Channel Plus 5115BID User Manual

5115 modulator series

Advertisement

Quick Links

P E R F O R M A N C E M U LT I - R O O M V I D E O
WARRANTY
5115 Modulator Series
Multiplex Technology, Inc. warrants this product to be
free from defects in materials and workmanship for a
Model 5115HHR
period of one year from the date of purchase or MTI will
repair, or at its option, replace the defective product. To
Model 5115BID
obtain warranty service, call MTI for a return material
authorization (RMA) number and return the product pre-
paid
to Multiplex Technology, Inc., 3001 Enterprise
Model 5115PAL
Street, Brea, CA 92821,
Attention: Customer Service.
Please put the RMA number on the outside of the car-
ton.
Any implied warranty arising from the sale of the prod-
uct including implied warranties of merchantability and
fitness for purpose are limited to the warranty stated
above. MTI shall not be responsible for losses or dam-
ages or expenses, whether direct, consequential or inci-
dental arising from the use of or the inability to use this
product. Some states do not allow limitations on how
long the implied warranty lasts or the exclusions or limi-
tations or incidental or consequential damages, so the
above limitations and exclusions may not apply to you.
This warranty gives you specific legal rights, and you
may have other rights which may vary from state to
state.
714-996-4100 * 800-999-5225 * fax 714-996-4900 *
www.channelplus.com
600-132 Rev.A
©1999 Multiplex Technology, Inc., Brea, Ca.

Advertisement

loading
Need help?

Need help?

Do you have a question about the CHANNEL PLUS 5115BID and is the answer not in the manual?

Questions and answers

Summary of Contents for Channel Plus CHANNEL PLUS 5115BID

  • Page 1 P E R F O R M A N C E M U LT I - R O O M V I D E O WARRANTY 5115 Modulator Series Multiplex Technology, Inc. warrants this product to be free from defects in materials and workmanship for a Model 5115HHR period of one year from the date of purchase or MTI will repair, or at its option, replace the defective product.
  • Page 2: Installation

    The 5115 series is a audio/video distribution system that creates a new channel to add to existing television channels. The new channel carries audio/video from any video source to all the TVs in the home The 5115 was designed to install effortlessly into existing coax home wiring or into new construction.
  • Page 3: Connecting A Video Source

    Installation of the wall plate Step Two The wall plate mounts using a low voltage ring into a wall cut out. Run a line of Cat 5 wire from the wall plate to the channel injector and connect wires as shown. Bl/W Blue Org/W...
  • Page 4 Applying Power and Programming Step Three The 5115 series has three different methods for applying power to the system. Use only one method for applying power. Method One: Apply power directly to the channel injector with the power supply. Lower right of channel injector Power plug The green LED in the upper right corner of the injector will be lit...
  • Page 5 Power Length Requirements Method One Up to 300’ of Cat 5 or quad wire maximum Power Length Requirements Method Two Up to 100’ of Cat 5 or quad wire maximum Up to 300’ of Cat 5 or quad power plug wire maximum Power Length Requirements Method Three...
  • Page 6 Programming a New Channel Valid channels are 14 thru 64 for UHF and 65 thru 125 for CATV Channels 95-99 are not available. Channels 21 thru 62 are for Pal. Channel Spacing: Skip at least one number between the new channel and the closest existing UHF/CATV channel.
