OWNER'S MANUAL
LED LCD MONITOR
Please read this manual carefully before operating
your set and retain it for future reference.
LED LCD MONITOR MODELS
E2370V
E2770V
www.lg.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E2370V-BF and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for LG E2370V-BF

Summary of Contents for LG E2370V-BF

  • Page 1 OWNER’S MANUAL LED LCD MONITOR Please read this manual carefully before operating your set and retain it for future reference. LED LCD MONITOR MODELS E2370V E2770V www.lg.com...

  • Page 2: Important Precautions

    Important Precautions This unit has been engineered and manufactured to ensure your personal safety, however improper use may result in potential electrical shock or fire hazards. In order to allow the proper operation of all safeguards incorporated in this display, observe the following basic rules for its installation, use, and servicing.
  • Page 3 Important Precautions On Installation Do not allow anything to rest upon or roll over the power cord, and do not place the display where the power cord is subject to damage. Do not use this display near water such as near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool.

  • Page 4: On Cleaning

    Important Precautions On Cleaning Unplug the display before cleaning the face of the display screen. Use a slightly damp (not wet) cloth. Do not use an aerosol directly on the display screen because over-spraying may cause electrical shock. When cleaning the product, unplug the power cord and scrub gently with a soft cloth to prevent scratching.
  • Page 5 Accessories !!! Thank you for selecting LGE products !!! Please make sure the following items are included with your monitor. If any items are missing, contact your dealer. Owner's Manual/Cards 15-pin D-Sub Signal Cable Remote control NOTE This accessories may look different from those shown here. User must use shielded signal interface cables (D-sub 15 pin cable, DVI-D cable) with ferrite cores to maintain standard compliance for the product.

  • Page 6: Connecting The Display

    Connecting the Display Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. Connecting the stand Place the monitor face down on the cushion or soft cloth. Assemble the Stand Base into the Stand Body in the correct direction as shown in the picture. Stand Body Stand Base Use a Coin on the bottom of the stand base and turn screw clockwise to tighten.

  • Page 7: Positioning Your Display

    Connecting the Display Detach the monitor to the Stand Base by turning the screw to the left. IMPORTANT This illustration depicts the general model of connection. Your monitor may differ from the items shown in the picture. Do not carry the product upside down holding only the stand base. The product may fall and get damaged or injure your foot.

  • Page 8: Connecting With The Pc

    Connecting the Display Connecting with the PC Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. Connect signal input cable of the signal cable. Connect DVI-D(Digital signal) Cable Connect D-sub(Analog signal) Cable Connect HDMI Cable NOTE...
  • Page 9 Connecting the Display Press the power button on the bottom right of the monitor to turn the power on. When monitor power is turned on, the 'Self Image Setting Function' is executed automatically. (Only Analog Mode) NOTE ‘ Self Image Setting Function’? This function provides the user with optimal display settings.When the user connects the monitor for the first time, this function automatically adjusts the display to optimal settings for individual input signals.

  • Page 10: Remote Control Functions

    Remote Control Functions Remote Control Controls Replacing the Remote Control Battery Button Use this button to turn the display on or off. Input Button Use this button to select the input signal. (D-SUB/DVI-D/HDMI1/HDMI2) User Mode Use this button to select the User Mode.

  • Page 11: Control Panel Functions

    Control Panel Functions Front Panel Controls G-MODE Button INPUT Button (SOURCE Hot key) Use this button to enter USER MODE, THRU MODE, SUPER+ RESOLUTION, ASPECT RATIO or AUTO BRIGHT menus. For more information, refer to page 15 to 20. When two input signals at least are connected, you can select the input signal (D-SUB/DVI-D/HDMI1/HDMI2) you want.
  • Page 12 Control Panel Functions MENU Button AUTO Button VOLUME Button EXIT Button Power Button & Power Indicator OSD LOCKED/UNLOCKED This function allows you to lock the current control settings, so that they cannot be inadvertently changed. Press and hold the MENU button for several seconds. The message "OSD LOCKED"...

  • Page 13: On Screen Display (Osd) Control Adjustment

    On Screen Display (OSD) Control Adjustment Screen Adjustment Making adjustments to the image size, position and operating parameters of the display is quick and easy with the On Screen Display Control system. A short example is given below to familiarize you with the use of the controls.

