Models for
Disinfection using Sodium
Hypochlorite
PH10000
PH11300
PH11330
Disinfection
USER MANUAL
Dec 2008 Version 9.0
Models
for Disinfection using Sodium
Hypochlorite & Sodium Bromide
PL11310
PL11313
Controllers
Models for
Disinfection using BCDMH
Tablets
PB11000
PB11030
AQUARIUS
T E C H N O L O G I E S P T Y L T D
W
Q
ATER
UALITY
C
ONTROL
Advertisement
Table of Contents
Related Manuals for AQUARIUS PH10000
Summary of Contents for AQUARIUS PH10000
- Page 1 Models for Models Models for Disinfection using Sodium for Disinfection using Sodium Disinfection using BCDMH Hypochlorite Hypochlorite & Sodium Bromide Tablets PH10000 PL11310 PB11000 PH11300 PL11313 PB11030 PH11330 Disinfection Controllers AQUARIUS USER MANUAL T E C H N O L O G I E S P T Y L T D Dec 2008 Version 9.0...
-
Page 2: Table Of Contents
Coopers Plains QLD 4108 (+617) 3274 4736 PO Box 71 Coopers Plains QLD 4108 e: info@aquariustech.com.au AUSTRALIA w: www.aquariustech.com.au This document is subjected to Aquarius Technologies Pty Ltd trading terms and conditions which can be obtained from the following link http://www.aquariustech.com.au/terms.html... - Page 3 Congratulations We know you will be happy with your decision Let us help you learn about your new to purchase a new Aquarius Technologies Controller. This manual will take you through 2006 Generation Controller. These units are all of the functions available from the keyboard...
-
Page 4: Where To Find The Serial Number
Where to find the serial number Model PH11330 Serial Identification Label Key data being: All Aquarius Technologies Controllers are manufactured with a Serial Identification Label Model e.g. PH11330 (SIL). This is actual Controller model and indicates This will be affixed to the wall of the controller, the configuration. -
Page 5: Section Contents
• ORP Read Screen System Configuration • pH Read Screen • Inhibitor Read Screen • Water Meter Inhibitor Read Screen Aquarius Control Systems Screen • Water Usage Meter Read Screen Buttons • Dispersant Read Screen • Default Screen • Seven Day Timer Config Read Screen 26 •... -
Page 6: Installation Guidelines
• Adequate bunding is provided for the system The Aquarius Controller is now ready for use. and chemical drums to prevent spills causing Liaise with your chemical specialist for advice damage. -
Page 7: Leaning Flow/Cond/Temp Sensor C
(AS9500) for about 5 minutes to completely dissolve any trace of inorganic Routine Testing foulants. The use of an Aquarius control system will Remove and rinse thoroughly in fresh water automatically vary the dosages and maintain before replacing it in the manifold. -
Page 8: Regular Inspections & Maintenance
Installation Guidelines Installation Guidelines Warnings Both pH & ORP sensors age with time and Chemicals in use as part of the treatment temperature, and have a typical life span of program may be hazardous. Please refer to 24-36 months depending on the application the full Material Safety Data Sheets (MSDS) in which they are operating and should be provided by your chemical supplier and ensure... -
Page 9: Installation Guidelines - Section
Installation Guidelines Typical Installation Schematic... -
Page 10: Aquarius Control Systems
System Configuration Aquarius Control Systems Your new Aquarius controller system features a front panel that consists of:- Screen A 4x20 line alphanumeric display Buttons The six button key pad is the primary user interface. The buttons provide the means to navigate the screens and set the operational parameters for your desired treatment program. -
Page 11: Default Screen
Combination Calibration Mode As both the pH and ORP sensors are contained within the one electrode it is possible to perform both pH calibration and ORP verification in one step. For this you will need Aquarius combination buffers. Part Number: AS7086 - pH 7.01 &... -
Page 12: Orp Verification Mode
System Configuration ORP Verification Mode To verify ORP separately press ENT for ORP verification. Then place the probe in the requested solution and press ENT. The screen will display the message ‘PROBE STABILISING PLEASE WAIT’. Then rinse the probe in fresh water and place it in the second solution requested, press ENT when ready. -
Page 13: Erase Calibration Mode
