Operating Instructions
Dishwasher GVW840XL

Advertisement

Table of Contents
loading

Related Manuals for Pelgrim GVW840XL

Summary of Contents for Pelgrim GVW840XL

  • Page 1 Operating Instructions Dishwasher GVW840XL...

  • Page 2: Table Of Contents

    Contents Front panel ....................Safety instructions ..................Before washing for the first time ............... Loading the dishwasher ................Using the dishwasher ................Settings ..................... Care and cleaning ..................Troubleshooting ..................Installation ....................Service ...................... Information for test institute ............... Technical information ................Front panel 14 15 Main power switch...

  • Page 3: Safety Instructions

    Safety instructions General Installation • Read the operating instructions and See the section Installation. keep them in a safe place! Child safety • Never use the dishwasher for any • Always start the dishwasher purpose other than that specified in immediately after adding detergent.

  • Page 4: Before Washing For The First Time

    Before washing for the first time The water softener take the packaging for recycling or direct you to the nearest recycling centre. The In order to achieve good dishwashing packaging is comprised of: results, the dishwasher needs soft water (water with low mineral content). Hard •...
  • Page 5 2 Place the funnel supplied with the 4 Close the lid firmly. dishwasher in the salt compartment Press to open top-up hole. First, pour in about 1 l of water. 3 Then add salt, a maximum of 1.5 kg, until the compartment is full. 4 Wipe up any excess salt so that the lid can be screwed on firmly.

  • Page 6: Loading The Dishwasher

    Loading the dishwasher Energy-efficient dishwashing Top cutlery tray • Do not start the dishwasher until it is The top cutlery tray has space for cutlery, fully loaded to save energy. ladles, whisks, serving cutlery and similar • Do not rinse under running water. items.
  • Page 7 Raising and lowering the upper basket Lower basket 1 Pull out the upper basket. Place plates, side plates, serving dishes 2 Grab the sides of the upper basket with and pots in the lower basket. both hands and lift it up. 3 Repeatedly lift the basket with both hands to change its position.

  • Page 8: Using The Dishwasher

    Using the dishwasher Add detergent detergent will not be released properly if the lid is tight and will not open correctly. Press to open NOTE! Dishwasher tablets are not recommended for short programmes (less than 75 minutes). Use powder or liquid dishwasher detergent instead.
  • Page 9 programmes and some options cannot be combined (available options glow dimly). Auto wash SpeedWash + Auto open SpeedWash An effective programme for daily use for This option shortens the programme time, slightly dried leftovers. (This programme but uses more energy and water. is not intended for burnt food, such as on oven dishes.) Auto open...
  • Page 10 If you want to cancel the Delayed start Do you want to add more dishes? option, open the door and press and hold Open the door. The dishwasher stops the main power switch until the display automatically. Add the dishes and close turns off.
  • Page 11 Self-cleaning programme (CLn) Unloading the dishwasher Self-cleaning programme for hygienic Hot porcelain is more fragile. Leave the cleaning of the dishwasher tub, spray dishes to cool in the dishwasher before arms and spray pipes. unloading them. This programme can be run (with no Unload the lower basket first to avoid any dishes in the machine) using normal water drops from the upper basket falling...

  • Page 13: Settings

    Settings Open the settings menu: First, open the door. Turn off the machine. Press and hold the main power switch until the display lights up. Within 10 seconds: - press the programme button for Auto wash and the option button for SpeedWash.
  • Page 14 Settings Options Adjusting the water softener. Read off Water hardness 2:00 - 2:09 the appropriate setting from the water hardness table below. °dH °fH °dH °fH 20-24 35-43 10-14 25-29 44-52 9-11 15-20 30-39 53-70 12-14 21-25 40-49 71-88 15-19 26-34 Do not forget to put salt in the salt compartment after you have set the...
  • Page 15 Settings Options Buzzer volume 4:00 - 4:03 The dishwasher uses a buzzer to indicate when a programme is finished or when a fault has occurred. Water tank 5:00 (Off) Built-in water tank. 5:01 (On) Before deactivating the water tank, run a self-cleaning programme.

