- Page 1 MANUAL ENGLISH Net-2 Panel, 5-pin Order code: 50813/50815 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
-
Page 2: Table Of Contents
4. Set DMX Port .................................17 5. Set Display ................................18 6. Set Default................................18 7. Firmware Version ..............................18 Settings Configuration via Web Browser ........................19 Changing the Password ............................20 Updating the Firmware ............................20 Maintenance ..................................20 Troubleshooting ................................21 Product Specifications ..............................22 Dimensions ..................................23 Notes ....................................24 Order code: 50813/50815... -
Page 3: Warning
Save the carton and all packing materials. In the event that a fixture must be returned to the factory, it is important that the fixture be returned in the original factory box and packing. Your shipment includes: ● Showtec Net-2 Panel, 5-pin ● User manual Safety Instructions Every person involved with the installation, operation and maintenance of this device has to: ●... -
Page 4: Operating Determinations
● If your Showtec device fails to work properly, discontinue use immediately. Pack the unit securely (preferably in the original packing material), and return it to your Showtec dealer for service. -
Page 5: Connection With The Mains
After this period complaints will not be handled anymore. Complaints will only then be considered if the client has so far complied with all parts of the agreement, regardless of the agreement of which the obligation is resulting. Order code: 50813/50815... -
Page 6: Description Of The Device
Description of the Device Features The Showtec Net-2 Panel is a cutting-edge network routing device which converts Art-Net or sACN to DMX-512 and vice versa. It is suitable for fixed installations and for making multiple patch points for DMX inputs or outputs in professional theaters, schools, universities, convention halls, clubs or churches. It allows for the transmission of a maximum of 1024 DMX channels over a single Ethernet cable. -
Page 7: Front
08) DMX port A, 5-pin DMX XLR 09) DMX port A, LED indicator This indicator lights up when there is DMX activity. 10) 12–36 V DC 2-pin Phoenix terminal power connector IN (use only when PoE is not available) 11) Ethernet RJ45 connector Order code: 50813/50815... -
Page 8: Installation
01) Place the mounting plate on a U50 wall box and tighten the screws. Fig. 03 02) Install the Net-2 Panel on the mounting plate by clicking it into place, starting with the top of the device. Fig. 04 Order code: 50813/50815... -
Page 9: Setup And Operation
IP address of the Net-2 Panel, see 2. IP Mode on page 15. Refer to Connecting to a Network on page 10 for the correct network settings. Fig. 05 Note: Link all cables before connecting electric power Order code: 50813/50815... -
Page 10: Setup Net-2 Panel With Lighting Controller
IP address of the Net-2 Panel, see 2. IP Mode on page 15. Refer to Connecting to a Network on page 10 for the correct network settings. Fig. 06 Note: Link all cables before connecting electric power Order code: 50813/50815... -
Page 11: Connecting To A Network
Please follow the instructions below in order to create an extra network cable. Take a standard network cable (CAT-5/CAT-E/CAT-6) and connect it to an RJ45 connector, as shown on Fig. 07. The wires should now be colored as follows: Fig. 07 Order code: 50813/50815... -
Page 12: Supported Pinout Modes
Note: Use of 3-pin XLR audio cables for DMX data transmission might lead to signal degradation and unreliable operation of the DMX network. Order code: 50813/50815... -
Page 13: Operation
BACKUP function. In case of a failure, or when there are no DMX values on the primary Art-Net/sACN universe for more than 3 seconds, the Net-2 Panel starts sending the DMX values from the backup port. Order code: 50813/50815... -
Page 14: Control Panel
02) Press the MENU button to enter the Main Menu. 03) If no button is pressed, after 45 seconds the display returns to one of the 2 start screens. Press the UP, DOWN, MENU or ENTER button to return to the Main Menu. Order code: 50813/50815... -
Page 15: Menu Overview
Net-2 Panel, 5-pin Menu Overview Order code: 50813/50815... -
Page 16: Main Menu Options
08) Press the ENTER button to confirm. 2. IP Mode In this menu you can configure the IP address of the device. 01) Press the UP/DOWN buttons to toggle between the 2 options: 02) Press the ENTER button to confirm your choice. Order code: 50813/50815... -
Page 17: Dhcp Ip
08) Press the ENTER button to save the IP address. 3. Set Netmask In this menu you can set the Netmask of the IP address. 01) Press the UP/DOWN buttons to scroll through the 3 options: 02) Press the ENTER button to confirm the selection. Order code: 50813/50815... -
Page 18: Set Dmx Port
This option is available only when the port is set as output and the DMX mode is set to HTP or LTP. 04) Press the ENTER button to select the desired setting. The selection will be highlighted. 05) Press the UP/DOWN buttons to change the values. 06) Press the ENTER button to set the value. Order code: 50813/50815... -
Page 19: Set Display
02) Select Yes (to reset all settings to factory defaults) or No (to cancel the reset and exit) and press the ENTER button to confirm your choice. 03) If you have selected Yes, press the ENTER button to return to the Main Menu. 7. Firmware Version This menu shows the firmware version: Order code: 50813/50815... -
Page 20: Settings Configuration Via Web Browser
Use the drop-down menus or enter the respective values to configure the settings of the device and the 2 DMX ports. ● Click on Apply to save the changes. ● Click on Cancel to discard the changes. Order code: 50813/50815... -
Page 21: Changing The Password
03) The electric power supply cables must not show any damages or material fatigue. The Showtec Net-2 Panel requires almost no maintenance. However, you should keep the unit clean. Disconnect the mains power supply and then wipe the cover with a damp cloth. Wipe the front glass panel clean with glass cleaner and a soft cloth. -
Page 22: Troubleshooting
This troubleshooting guide is meant to help solve simple problems. If you are unable to determine the cause of the problem, do not open the unit, as this may damage the device and the warranty will be deemed void. Return the device to your Showtec dealer. Problem... -
Page 23: Product Specifications
2 x 5-pin XLR IN/OUT, RJ45 connector Power connection: 2-pin Phoenix terminal (maximum cable gauge: 0,75 mm AWG: 18) Housing: ABS plastic Color: Black (50813), White (50815) Mounting: Masonry 3,5” back box / U50 wall box Operating temperature: 0–40 °C Max. ambient temperature t 40 °C Max. -
Page 24: Dimensions
Net-2 Panel, 5-pin Dimensions Order code: 50813/50815... -
Page 25: Notes
Net-2 Panel, 5-pin Notes Order code: 50813/50815... - Page 26 Net-2 Panel, 5-pin Order code: 50813/50815...
- Page 27 Net-2 Panel, 5-pin Order code: 50813/50815...
- Page 28 ©2020 Showtec...
