- Page 1 TSP40 User Manual www.audac.eu...
- Page 2 This manual is put togheter with much care, and is as complete as could be on the publication date. However, updates on the specifications, functionality or software may have occurred since publication. To obtain the latest version of both manual and software, please visit the Audac website @ www.audac.eu.
-
Page 3: Table Of Contents
Chapter 1: Pin connections and connectors Connection standards Chapter 2: Front & rear panel Front panel overview Front panel description Rear panel overview Rear panel description Chapter 3: Using the TSP40 Main screen TSP40 settings General settings Chapter 4: Additional information Technical specifications... -
Page 5: Introduction
Introduction Professional FM tuner The TSP40 is a professional FM tuner with worldwide FM band support which provides access to a wide variation of radio stations while guaranteeing a high-quality audio reproduction. Station selection can be done manually or automatically, while up to 10 preferred channels can be internally stored and recalled. -
Page 6: Precautions
Precautions READ FOLLOWING INSTRUCTIONS FOR YOUR OWN SAFETY ALWAYS KEEP THESE INSTRUCTIONS. NEVER THROW THEM AWAY ALWAYS HANDLE THIS UNIT WITH CARE HEED ALL WARNINGS FOLLOW ALL INSTRUCTIONS NEVER EXPOSE THIS EQUIPMENT TO RAIN, MOISTURE, ANY DRIPPING OR SPLASHING LIQUID. AND NEVER PLACE AN OBJECT FILLED WITH LIQUID ON TOP OF THIS DEVICE. DO NOT PLACE THIS UNIT IN AN ENCLOSED ENVIRONMENT SUCH AS A BOOKSHELF OR CLOSET. -
Page 7: Waste Of Electrical And Electronic Equipment (Weee)
WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT (WEEE) The WEEE marking indicates that this product should not be disposed with regular houshold waste at the end of its life cycle. This regulation is created to prevent any possible harm to the environment or human health. -
Page 9: Chapter 1: Pin Connections And Connectors
TSP40 RX PIN 5 Settings 19200 Baud 8 Bit 1 Stop bit No parity No Handshaking RS232 The complete command set for controlling the TSP40 through RS-232 is available in the TSP40 commands user manual which is freely downloadable on www.audac.eu... -
Page 10: Chapter 2 Front & Rear Panel
Chapter 2 Front & rear panel Front Panel overview Front panel description Graphical LCD display with tactile push buttons and rotary selection dial: A clear system overview and intuitive user experience is offered using the 2.8” graphical LCD display accompanied with four tactile selection buttons (left side) and a rotary selection dial (right side). -
Page 11: Rear Panel Overview
The pinout and communication settings are described in an earlier chapter of this user manual. The complete RS232 command instruction set and configuration information can be downloaded from the AUDAC website. USB (Update) Connection: The USB (Update) connection can be used for system firmware updates and/or for connection of the RF remote control (RMT40) receiver. -
Page 12: Chapter 3 Using The Tsp40
Chapter 3 Using the TSP40 The TSP40 control and configuration is done through the front panel of the device which includes a 2.8” graphical LCD display, which is accompanied with four tactile push buttons (left side) and a rotary selection dial (right side). This combination allows you to navigate through the systems user interface and access all the available control and configuration possibilities of the system. -
Page 13: Tsp40 Settings
TSP40 Settings screen The settings menu for TSP40 can be loaded by rotating the rotary dial until the (settings) symbol is highlighted in blue colour. When highlighted, confirm to proceed to the settings menu by single pressing the rotary dial. -
Page 14: General Settings
(if the password is enabled). Info: Info will give an overview of the software versions the TSP40 is running. LCD Settings: Adjustments for the LCD settings can be made here. The brightness can be adjusted within a range of 10% to 100% (standard is 80%). - Page 15 The currently set password will be shown and the adjusting digit can be selected (turns red) and confirmed by turning and pressing the rotary selection dial. Consecutive digits will increase when the maximum value has been reached. After the desired password has been selected it can be confirmed by pressing (turns red) and turning the function dial clockwise to the entire right side where the ‘OK’...
-
Page 16: Chapter 4: Additional Information
Chapter 4 Additional information Technical specifications F-type antenna connection (75 Ω) Input Output Balanced stereo line output (2 x 3-pin Euro Terminal Block ~ 3.81 mm) FM tuning range 64 ~ 108 MHz 87.5 ~ 108 MHz Output level +8 dB ~ -55 dB (Software configurable) Control Front panel...