  • Page 14: On Screen Display(Osd) Selection And Adjustment

    On Screen Display(OSD) Selection and Adjustment The following table indicates all the On Screen Display control, adjustment, and setting menus. Main menu G-MODE USER MODE THRU MODE SUPER+ RESOLUTION ASPECT RATIO AUTO BRIGHT INPUT D-SUB DVI-D HDMI 1 HDMI 2 BRIGHTNESS PICTURE CONTRAST...
  • Page 15 On Screen Display(OSD) Selection and Adjustment HORIZONTAL DISPLAY VERTICAL CLOCK PHASE OVERSCAN OTHERS LANGUAGE WHITE BALANCE POWER INDICATOR FACTORY RESET PIP ON / OFF PIP INPUT PIP POSITION PIP SWAP PIP SOUND PIP VOLUME NOTE The order of icons may differ depending on the model (13 to 28). To adjust the position of the D-SUB screen...
  • Page 16 On Screen Display(OSD) Selection and Adjustment You were introduced to the procedure of selecting and adjusting an item using the OSD system. Listed below are the icons, icon names, and icon descriptions of the all items shown on the Menu. Press the G-MODE Button, then the main menu of the OSD appears.
  • Page 17 On Screen Display(OSD) Selection and Adjustment This menu allows you to easily customize the settings to your preferences, such as Brightness, SUPER+ RESOLUTION, and screen Aspect Ratio. Once set, you can select the optimized mode depending on your preferences. Main menu USER MODE USER MODE G-MODE...
  • Page 18 On Screen Display(OSD) Selection and Adjustment Main menu THRU MODE THRU MODE G-MODE G-MODE THRU MODE THRU MODE G-MODE THRU MODE G-MODE G-MODE THRU MODE THRU MODE G-MODE THRU MODE : Move to the upper menu : Move EXIT : Exit * Frame buffer must be used for PIP, screen aspect ratio, and HDMI video signal input.
  • Page 19 On Screen Display(OSD) Selection and Adjustment Main menu SUPER+ RESOLUTION SUPER+ RESOLUTION G-MODE G-MODE SUPER+ RESOLUTION SUPER+ RESOLUTION G-MODE SUPER+ RESOLUTION G-MODE G-MODE SUPER+ RESOLUTION SUPER+ RESOLUTION G-MODE SUPER+ RESOLUTION G-MODE G-MODE SUPER+ RESOLUTION SUPER+ RESOLUTION G-MODE SUPER+ RESOLUTION G-MODE G-MODE SUPER+ RESOLUTION SUPER+ RESOLUTION...
  • Page 20 On Screen Display(OSD) Selection and Adjustment Main menu ASPECT RATIO ASPECT RATIO G-MODE G-MODE ASPECT ASPECT RA RATIO G-MODE ASPECT RATIO FULL ORIGINAL ORIGINAL FULL ORIGINAL G-MODE G-MODE ASPECT RA ASPECT RATIO G-MODE ASPECT RATIO FULL FULL ORIGINAL FULL ORIGINAL G-MODE G-MODE ASPECT...
  • Page 21 On Screen Display(OSD) Selection and Adjustment Main menu AUTO BRIGHT AUTO BRIGHT AUTO BRIGHT G-MODE G-MODE AUTO BRIGHT O BRIGHT G-MODE AUTO BRIGHT G-MODE AUTO BRIGHT G-MODE AUTO BRIGHT G-MODE AUTO BRIGHT G-MODE G-MODE AUTO BRIGHT O BRIGHT : Move to the upper menu : Move EXIT : Exit G-MODE...

  • Page 22: The Monitor

    On Screen Display(OSD) Selection and Adjustment The OSD screen will appear when you press the INPUT button on the front of the monitor. Menu Name Sub-menu Name Button Tip Main menu INPUT INPUT INPUT INPUT INPUT D-SUB D-SUB DVI-D DVI-D D-SUB DVI-D D-SUB...
  • Page 23 On Screen Display(OSD) Selection and Adjustment You were introduced to the procedure of selecting and adjusting an item using the OSD system. Listed below are the icons, icon names, and icon descriptions of the all items shown on the Menu. Press the MENU Button, then the main menu of the OSD appears.
  • Page 24 On Screen Display(OSD) Selection and Adjustment Main menu D-SUB/DVI-D input HDMI input : Move to the upper menu : Decrease : Increase : Select another sub-menu EXIT : Exit WARM WARM GAMMA 2 GAMMA 2 WARM WARM GAMMA 2 GAMMA 2 Sub menu Description To adjust the brightness of the...

