Connector Description
Label
CN1
CN2
CN3
CN4
CN5
CN9
CN10
CN7
PC11,12,13
CN13,14
U13
CN17
JP7
U1
U15
BAT1
CH19
JP8(COM2)
CN23
CN24
CN18
U16
CN15,16
JP4
U12
U9
JP2
CN1
CN2
72
Description
Serial Port
PS2-KBMS
Game Port
LPT Port
NIC/USB Port
12V Port
FP Audio Port
CD-IN2
PCI Slot
FP USB Header
ICH4(South Bridge)
FP Header
FAN3
VGA Port
BIOS Chipset
Battery
IDE Connector 2
1-2 clear CMOS/2-3 Normal
IDE Connector 1
Floppy Connector
Power Port
I/O chipset
DIMM Slot
FAN1
(main chipset) North Bridge
478pin CPU Slot
FAN2
Serial Port
PS2-KBMS
Chapter 5
