Technibel GRF188R5TAA Technical Data & Service Manual

Split system air conditioner

Advertisement

Quick Links

TECHNICAL DATA
& SERVICE MANUAL
OUTDOOR UNIT:
Model No.
GRF188R5TAA
GRF228R5TAA
GRF228R7TAA
GRF188R5TAA
GRF188R5TAA
GRF228R5TAA
GRF228R7TAA
SPLIT SYSTEM AIR CONDITIONER
Product Code No.
38.7107.083
38.7107.084
38.7107.085
0.8180.537.1
July 2008 b
GRF228R5TAA - GRF228R7TAA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GRF188R5TAA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Technibel GRF188R5TAA

  • Page 1 TECHNICAL DATA & SERVICE MANUAL GRF188R5TAA OUTDOOR UNIT: GRF228R5TAA GRF228R7TAA SPLIT SYSTEM AIR CONDITIONER Model No. Product Code No. GRF188R5TAA 38.7107.083 GRF228R5TAA 38.7107.084 GRF228R7TAA 38.7107.085 GRF188R5TAA GRF228R5TAA - GRF228R7TAA 0.8180.537.1 July 2008 b...
  • Page 2 IMPORTANT! • Ground the unit following local electrical codes. • The Yellow/Green wire cannot be used for any connection Please read before installation different from the ground connection. • Connect all wiring tightly. Loose wiring may cause overheating This air conditioning system meets strict safety and operating at connection points and a possible fire hazard.
  • Page 3: Table Of Contents

    Table of Contents Page 1. OPERATING RANGE 2. SPECIFICATIONS 2-1 Unit specifications 2-2 Major Component specifications 2-3 Other Component specifications 3. DIMENSIONAL DATA 4. REFRIGERANT FLOW DIAGRAM 5. PERFORMANCE DATA 5-1 Performance Charts 5-2 Cooling Capacity 5-3 Heating Capacity 6. ELECTRICAL DATA 6-1 Electrical characteristics 6-2 Electric Wiring Diagram 6-3 System Wiring Diagram...
  • Page 4: Operating Range

    1. OPERATING RANGE Temperature Indoor Air Intake Temp. Outdoor Air Intake Temp. 32°C D.B. / 23°C W.B. 43°C D.B. Maximum Cooling 19°C D.B. / 14°C W.B. 19°C D.B. Minimum 27°C D.B. 24°C D.B. / 18°C W.B. Maximum Heating -8°C D.B. / -9°C W.B. Minimum...
  • Page 5: Specifications

    2. SPECIFICATIONS 2-1 Unit Specifications GRF188R5TAA 220 - 240V ~ 50Hz Power source 230V Voltage rating Cooling Heating Performance * MPAF188R5TAA Capacity 5,00 5,80 BTU/h 17050 19780 Air circulation (High) m³/h Moisture removal (High) Liters/h Cooling Heating Electrical Rating 198 ~ 264...
  • Page 6 GRF228R5TAA 220 - 240V ~ 50Hz Power source 230V Voltage rating Cooling Heating Performance * MPAF228R5TAA Capacity 6,60 7,80 BTU/h 22500 26600 Air circulation (High) m³/h 3000 Moisture removal (High) Liters/h Cooling Heating Electrical Rating 198 ~ 264 Available voltage range 9,20 Running amperes 2050...
  • Page 7 GRF228R7TAA 380 - 415V 3N ~ 50Hz Power source 400V Voltage rating 230V ~ 50Hz Control Circuit Cooling Heating Performance * MPAF228R5TAA Capacity 6,80 8,00 BTU/h 23190 27280 Air circulation (High) m³/h 3000 Moisture removal (High) Liters/h Cooling Heating Electrical Rating 342 ~ 418 Available voltage range 4,10...
  • Page 8: Major Component Specifications

    2-2 Major Component Specifications GRF188R5TAA Compressor Rotary (Hermetic) Type 5KS205EAA21 Compressor model 1700 Nominal input FV50S …670 Compressor oil…Amount Ω C-R: 1,780 Coil resistance (Ambient temp. 20°C) C-S: 2,175 Internal Overload relay Thermal protector Safety devices Type Operating Temp. Open °C...
  • Page 9 GRF228R5TAA Compressor Rotary (Hermetic) Type 5JS270DAA01 Compressor model 1800 Nominal output Compressor oil…Amount RB68A / Freol Alpha 68M…1130 Ω C-R: 1,166 Coil resistance (Ambient temp. 20°C) C-S: 1,534 Internal Overload relay Thermal protector Safety devices Type Operating Temp. Open °C Close °C Run capacitor...
  • Page 10 GRF228R7TAA Compressor Rotary (Hermetic) Type 5JS270PAA21 Compressor model 1800 Nominal output Compressor oil…Amount FV50S … 1130 Ω U-V: 5,786 Coil resistance (Ambient temp. 20°C) U-W: 5,954 V-W: 5,562 Internal Overload relay Safety devices Type Thermal protector Operating Temp. Open °C Close °C Run capacitor...
  • Page 11: Other Component Specifications

    2-3 Other Component Specifications GRF188R5TAA 4-way Valve (20S) STF-0201G3 Coil model STF-01AJ504D1 AC 220/240 V, 50 Hz Coil rating Ω (at 20°C) Coil resistance ACB-2UB106 High Pressure Switch (HP) 42 ±1 bar set pressure open close 33 ±1,5 bar AC 250V - 1 ~ 6A...
  • Page 12: Dimensional Data

    3. DIMENSIONAL DATA dimension mm GRF188R5TAA 4 - Ø12 for anchor bolt WIDE TUBE D.12,7 (1/2") NARROW TUBE D.6,35 (1/4") GRF228R5TAA dimension mm GRF228R7TAA NARROW TUBE D.6,35 (1/4") WIDE TUBE D.15,88 (5/8") 4 - Ø13 for anchor bolt...
  • Page 13: Refrigerant Flow Diagram

