- Page 1 RF-8000E Microwave RF Repeater Operations Manual 550-0158-01 Revision D January 2019 Corporate Headquarters PO Box 1095 Danville, CA 94526 United States of America Telephone: +1 925 837-2243 Facsimile: +1 925 837-2298 www.peninsulaengineering.com...
- Page 2 © 2019 Peninsula Engineering Solutions, Inc. All rights reserved. The materials in this manual, the figures, tables and text, are the property of Peninsula Engineering Solutions, Inc. Peninsula Engineering Solutions provides this manual to aid its customers in obtaining product, ordering, installation, testing, maintenance, and application information for this product.
-
Page 3: Installation By Professionals
Antenna Systems in the United States of America, Canada, or the European Union are normally qualified to install or maintain the RF-8000E Microwave RF Repeater. This product has been evaluated to the U.S. and Canadian (Bi-National) Standard for Safety of Information Technology Equipment, Including Electrical Business Equipment, CAN/CSA C22.2, No. -
Page 4: Protection From Rf Burns
WARNING - This equipment is intended to be grounded. If you are not using the power supply provided by Peninsula Engineering Solutions, you will need to connect the grounding conductor of your power source to the grounding terminal located on the bottom of the unit; or, connect a grounding conductor between the unit’s ground terminal and your ground point. -
Page 5: Table Of Contents
Contacting Peninsula Engineering Solutions ....................36 Chapter 2. Installation Preparation ........................37 Installation Overview ............................37 Receipt and Inspection of the RF-8000E Microwave RF Repeater ..............37 Installation Equipment ............................ 39 Accessory Kits ............................39 ... - Page 6 Figure 22, Repeater Power Wiring Pictorial ....................35 Figure 23, Typical RF Repeater Installation ....................38 Figure 24, Enclosure Mounting Dimensions RF-8000E, 2 ~ 4 Antenna Port, 1 ~ 4 Amplifier or Frequency Channels ........................41 ...
- Page 7 Table 1, DC Power Consumption and Weight per Model ................. 8 Table 2, Branching Losses – RF-8000E 30 MHz Channel Bandwidth Models ..........9 Table 3, Branching Losses – RF-8000E 40/56 MHz Channel Bandwidth Models .......... 10 ...
- Page 8 THIS PAGE INTENTIONALLY LEFT BLANK — Contents RF-8000E Operations Manual...
-
Page 9: Chapter 1. Overview
General Information The Peninsula Engineering Solutions’ RF-8000E Microwave RF Repeater, hereafter referred to as the RF-8000E (or the repeater), is a linear, bi-directional, on-frequency RF repeater for microwave point-to-point networks. The RF-8000E may be used with any manufacturer's compatible 8-GHz radio operating in the 7.7-8.5 GHz frequency range to provide an intermediate repeater. -
Page 10: Functional Description
Functional Description 1. The RF-8000E assembly is an RF through repeater designed for remote locations. Little alignment is required, and the use of highly reliable components and minimum active circuitry eliminates most subsequent maintenance. The repeater assembly consists of an equipment mounting panel, contained in an aluminum, weatherproof, enclosure. -
Page 11: Amplifiers
Power Supply 12. The only active element in each frequency channel of the RF-8000E assembly is the amplifier which operates from a +11~16.5 VDC source. Current requirements are 1.95 Amperes maximum for higher power Level 2 amplifiers. Solar Rated power consumption accounts for lower current demands under normal conditions. -
Page 12: Alarms
Primary cell batteries capable of powering an RF-8000E repeater in excess of a year may be used. In such applications, the battery installation should be given an environmental shelter according to the manufactures’... -
Page 13: Licensing
Licensing All owners of the RF-8000E should consult with the appropriate local and national agencies for information about licensing. US NTIA ID (note 1) RF-8000E, Doc. 36813/1, SPS – 16782/1 US DOD MECB ID (note 1) RF-8000E, J/F 12/9185 Booster, Repeater, Amplifier, or same as terminal... -
Page 14: Technical Specification Summary
Antenna Ports CPR112G, Contact, Gasket Flange Waveguide Type WR112 Return Loss, Antenna Port 26 dB across assigned channels Frequency Plans RF-8000E-041 ~ -109 -241 ~ -299 Channel Bandwidth 30 MHz maximum 56 MHz maximum T-R Spacing 80 MHz minimum 130 MHz minimum... - Page 15 Note: Standard +12 VDC voltage operating range is specified to 11 VDC with full specification compliance. RF-8000E Repeater amplifiers will typically operate to about 9 VDC with some loss of gain and power output. Rapid degradation in performance occurs at less than 9 VDC.