  • Page 16: Care And Cleaning

    Care and cleaning Coarse filter NOTE! The coarse filter traps larger food The dishwasher must not be used particles, which cannot get past the without the filters in place! drainage pump. Empty the coarse filter as Dishwashing results may be affected if necessary.
  • Page 17 Spray arms The door and the door seal Holes and bearings can sometimes Regularly clean the sides of the door and become blocked. Remove any debris the door seal. Use a slightly damp cloth using a pin or the like. The spray arms (with a little cleaner if necessary).
  • Page 18 4 In order to inspect the drainage pump, Unblocking the inlet hose filter remove the coloured stop on the right If the water supply contains small in the bottom drain. particles, the outer filter on the inlet hose 5 Turn the pump wheel located behind may become blocked, which results in the drainage pump stop by hand.

  • Page 19: Troubleshooting

    Troubleshooting Type of fault on the Action display Overfilling Clear the drainage pump. See the section Care and cleaning. If the problem persists, call the service department. Water outlet fault See “Water remains in the dishwasher” in the table “Problem” below. If the problem persists, call the service department.
  • Page 20 Problem Possible causes Action Cannot close door. The baskets are not Check that the baskets are correctly positioned. correctly positioned horizontally. Check that the dishes are not blocking the baskets from sliding properly into place. The door lock does not click Check the door lock.
  • Page 21 Problem Possible causes Action The dishwasher does not The door is not properly Check. start. closed. You have opened the Close the door and wait. dishwasher to add more After a while, the dishes while a programme dishwasher continues the is in progress.
  • Page 22 Problem Possible causes Action The dishes are not clean. The spray arms do not Remove the arms and clean rotate. them. Check that the dishes are not blocking the spray arms. Old detergent. Detergent is Avoid large packages. a perishable product. Incorrect detergent dosage.
  • Page 23 Problem Possible causes Action Spots or films on the dishes. The water softener is Check that the salt leaking salt. compartment lid is properly tightened. Otherwise call the service department. Incorrect water softener See the section Settings. setting. Incorrect rinse aid dosage See the section Settings.
  • Page 24 Problem Possible causes Action Sound from a fan is heard The special programme ION See the section Using the even when no dishwashing is activated. dishwasher. programme is running. "CLn" is shown on the The dishwasher tub, spray Run a self-cleaning display.
  • Page 25 Problem Possible causes Action Bad odour in dishwasher. Dirt around the seals and in Clean with washing-up corners. brush and low foaming cleaner. Low temperature Run a programme with a programmes have been higher temperature about selected for a prolonged once a month.

  • Page 26: Installation

    Installation [mm] 1234 Door length Nominal dimensions. Actual measurements may vary. It is important that you read through and Check also that none of the follow the instructions and directions connections leak. below. Conduct installation and WARNING! connection in accordance with the Turn off the water supply when installing separate installation instructions.
  • Page 27 • Make sure the area on which the No part of the drainage hose may be more dishwasher is to be installed is firm. than 950 mm above the bottom of the Adjust the adjustable feet so that the dishwasher. dishwasher is level.

  • Page 28: Service

    Service Read the chapter Troubleshooting before Electrical connection contacting the service department. Information about the electrical connection Provide the details on the serial number can be found on the serial number plate. plate in all contact. Include the article This specification must match the number (1) and the serial number (2).

  • Page 29: Information For Test Institute

    Information for test institute Request test institute information via e-mail ART. NO. dishwashers@appliance-development.com. SERIAL NO. The request should include the details on the serial number plate. Include the article number (1) and the serial number (2).
  • Page 30 Your notes...
  • Page 31 Your notes...

  • Page 32: Technical Information

    Technical information Information on energy labelling Information sheet, in compliance with Commission Delegated Regulation (EU) No. 1059/2010 Pelgrim Model designation: GVW840XL Number of standard place settings: Energy efficiency class: A+++ Annual energy consumption(AE 245 kWh per year Energy consumption of the standard cleaning cycle(E 0.86 kWh...