    4. REFRIGERANT FLOW DIAGRAM outdoor unit GRF188R5TAA cooling cycle heating cycle indoor unit MPAF188R5TAA wide tube O.D. 12,7mm (1/2") narrow tube O.D. 6,35mm (1/4") outdoor unit GRF228R5TAA - GRF228R7TAA indoor unit MPAF228R5TAA wide tube O.D. 15,88mm (5/8") narrow tube O.D. 6,35mm (1/4")
  • Page 14: Performance Data

    5. PERFORMANCE DATA 5-1 Performance charts GRF188R5TAA Cooling Characteristics Heating Characteristics Indoor inlet air Indoor inlet air D.B. (°C) D.B. (°C) 0,74 Outdoor inlet D.B. temp. (°C) Outdoor inlet air D.B. temp. (°C) 1,20 4,00 Indoor inlet air Indoor inlet air D.B.
  • Page 15 GRF228R5TAA Cooling Characteristics Heating Characteristics 11,5 11,5 Indoor inlet air Indoor inlet air D.B. (°C) D.B. (°C) 11,0 11,0 10,5 10,5 10,0 10,0 0,74 Outdoor inlet D.B. temp. (°C) Outdoor inlet air D.B. temp. (°C) 1,10 Indoor inlet air Indoor inlet air D.B.
  • Page 16 GRF228R7TAA Cooling Characteristics Heating Characteristics Indoor inlet air Indoor inlet air D.B. (°C) D.B. (°C) 0,74 Outdoor inlet D.B. temp. (°C) Outdoor inlet air D.B. temp. (°C) 1,10 Indoor inlet air Indoor inlet air D.B. (°C) D.B. (°C) 1,00 0,90 0,80 0,70 0,60...
  • Page 17: Cooling Capacity

    5-2 Cooling Capacity OUTDOOR UNIT: GRF188R5TAA INDOOR UNIT: MPAF188R5TAA 220 - 240V ~ 50Hz 5,00 kW 1,5 l/h RATING CAPACITY moisture removal 1,377 kW 1,927 kW COMP. POWER INPUT max comp input 760 m³/h AIR FLOW RATE EVAPORATOR CONDENSER ENT.TEMP. °C OUTDOOR AMBIENT TEMP.
  • Page 18 OUTDOOR UNIT: GRF228R5TAA INDOOR UNIT: MPAF228R5TAA 220 - 240V ~ 50Hz 6,60 kW 2 l/h RATING CAPACITY moisture removal 1,82 kW 2,27 kW COMP. POWER INPUT max comp input 3000 m³/h AIR FLOW RATE EVAPORATOR CONDENSER ENT.TEMP. °C OUTDOOR AMBIENT TEMP. °C W.B.
  • Page 19 OUTDOOR UNIT: GRF228R7TAA INDOOR UNIT: MPAF228R5TAA 380 - 415V 3N ~ 50Hz 6,80 kW 2 l/h RATING CAPACITY moisture removal 1,87 kW 2,37 kW COMP. POWER INPUT max comp input 3000 m³/h AIR FLOW RATE EVAPORATOR CONDENSER ENT.TEMP. °C OUTDOOR AMBIENT TEMP. °C W.B.
  • Page 20: Heating Capacity

    5-3 Heating Capacity NOTE: ● Point of rating condition Black dot in the chart indicate the following rating condition. indoor: 20 °C D.B. outdoor: 7 °C D.B. / 6 °C W.B. 2) Above characteristics indicate instantaneus operation, which does not take into consideration defrost operation. 3) Fan speed: High 4) Because this air conditioner heats a room by drawing in the heat of the outside air (heat pump system).
  • Page 21: Electrical Data

    6. ELECTRICAL DATA 6-1 Electrical characteristics OUTDOOR UNIT: GRF188R5TAA COOLING Indoor Unit Outdoor unit Complete Unit Fan Motor Fan Motor Compressor performance at 230V 1-Phase 50 Hz Rating conditions Running Amps. 0,40 0,41 6,19 7,00 Power input 0,086 0,087 1,377...
  • Page 22 OUTDOOR UNIT: GRF228R5TAA COOLING Indoor Unit Outdoor unit Complete Unit Fan Motor Fan Motor Compressor performance at 230V 1-Phase 50 Hz Rating conditions Running Amps. 0,40 0,67 8,13 9,20 Power input 0,086 0,144 1,820 2,050 Full load conditions Running Amps. 0,40 0,67 9,93...
  • Page 23 OUTDOOR UNIT: GRF228R7TAA COOLING Indoor Unit Outdoor unit Complete Unit Fan Motor Fan Motor Compressor performance at 230V 1-Phase 50 Hz Rating conditions Running Amps. 0,40 0,67 3,03 Power input 0,086 0,144 1,870 2,100 Full load conditions Running Amps. 0,40 0,67 3,93 Power input...
  • Page 24: Electric Wiring Diagram

    6-2 Electric Wiring Diagram GRF188R5TAA GRF228R5TAA GRF228R7TAA 6-3 Wiring System Diagram 1-phase 3-phase MPAF228R5TAA GRF228R7TAA MPAF188R5TAA GRF188R5TAA MPAF228R5TAA GRF228R5TAA model power supply control line delayed fuse GRF188R5TAA 16 A GRF228R5TAA GRF228R7TAA...
  • Page 25 R.D. 28 Reyrieux BP 131 - 01601 Trévoux CEDEX France Tél. 04.74.00.92.92 - Fax 04.74.00.42.00 R.C.S. Bourg-en-Bresse B 759 200 728...
