Summary of Contents for AUDAC DSP40
- Page 1 DSP40 User Manual www.audac.eu...
- Page 2 This manual is put together with much care, and is as complete as could be on the publication date. However, updates on the specifications, functionality or software may have occurred since publication. To obtain the latest version of both manual and software, please visit the Audac website @ www.audac.eu.
-
Page 3: Table Of Contents
Chapter 1: Pin connections and connectors Connection standards Chapter 2: Front & rear panel Front panel overview Front panel description Rear panel overview Rear panel description Chapter 3: Using the DSP40 Main screen DSP40 settings General settings Chapter 4: Additional information Technical specifications... -
Page 5: Introduction
Introduction Professional DAB/DAB+ & FM tuner The DSP40 is a professional DAB/DAB+ & FM tuner which provides access to a wide variation of radio stations while guaranteeing a high-quality audio reproduction. Station selection can be done manually or automatically, while up to 10 preferred channels can be internally stored and recalled. -
Page 6: Precautions
Precautions READ FOLLOWING INSTRUCTIONS FOR YOUR OWN SAFETY ALWAYS KEEP THESE INSTRUCTIONS. NEVER THROW THEM AWAY ALWAYS HANDLE THIS UNIT WITH CARE HEED ALL WARNINGS FOLLOW ALL INSTRUCTIONS NEVER EXPOSE THIS EQUIPMENT TO RAIN, MOISTURE, ANY DRIPPING OR SPLASHING LIQUID. AND NEVER PLACE AN OBJECT FILLED WITH LIQUID ON TOP OF THIS DEVICE. -
Page 7: Waste Of Electrical And Electronic Equipment (Weee)
WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT (WEEE) The WEEE marking indicates that this product should not be disposed with regular household waste at the end of its life cycle. This regulation is created to prevent any possible harm to the environment or human health. This product is developed and manufactured with high quality materials and components which can be recycled and/or reused. -
Page 9: Chapter 1: Pin Connections And Connectors
DSP40 RX PIN 5 Settings 19200 Baud 8 Bit 1 Stop bit No parity No Handshaking RS232 The complete command set for controlling the DSP40 through RS-232 is available in the DSP40 commands user manual which is freely downloadable on www.audac.eu... -
Page 10: Chapter 2 Front & Rear Panel
Chapter 2 Front & rear panel Front Panel overview Front panel description Graphical LCD display with tactile push buttons and rotary selection dial: A clear system overview and intuitive user experience is offered using the 2.8” graphical LCD display accompanied with four tactile selection buttons (left side) and a rotary selection dial (right side). The true colour display offers a clear overview of the systems current operation mode with intuitive and user friendly browsing through the menu structure. -
Page 11: Rear Panel Overview
The pinout and communication settings are described in an earlier chapter of this user manual. The complete RS232 command instruction set and configuration information can be downloaded from the AUDAC website. USB (Update) Connection: The USB (Update) connection can be used for system firmware updates and/or for connection of the RF remote control (RMT40) receiver. -
Page 12: Chapter 3 Using The Dsp40
Chapter 3 Using the DSP40 The DSP40 control and configuration is done through the front panel of the device which includes a 2.8” graphical LCD display, which is accompanied with four tactile push buttons (left side) and a rotary selection dial (right side). -
Page 13: Main Screen
Main screen FM Radio station selection: • Automatic tuning: The currently playing FM radio station (if FM mode is DAB/FM tuner enabled) is selected by pressing the (tuning down) and (tuning up) buttons. When pressed, it will automatically start searching for the next station with sufficient signal strength. -
Page 14: Dsp40 Settings
DSP40 Settings screen The settings menu for DSP40 can be loaded by rotating the rotary dial until the (settings) symbol is highlighted in blue colour. When highlighted, confirm to proceed to the settings menu by single pressing the rotary dial. -
Page 15: General Settings
General settings The general settings menu for DSP40 is loaded when pressing the (general settings) button. The general settings menu allows to configure all the global settings for the DSP40 unit, keeping aside the audio and frequency settings. Lock: When selecting ‘Lock’, the system will be locked and will... -
Page 16: Chapter 4: Additional Information
Chapter 4 Additional information Technical specifications Control Front panel RS-232 F-type antenna connection (75 Ω) Inputs Tuning Range (-10 dB) 87.5 ~ 108 MHz Sensitivity (1W/1m) -108 dBm Signal / Noise 52 dB THD+N (@ 1 kHz) 0.22% Frequency Response (± 3 dB) 30 Hz - 12.5 kHz Crosstalk (@ 1 kHz) 26 dB...