-
Page 16: Table 1, Dc Power Consumption And Weight Per Model
Combined A + B Battery currents are shown. Normally, each battery current is half of the total for even numbers of provisioned amplifiers. Power is quite constant over the operating voltage range due to the switching DC/DC converters. — Chapter 1. Overview RF-8000E Operations Manual... -
Page 17: Table 2, Branching Losses - Rf-8000E 30 Mhz Channel Bandwidth Models
Table 2, Branching Losses – RF-8000E 30 MHz Channel Bandwidth Models Delay Receive Branch Loss, Transmit Branch Loss, MODEL Channel Typical*, dB Typical*, dB RF-8000E-041 F1, F2 F1, F4 RF-8000E-042 F2, F3 RF-8000E-043 F1, F3 RF-8000E-044 F2, F4 RF-8000E-051 F1, F2... -
Page 18: Table 3, Branching Losses - Rf-8000E 40/56 Mhz Channel Bandwidth Models
Table 3, Branching Losses – RF-8000E 40/56 MHz Channel Bandwidth Models Delay Receive Branch Loss, Transmit Branch Loss, MODEL Channel Typical*, dB Typical*, dB RF-8000E-241 40/56 F1, F2 F1, F4 RF-8000E-242 40/56 F2, F3 F1, F4 RF-8000E-279 40/56 F2, F1-SD... -
Page 19: Table 4, Transmit Power Backoff Per Modulation Type
For Example: Level 2 Amplifier Power Output = +30 dBm without backoff reduction; Modulation is 256QAM, therefore backoff = 13.0 dB, RF-8000E-041 Tx Branch Loss = 2.6 dB; Output power at antenna port flange = +30.0 – 13.0 – 2.6 = +14.4 dBm. -
Page 20: Ordering Information
Part numbers are listed in Table 7. When doing the initial system layout of a radio link which includes an RF-8000E Microwave RF Repeater Assembly, several factors must be considered prior to ordering, to ensure correct antenna connections and proper installation. -
Page 21: System Options And Assembly Part Number
System Options and Assembly Part Number Table 5, RF-8000E Microwave RF Repeater, 30 MHz Channel Models 30 MHz Channel Bandwidth (maximum) Standard Part Number Description Frequencies Assembly 1+0/1+1 Hot Standby Equivalent, Duplex, Un-Equalized, RF-8000E-041 900-0158-041 F1, F2 PA Level 2, 2. 2-Port, 2-Amplifier. -
Page 22: Table 6, Rf-8000E Microwave Rf Repeater, 40/56 Mhz Channel Models
Table 6, RF-8000E Microwave RF Repeater, 40/56 MHz Channel Models 40/56 MHz Channel Bandwidth Standard Part Number Description Frequencies Assembly 1+0/1+1 Hot Standby Equivalent, Duplex, Un-Equalized, RF-8000E-241 900-0158-241 F1, F2 PA Level 2, 2. 2-Port, 2-Amplifier. 1+1 Frequency Diversity or 2+0, Duplex, Un-Equalized,... -
Page 23: Table 7, Coaxial Attenuator Pads
Alarm closures can be adapted to SNMP reporting over IP networks using Peninsula Engineering’s SNMP-SL10 and other SNMP equipment. Contact Peninsula Engineering Solutions for details and assistance. Adds components to adapt standard +12VDC repeaters to +24VDC battery power. Kit includes two converter assemblies and parts for A and B sides. -
Page 24: Figure 1, Mechanical Layout, 2 Amplifier Or Frequency Channels
Figure 1, Mechanical Layout, 2 Amplifier or Frequency Channels — Chapter 1. Overview RF-8000E Operations Manual... -
Page 25: Figure 2, Mechanical Layout, 3 - 4 Amplifier Or Frequency Channels
Figure 2, Mechanical Layout, 3 - 4 Amplifier or Frequency Channels RF-8000E Operations Manual Chapter 1. Overview — 17... -
Page 26: Figure 3, Mechanical Layout, Bottom Detail
Figure 3, Mechanical Layout, Bottom Detail — Chapter 1. Overview RF-8000E Operations Manual... -
Page 27: Figure 4, Linear Power Amplifier
Figure 4, Linear Power Amplifier RF-8000E Operations Manual Chapter 1. Overview — 19... -
Page 28: Figure 5, Block Diagram, 1+0 Duplex, Un-Equalized
