Removing the ODD Module and Dummy Card
Slightly pull the ODD module and remove it.
1.
Pull the dummy card from the slot and remove it.
2.
Removing the Main Board
Disconnect the fan cable.
1.
Disconnect the speaker cable and Bluetooth module cable.
2.
Remove the four screws securing the main board.
3.
Then detach the main board from the lower case.
4.
67
Chapter 3
