- Page 1 Compact Manual Microwave User Guide Model Number: RHMM713 (G) For Customer Services & Spare Parts please call 0345 209 7461 Or visit us at http://mda.russellhobbs.com PLEASE RETAIN FOR FUTURE REFERENCE...
-
Page 2: Table Of Contents
CONTENTS Page(s) Safety instructions About your microwave 10-11 Product information Unpacking the microwave Product overview Microwave oven installation 15-16 Turntable installation 17-18 Control panel Using the microwave Cooking tips Cleaning the microwave Important utensil information Problem solving 24-27 Guarantee & customer services Spare parts Connection to the mains supply 30-31... -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE WARNING: • If the door or door seals are damaged, the oven must not be operated until it has been repaired by a competent person. • It is hazardous for anyone other than a competent person to carry out any service or repair operation that involves the removal of a cover which gives protection against exposure to microwave energy. - Page 4 SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE WARNING: • This microwave is intended for heating food and beverages only. The drying of food or clothing and heating of warming pads, wheat bags, slippers, sponges, damp cloth and similar is extremely dangerous and may lead to risk of injury, ignition or fire.
- Page 5 SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE WARNING: • When heating or cooking food or liquid, remember that there are certain foods (such as, jam, Christmas pudding, and mincemeat) which heat up very quickly. • Microwave heating of beverages can result in delayed eruptive boiling, therefore care must be taken when handling the container.
- Page 6 SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE WARNING: • When heating food in plastic or paper containers, keep an eye on the oven due to the possibility of ignition. • If materials inside the oven smoke or catch fire, keep the oven door closed to stifle the flames, turn the oven off at the wall switch, or shut the power off at the fuse or circuit-breaker panel.
- Page 7 SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE WARNING: • When using the grill rack and baking tray, be aware that these will become HOT during cooking as they aren’t heatproof. Please use suitable oven gloves when removing these. •...
- Page 8 SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE WARNING: • On the right hand wall of the cavity is the plastic waveguide cover, microwaves are passed through this to enable your food to cook. It is important that this waveguide cover is kept clean at all times.
- Page 9 SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE WARNING: • Regularly remove the glass turntable to clean it, wash it in warm soapy water or a dishwasher. Regularly clean the turntable support and oven floor. Simply wipe the bottom surface of the oven with mild detergent and water, then dry.
-
Page 10: About Your Microwave
And that’s it! Cooking has never been so easy. With the RHMM713 you can tailor cooking to suit your recipe using the 5 power levels available for selection. For added functionality, there’s also an essential defrost setting, saving you time so that you can cook meals straight from the freezer. - Page 11 ABOUT YOUR MICROWAVE How do microwaves work? Microwaves are high-frequency electromagnetic waves similar to radio waves. While radio waves may vary in length from one metre to many kilometres, microwaves are very short (less than 12.5 centimetres.) Microwaves do not make any heat themselves but cause water molecules in food to vibrate.
-
Page 12: Product Information
PRODUCT INFORMATION Rated Voltage 220-240V/50Hz Rated Input Power (Microwave) 1150W Rated Output Power (Microwave) 700W Oven Capacity Turntable Diameter 24.5cm External Dimensions (H x W x D) 25.6 x 45.1 x 32.6 (cm) Net Weight; Approx 10.4Kg Number of Power Levels 5 + defrost Turntable coupling Accessories Included... -
Page 13: Unpacking The Microwave
UNPACKING THE MICROWAVE Before you use your microwave oven 1. Remove all the packaging. Do not remove the large piece of card from the right hand side of the cavity wall. (Refer to the below image). This is called a waveguide cover and allows the microwaves to pass through to cook the food. -
Page 14: Product Overview
PRODUCT OVERVIEW 1. Safety interlock latches 2. Door assembly and window 3. Glass turntable 4. Microwave inside door frame 5. Time control dial 6. Turntable ring 7. Turntable coupling 8. Power control dial 9. Plastic Waveguide cover... -
Page 15: Microwave Oven Installation
MICROWAVE OVEN INSTALLATION • Place the oven as far away from radios and televisions as possible. Using the oven may cause interference with the reception. • Plug the oven into a suitable 13 amp mains socket, make sure the voltage is the same as on the rating label (do not use extension cables or mains socket adaptors.) •... - Page 16 MICROWAVE OVEN INSTALLATION The minimum installation height is 85cm. A minimum clearance of 7.5cm is required between the oven and any adjacent walls. Leave a minimum clearance of 30cm above the oven. WARNING: DO NOT install the oven over a cooker or other heat or steam producing appliance as this will damage the microwave oven.