Panel Selection Mode While in calibration mode the user has the choice of viewing either the standard Aquarius default screen or having all sensor data displayed as the default screen. To make this selection press ENT and there will be a prompt to select the default option. -
Page 14: Set Mode
System Configuration Set Screens Menu All Aquarius controllers come loaded with preset default values for all of the treatment program parameters. On start up the controller will operate according to those defaults. However, every application should have a planned treatment program developed. Decisions need to be made on what values are most appropriate for ORP, pH, Conductivity, biocide, dispersant and inhibitor dosing requirements. -
Page 15: Set Time & Date Screen
System Configuration Set Time and Date Screen TIME & DATE The current time, day, week, and date are important for managing CLK=01:50:36 DAY=Mon WEEK=2 the treatment program and timing of ORP, biocide control, and for DATE=21/03/2006 time stamping the data log. Only two values are adjustable but each contains several components. -
Page 16: Set Alarm Screen - Name & Phone
System Configuration Set Alarm Screen - Name and Phone Allows the user to enter up to three names and contact phone numbers to receive notification of system alarms via mobile phone sms alerts. Only available when a Communications Kit is fitted to the controller Options: (three phone numbers) PH1/PH2/PH3 Use the arrow keys to cycle through these... -
Page 17: Set Orp Screen
System Configuration Set ORP Screen Set ORP Not Available on all Controllers. Refer to table 2. Adjacent. ORP=474mV SET=475 DUTY=50% MODE=FLOW Allows the user to set the ORP options for the controller. ALM=+/- LOCK=300 Table 2. SET: C [x] A & P Models - ORP [value from Table 2] Options: Series... -
Page 18: Set Ph Screen
System Configuration Set pH Screen Refer to Table 3. Adjacent. Allows the user to set the pH options. This screen should never require changing whilst in a monitoring mode. pH is a read only value generated by the controller and is not a value that can be set from this screen. -
Page 19: Set Inhibitor Screen With Wm Option
System Configuration Set Inhibitor Screen Allows the user to set inhibitor options. PUMP CAP: [1.00] Options: (Pump capacity in lts/hr) Value between 0.01 and 20.0. Use arrow keys to cycle these selections. DOSE: [1.00] Options: (Preferred dose rate) Set a value in the range of 10 mls/hr (240 mls/day) to 20.0 lts/hr. Use arrow keys to cycle these selections. -
Page 20: Set Dispersant Screen
System Configuration Set Dispersant Screen Allows user to set dispersant options. PUMP CAP: [1.00] Options: (Pump capacity in lts/hr) Value between 0.01 and 20.0. Use arrow keys to cycle these selections. DOSE: [1.00] Options: (Preferred dose rate) Set a value in the range of 10 mls/hr (240 mls/day) and 20.0 lts/hr. Use arrow keys to cycle these selections. -
Page 21: Set Pre-Bleed/Lockout Screen
System Configuration Set Pre-Bleed/Bleed Lockout Screen Allows the user to set pre-bleed and bleed lockout times in hours. PRE-BLEED SET: [0] Options: Value in the range of 0 to 9.9 hours. Use arrow keys to cycle these selections. For a value of 0 pre-bleed is inactive. Pre-bleed is a function used to reduce the conductivity of the system before each biocide dose. -
Page 22: Set Disinfection Screen
System Configuration Set Disinfection Screen Refer to the Table 4. below. Allows the user to utilise a function of the controller that applies a boost disinfection (superchlorination) by means of raising the ORP control set point and dosing oxidising biocide according to the program set. This program is for a time interval in hours on any one day of the week, on any frequency of DAY: [OFF] weeks. -
Page 23: Set Calcium Hardness Screen
Options: AquaGuard/MODBUS. Use arrow keys to cycle these selections. The Read Status Mode: Aquarius controllers offer a number of read–only screens that show the status of the current treatment program. These are read–only screens and cannot be used to modify a program. -
Page 24: Alarm Read Screen
System Configuration Alarm Read Screen The alarm read screen shows the configuration of the system alarms. The second line of the display shows how often alarms will be re transmitted. The third line displays current active alarm. Note: where multiple alarms are active the screen will briefly rotate each alarm into view. -
Page 25: Orp Read Screen