  • Page 25: Main Menu

    On Screen Display(OSD) Selection and Adjustment Main menu PRESET Mode WARM WARM GAMMA 2 GAMMA 2 USER Mode WARM WARM WARM GAMMA 2 GAMMA 2 D-SUB/DVI-D input HDMI input : Move to the upper menu : Decrease : Increase : Select another sub-menu EXIT : Exit Sub menu Description...
  • Page 26 On Screen Display(OSD) Selection and Adjustment Main menu D-SUB input HDMI input : Move to the upper menu : Decrease : Increase : Select another sub-menu EXIT : Exit Sub menu Description To move image left and right. HORIZONTAL To move image up and down. VERTICAL To minimize any vertical bars or stripes CLOCK...
  • Page 27 On Screen Display(OSD) Selection and Adjustment Main menu D-SUB input HDMI/DVI-D input : Move to the upper menu : Decrease : Increase : Select another sub-menu EXIT : Exit PIP ON / OFF PIP INPUT PIP ON / OFF PIP POSITION PIP INPUT PIP SWAP NOTE...
  • Page 28 On Screen Display(OSD) Selection and Adjustment Main menu D-SUB/DVI-D input PIP ON / OFF PIP ON / OFF PIP INPUT PIP INPUT PIP INPUT DVI-D PIP POSITION PIP POSITION PIP POSITION PIP SWAP PIP SWAP PIP SWAP PIP SOUND PIP SOUND PIP SOUND PIP VOLUME PIP VOLUME...
  • Page 29 On Screen Display(OSD) Selection and Adjustment The OSD screen will appear when you press the VOLUME button on the front of the monitor. Menu Name Sub-menu Name Button Tip Main menu HDMI input Sub menu Description VOLUME To adjust the volume of headphone/ Earphone.

  • Page 30: Troubleshooting

    Troubleshooting Check the following before calling for service. No image appears No image appears Is the power cord of the display connected? Is the power indicator light on? Is the power indicator blinking? Do you see an "OUT OF RANGE" message on the screen? Do you see a "CHECK SIGNAL CABLE"...

  • Page 31: Display Image Is Incorrect

    Troubleshooting Display image is incorrect Display Position is incorrect. On the screen background, vertical bars or stripes are visible. Any horizontal noise appearing in any image or characters are not clearly portrayed. IMPORTANT Check Control Panel --> Display --> Settings and see if the frequency or the resolution were changed.

  • Page 32: The Audio Function Is Not Working

    • Be sure to install the display driver from the display driver CD (or diskette) that comes with your display. Or, you can also download the driver from our web site: http://www.lg.com. • Make sure to check if the video card supports Plug&Play function.

  • Page 33: Specifications

    Specifications Display 58.42 cm (23 inch) Flat Panel Active matrix-TFT LCD Anti-Glare coating Visible diagonal size : 58.42 cm 0.2652 mm x 0.2652 mm (Pixel pitch) Horizontal Freq. Sync Input Vertical Freq. Input Form Signal Input Video Input Input Form Resolution Recommend Plug&Play...
  • Page 34 Specifications Display 68.6 cm (27 inch) Flat Panel Active matrix-TFT LCD Anti-Glare coating Visible diagonal size : 68.6 cm 0.3114 mm x 0.3114 mm (Pixel pitch) Horizontal Freq. Sync Input Vertical Freq. Input Form Signal Input Video Input Input Form Resolution Recommend Plug&Play...

  • Page 35: Preset Modes (Resolution)

    Specifications Preset Modes (Resolution) D-SUB/DVI-D Timing Display Modes (Resolution) 640 x 350 720 x 400 640 x 480 640 x 480 800 x 600 800 x 600 1024 x 768 1024 x 768 1152 x 864 1280 x 1024 1280 x 1024 1680 x 1050 1680 x 1050 1920 x 1080...

  • Page 36: Installing The Wall Mount Plate

    Installing the Wall mount plate This monitor satisfies the specifications of the Wall mount plate or the interchange device. Place the monitor face down on the cushion or soft cloth. To remove the Stand Base from the Stand Body, turn the screw counterclockwise using a coin.
  • Page 37 Installing the Wall mount plate Install the Wall mount plate. Wall mount plate(Separate purchase) This is stand-type or wall mount type and is connectable with Wall mount plate. Please refer to the installation guide for more details, which is provided when Wall mount plate is purchased.
  • Page 38 Make sure to read the Important Precautions before using the product. Ke e p t h e O w n e r ’ s M a n u a l (C D ) i n a n accessible place for future reference. The model and serial number of the SET is located on the back and one side of the SET.

This manual is also suitable for:

E2770vE2770v-bfE2370v