-
Page 17: Turntable Installation
TURNTABLE INSTALLATION • Before first use, check that any securing tape and all packaging has been removed from the glass tray and turntable ring assembly. • These parts must never be restricted from rotating. • Never place the glass tray upside down. •... - Page 18 TURNTABLE INSTALLATION The glass tray, turntable ring, and turntable coupling assembly must always be used during cooking (as shown below). • Do not place the food directly onto the glass tray, always place on or in suitable microwaveable cookware. Please check that crockery is microwave safe before using. •...
-
Page 19: Control Panel
CONTROL PANEL TIME control dial Turn the dial clockwise to increase the time set. You can set your cooking time for up to 30 minutes. The arrow on the dial will indicate how many minutes you have selected, each circular mark represents a minute. When the time has ran out, the microwave will produce a ‘ping’... -
Page 20: Using The Microwave
USING THE MICROWAVE • Put the food to be cooked or defrosted in a suitable microwave safe container, cover the food with a suitable cover or with microwave safe cling film (pierce the film with a fork.) • Put the container into the microwave oven and close the door. •... -
Page 21: Cooking Tips
COOKING TIPS Defrosting tips Microwaves penetrate around 4cm into most food. To maximize defrosting effectiveness follow the below guidelines. 1. For thick foods, turn regularly during operation in order to defrost evenly. 2. If food weighs over 500g, it is advised to turn at least 2 times. 3. -
Page 22: Cleaning The Microwave
CLEANING THE MICROWAVE • Before you clean the oven, turn it off and unplug it. • Keep the inside of the oven clean. When food or liquids stick to the oven walls, wipe with a damp cloth. We recommend that you do not use harsh detergent or abrasives. •... -
Page 23: Important Utensil Information
IMPORTANT UTENSIL INFORMATION • Do not use metal pans or dishes with metal handles. • Do not use anything with a metal trim. • Do not use paper covered wire twist-ties on plastic bags. • Do not use melamine dishes as they contain a material which will absorb microwave energy. -
Page 24: Problem Solving
PROBLEM SOLVING WARNING: To reduce the risk of personal injury, always unplug the microwave before performing maintenance or trouble shooting checks. The microwave oven may cause interference to your radio, TV or similar equipment. If this happens, you stop the interference by moving the radio, TV or equipment as far away from your microwave oven as possible. - Page 25 PROBLEM SOLVING Problem Potential reason Potential solution Spillages or splashes can burn and catch fire, all food that is put into the microwave should be appropriately covered. All spillages or splashes must be cleaned, and all areas of microwave cleaned after each use. Burnt on food debris in the microwave, on the waveguide and the behind the waveguide can cause the microwave to 'spark'.
- Page 26 PROBLEM SOLVING Potential solution Problem Potential reason By the very nature of how a microwave works, it ‘excites’ the water molecules in the food it is heating, causing them to move about and generate heat from within the food. Often when the food heats up it reaches the point where steam is released.
- Page 27 PROBLEM SOLVING Problem Potential reason Potential solution Check that the glass turntable has been placed correctly on 1. Glass turntable fitted the turntable and is not stopping the door from shutting incorrectly Door not correctly. shutting/ If the microwave is within its warranty period, please locking 2.
-
Page 28: Guarantee & Customer Services
GUARANTEE & CUSTOMER SERVICES At Russell Hobbs, we take all our customer feedback seriously. Feel free to contact our Customer Service Team on 0345 209 7461 who will be more than happy to assist you. This product is guaranteed for 12 months from the date of the original purchase. -
Page 29: Spare Parts
SPARE PARTS To check the availability of the following spare parts, simply contact our friendly Customer Services team on 0345 209 7461. Turntable coupling Turntable Ring Glass turntable... -
Page 30: Connection To The Mains Supply
CONNECTION TO THE MAINS SUPPLY WARNING- THIS APPLIANCE MUST BE EARTHED This appliance is designed to operate from a mains supply of 220-240V~ 50Hz. Check that the voltage marked on the product corresponds with your supply voltage. This product is fitted with a 13A plug complying with BS1363. If this plug is unsuitable or needs to be replaced, refer to customer services. - Page 31 CONNECTION TO THE MAINS SUPPLY For UK use only – PLUG • As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows: •...
-
Page 32: Disposal Information
For Customer Services & Spare Parts please call: 0345 209 7461 Or visit us at http://mda.russellhobbs.com Revision 1.1 This symbol is known as the 'Crossed-out wheelie bin Symbol'. When this symbol is marked on a product/batteries, it means that the product/batteries should not be disposed of with your general household waste.
