FY-TECH FY-3D Instruction Manual

Shortwave infrared paint curing system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Instruction Manual
FY-3D
Our equipment is approved by the following car manufacturers

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FY-3D and is the answer not in the manual?

Questions and answers

Related Manuals for FY-TECH FY-3D

Summary of Contents for FY-TECH FY-3D

  • Page 1 Instruction Manual FY-3D Our equipment is approved by the following car manufacturers...

  • Page 2: Table Of Contents

    CONTENTS 1. Precautions 2. Specifications 3. Installation 4. Controls 5. Operation 6. Troubleshooting 1) Troubleshooting 2) Light Tube Replacement 7. Exploded View 8. Circuit Diagram...

  • Page 3: Precautions

    1. PRECAUTION 1. Read this manual carefully before installing or using this equipment. 2. This equipment is designed for paint drying applications. Adjust to the correct temperature and check minimum safe distance from the heat source when using. Improper use may cause paint surface damage. 3.

  • Page 4: Specifications

    2. SPECIFICATIONS FY-3D Model 230V / 1-ph / 50-60Hz Input Voltage 3 × 1000W Input Power 1200 × 1000mm Curing Area 35°C - 100°C Temperature 0min - 99min adjustable Time Setting Light Intensity 10% - 100% 20cm-120cm Curing Distance 2400mm...

  • Page 5: Installation

    3. INSTALLATION The shortwave infrared curing lamp is divided into 3 parts (a base, a column and a cassette). 1) Installation of the base. a. Open the packing of the base. b. Install the four wheels on the base respectively and tighten up the screws. Usually, the wheels with brakes should be mounted on the rear of the base.

  • Page 6: Controls

    4. CONTROLS 1. LCD display 2. Lamp selector (each lamp can be controlled separately) 3. Power adjustment 4. Time adjustment 5. Setting: - Press the button once, it will enter into "Routine" mode when the lamp is on. ① ② ③...

  • Page 7: Operation

    5. OPERATION 1. Automatic Mode a. Properly assemble the curing system according to the instruction (see page 3). b. Switch on the power supply. The system is ready to use when the graphic appears on the display screen as follows: 00: 00 POWER: 80% 00CM...
  • Page 8 5. OPERATION 2. Manual Mode a. Press the navigation buttons "Power +/- " and "Time +/-" when the lamp is ready to use to adjust the curing power and time. b. Press the button "Setting" to set the mode of "Routine" or "Pulse”. c.

  • Page 9: Troubleshooting

    6. TROUBLESHOOTING 1. Troubleshooting PROBLEM CAUSE SOLUTION a. Light tube damaged a. Check light tube Light tube does not work b. Lamp is not plugged in b. Check the connections c. Control silicon damaged c. Check control silicon Light tube does not turn a.

  • Page 10: Light Tube Replacement

    6. TROUBLESHOOTING 2. Light Tube Replacement a. Prepare the cassette which needs replacement. b. Remove the grille of cassette. c. Remove the plates from both ends of the cassette. d. Remove the fixed plates from both ends of the cassette. e.

  • Page 11: Exploded View

    7. EXPLODED VIEW NAME NAME NAME NAME Upright post Plastic nut Front caster Transformer Top cover Connecting axle U-type base Cover plate (upper) Plastic band Connector (right) Back wheel Circuit board Connector (left) Handle Cover plate (lower) Bracket Lower support arm Flange Clamping bar Upper support arm...

  • Page 12: Circuit Diagram

    CIRCUIT DIAGRAM Page 10...