ANTENNA A ANTENNA B WEST EAST PORT B PORT D Figure 5, Block Diagram, 1+0 Duplex, Un-Equalized RF-8000E-041, RF-8000E-241 — Chapter 1. Overview RF-8000E Operations Manual... -
Page 29: Figure 6, Block Diagram, 1+1, 2+0 Duplex, Un-Equalized
Figure 6, Block Diagram, 1+1, 2+0 Duplex, Un-Equalized RF-8000E-042, RF-8000E-242 RF-8000E Operations Manual Chapter 1. Overview — 21... -
Page 30: Figure 7, Block Diagram, 1+0 One-Way, Un-Equalized
Figure 7, Block Diagram, 1+0 One-Way, Un-Equalized RF-8000E-043 ANTENNA A ANTENNA B WEST EAST PORT D PORT B Figure 8, Block Diagram, 1+0 One-Way, Delay Equalized RF-8000E-053 — Chapter 1. Overview RF-8000E Operations Manual... -
Page 31: Figure 9, Block Diagram, 1+1 Duplex, Un-Equalized, 2-Amplifier
ANTENNA A ANTENNA B WEST EAST PORT B PORT D Figure 9, Block Diagram, 1+1 Duplex, Un-Equalized, 2-Amplifier RF-8000E-044 RF-8000E Operations Manual Chapter 1. Overview — 23... -
Page 32: Figure 10, Block Diagram, 1+0 Duplex, Delay Equalized
ANTENNA A ANTENNA B WEST EAST PORT B PORT D Figure 10, Block Diagram, 1+0 Duplex, Delay Equalized RF-8000E-051 — Chapter 1. Overview RF-8000E Operations Manual... -
Page 33: Figure 11, Block Diagram, 1+1, 2+0 Duplex, Delay Equalized
ANTENNA A ANTENNA B WEST EAST PORT B PORT D Figure 11, Block Diagram, 1+1, 2+0 Duplex, Delay Equalized RF-8000E-052 RF-8000E Operations Manual Chapter 1. Overview — 25... -
Page 34: Figure 12, Block Diagram, 3-Port, 4-Amplifier, Duplex, Un-Equalized Space-Frequency Hybrid Diversity And Y-Junction Applications
ANTENNA A ANTENNA B WEST EAST PORT B PORT C PORT D ANTENNA C Figure 12, Block Diagram, 3-Port, 4-Amplifier, Duplex, Un-Equalized Space-Frequency Hybrid Diversity and Y-Junction Applications RF-8000E-079, RF-8000E-279 — Chapter 1. Overview RF-8000E Operations Manual... -
Page 35: Figure 13, Block Diagram, 3-Port, 4-Amplifier, Duplex, Delay Equalized Space-Frequency Hybrid Diversity And Y-Junction Applications
ANTENNA A ANTENNA B WEST EAST PORT B PORT C PORT D ANTENNA C Figure 13, Block Diagram, 3-Port, 4-Amplifier, Duplex, Delay Equalized Space-Frequency Hybrid Diversity and Y-Junction Applications RF-8000E-089 RF-8000E Operations Manual Chapter 1. Overview — 27... -
Page 36: Figure 14, Block Diagram, 4-Port, 3-Amplifier, Duplex, Un-Equalized Space Diversity Applications
ANTENNA A ANTENNA B WEST EAST PORT B PORT D PORT A PORT C ANTENNA C Figure 14, Block Diagram, 4-Port, 3-Amplifier, Duplex, Un-Equalized Space Diversity Applications F3 = F1 Diversity RF-8000E-098, RF-8000E-298 — Chapter 1. Overview RF-8000E Operations Manual... -
Page 37: Figure 15, Block Diagram, 4-Port, 4-Amplifier, Duplex, Un-Equalized 1+1 Space-Frequency Hybrid Diversity, 2+0 Dual Polarized And Y-Junction Applications
WEST EAST PORT B PORT D PORT A PORT C ANTENNA C Figure 15, Block Diagram, 4-Port, 4-Amplifier, Duplex, Un-Equalized 1+1 Space-Frequency Hybrid Diversity, 2+0 Dual Polarized and Y-Junction Applications RF-8000E-099, RF-8000E-299 RF-8000E Operations Manual Chapter 1. Overview — 29... -
Page 38: Figure 16, Block Diagram, 4-Port, 3-Amplifier, Duplex, Delay Equalized Space Diversity Applications
ANTENNA A ANTENNA B WEST EAST PORT B PORT D PORT A PORT C ANTENNA C Figure 16, Block Diagram, 4-Port, 3-Amplifier, Duplex, Delay Equalized Space Diversity Applications F3 = F1 Diversity RF-8000E-108 — Chapter 1. Overview RF-8000E Operations Manual... -
Page 39: Figure 17, Block Diagram, 4-Port, 4-Amplifier, Duplex, Delay Equalized 1+1 Space-Frequency Hybrid Diversity, 2+0 Dual Polarized And Y-Junction Applications
