OWNER'S MANUAL
LCD MONITOR
Please read this manual carefully before operating your set and
retain it for future reference.
LCD MONITOR MODEL
E2722PY
www.lg.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E2722PY and is the answer not in the manual?

Questions and answers

Related Manuals for LG E2722PY

Summary of Contents for LG E2722PY

  • Page 1 OWNER’S MANUAL LCD MONITOR Please read this manual carefully before operating your set and retain it for future reference. LCD MONITOR MODEL E2722PY www.lg.com...

  • Page 2: Important Precautions

    Important Precautions This unit has been engineered and manufactured to ensure your personal safety, however improper use may result in potential electrical shock or fire hazards. In order to allow the proper operation of all safeguards incorporated in this display, observe the following basic rules for its installation, use, and servicing.
  • Page 3 Important Precautions On Installation Do not allow anything to rest upon or roll over the power cord, and do not place the display where the power cord is subject to damage. Do not use this display near water such as near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool.
  • Page 4 Important Precautions On Cleaning Unplug the display before cleaning the face of the display screen. Use a slightly damp (not wet) cloth. Do not use an aerosol directly on the display screen because over-spraying may cause electrical shock. When cleaning the product, unplug the power cord and scrub gently with a soft cloth to prevent scratching.
  • Page 5 Accessories !!! Thank for selecting LGE products !!! Please make sure the following items are included with your monitor. If any items are missing, contact your dealer. Power Cord User's Guide/Cards 15-pin D-Sub Signal Cable DVI-D Signal Cable (To set it up, this signal cable may be (This feature is not available in all attached to this product before countries.)

  • Page 6: Connecting The Display

    Connecting the Display Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices are turned off. Connecting the stand base or Removing the stand base Place the monitor with its front facing downward on a cushion or soft cloth. Align the hooks on the Stand Body with the matching slots in the Stand Base.
  • Page 7 Connecting the Display Attach the monitor to the Stand Base by turning the screw to the right. Screw : Turn the screw by using the screw handle. Lift and turn the monitor to face towards the front after the connection is made to the female part of the cable you're attaching.

  • Page 8: Positioning Your Display

    Connecting the Display Positioning your display After installation, adjust the angle as shown below. Adjust the position of the panel in various ways for maximum comfort. Tilt Range Swivel Range : 355˚ Height Range : maximum 3.93 inches (100.0 mm) 100.0 mm * Please be sure to remove the Locking...
  • Page 9 Connecting the Display When adjusting the angle of the screen, do not put your finger(s) in between the head of the monitor and the stand body. You can hurt your finger(s). When adjusting the height of the screen, do not put your finger(s) in between the head of the monitor and the stand base.

  • Page 10: Using The Pivot Function

    Connecting the Display Using the Pivot function -The pivot function allows you to rotate the screen 90 degrees clockwise. Lift the monitor to its highest height to utilize the Pivot function. . Landscape & Portrait : You can rotate the panel 90 clockwise.

  • Page 11: Connecting With The Pc

    Connecting the Display Connecting with the PC Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. Connect signal input cable and power cord in order, then tighten the screw of the signal cable.
  • Page 12 Connecting the Display Press the power button on the front panel to turn the power on. When monitor power is turned on, the 'Self Image Setting Function' is executed automatically. (Only Analog Mode) Power Button NOTE ‘ Self Image Setting Function’? This function provides the user with optimal display settings.When the user connects the monitor for the first time, this function automatically adjusts the display to optimal settings for individual input signals.

  • Page 13: To Arrange The Cables

    Connecting the Display To arrange the cables Connect the power cord and the signal cable as shown in the figure and then fix them to the cable holders 1 and 2. Please put the power cord and Please insert the cable holder1 into the hole.

  • Page 14: Connecting The Usb(Universal Serial Bus) Cable

    Connecting the Display Connecting the USB(Universal Serial Bus) Cable You can use the USB port at the back of the monitor to connect peripherals (USB mouse, USB keyboard, etc.) to the monitor, not to the computer. Two USB Downstream ports Connect these ports to a mouse, USB keyboard,memory stick with current spec under 100mA.

  • Page 15: Control Panel Functions

    Control Panel Functions Front Panel Controls MENU Button OSD LOCKED/UNLOCKED This function allows you to lock the current control settings, so that they cannot be inadvertently changed. Press and hold the MENU button for several seconds. The message "OSD LOCKED" should appear. You can unlock the OSD controls at any time by pushing the MENU button for several seconds.
  • Page 16 (display mode). The best display mode is E2722PY : 1920 x 1080 When two input signals are connected, you can select the INPUT Button input signal (D-SUB/DVI/DP) you want. When only one (SOURCE Hot key) signal is connected, it is automatically detected.

