: Operation Features
Operation Features Operating temperature and humidity When using the air conditioner follow the operating temperature and humidity ranges. Outdoor Indoor Indoor Mode If out of conditions temperature temperature humidity Condensation may occur on the indoor Cool 16˚C to 32˚C 80% or less unit with risk to have either water blow mode off or drop on the floor. -
Page 12: Cleaning And Maintenance
Cleaning and Maintaining Before cleaning the indoor unit, be sure to turn off the auxiliary power switch. Cleaning the indoor unit exterior Wipe the surface of the unit with a slightly wet or dry cloth when needed. Wipe off dirt of odd- shaped areas by using a soft brush. - Page 13 NOTE • The hooks are located on both sides of the front grill with the Samsung logo. Pull out the air filter from the indoor unit. 2 Cleaning the air filter Clean the air filter with a vacuum cleaner or soft brush.
- Page 14 Cleaning and Maintaining 3 Reassembling the air filter CAUTION • If the indoor unit is used without the air filter, the indoor unit may be damaged due to dust. 4 Resetting the air filter (Wired remote control is an optional item) After cleaning and reassembling the air filter, be sure to reset the filter-cleaning reminder as follows:...
- Page 15 Periodical maintenance Requires qualified Unit Maintenance item Interval technicians Clean the air filter. At least once a month Clean the condensate drain pan. Once a year Required Indoor Clean up the heat exchange. Once a year Required unit Clean the condensate drain pipe. Once every 4 months Required Replace the remote control batteries.
- Page 16 Cleaning and Maintaining Troubleshooting Refer to the following chart if the air conditioner operates abnormally. This may save time and unnecessary expense. Problem Solution The air conditioner • Because of the protective mechanism, the appliance does not start does not operate operating immediately to keep the unit from overloading.
- Page 17 Problem Solution • A bubbling sound may be heard when the refrigerant is circulating The air conditioner through the compressor. Let the air conditioner operate in a selected mode. makes a bubbling • When you press the Power button on the remote control, noise may be sound.
-
Page 18: Information About Refrigerant
Information about refrigerant Important information: regulation regarding the refrigerant used This product contains fluorinated greenhouse gases. Do not vent gases into the atmosphere. CAUTION • If the system contains 5 tCO e or more of fluorinated greenhouse gases, it must be checked for leakage at least once every 12 months, according to regulation No. - Page 19 English...
- Page 20 *8000 (apel in retea) ROMANIA www.samsung.com/ro/support 08008-726-78-64 (08008-SAMSUNG) Apel GRATUIT CYPRUS 8009 4000 only from landline, toll free www.samsung.com/gr/support 80111-SAMSUNG (80111 726 7864) only from land line GREECE www.samsung.com/gr/support (+30) 210 6897691 from mobile and land line LITHUANIA 8-800-77777 www.samsung.com/lt/support...