WEST EAST PORT B PORT D PORT A PORT C ANTENNA C Figure 17, Block Diagram, 4-Port, 4-Amplifier, Duplex, Delay Equalized 1+1 Space-Frequency Hybrid Diversity, 2+0 Dual Polarized and Y-Junction Applications RF-8000E-109 RF-8000E Operations Manual Chapter 1. Overview — 31... -
Page 40: Figure 18, Power Connection Block Diagram, 12V Standard
UHF RADIO, +13.5 V PRI 2 PRI 2 PRI 2 PRI 2 SEC 3 SEC 3 SEC 3 SEC 3 AMPLIFIER 1 AMPLIFIER 2 AMPLIFIER 3 AMPLIFIER 4 Figure 18, Power Connection Block Diagram, 12V Standard — Chapter 1. Overview RF-8000E Operations Manual... -
Page 41: Figure 19, Power Connection Block Diagram, 24V Option
PRI 2 PRI 2 PRI 2 PRI 2 SEC 3 SEC 3 SEC 3 SEC 3 AMPLIFIER 1 AMPLIFIER 2 AMPLIFIER 3 AMPLIFIER 4 Figure 19, Power Connection Block Diagram, 24V Option RF-8000E Operations Manual Chapter 1. Overview — 33... -
Page 42: Figure 20, Power Connection Diagram, Ac Single Power Supply Option
Figure 20, Power Connection Diagram, AC Single Power Supply Option Figure 21, Power Connection Diagram, AC Dual Power Supply Option — Chapter 1. Overview RF-8000E Operations Manual... -
Page 43: Figure 22, Repeater Power Wiring Pictorial
Figure 22, Repeater Power Wiring Pictorial RF-8000E Operations Manual Chapter 1. Overview — 35... -
Page 44: Technical Services
Quotations for technical services are available upon request. Contacting Peninsula Engineering Solutions Contact the Peninsula Engineering Solutions corporate headquarters for sales information or technical assistance for the RF-8000E Microwave RF Repeater, or any other of our communications or related products. Corporate Headquarters Peninsula Engineering Solutions, inc. -
Page 45: Chapter 2. Installation Preparation
Customer Service Department of Peninsula Engineering Solutions in writing. NOTE: Save original shipping crate and packing materials for any future transport of the unit. If the RF-8000E repeater is to be stored for later installation or shipment, reseal the packaging of the accessory kit and the repeater. -
Page 46: Figure 23, Typical Rf Repeater Installation
The following illustrates a typical installation with external equipment. Figure 23, Typical RF Repeater Installation — Chapter 2. Installation Instructions RF-8000E Operations Manual... -
Page 47: Installation Equipment
137-0782-05 Connector, D-Sub 37 Pin 087-0444-01 Transducer Assy (Battery Temperature Sensor) 034-0004-01 Pressure Switch Assy (Feedline Pressure Sensor) Per Order Per Order 125-0001-11 Screw, PHP 12-24 x .750, S/S (Rack mounting) RF-8000E Operations Manual Chapter 2. Installation Instructions — 39... -
Page 48: Pre-Installation Site Review
Determine whether there is enough room for the repeater door to open, once mounted. The RF-8000E assembly can be mounted on a steel tower, on a steel pipe or square-rail frame, or on a wall. The length of all power leads should be limited and the wire size adequate to minimize the voltage drop. -
Page 49: Figure 24, Enclosure Mounting Dimensions Rf-8000E, 2 ~ 4 Antenna Port, 1 ~ 4 Amplifier Or Frequency Channels
Figure 24, Enclosure Mounting Dimensions RF-8000E, 2 ~ 4 Antenna Port, 1 ~ 4 Amplifier or Frequency Channels Dimensions are in Inches [mm] See block diagrams and Mounting Dimension drawing M900-0158-XXX (Appendix) for port assignments and more details. RF-8000E Operations Manual... - Page 50 THIS PAGE INTENTIONALLY LEFT BLANK — Chapter 2. Installation Instructions RF-8000E Operations Manual...
