SOL8SDR-P Quick Start Guide
No
Item
1
Lemo 4-way jack
2
RJ45 8-way jack
3
SMA 50 ohm jack
4
SMA 50 ohm jack
5
DIN 1.0/2.3 jack
6
DIN 1.0/2.3 jack
Revision 1.0
Connection
Connect 12V power via CA0002 or CA3172.
Connect to a PC or network Ethernet port.
RF-A COFDM antenna.
RF-B COFDM antenna.
SDI-1 video input. Connect CA2396 DIN 1.0/2.3 to BNC adaptor.
SDI-2 video input. Connect CA2396 DIN 1.0/2.3 to BNC adaptor.
Page 1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for DTC SOL8SDR-P
Summary of Contents for DTC SOL8SDR-P
- Page 1 SOL8SDR-P Quick Start Guide Item Connection Lemo 4-way jack Connect 12V power via CA0002 or CA3172. RJ45 8-way jack Connect to a PC or network Ethernet port. SMA 50 ohm jack RF-A COFDM antenna. SMA 50 ohm jack RF-B COFDM antenna.
- Page 2 SOL8SDR-P Quick Start Guide The SOL8SDR-P IP address can be established using DTC’s Node Finder application. If DHCP settings need to be disabled and a fixed address applied, right click on the device to reconfigure. Double click the device on Node Finder to open web browser communications.