System Configuration ORP Read Screen This screen displays the ORP status. RL (relay): OFF/ON ORP: The current value of the ORP in millivolts SET: the current control setting for ORP in millivolts DUTY: The current dose pump duty set MODE: ORP/FLOW/CON/OFF Will flash a value if alarmed LOCK:... -
Page 26: Inhibitor Read Screen
System Configuration Inhibitor Read Screen This screen displays the inhibitor status. RL (relay): OFF/ON PUMPCAP lts/hr: Pump output set DOSE ml/hr: Dose rate set MODE: BLEED/CON/FLOW/WM/OFF For descriptions and information on setting these items, refer to the section Set Inhibitor Screen. Water Meter Inhibitor Read Screen This screen displays the Water Meter inhibitor status on systems with a Water Meter configured. -
Page 27: Pre-Bleed/Lockout Read Screen
System Configuration Seven Day Timer Config Read Screen Biocide-B RL=OFF This screen displays the biocide pump duty and mode of operation. DUTY=100% MODE=T&FLO WK1=BIO-B WK2=BIO-B RL (relay): OFF/ON WK3=BIO-B WK4=BIO-B DUTY: the current value set MODE:T&FLO/TIMER WK1: BIO-A/B WK2: BIO-A/B WK3: BIO-A/B WK4: BIO-A/B For descriptions and information on setting these items, refer to the... -
Page 28: Lsi/Fah Read Screen
System Configuration LSI/FAH Read Screen This screen displays the calculated values for Langelier Saturation Index and Free Available Halogen. LSI: Current calculated value for LSI CAL. H: Value entered for calcium hardness FAH: Current calculated value of FAH For descriptions and information on entering user data, refer to the relevant Set Screen sections. -
Page 29: Data Logging & Communications Setup
System Configuration Data Logging and Communications Set up HyperTerminal Setup Data logging facilities are a standard in all “C” series controllers, and with the Data Log interval set to 30 mins - over 4 weeks of data 1. Start Programs, Accessories, Communica- logged on a 24/7 basis, can be stored before it tion, HyperTerminal to start the program (the is over written. -
Page 30: Gsm Modem Set Up
Provider Set up the communications program for direct 1. Aquarius recommends using Telstra as a connection to your serial port (COM1, COM2 etc) Service Provider for Data Communications at 9600 Baud, 8 Data & 1 Stop Bit, with no Parity in Australia - between AquaGuard and the or Flow Control. -
Page 31: Using Aquaguard 2 Software
PC hardware and software is and is auto-answering. developing make it impossible to ensure that Supply Aquarius with the site details to ascertain AquaGuard will operate in all situations. The if a connection can be made from another PC. -
Page 32: Bms 4 - 20 Ma Interface
System Configuration BMS 4 - 20 mA. Interface Introduction Flow and all available relay outputs. Relay numbering is consistent within each family The Building Management System output option of controllers, but dynamic across the full range, for your controller provides a local BMS/PLC/ SCADA system with 4-20 mA signals proportional so relay numbers may change depending on your to measured values, along with ON/OFF, clean... -
Page 33: Po Box 71
Alarm in the controller (remove sensor, alter SET point etc.) and look for an Alarm indication at the BMS. Useful Contact Information Aquarius Technologies Pty Ltd Record details of your controller here: ABN 94 010 393 254 Controller: Technical Support: Serial Number: ......... -
Page 34: Manufacturer's Product Warranty
(iv) the Product will be of merchantable quality days; or (vi) replace the Product. and free from defects in material and 3. The Buyer will be liable to Aquarius for all workmanship. 2. If within twelve (12) months (from either the reasonable costs incurred by Aquarius in... -
Page 35: Commissioning & Warranty Registration
This form should be completed by the Equipment OWNER promptly after installation & commissioning. When signed is should be faxed to Aquarius Technologies Pty Ltd on +617 3274 4736. This will ensure the equipment details are logged to our confidential Warranty Database to activate your warranty registration and assist our ability to process any future service inquiries. - Page 36 Warranty Registration Faxing Instructions for Registration Fax this form immediately to Aquarius Technologies Pty Ltd +617 3274 4736 Upon receipt your controller will be regis- tered in our equipment database. This will provide a ready confirmation of the actual equipment installed, and the configuration characteristics at your specific installation.