-
Page 51: Chapter 3. Mounting The Antennas
6. Consult the path calculations, PDS, for the net path loss calculated between the antennas. Correct for feedline losses when connected directly to the antenna waveguide ports. Path Align-R™ is a popular test radio. Manufactured by: Spectracom Corp, XL-Microwave, Pendulum RF-8000E Operations Manual Chapter 3. Mounting the Antennas — 43... -
Page 52: Alternative Fine Alignment Using Repeater Power Measurements
Alternative Fine Alignment using repeater power measurements 9. This method requires the RF-8000E repeater to be installed, connected to the antenna feedlines, and powered up. See Chapter 4 for repeater installation details. 10. Before antenna orientation begins, the amplifiers must be operating in their full gain mode (out of AGC/ALC range). -
Page 53: Antenna Feedlines
If necessary, use rigid twist and bend sections to aid in alignment. 4. Connect the waveguide to the antenna. 5. Securely install the feedline so that it reaches to the installation site of the RF-8000E, with enough room to connect to the repeater. -
Page 54: Lightning Protection
14. Install dehydration equipment. Lightning Protection Peninsula Engineering Solutions strongly recommends installing protection on the tower, structure and on all feedlines to the repeater. A direct lightning strike can damage any electronic equipment. Damage resulting from a lightning strike is not covered under the equipment warranty, whether or not lightning protection is used. -
Page 55: Measuring Antenna Isolation - Decoupling
Figure 25 shows the equipment set-up. Losses between 80 and 120 dB are measured. Be sure the test equipment is capable of adequately measuring such high loss values. RF-8000E Operations Manual Chapter 3. Mounting the Antennas — 47... -
Page 56: Table 13, C/E Requirements Per Modulation
BER or BER < 10 at normal RSL. Isolation objective assumes a maximum repeater net gain of 60 dB. Isolation required for a specific C/E decreases dB-for-dB as the maximum gain decreases. — Chapter 3. Mounting the Antennas RF-8000E Operations Manual... -
Page 57: Figure 25, Antenna Isolation Measurement - Equipment Configuration
For example: = 10 dBm = 1.0 dB C-GEN = 1.0 dB C-SA = -92 dBm = 10 dBm – (1 dB + 1 dB) – (-92 dBm) = 100 dB RF-8000E Operations Manual Chapter 3. Mounting the Antennas — 49... - Page 58 THIS PAGE INTENTIONALLY LEFT BLANK — Chapter 3. Mounting the Antennas RF-8000E Operations Manual...
-
Page 59: Chapter 4. Mounting The Rf-8000E Repeater
Installation Overview The RF-8000E assembly can be mounted on a steel tower, on a steel pipe or square-rail frame, or on a wall. The length of all power leads should be limited and the wire size adequate to minimize the voltage drop. -
Page 60: Mounting Associated Equipment And Space Planning
1. Ground Ring or grounding provision 2. Battery Enclosures and Batteries 3. Photovoltaic Array, mounting frame and modules 4. Wind Turbine Generator, pipe mount and generator 5. PV Array Combiners 6. PV Controller — Chapter 4. Mounting the RF-8000E RF-8000E Operations Manual... -
Page 61: Mounting The Repeater
Figure 28, Example of Solar and Wind Power Installation Mounting the Repeater The RF-8000E has mounting rails on the rear of the enclosure. The mounting holes and slots fit 3/8-inch hardware. Mounting-hole dimensions for the repeater enclosure are shown in Figure 24. -
Page 62: Earth, Ground, And Lightning Protection
Earth, Ground, and Lightning Protection When grounding the RF-8000E and associated equipment, follow the general guidelines in the Peninsula Engineering Solutions application note, Installation Standards for Grounding Requirements. Installing the input power to the repeater includes installing the standard electrical service grounds. -
Page 63: Figure 31, Typical System Ground Rod
12 VDC or 11.5 VDC Internal Battery B Battery A & Ground & Ground Figure 32, Wiring and Ground Connections, Main Repeater Panel RF-8000E Operations Manual Chapter 4. Mounting the RF-8000E — 55... - Page 64 THIS PAGE INTENTIONALLY LEFT BLANK — Chapter 4. Mounting the RF-8000E RF-8000E Operations Manual...