  • Page 17: On Screen Display (Osd) Control Adjustment

    On Screen Display (OSD) Control Adjustment Screen Adjustment Making adjustments to the image size, position and operating parameters of the display is quick and easy with the On Screen Display Control system. A short example is given below to familiarize you with the use of the controls.

  • Page 18: On Screen Display(Osd) Selection And Adjustment

    On Screen Display(OSD) Selection and Adjustment The following table indicates all the On Screen Display control, adjustment, and setting menus. : D-SUB(Analog signal) input DSUB : DVI-D(Digital signal) input DVI-D : DP(DisplayPort signal) input Main menu Sub-menu Supported input Description MENU To adjust the volume VOLUME...
  • Page 19 On Screen Display(OSD) Selection and Adjustment You were introduced to the procedure of selecting and adjusting an item using the OSD system. Listed below are the icons, icon names, and icon descriptions of the all items shown on the Menu. Press the MENU Button, then the main menu of the OSD appears.
  • Page 20 On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description To adjust the volume of headphone/Speaker. To adjust the brightness of the screen. WIDE Switch to full screen mode according to input image signal. ORIGINAL Change the input image signal ratio to original.
  • Page 21 On Screen Display(OSD) Selection and Adjustment Main menu Description To adjust the contrast of the screen. (only for DP input) You can set the offset level. If you select 'HIGH', the screen will be bright and if you select ‘LOW’, the screen will be dark. * Offset? As the criteria for video signal, it is the darkest screen the monitor can show.
  • Page 22 On Screen Display(OSD) Selection and Adjustment You were introduced to the procedure of selecting and adjusting an item using the OSD system. Listed below are the icons, icon names, and icon descriptions of the all items shown on the Menu. Press the SUPER ENERGY SAVING Button, then the main menu of the OSD appears.
  • Page 23 On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description Turn on the SUPER ENERGY SAVING fuction. When current setting value is ON,the SUPER SAVING color is green. Turn off the SUPER ENERGY SAVING function.Now the monitor is LED SAVING function. When current setting value is OFF,the SUPER SAVING color is gray.
  • Page 24 Saving Data depends on the Panel. So,those values should be different from each panel and panel vendor. LG accumulate those values using integrated function with 10 minutes broadcast video signal. LED Saving means that how much power can be saved using WLED Panel instead of CCFL panel.

  • Page 25: Troubleshooting

    Troubleshooting Check the following before calling for service. No image appears No image appears Is the power cord of the • Check and see if the power cord is connected display connected? properly to the power outlet. Is the power indicator •...

  • Page 26: Display Image Is Incorrect

    • Be sure to install the display driver from the display display driver? driver CD (or diskette) that comes with your display. Or, you can also download the driver from our web site: http://www.lg.com. • Make sure to check if the video card supports Plug&Play function.

  • Page 27: Specifications

    Specifications Display 68.6 cm (27 inch) Flat Panel Active matrix-TFT LCD Anti-Glare coating Visible diagonal size : 68.6 cm 0.3114 x 0.3114 mm (Pixel pitch) Horizontal Freq. 30 kHz to 83 kHz (Automatic) Sync Input Vertical Freq. Analog,Digital:56 Hz to 75 Hz (Automatic) DisplayPort:56 Hz to 61 Hz (Automatic) Input Form Separate Sync.
  • Page 28 Specifications Operating Conditions Environment Temperature 10 ˚C to 35 ˚C al Conditions Humidity 10 % to 80 % non-Condensing Storage Conditions Temperature -20 ˚C to 60 ˚C Humidity 5 % to 90 % non-Condensing Attached ( ), Detached ( O ) Stand Base Power cord Wall-outlet type...

  • Page 29: Preset Modes (Resolution)

    Specifications Preset Modes (Resolution) E2722PY Display Modes (Resolution) Horizontal Freq. (kHz) Vertical Freq. (Hz) 31.468 720 x 400 31.469 640 x 480 37.500 640 x 480 37.879 800 x 600 46.875 800 x 600 48.363 1024 x 768 60.023 1024 x 768 67.500...

  • Page 30: Installing The Wall Mount Plate

    Installing the Wall mount plate This monitor satisfies the specifications of the Wall mount plate or the interchange device. After moving the product to face downward, make sure to place it on a soft cloth or a cushion to avoid surface damage.
  • Page 31 Installing the Wall mount plate Install the Wall mount plate. Wall mount plate(Separate purchase) This is stand-type or wall mount type and is connectable with Wall mount plate. Please refer to the installation guide for more details, which is provided when Wall mount plate is purchased.
  • Page 32 Make sure to read the Safety Precautions before using the product. Keep the OWNER’S MANUAL(CD) in an accessible place for furture reference. The model and serial number of the SET is ENERGY STAR is a set of power-saving located on the back or one side of the SET. guidelines issued by the U.S.Environmental Record it below should you ever need service.