-
Page 65: Chapter 5. Repeater Tests
Chapter 5. Repeater Tests Overview This chapter describes how to test the RF-8000E repeater, to set levels and to verify that it is operating properly. Test Equipment Required Table 10, in Chapter 2, lists test equipment and tools required for testing the RF-8000E repeater. -
Page 66: Transmit Power Adjustment
4. Measure and record the power meter reading. Typically, this reading will be between -15 and +15 dBm at RF MON. — Chapter 5. Repeater Tests RF-8000E Operations Manual... -
Page 67: Figure 33, Power Amplifier Rf Mon And Tx Branch Loss
“ ” PWR F4 Clear “ ” PWR F5 ~ F8 Clear “ ” not available for RF-8000E AMP 1 ~ 8 Clear Current out of range, high or low UNCOM SUM (UC1 ~ 7) Either, Clear if not used. -
Page 68: Receive And Transmit Attenuator Pads
When setup and tests are complete, set the RMAS Transmit Alarm LED SWITCH jumper to the ENB position to conserve power by only displaying alarm LEDs when the yellow test button is pressed. Refer to the RMAS-120 manual for alarm system tests. — Chapter 5. Repeater Tests RF-8000E Operations Manual... -
Page 69: Chapter 6. Maintenance And Troubleshooting
Chapter 6. Maintenance and Troubleshooting The RF-8000E active components are the linear power amplifiers, the DC/DC converters, and the optional RMAS alarm equipment if equipped. RF repeaters provide long field operating life, often 15 to 20 years. Technologies and traffic needs often drive upgrades or replacement rather than old age. -
Page 70: Administrative Requirements
Check the standby battery in accordance with the instructions given by the manufacturer of the power supply. NOTE: Contact the Customer Service Department of Peninsula Engineering Solutions whenever problems with the unit cannot be resolved. Table 14, System Troubleshooting... - Page 71 MPPT: Maximum Power Point Tracking. PV controller type includes a DC/DC converter to “step down” higher voltage PV arrays. Maximum V is limited to the maximum rating of the MPPT controller, typically 150 to 200 VDC. RF-8000E Operations Manual Chapter 6. Maintenance and Troubleshooting — 63...
-
Page 72: Amplifier Replacement
Set output power by adjusting AGC/ALC per Chapter 5. Confirm the RMAS alarm transmitter PWR alarm clears. Adjust the alarm as required. ii) Amplifier’s RF Detector DC sensitively and output can vary, thus requiring adjustment. — Chapter 5. Repeater Tests RF-8000E Operations Manual... -
Page 73: Keeping Spares
While most telecommunications carriers or system operators have internal policies relative to equipment sparing, in the event that one does not exist, Peninsula Engineering Solutions recommends maintaining a minimum of one (1) spare unit for every increment of 10 units or fraction thereof. -
Page 74: Returning The Repeater Equipment For Repair
Returning the Repeater Equipment for Repair If a repair or return of the RF-8000E, or its components, is necessary, contact the Peninsula Engineering Solutions Customer Service Department for instructions. When calling, include the following information: ⇒ Nature of the problem ⇒... -
Page 75: Table 15, Rf-8000E Maintenance Record
Table 15, RF-8000E Maintenance Record Date PV-A Voltage, V PV-A Voltage, V charge PV-B Voltage, V PV-B Voltage, V charge Battery-A Voltage Battery-A Temperature Battery-B Voltage Battery-B Temperature Battery-A Load Current Battery-B Load Current Battery-A ONLY Load Current Battery-B ONLY Load Current... - Page 76 THIS PAGE INTENTIONALLY LEFT BLANK — Chapter 5. Repeater Tests RF-8000E Operations Manual...
-
Page 77: Appendix
Appendix 1. M900-0158-XXX RF-7000E/RF-8000E Mounting Dimensions Drawing RF-8000E Operations Manual Maintenance Record — 69... - Page 78 POWER & ALARM GROUND LUG CONDUITS, 14-6 AWG 21.00 1/2-INCH, 13 mm 18.98 18.60 UNLESS OTHERWISE SPECIFIED: NAME DATE PENINSULA ENGINEERING SOLUTIONS, INC. SAN RAMON, CALIFORNIA, USA 11/25/09 DRAWN DIMENSIONS ARE IN INCHES[mm] TOLERANCES: TITLE: CHECKED FRACTIONAL RF-7000E, RF-8000E ANGULAR: MACH BEND ENG APPR.
